XtendLan SDOMEOATM User manual

SDOMEOATM
USERMANUAL
Object Tracking/High Speed Mini Dome II

i / iii
Thank You for Choosing our PTZ Camera!
When you open the box:
Check that the packing and the contents are not visibly damaged. Contact the
retailer immediately if any parts are either missing or damaged.
Make sure if the contents are all included as per the packing list.
Do not attempt to use the device with missing or damaged parts. Send the product
back in its original packing if it is damaged.
The information contained in the document is subject to change without
notice.

Table of Contents
1. Safety Notes --- Important!!! ..............................................................................1
2. About The Product.............................................................................................3
2.1. Features........................................................................................................3
2.2. Functions.......................................................................................................3
2.3. Technical Parameters....................................................................................6
3. Installation...........................................................................................................8
3.1. DIP Switch Setting.........................................................................................8
3.2. Installation.....................................................................................................9
4. Operation Guide ............................................................................................. 11
4.1. Operation At Power Up .............................................................................. 11
4.2. How To Use Our Control Keyboard ........................................................... 11
4.2.1. Control Keypad Password And Access .............................................. 12
4.2.2. Control Keypad Command Syntax ..................................................... 12
4.2.3. Control Keypad Command Types ...................................................... 13
4.3. Select A Camera ....................................................................................... 13
4.4. Camera Motions ........................................................................................ 13
4.4.1. Pan And Tilt Functions ....................................................................... 13
4.4.2. Zoom Functions ................................................................................. 15
4.4.3. Focus Functions ................................................................................. 15
4.4.4. IRIS Opening Functions ..................................................................... 15
4.4.5. Preset Positions Programming And Recalling .................................... 15
4.5. Function Program Menu ............................................................................ 16
4.5.1. System Menu ..................................................................................... 18
4.5.1.1. Soft DIP Switch ............................................................................... 19
4.5.1.2. Dome Label .................................................................................... 19
4.5.1.3. Display Setup ................................................................................. 20
4.5.1.4. Password ........................................................................................ 23
4.5.1.5. Bootup Screen ................................................................................ 24
4.5.2. Camera ...............................................................................................24
4.5.2.1. Exposure ........................................................................................ 25
4.5.2.2. White Balance ................................................................................ 26
4.5.2.3. Day/Night ........................................................................................ 27
4.5.2.4. Focus/IRIS ...................................................................................... 28
4.5.2.5. Privacy ............................................................................................ 29
4.5.2.6. Additional ........................................................................................ 31
4.5.3. PTZ Menu .......................................................................................... 31
4.5.3.1. Motion ............................................................................................. 32
4.5.3.2. Presets ........................................................................................... 38
4.5.3.3. Scan ............................................................................................... 39
4.5.3.4. Power Up ........................................................................................ 42
4.5.3.5. Cruise Setting ................................................................................. 43
4.5.3.6. Clear Set ........................................................................................ 44
ii / iii

iii / iii
4.5.4. Alarm ...................................................................................................44
4.5.5. Track .................................................................................................. 46
4.5.6. Event .................................................................................................. 50
4.5.7. Set Default ......................................................................................... 54
4.6. Special Control Panel Commands ............................................................. 54
5. Trouble Shooting ............................................................................................ 56

1 / 56
1. SAFETY NOTES --- IMPORTANT!!!
The following important notes must be followed carefully to run the PTZ camera and
respective accessories in total safety. The camera and relative accessories are called
video system in this section.
Use the instructions correctly and fully
Read all safety rules and instructions carefully before starting to run the video system.
Follow the instructions in the instruction manual. Pay attention to all warnings on the
camera and in the instruction manual. Keep the safety notes and instructions for use for
future reference.
Attachments & Accessories
Do not use attachments other than those recommended in the instruction manual
because this could cause risks to the products. Only use the recommended accessories
for the camera for installation and operation.
Protect the video system
To protect the camera, avoid installing and using it in direct sunlight or any source of
bright light. Bright light, like that from a spotlight, can cause dimming and blurs. A vertical
line may appear on the screen. This does not indicate a problem.
Keep it away from rain and dust. Do not touch the zoom lens with your fingers. If needed,
use a soft cloth and methylated spirit to remove traces of dust. Apply a specific cap to
protect the zoom lens when the camera is not in use.
Install the camera away from video interference. The pictures could present interference
if the leads are arranged near a TV set or other device. Either move the leads or
re-install the device to solve the problem.
Do not use any part of the video system near water, i.e. bathtubs, wash basins, sinks,
tubs, on damp surfaces, near swimming pools, etc. Do not insert objects of any kind
through the camera openings to avoid touch live parts: fire and electrocution risk. Do not
pour any kind of liquid on the device.
A switch for performing maintenance operations on the camera must be included.
Connect the camera only to the electrical power supply shown on the ratings plate.
Contact your retailer if in doubt.
Lay the power wires keeping them from being trodden on or squeezed by objects placed
on top of them. Pay particular attention to leads near plugs, screws and the product
outlet.
Disconnect the power lead and the wiring to protect the camera during electrical storms
or when it is left unattended and not used for a long time. This will prevent damage to the

video system in the event of lightening or electrical line overload.
Do not overload the electrical power and the extensions to prevent the risk of fire or
electrocution.
Do not place the camera near or over radiators or sources of heat. Check that the area is
suitably ventilated before installing the camera inside partially closed areas (such as
recesses, bookshelves and shelves).
Do not position the camera on unsteady trolleys, stands, brackets or tables. The camera
could fall and severely injury adults and children in addition to seriously damaging the
product.
Maintenance & Repairs
Always contact a qualified service technician to repair the camera (or any other part of
the video system). Unauthorized opening or removing the lids may cause fire and
electrocution risk and other dangers.
Disconnect all electrical parts from the mains before cleaning.
Uses spare parts specified by the manufacturer or spare parts with equivalent
characteristics when replacements required. Unauthorized replacements can cause fires,
electrical shocks and other dangers.
After any servicing intervention or repair to the video system, ask the technician to run a
safety check to ensure that everything is working safely.
Damage requiring professional assistance
Disconnect the video system from the power mains and call qualified service personnel
in the following cases:
If the power lead or plug is damaged.
If liquid or foreign objects accidentally penetrate inside the device.
If the device was exposed to rain or water.
If the device was dropped, subjected to heavy shocks or if the camera packaging
was damaged.
If the device performance changes considerably.
2 / 56

2. ABOUT THE PRODUCT
The Auto Tracking/ High Speed Mini PTZ II is based on our unique motion tracking
technology with high resolution, high speed, low price and selectable communication
protocols. It is widely used in surveillance system as unattended CCTV device.
2.1. FEATURES
Auto tracking of moving object (auto PTZ) based on our motion tracking
technology;
Max 10X optical, 0.02Lux of module specifications;
Pan: 360º at maximum speed of 250º /sec;
Tilt: 0º to 90º at maximum speed of 250º/sec;
Auto panning function with 256 preset positions;
Built-in OSD Menu, to change dome parameter, save or call preset, and achieve
auto scan, pattern etc;
Password protection to prevent unauthorized changes to the dome setting;
Windows blanking and tracking boundary for privacy purpose;
The feature of defining specific activity when the dome parks;
Integrated design with high reliability;
RS-485 data communication;
Auto-flip to follow object and surveillance of any subject that is constant and
continuous;
The speed can be adjusted automatically according to zooming times;
Auto focus lens and auto white balance, BLC function;
Multi protocol compatible (Pelco- D / P, DAHUA);
Alarm input, Alarm output, Alarm action.
2.2. FUNCTIONS
Object Tracking
In auto tracking mode, the camera can track a moving object in the target area with auto
pan, tilt and zoom which realizes smart unattended surveillance.
Tracking Cruise
The tracking function can be activated during cruise. At a preset of the cruise list, the
3 / 56

camera can track moving objects automatically.
Soft Address
The camera address can be programmed with built-in OSD menu, and the user does not
need to dismount the camera from field or do any screw work.
Wide Dynamic Range (WDR)
A camera is intended to provide clear images even under back light circumstances
where intensity of illumination can vary excessively, when there are both vary bright and
vary dark areas simultaneously in the field of view. WDR enables the capture and
display of both bright areas and dark areas in the same frame, in a way that there are
details in both areas, i.e. bright areas are not saturated, and dark areas are not too dark.
Day/Night Function
The IR cut filter of camera module inside the camera can be removed by sending special
command, so that the camera can change from color to mono.
Wide Dynamic Range (WDR) and Day/Night function are based on the relative
modules.
Proportional Pan
Proportional pan automatically reduces or increases the pan and tilt speeds in proportion
to the zooming times. At telephoto zoom settings, the pan and tilt speeds will be slower
for a given amount of joystick deflection then at wide zoom settings. This keeps the
image from moving too fast on the monitor when there is a large amount of zoom.
Auto Flip
When the camera tilts downward and goes just beyond the vertical angle, the camera
rotates 180º. When the camera rotates (flips), the camera starts moving upward as you
continue to hold joystick in the down position. Once you let go of the joystick after the
dome rotates, joystick control returns to normal operation. The auto-flip feature is useful
for following a person who passes directly beneath the camera.
Save/Call Preset
Preset function is that dome saves current horizontal angle and title angle of pan/tilt,
zoom and position parameters into memory. When necessary dome calls these
parameters and adjusts Pan/Tilt and camera to that position. User can save and call
presets easily and promptly by using keyboard controller or infrared controller. The
camera supports up to 256 presets.
Lens Control
1) Zoom control
User can adjust zoom in or out by controller to get desired image.
2) Focus control
System defaults Auto Focus mode, that is, the lens and camera will automatically adjust
4 / 56

the focus to get the best image.
Focus can also be controlled manually from the controller if required. Press Focus Near
or Focus Far key to manually focus. Focus can be manual via keyboard or matrix,
please refer to control keyboard or matrix operation manual for detailed operation. When
adjusting position is set with auto focus status, it goes back to auto focus.
The camera will NOT auto focus in the following status.
Target is not in the center of image.
Targets are in near and far at the same time.
Target is of strong light object. Such as spotlight etc.
Target is behind the glass with water drop or dust.
Target moves too fast.
Large area target such as wall.
Target is too dark or vague.
3) IRIS control
System defaults Auto IRIS. Camera can adjust immediately according to the alteration of
back ground illumination so that a lightness steady image can be achieved.
You may adjust IRIS by controller to get required image brightness, and call back Auto
IRIS by controlling the joystick.
Auto White Balance
Camera can automatically adjust white balance (WB) according to the alteration of
background lightness to give a true color image.
Back Light Compensation (BLC)
If a bright backlight presents, the subjects in the picture may appear dark or as a
silhouette. Backlight compensation enhances objects in the center of the picture. The
camera uses the center of the picture to adjust the IRIS. If there is a bright light source
outside this area, it will wash out to white. The camera will adjust the IRIS so that the
object in the sensitive area is properly exposed.
Auto Cruise
The preset position is programmed to be recalled in sequence. This feature is called
auto cruise. Up to 30 presets can be saved in each cruise tour.
Patterns
A pattern is a saved, repeating, series of pan, tilt, zoom and preset functions that can be
recalled with a command from a controller or automatically by a programmed function
(alarm action or park action or power-up action).
5 / 56

Auto, Random and Frame Scan
Auto Scan: Make the camera scan 360º ranging from the current position.
Random Scan: Make the camera random scan 360º ranging from the current position.
Frame Scan: This feature freezes the scene on the monitor when going to a preset. This
allows for smooth transition from one preset scene to another.
Zones Setting
A zone is a pan area, defined by a left and right limit, on the 360º pan plane. The camera
has eight zones, each with a 6-character label.
Alarms Input
The camera has four alarm inputs, which can be programmed as high, medium or low
priority. When an alarm is received, an input signal to the camera triggers the user-
defined action (go to preset, run pattern, etc.) programmed for the alarm.
Auxiliary Output
An auxiliary output is a programmable signal from the camera back box that can trigger
another device to operate. An auxiliary output is programmable to trigger from an alarm
or from a controller.
Password Protection
The camera features password protection to prevent unauthorized changes to the
camera settings. You can open the System Information and Display Setup Screens, but
cannot access any of the camera Settings menus.
Windows Blanking
A set window can be saved so that it is the only blanked tilt area of the scene. All other
parts of the tilt area of the scene will be visible.
Windows blanking is only available for Sony Modules at present.
2.3. TECHNICALPARAMETERS
Signal Format
NTSC
PAL
CCD
1/4 inch color CCD
Max. Pixels
811(H)×508(V)410K
795(H)×596(V)470K
Effective Pixels
768(H)×494(V)380K
7521(H)×582(V)440K
Horizontal
Resolution
500TV Line (color), 570 TV Line(b/w)
S/N Ratio
50dB
Zoom
10X optical, 10X digital
Focal Range
F1.8, f=3.8~38mm
6 / 56

Sensitivity
0.7Lux(Color) / 0.02Lux(B/W), 50IRE
Switch Mode
Auto / Day/Night(ICR)
Focus
Auto / Manual /Semi Auto
Iris
Auto / Manual
Shutter Speed
X128~1/120000sec
AGC
Normal / High / Off
White Balance
Auto / MAN
BLC
Low / Mid/ High / Off
SSNR
Low / Mid/ High / Off
Rotating Range
Pan:360°continuous, Tilt: 0°~90° (Auto flip)
Pan/Tilt Speed
Pan:0.05°～400°/s; Tilt:0.03°～240°/s
Preset
256
Auto Cruise
Presets switch sequentially from 1 to 30 automatically
Pattern Cruise
4
Regional Setting
8
Alarm Input
4
Alarm Output
2
COMM. Port
RS-485
Baud Rate
1200bps, 2400bps,4800bps, 9600bps
Address Range
0~63
Power
DC24V
Operating
Temperature
-20°C~70°C(Without Heater)/ -50°C~70°C(With Heater)
Dome Size
4 inch
IP Code
IP66
Mounting Modes
Wall (Outdoor or Indoor), Pole (Outdoor or Indoor), Surface
(Indoor)
Table 1: Samsung Modules
Parameters vary if cameras other than Samsung are equipped with.
The specifications are subject to change without notice.
7 / 56

3. INSTALLATION
This section contains detailed instructions for installing the camera. These instructions
assume that the installer has a good knowledge of installation techniques and is capable
of adopting safe installation methods.
3.1. DIP SWITCH SETTING
Before installing the camera drive, check the DIP switch; configure the receiver address,
communication protocol, and baud rate setting. Pic. 1 shows switch position and default
settings. For normal user, setting switches to default position is suggested.
Pic. 1 Switch Position
The camera can be controlled via various communication protocols by setting SW2
switch (3 and 4 bit) and operate at 1200bps, 2400bps, 4800bps and 9600bps baud rate
by setting SW2 switch (1and 2 bit). Refer to Table 2: SWITCH SETTING for address,
communication protocol and baud rate settings, do not set the switches to reserved
position.
SW2: Baud Rate, Protocol
SW1: Address
Pic. 2 DIP Switches
Please refer to the below table to set baud rate, communication protocol type and
camera address.
POS
(SW1)
Addr
1
2
3
4
5
6
7
8
Addr
0
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
8 / 56

2
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
3
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
4
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
9
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
10
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
11
ON
ON
OFF
ON
OFF
OFF
OFF
OFF
12
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
…
…
…
…
…
…
…
…
…
253
ON
OFF
ON
ON
ON
ON
ON
ON
254
OFF
ON
ON
ON
ON
ON
ON
ON
255
ON
ON
ON
ON
ON
ON
ON
ON
POS
(SW2)
BAUD
RATE
1
2
BAUD
RATE
(BPS)
1200
OFF
OFF
2400
ON
OFF
4800
OFF
ON
9600
ON
ON
POS
(SW2)
PROTOCOL
3
4
COMM
PTOL
PELCO
(PELCO-P/
PELCO-D)
OFF
OFF
reserved
ON
OFF
reserved
OFF
ON
reserved
ON
ON
Table 2: SWITCH SETTING
3.2. INSTALLATION
Step 1. Install lower dome.
9 / 56

Line up the mounting screw holes, and install the three mounting screws. Push the lower
dome inside the back box.
Step 2. Install the bracket for wall-mounted dome
Dig four holes on the wall as Pic. 3. Take out the cables from the backward of the
bracket. Install the bracket on the wall.
Pic. 3
When installing outdoors, make sure installation is properly sealed to keep
moisture out.
The surface, pole and in-ceiling mounting modes are like the wall mounting mode.
Pic. 4
Pic. 5
10 / 56

4. OPERATION GUIDE
4.1. OPERATION AT POWER UP
The camera employs the default settings the first time it is switched on. Changes to the
settings will be permanently stored and will be made available the next time the camera
is switched on. You can return to the default settings by means of the appropriate menu
option at any time.
The camera will work as follows when it is switched on.
The camera will run a calibration procedure and a message showing the following
information will appear on the video output OSD (On Screen Display): software version,
address, protocol, baud rate and zoom module brand.
Check that the data are suitable for operation. Otherwise, refer to the section in this
document that shows how to install the camera correctly.
MINI DOME II
SOFT VERSION: 5.3
ADDRESS: 1
PROTOCOL: PELCO－D/P
BAUD RATE: 2400
TEMPERATURE 25C
SAMSUNG SERIES CAMERA
At the end of the calibration step, the camera will switch to stand-by as programmed
(PTZ > POWER UP > ACTION). The camera will continue working this way until any
command is received from the keypad. The camera during this phase can be pointed to
a fixed point or pan across the field. Refer to the details described in the POWER UP menu
section.
4.2. HOW TO USE OUR CONTROL KEYBOARD
The camera is ready to receive commands from our control keyboard (see figure below)
after connecting.
11 / 56

4.2.1. CONTROL KEYPAD PASSWORD AND ACCESS
The system will wait for the password to be entered after being switched on.
The control panel requires a 6-digit password.
The entered digits will be replaced by a “*” symbol on the screen for privacy.
Access to the menu is gained after entering all the digits correctly.
Refer to the corresponding manual for using the control panel.
The default user password is “000000”.
It is advisable to change the default password to prevent intrusions.
Do not lose or forget the programmed password.
4.2.2. CONTROL KEYPAD COMMAND SYNTAX
Controls can use the joystick, single keys or key combinations.
The key command syntax is shown below.
Key command syntax
The syntax used in this manual for controls using keys consists of various elements
(words and three digit numbers). Each command is always in braces and each element
is separated by commas. Each word or decimal digit used in the syntax is identified by a
corresponding key on our control panel. Words can be enclosed in round brackets,
square brackets or no brackets. Three digit decimals are never enclosed in brackets.
The following words only can be used: PRESET, CALL, ESC, OPEN, CLOSE, NEAR, FAR,
ZOOM OUT, ZOOM IN, CAM, MON, SCAN, ENTER. The decimal digits are: 0, 1, 2, 3, 4, 5, 6,
7, 8, and 9.
Some application examples of controls are shown in detail below.
Using the joystick
A command can also be given simply by moving the joystick because this generates
actions on the camera or OSD (On Screen Display) menu.
Using a single key
Pressing a single key can cause camera action. For example, the following command
will zoom out of the frame. Underling indicates the key is in use.
ZOOM OUT
Key combinations
Pressing a key combination in rapid sequence extents the command set. For example,
the following command (select camera address 1) is performed by pressing the following
keys:
12 / 56

CAM + 1 + ENTER
4.2.3. CONTROL KEYPAD COMMAND TYPES
There are four command types:
Select camera,
Move camera (tilt and pan, zoom, adjust focus and IRIS opening, go to preset
positions),
Adjust camera operation mode using menus,
Various quick controls operable from the control panel.
The method for accessing these controls will be shown in details in the following
paragraphs.
4.3. SELECT ACAMERA
The camera to be controlled must be selected first. For example, the following command
selects camera 1:
CAM + 1 + ENTER
After this operation, the message CAM 1 will appear on the control panel display.
4.4. CAMERAMOTIONS
After selecting a camera, it can be moved either directly using the control panel as
described below:
Panning (horizontal) and tilting (vertical).
Zooming, focusing and IRIS opening.
Preset positions programming and recalling.
These functions can be directly accessed using a single key or joystick or a simple key
combination.
4.4.1. PAN AND TILT FUNCTIONS
The camera may be moved using our keyboard controller. Move the joystick vertically to
tilt the camera and horizontally to pan it.
13 / 56

The maximum pan span is from 0º to 360º with continuous rotation. The maximum tilt
span is from 0º (camera in vertical position) and 90º.
The panning and tilting speed can be modulated by operating the joystick appropriately.
Note that the maximum speed that can be obtained by operating the joystick is not
always equal to that programmed in the working settings. This in fact depends on the
value of the PTZ > MOTION > PROPORTIONAL PAN setting. If the option is ON, the
maximum rotation speed which can be obtained using the joystick is proportional to the
magnification used to obtain the best frame.
Panning (horizontal)
Tip the joystick rightwards to turn the camera horizontally clockwise and tip it leftwards to
turn it anticlockwise.
If no advanced options are set (e.g. range limits set enabled), the camera can be turned
continuously without interruptions.
The pan span may be limited between two angles in PTZ > MOTION > MANUAL LIMIT.
Tilting (vertical)
Tip the joystick upwards to turn the camera vertically upwards and tip it downwards to
turn the camera downwards. The camera rotation is limited upwards by the horizontal
plane or downwards by the vertical axis.
Performance will change considerably near the vertical axis according to whether the
AUTO FLIP is on or not (default setting is on).
With AUTO FLIP off, the camera will stop in perfectly vertical position and will stop
turning when the joystick is tipped downwards.
With AUTO FLIP on, the camera will proceed over the vertical axis when the
joystick is tipped downwards. This is because, when the vertical axis is reached,
the camera flips automatically by 180 degrees and resumes the initial trajectory.
The AUTO FLIP function can be used to follow a subject arriving in a certain direction
passes under the camera and continues in a straight line. To do this, hold the joystick
tipped downwards following the movement of the subject. Observe that in this case the
joystick performance after the camera passes over the vertical axis opposite to the
normal axis because tipping the joystick downwards will turn the camera upwards.
Normal operation of the joystick will be resumed as soon as the downward tip is
interrupted (also only for an instant). At this point, to follow the subject in the same
direction, you will need to tip the joystick upwards, as you would normally.
14 / 56

4.4.2. ZOOM FUNCTIONS
The camera frame may be adjusted by using the ZOOM IN and ZOOM OUT commands.
Use ZOOM IN to zoom into the detail; use ZOOM OUT to zoom out.
Zoom can be set as per the zoom specifications of relative modules, combined between
optical zoom and digital zoom. Refer to the specific section for programming the
function.
4.4.3. FOCUSFUNCTIONS
The camera focus may be adjusted manually using the NEAR and FAR controls.
As the auto focus function is always on, a manual setting made using NEAR and FAR will
be kept only until a pan, tilt or zoom command is used. In this case, auto focus will adjust
focus automatically again.
Refer to the specific section for additional details on focusing and on the various options.
The auto focus function cannot work correctly in the following cases:
The object to be focused on it not in the middle of the image.
There are far and near object in the frame.
Bright light is shining on the subject.
The subject is behind a glass pane covered in drops or dust.
The subject is moving very quickly.
The subject is not well lit.
The subject is too big.
4.4.4. IRIS OPENING FUNCTIONS
The IRIS opening may be controlled manually using the OPEN and CLOSE commands.
The manual setting made using OPEN and CLOSE will be kept only until a pan, tilt or
zoom command is used if the automatic IRIS opening option is enabled (the default
setting is on). In this case, the opening will be controlling automatically again.
Refer to the specific section for additional details on IRIS opening adjustment.
4.4.5. PRESET POSITIONS PROGRAMMING AND RECALLING
15 / 56

The camera can store up to 256 panning, tilting and zooming configurations (called
preset positions) which can be recalled at any time.
The manual focusing and IRIS opening settings cannot be stored.
When storing presets, it is important to remember that some are reserved and
cannot be either stored or used for positioning the camera.
Presets from 80 to 99 are reserved for management controls
Presets from 100 to 103, 170 to 173 are reserved for Tracking and Pattern
controls
The following examples show how to program the free Presets and recall them.
Example: programming preset number 32
1) Position the camera in a certain pan, tilt and zoom configuration.
2) Enter the command PRESET + 32 + ENTER.
From this moment onwards, simply enter the command CALL + 32 + ENTER to
move the camera to the preset position.
The saved value will be written over if the setting is reprogrammed.
The Presets are saved in a permanent memory area of the camera where they
are maintained also when power is disconnected. However, restoring default
settings will delete all preset values.
Press PRESET + 83 + ENTER to delete all the saved preset values.
The Presets store the coordinates according to an angular reference system.
Therefore, the reference system zero point may become misaligned with the
camera mechanics after prolonged use of the tilting and panning functions.
Minor inaccuracies in preset positions may occur. In this case, calibrate the
angular coordinate system using the REBOOT SYSTEM command. This
calibration is automatically run when the camera is switched on.
4.5. FUNCTION PROGRAM MENU
Use the following control panel command to access the function programming menu.
PRESET + 95 + ENTER
At this point, if no password is required for access, the following first level menu will
appear on the screen:
16 / 56
