XtendLan ABOX56022 User manual

ABOX56022
Auto Zoom Color Camera
User’s Guide

1. Main Features:

HighResolution
TheHorizontalresolutionof560/480/420TVLcanbeachievedbyusingahighdensityCCDwhichprovideclean,
noiselessandreliablepictures.

ZoomUpto22X
Upto22Xwiththeopticalf:=3.9‐85.8mm

ControlledbyOSD
YoucancontrolthecamerausingOSDmenuandyoucancontrollensdirectlywithexternalcontrol
connection.

Day&NightFunction
Itautomaticallyjudgeswhetheritisdayornighttoshowthebestpicture,duringthedaycolorpictureis
providedandblackandwhitepictureisprovidedatnight.

AutoFocus
TheCameracanfocusonsubjectsfromabout0.1m(wide)fromLenssurfacetoinfinityautomatically.
2. Technical Specification:
Imagesensor3/1SONYSUPERHADCCD
Powerrequirement12VDC10%(3.6WATTS)
SyncsystemPAL/NTSC
Resolution560TVL
MinSceneillumination0.1LUX(F1.6/0.3P‐P)
Videooutput1.0Vp‐p75ohmVBS
S/N50dB(AGCoff)
FocusLength3.9mm‐85.8mm
Max.ApertureRatioF1.6(WIDE)‐F3.7(TETE)
ZoomRatioOpticalx22
Minimumobjectdistance10cm(wide)1m(tete)
FocuscontrolAuto
ExposurecontrolAuto
WhitebalancecontrolAuto
BLCfunctionOn/Off
OSDB/W,in(PushOn/Off/On)
Ambienttemp‐10℃‐50℃
Tolerancehumidity0%‐96%
Cameracontrolosd,ext.control

XtendLan ABOX56022 User's guide
______________________________________________________________________________________________________
www.xtendlan.com
2

3. Precaution
Donotinstallthecamerainextremetemperatureconditions.
Usethecameraunderconditionswheretemperaturesarewithin‐10°Cto+50°C.Especiallybecarefulfor
ventilationunderhightemperature.
Donotinstallorusethecamerainanenvironmentwherethehumidityishigh.
Itcancausetheimagequalitytobepoor.

Donotinstallthecameraunderunstablelightingconditions.
Severelightingchangeorflickercancausethecameratoworkimproperly.

Neverusethecameraclosetoagasoroilleak.
Itcancausethenonfunctions.

Donotdisassemblethecamera.
Therearenouser‐serviceablepartsinside.

Donotdropthecameraorsubjectsthemtophysicalshocks.
Itcancausemalfunctions.

Neverkeepthecamerafacetostronglightdirectly.
ItcandamagetheCCD.

Donotexposethecameratorainorspillbeverageonit.
Ifitgetswet,wipeitdryimmediately.Liquidscancontainmineralsthatcorrodetheelectroniccomponents.

Donottouchthefrontglassofthecamera.
Itisoneofthemostimportantpartsofthecamera,becarefulnottostainbyfingerprint.

Ifthecameraisexposedtospotlightorsubjectreflectingstronglight,smearorbloomingmayoccur.
Pleasecheckthepowerwhetheritsatisfiesthenormalspecificationbeforeconnectingthecamera

4. Rear panel
(T) Tele x (W) Wide - Zoom functions
(N) Near x (F) Far - Focus+ • Focus-
MENU - Setup Camera
Video Out connector (S-Video)
Video Out connector (BNC)
RS485 – Zoom control
External Control Connector
XtendLan ABOX56022 User's guide
______________________________________________________________________________________________________
www.xtendlan.com
3

External Control Connector pin setting:
PIN NO NAME I/O NOTE
l ZOOM (TELE,WIDE) INPUT ±3V ~ ±12V
2 FOCUS (NEAR,FAR) INPUT ±3V ~ ±12V
3 IRIS (OPEN,CLOSE) INPUT ±3V ~ ±12V
4 COM (ZOOM,FOCUS,IRIS) INPUT ±3V ~ ±12V
5. Camera Setup Menu
CAMERA ID 000
ID DISPLAY OFF
SHUTTER SPEED AUTO
AWB AUTO
BLC OFF
AGC GAIN 180
FOCUS AUTO
CAMERAID‐SetupCameraIDfrom000To256
IDDISPLAY‐SetupIDDisplayONorOFF
SHUTTERSPEED‐SetupShutterSpeed:AUTO,1/50~1/10000
AWB‐SetupCameraAWB(autowhitebalance)
BLC‐SetupBLC(Backlightcompensation)ON/OFF
AGC‐SetupAGC(autogaincontrol‐AGCgainincrease/decreaseraisingthevideosignallevelaccordingto
illuminationlevels)
FOCUS‐SetupFocusMode:AUTO,MANUKEYAUTO
