XtendLan PEDOMEOIR48023SD User manual

PEDOMEOIR48023SD
Smart Constant Speed Dome Camera
User Manual

● Please read the manual carefully before installing and using the unit. ●
Part I: Introduction
1-1. Instructions
We greatly appreciate your choosing our product!
As stated in the warranty instruction, when a breakdown occurs to the properly
used product, the product under warranty will be granted free maintenance or
spare parts replacement. Do not disassemble or maintain the unit without the
company’s authorization.
Within one year from the purchase date, if any damage or breakdown occurs to the
product (excluding housing, bracket and external wires) when it is properly used,
we will provide free maintenance or spare parts replacement after our technician
confirms the case.
No free maintenance under the following circumstances:
1. Damage or breakdown arising from the dismantling or repairing of the unit
without the company’s authorization;
2. Damage or breakdown arising from the client-arranged transportation, loading
or unloading of the unit;
3. Damage or breakdown arising from using and maintenance of the unit without
observing the instructions in the User’s Manual, including damage or
breakdown arising from crashing, crushing, and unit affected with liquids,
damp, corrosive or other man-made causes.
4. Damage or breakdown arising from inapplicable operating ambient or
overloaded operation; surface abrasion or damage emerging when the unit is
used;
5. Damage or breakdown arising from natural disasters and other accidents.
Attention: To realize all the functions of the unit, a compatibility test must be
carried out before applying other manufacturer’s spare parts in the system.
1-2. Characteristics
1. The design of the outer housing of the Constant Speed Ball is reasonable,

elegant and practical. The outer housing can endure long-term operation
without distortion.
2. Precise conductive slip-ring is adopted, with which pan 360° endless running is
realized and all-direction monitoring effect is realized.
3. The function of Position Limiting is realized by photoelectrical sensors, which
avoids the limitations of traditional mechanical Position Limiting.
4. The operation is based on advanced stepper motors and driving circuits, which
ensures smooth running, long time consecutive working, long lifespan and
high reliability.
5. The running speed of the unit can be adjusted according to actual conditions.
6. Left/right limiting positions can be setup on the key-press of ball panel, it also
can be set up through long-distance control of our company’s keyboard.
7. The installation of the unit is fast, convenient and more human, which greatly
reduces the inconvenience in installation.
8. The unique wall bracket installing style enables the placing of our company’s
adaptor inside the bracket.
9. The built-in decoding board supports multi mainstream protocols, and many
more protocols can be input according to the customer’s needs. The Baud rate
is also adjustable.
10. The unit adopts DC12V power supply and separates from it the components
that produce heat in the process of transformation, which prolongs the
durability of the unit. The unit possesses the functions of anti-jamming and
anti-crashing. It also features memory function, which enables the unit to
automatically resume the last-time operated condition once supply of power is
on after the power-off state.
*11. The unit has one default position; the user can preset the default position for a
key monitoring area according to the actual conditions. If not operated after 5
minutes, the constant speed ball will automatically monitor the preset position.
Remarks：The function of item 11 can be realized only when the protocol
adopted supports the keyboard produced by this company. Also, the
user can include our protocols into the DVR or existing software.
1-3. Main Technical Data：
1. Electric Index
Power supply: DC12V /4A~ DC15V /4A
Dome motor: DC12V /0.5A
Camera power supply: 12V/2A
Temperature controlling devices ambient: fan, ≥50º; heater, ≤5º
Addresses range: 1～63
Communication system: RS485 bus-mastering
Communication protocol: supporting multi protocols
Baud rate: 1200bps(19200bps)、2400bps、4800bps、9600bps、as per customers’needs
Controlling device: video matrix, hard disk video recorder, DVR controlling

keyboard
Pre-set position quantity: 16 preset positions
Tour group quantity: 1 group (16 preset positions can be included)
2. Mechanical Index
Dome movement: pan 360° endless, tilt 0°-90°
Dome speed: pan/tilt, Pan 6º、9º、12º、15ºadjustable
Movement limiting position: adjustable between any two points
3. Ambient Index
Ambient temperature: 0ºC～49ºC (without temperature controlling devices)
-35ºC～49ºC (with temperature controlling devices)
Relative Humidity: below 90%RH
1-4. Styles of Installation andAncillary Components
Table 1: Styles of Installation and Ancillary Components of Constant Speed Ball
Table 1: Styles of Installation and Ancillary Components
The style of
installation Bracket cables（with connector）
Ancillary
components
Power
supply
temperature
- controlling
device
Wall mount
installation Wall-mount bracket
P
ower supply
connecting
cable, video
connecting
cable, RS458
connecting
cable
DC 12V
/4A Required
below 0℃
Pendant
mount
installation
Bracket
length:
20cm
(standard)
or 40cm
Ceiling mount
installation
No bracket;
Steel wire
rope to be
prepared by
the user

Part II: Installation Procedures
2-1. Outer shape and installation size
Outer shape and installation size
第二部分：设备安装步骤
2-1、外形和安装尺寸
外形和安装尺寸
图1 壁挂式外形尺寸图
图2 吊装式外形尺寸图
Picture 1 Outer shape and size of wall mount style
Picture 2 Outer shape and size of pendant mount style

2-2. Installation of Video Camera
Connecting Lens Controlling Cable
Camera Lens Controlling Cable should be provided by the camera supporter.
Connect the Camera Lens Controlling Cable well according to the corresponding
relationship between the camera and the outlet of decoding panel shown in the
following table.
Controlling signal of the camera lens Corresponding outlet on decoding panel
Camera power supply +12VDC、GND
Lens Zoom ZOOM
Lens Focus FOCUS
Lens Iris IRIS
Lens Controlling public ground COM
3. Connecting Video Cable
Connect BNC video outlet with the video output outlet of the camera, then use the
binding wire to tie the video cable inside the camera and the lens cable into the hole
beside the lens connecting outlet on the decoding penal. After installing the camera,
please setup communication protocol, baud rate, address, etc.
2-3. Installation of the Whole Housing and Bracket
图3 吸顶式外形尺寸图
Picture 3 Outer shape and size of ceiling mount style
Screw slot

Picture 4
Push the connecting ports end of the power, video and RS458 controlling integrated
cable through the round hole of the bracket, and then fix the ball housing top to the
round hole of the bracket. Fix the three M6 screws with screw knife, enabling the screws to
get into the screw slots. (See Picture 4))
2-4. Installation of Bracket of Constant Speed Ball
☆Installation of bracket of outer-door Constant Speed Ball of wall mount type
墙壁
Picture 5 Size of bracket of outer-door Constant Speed Ball of wall mount
type
Select the position for installation of Constant Speed Ball and confirm the place with
good endurance ability, mark the corresponding positions of 4φ7.5 installation holes
of wall mount bracket on the wall with a pencil, then install the peg-board of the
bracket in the wall with expanding bolts (not provided). (See picture 5)
☆Installation of bracket of outer-door Constant Speed Ball of pendant
螺丝卡槽
Wall

mount type
或200
出线槽
Picture 6: Size of bracket of outer-door Constant Speed Ball of pendant mount type
Select the position for installation of Constant Speed Ball and confirm the place
with good endurance ability, mark the corresponding positions of 3 installation holes
of the fixing tray on the ceiling with a pencil, then install the fixing tray in the ceiling
with expanding bolts (not provided). Please don’t forget to push the connecting ports
end of the power, video and controlling integrated cable through the in-going slot of
the bracket (See picture 6).
2-5. Fixing of the Set
Picture 7
Step 1: Put the power adaptor into the well-connected bracket of pendant mount type
and pin the power adaptor with the adaptor pinning board lest the adaptor slides out.
(See picture 7)
电源压板
Adaptor pinning board
400 or 200
Cable slot

锁紧螺钉
Picture 8
Step 2: Pull the power cable, video cable and controlling cable out via the cable
out-going slot, then direct the dotted-line part of the bracket shown in the figure to the
two corresponding pegs on the installed peg-board, then push the bracket downward
until it locks in place. Make sure the bracket fits well with the peg-board, then tighten
the screws on the bracket with the peg in underside part of the peg-board. (See Picture
8)
2-6. Installation of Half Ball
Locations with suspended top suit the constant speed ball with in-ceiling
installation style, which appears to be a hemisphere, having an elegant look and good
concealment. The hemisphere style installation applies to solid locations of the ceiling.
First, select the desired location, mark the outline of the upper housing on the ceiling
with a pencil and make a corresponding-sized bore, then insert the upper housing into
the ceiling, and press the spring pinning boards against the edge of the ceiling opening.
After that, tighten the screw adjusting the spring pinning boards, and lock the upper
housing in the ceiling tightly. For the sake of better safety, please use a metal wire
rope to connect the top of the upper housing to a reinforced structure of the ceiling.
(The wire rope is required to bear at least 5 times the weight of the constant speed
ball.) (See Picture 9)
Tightening screw

弹簧压块
Picture 9
2-7. Connection of Power Supply Cable and Signal Cable
The connection of cables begins with the completion of installation.
1. Please see in table 1 the application of cables
Table 1
Cable Application Connecting objects Remarks
4-strand cable
DC12V power
supply Decoding PCB penal
—Power Supply Adaptor
Power outlet
485
controlling
signal
Decoding PCB penal－
controlling device Green(+) white(-)
Video cable Camera signal Camera －monitoring
device BNC connector
Power cable for
temperature
controlling
device
DC12V power
supply
Temperature controlling
device －
power supply
adaptor
Parallel connection
with the power
supply of Decoding
PCB penal
Camera lens
controlling cable Camera lens control/
power
Decoding PCB penal－
camera
Provided with the
integrated camera
(including power
cables)
2. Connection of temperature controlling power cable
If the bought products are with temperature controlling function, users can select
those suiting application environments with reference to the selecting conditions of
Picture 2 (connection of temperature controlling power cable) and connection of
power supply cable and RS485 cable.
3. Connect the outlet of 12V power supply with power connector of the set core. Connect the
485 controlling cables to the provided 485 interfaces of the ball set, green to 485+, white to 485-.
4. Connection of Video Cable
Please weld a BNC connector to the already installed video cable, and then
Spring pinning bar

connect to the video outlet provided by our company.
Now, all the power cables and signal cables have been connected. Please check
carefully to guarantee correctness and firmness of all connections.
5. Finally, please connect the 220V interface of our company’s provided special
adaptor to AC220V power supply.
Part III: Setup the Functions of the Ball
3-1. Setup of Communication Protocol, Baud Rate and Address of
Constant Speed Ball
The constant speed ball has built-in Decoding PCB penal, the control of the dome
and camera lens is realized by setting up address, protocol and baud rate through the
decoding PCB penal.
1. Address Setup
As shown in the picture 10 and picture 11, DIP-1 to DIP-6 of the 8-button coding
switches is used to setup address of the constant speed ball from 1 to 63. Control can
be realized only when address code of the constant speed ball is identical to that of the
hard disk video camera or matrix or controlling keyboard. The coding switches from
DIP-1 to DIP-6 are equivalent to a 6-bit binary figure. The state “ON” of each bit
means “1” while”OFF”means”0”. Table 2 shows states of coding switches.

ON
1 2 437 865
DIP
DIP
3421
ON
J11
J1
J9
J8
视频输入接口
协议拨码开关(1-4)
6 地址拨码开关
7、8 波特率拨码开关
右限位设置按钮
左限位设置按钮
输入
视频输出接口
电源输入接口
摄像机电源 +12
摄像机电源
镜头公共端
镜头光圈IRIS
镜头聚焦FOCUS
镜头变倍ZOOM
限位设置指示灯
电源指示灯
ON
65
云台速度拨码开关(5-6)
Picture 10
Camera power +12V
Camera power GND
Lens common terminal
Iris
Focus
Zoom
485 input
Video outlet
Power supply input
1-6 Address select switch
7, 8 Baud rate select switch
Key for left position setup
Key for dome speed adjustment(5-6)
Protocol select switch(1-4)
Key for right position setup
Video inlet
Posit
ion setup
indicator
Power indicator

ON
1 2 437 865
DIP
DIP
3421
ON
J1
协议拨码开关(1-4)
6 地址拨码开关
7、8 波特率拨码开关
右限位设置按钮
左限位设置按钮
摄像机电源 +12
摄像机电源
镜头公共端
镜头光圈IRIS
镜头聚焦FOCUS
镜头变倍ZOOM
限位设置指示灯
电源指示灯
ON
65
云台速度拨码开关(5-6)
滑环接口
视频 +
视频 -
485 -
485 +
GND
12V +
Picture11: Position of select switches of decoding PCB penal
Table 2: Correspondence of Address and Coding Switches
No 654321 No 654321 No 654321 No 654321
1 000001 17 010001 33 100001 49 110001
2 000010 18 010010 34 100010 50 110010
3 000011 19 010011 35 100011 51 110011
4 000100 20 010100 36 100100 51 110100
5 000101 21 010101 37 100101 53 110101
6 000110 22 010110 38 100110 54 110110
7 000111 23 010111 39 100111 55 110111
8 001000 24 011000 40 101000 56 111000
9 001001 25 011001 41 101001 57 111001
10 001010 26 011010 42 101010 58 111010
11 001011 27 011011 43 101011 59 111011
12 001100 28 011100 44 101100 60 111100
1-6 Address select switch
7, 8 Baud rate select switch
Key for left position setup
Key for dome speed adjustment(5-6)
Protocol select switch(1-4)
Key for right position setup
Camera power +12V
Camera power GND
Lens common terminal
Iris
Focus
Zoom
P
osition setup
indicator
Power indicator
458-
458+
Video-
Video+
GND
12V+
Slip-ring interface

13 001101 29 011101 45 101101 61 111101
14 001110 30 011110 46 101110 62 111110
15 001111 31 011111 47 101111 63 111111
16 010000 32 100000 48 110000
Protocol KRE-301 for KODICOM card hard disk video recorder, protocol
PELCO-D and RM110 for Shanghai Chenova hard disk video recorder all adopt the
hexadecimal system, which is different from other protocols adopting decimal system,
so the address should be converted into decimal system. For details, please see coding
switches in Table 3.
Table 3：Correspondence of Hexadecimal Address and Coding Switches
No 654321 No 654321 No 654321 No 654321
1 000001 5 000101 9 001001 13 010011
2 000010 6 000110 10 010000 14 010100
3 000011 7 000111 11 010001 15 010101
4 000100 8 001000 12 010010 16 010110
Please setup coding switches according to Table 2 or Table 3 as per the address you
defined by yourself.
2. Communication Baud Rate Setup
As shown in picture 11, DIP-7 and DIP-8 of the 8-button coding switches are
used to setup Baud rate of communication and 4 different Baud rate can be selected
(1200BPS/2400BPS/4800BPS/ 9600BPS). The state “ON” of each bit means“1”,
while”OFF”means”0”. Table 4 shows states of correspondence of Baud rate and
coding Switches.
Table 4：Correspondence of Baud Rate and Coding Switches
Coding
switches 1200 bps 2400 bps 4800 bps 9600 bps
No. 7 OFF ON OFF ON
No. 8 OFF OFF ON ON
Please setup the coding switches according to Table 4 based on the communication
baud rate applied for constant speed ball device.
3. Protocol Setup
As indicated in the picture 11, DIP-1 to DIP-4 of the 6-button coding switches
are used to setup protocol of the constant speed ball. The built-in Decoding PCB
penal provides protocols as listed in Table 5. Other protocols can also be written-in as
the user requires.

Table 5 Correspondence of Coding Switches and Protocols.
No. DIP- 4,3,2,1 Types of Protocols
1 0 0 0 0 PELCO_D
2 0 0 0 1 PELCO_P
3 0 0 1 0 VICON
4 0 0 1 1 PELCON
5 0 1 0 0 KALATEL-312
6 0 1 0 1 CCR-20G
7 0 1 1 0 ADR-8060
8 0 1 1 1 HY
9 1 0 0 0 M800-CIA
10 1 0 0 1 PANASONIC
11 1 0 1 0 LILIN
12 1 0 1 1 KRE-301
13 1 1 0 0 WISDOM
14 1 1 0 1 RM110
15 1 1 1 0 NEW
16 1 1 1 1 PELCO_D1
The built-in Decoding PCB penal provides the above sixteen protocols. More
protocols can also be provided as the user requires, such as:
Communication protocols with matrix: SAMSUNG, KONY Matrix, TDTC
Matrix, PELCO Matrix, VICANYX Matrix and LP Matrix.
Communication protocols with hard disk video recorder: CNEUOL embedded,
Enterasys embedding, DM embedding, Hikvision embedding, KCL, YAAN,
SAMSUNG, KIDICOM-SX. For information of hard disk video recorder protocols
and Baud rate, please refer to Table 6.
Communication protocols with keyboard: Video keyboard, PWT keyboard,
Samsung keyboard and YAAN keyboard.
Table 6: Reference for Hard Disk Video Recorder Protocols and Baud Rate
KOMSA series hard disk PELCO-D 2400，RM110 9600，HY 9600
MPG4 card of Viewse
software HY 9600，PELCO-D 2400，RM110 9600
MPG4 card of Shanghai
Chenova software
PELCO-D 2400
，
RM110 9600
KODICOM hard disk
PELCO-D 2400
，
LILIN SD 9600
，
KRE-301 9600
PICO video
collection card PELCO-D，KTD-312，VICON, etc，Baud rate adjustable
PICASO hard disk
PELCON 2400
，
PELCO-D 2400
，
CCR-20G 4800
MPG4 card of DVTECH
Software ADR-820 4800

MPG4 card of
zhongjiaman Software
HY 9600，PELCO-P 2400
Image sensitive
card（Chengdu Kony）
M800-CIA 2400
MPG4 card of Milky
Way software
PELCO-D 2400，WISDOM 4800
Please choose appropriate communication protocols according to the protocols adopted by
constant speed ball controlling equipment (such as matrix, HD video recorder, keyboard). Before
installation, a compatibility test of controlling and controlled equipment is recommended.
To control the three alternative camera lens of KODICOM HD video recorder, please adopt
KRE-301 protocol. Operation is shown below:
Switch on the “POWER” button on the top of the controlling interface and press the focus
button, and then the state is Iris control. Switch off the “POWER” button, and press the focus
button, then it will resume focusing control.
4. Functions Setup of the Constant Speed Ball
Code Name
of the
function
Definition for the keyboard
operation
Code Name
of the
function
Definition for the
keyboard operation
160
Begin with left/right limiting
position setup 140
Begin with the tour
group setup
161
Finish left/right limiting
position setup 141
Finish the tour group
setup
130 Setup left limiting position 142 Start Tour Group
131 Setup right limiting position 162
Activate Home
Position function
132 Start left/right scan 163 Disable Home Position
function
135
Start 360°scan of the dome
164
Setup Home Position
138 Stop auto scan of the dome
If preset position numbers larger than 128 could not be previewed on the
controlling device, please choose PELCO-D1 protocol, functions operation table
as below:
Code Name
of the
function
Definition for the keyboard
operation
Code Name
of the
function
Definition for the
keyboard operation
120
begin with left/right limiting
position setup 110
Begin with the tour
setup
121
Finish left/right limiting
position setup 111 Finish the tour setup

100 Setup left limiting position 112 Start Tour
101 Setup right limiting position 122
Activate Home
Position function
102 Start left/right scan 123 Disable Home Position
function
105 Start 360°scan of the dome 124 Setup Home Position
108
Stop auto scan of the dome
5. Setup the Movement Speed of the Dome
The movement speed of the dome can be setup through the coding switch.
DIP 5 and DIP6 of the 6-button coding switch (see figure above) are used to setup the movement
speed of the dome. Please refer details as Table 5:
No. DIP: 5，6
Circling speed
1 00 6°
2 10 9°
3 01 12°
4 11 15°
Table 5
3-2. Running state examination while Supplying Power to the Unit
Once the power supply begins, check whether the power indicator on the PCB
panel is on. Now the constant speed ball begins with self-check. After the self-check,
the position of the dome is horizontally on the left limiting position, tilt 30º. Two
states may follow the self-check:
a. The constant speed ball makes no action
b. The constant speed ball is in the state of pan auto- touring
If the constant speed ball is in the state of pan auto-touring, the tour should be
stopped through the controlling device to avoid possible friction or collision between
camera cable and inner housing caused by inappropriate installation of the camera.
After installing the vitreous cover, control the constant speed ball to make slow
pan/tilt movement, and observe its agility and stability, and check whether there is
friction or collision between camera, cable and inner housing.
If the ball movement is unstable and with noise, please check whether the
connection between the constant speed ball and the bracket is vertical, or whether the
ball movement is in good connection with the peg-board. If not, switch off the power
supply, then check and re-install the unit following the above-mentioned installation
instructions.
If there is friction or collision between the camera, cable and the inner housing,
switch off the power and open the vitreous cover to adjust the position of the camera
on the suspender, or tidy up the cables inside the inner housing. Then reinstall the
vitreous cover.

Switch on the power again, control the constant speed ball to make slow pan/tilt
movement, observe its agility and stability, and check whether there is friction or
collision between camera, cable and inner housing.
If the process goes smoothly, you can adjust the scope of pan scan, i.e. scope of
maximum left/right positions.
Functions Setup: If PELCO-D1 protocol is chosen for
the control, please choose the Function Codes inside the
bracket to operate.
3-3. Setup and Preview Preset Positions
The function of preset positions works in this way: the constant speed ball saves the current
pan/tilt parameters in number order (1-16), quickly previews those parameters when needed, and
adjust the dome to the corresponding positions. Users can use such devices as controlling
keyboard to save and preview preset positions fast and conveniently. The constant speed ball can
support 16 preset positions.
1. Setup preset positions
After controlling pan/tilt of the constant speed ball to desired position through the
keyboard, enter the number representing the preset position and LED displays the
entered preset position number. Press the “PRESET” key, then LED resumes to
previous displaying state again, now you have setup the preset position successfully.
Example: Setup preset position No.1
a. Use the joystick to move the constant speed ball to the desired position.
b. Enter “1”
c. Press the “PRESET”key
2. Preview Preset Positions
The function enables the constant speed ball to quickly return to the preset position.
Enter the number key for preset position number which you need to preview;
LED displays the preset position number.
Press the “PREVIEW” key, then the constant speed ball to the preset position.
Example: Previewing Preset position No.1
a. Enter “1”
b. Press the “PREVIEW” key
3-4．Setup of Tours
Auto-tour is a latest new function of constant speed ball, tour course can be set
casually through operation, and only an external command is enough to start the
constant speed ball to tour according to regulated course. Tour group can keep 16

preset positions in memory at most.
Setup of tour group
a. In the keyboard initial state, enter number “140”(110) and press the “PREVIEW”
key to enter the tour setup.
b. After entering the setup, add preset position number to the tour. Enter the first
desired preset position number and press the “PREVIEW” key, and the first preset
position is successfully added. Then it goes to the second one. Enter the second
desired preset position number and press the “PREVIEW” key, and the second
preset position is successfully added. More preset position can be added in the same
way.
c. After all the required preset positions having been added in the tour, enter the
number “141”(111) on the keyboard and press the “PREVIEW” key to exit the tour
setup.
1. Start Running a Tour
In the keyboard initial state, enter number “142”(112) and press the “PREVIEW”
key to start running the preset tour.
Example: Setup the tour order to be 1→2→5→3→4→6 (please setup preset
positions before tour setup)
1. Preview preset position 140(110) to enter tour setup (Enter number
“140”(110) and press the “PREVIEW” key)
2. Preview preset position 1 to setup the first tour position (Enter
number “1”and press the “PREVIEW” key)
3. Preview preset position 2 to setup the second tour position (Enter
number “2”and press the “PREVIEW” key)
4. Preview preset position 5 to setup the third tour position (Enter
number “5”and press the “PREVIEW” key)
5. Preview preset position 3 to setup the fourth tour position (Enter
number “3”and press the “PREVIEW” key)
6. Preview preset position 4 to setup the fifth tour position (Enter
number “4”and press the “PREVIEW” key)
7. Preview preset position 6 to setup the sixth tour position (Enter
number “6”and press the “PREVIEW” key)
8. Preview preset position 141(111) to exit tour setup (Enter number
“141”(111) and press the “PREVIEW” key)
9. Preview preset position 142(112) to start running the tour, and the
constant speed ball runs the tour and begins to scan in the order of
1→2→5→3→4→6.
If other devices are used to control the constant speed ball, due to the
protocol limitation, some special functions of the constant speed ball may be
not operational. (Enter number “142” (112) and press the “PREVIEW” key)
3-5. Setup of Left/right Limiting Positions
The default rotating angle of the set is 360°. The user can reset running angle
according to the spot requirements. Left/right limiting positions of the dome can be

setup in three ways:
☆Setting the dome’s left/right limiting positions through the company’s special
keyboard
A. Once the dome is installed and power is on, the constant speed ball starts a
self-check. After the self-check, the position of the dome is the left position, Setup the
maximum left/right positions by the company’s keyboard connected to the constant
speed ball through 485 bus cable. First, setup the Baud rate, protocol and address of
the keyboard identical with those of the constant speed ball, and make sure the
keyboard can control the movement of the constant speed ball.
B. Enter the number “160”(120) on the keyboard, and press “PREVIEW” key to
enter the setup of maximum left/right positions, then turn the joystick on the keyboard
to the right direction till the dome reaches the desired point of right limiting position,
then enter 131(101), and press “PREVIEW” key again, now the dome’s right limiting
position has been setup successfully. Next, turn the joystick on the keyboard to the left
direction till the dome reaches the desired point of left limiting position, enter
130(100) and press “PREVIEW” key again, now the dome’s left limiting position
have been setup successfully. After the setup, enter 161(121) and press “PREVIEW”
key to exit the setup. Now the setup of left/right limiting positions is completed.
☆Setting up the dome’s left/right limiting positions through the coordinated
operation of DVR and the buttons on the dome camera’s master board (The
operation requires the co-operation of two people)
A. Once the dome is installed well and power is on, the constant speed ball starts
a self-check. After the self-check, the position of the dome is the default left position
of the constant speed ball. Open the vitreous cover, find on the dome camera panel the
two keys-”S1”, “S2”, then, press the two keys simultaneously with your forefinger
and middle finger for about 2 seconds till the green indicator—D11 is continuously
on . The continuous-on state of the green indicator suggests entering the setup of the
dome’s left/right position.
B. Inform the personnel in the controlling room with an interphone, and the
personnel should control through the DVR to move the dome right till it reaches the
desired point of right position setup, and then the personnel should inform the person
at the terminal that the constant speed ball is in the desired place. Then the person at
the terminal should press key “S2” for about 2 seconds till the same green indicator
glistens once. The glistening means the setup of the dome’s right position is
successful.
C. Once again, inform the personnel in the controlling room with an interphone,
and the personnel should control through the DVR to move the dome left till it
reaches the desired point of left limiting position setup, and then the personnel should
inform the person at the terminal that the constant speed ball is in the desired place.
Then the person at the terminal should press key “S1” for about 2 seconds till the
same green indicator glistens once. The glistening means the setup of the dome’s left
position is successful.
