YASKAWA VS MINI J7 Guide

Yaskawa Electric Corporation
Marketing Sect. Marketing Dept.
Drives Division
―― Contents ――
1Applicable Drives .................................................................................................................2
2Drive Replacement Checklist...............................................................................................2
3Terminals ..............................................................................................................................4
3.1 Main circuit terminals ..................................................................................................4
3.2 Control Terminals, Signal Levels.................................................................................4
3.3 DIP Switches...............................................................................................................4
3.4 Main Terminal Size/ Electric Wire Differences............................................................5
3.5 Control terminal sizes and wire sizes .........................................................................6
4Dimensions...........................................................................................................................7
5Options Replacement...........................................................................................................8
6Parameter Settings ..............................................................................................................9
6.1 J7 to J1000 Parameter Correspondence for Drive Replacement............................9
6.2 J7 and J1000 Differences in Parameter Settings .....................................................14
6.3 Replacement of J7 Drives with Special Software .....................................................15
7Rated Power, Current and Carrier Frequency ...................................................................15
Revision History .......................................................................................................................16
VAN-V07007E [J7→J1000] Replacement Instructions 1/16
VS mini J7 to J1000 Replacement Instructions

1 Applicable Drives
This document describes the substitution of the following drives:
Original drive: CIMR-J7xAxxxx
Spec: xxxx0 (IP20)
Software Version: Standard 001x, 002x
High Carrier Frequency 14.5 kHz 506X
Replacement: CIMR-JAxAxxxxxx
The replacement drive must be selected using the Heavy Duty rating.
The description is not valid for drives with other specs or other firmware installed!
2 Drive Replacement Checklist
VAN-V07007E [J7→J1000] Replacement Instructions 2/16
Item Checkpoints Checked?
＜Digital operator panel ＞
∗ Does the digital operator panel need to be at the same position
as before?
 If necessary try to readjust the position in order to have the
operator panel at the same location as before.
∗ Was a remote operator panel connected to the old unit?
 If so, never connect the old remote operator panel to the
J1000. Replace existing remote operators by the new type.
See part 5 of this manual for options replacement.
Basic
＜Special specifications ＞
∗ Check the installed drives specification to make sure, that it is
compliant to the standard specification (no special firmware, ...)
＜Wire Length ＞
∗ In the J7 drive main terminals are located at the top of the drive.
The J1000 drive has all main terminals at the bottom. Check if
all cables are long enough to be connected without tension to
the new unit.
Hardware
Main and
control
terminals ＜Main circuit wires and terminal specifications＞
∗ Compare the occupied terminals of the old unit with the new
drives terminals (shape, size, etc.) and check if the wires fit in
the new unit’s terminals using part 3 of this document.
Software Software
version
＜Check for special software ＞
∗ Check the software number in the old to be sure that it can be
replaced by the J1000 drive. Also refer to 6.3.
 If necessary, ask your dealer for identifying the software
installed on the drive that has to be replaced and for further
replacement instructions.
Software Parameter
＜Check the parameter settings＞
∗ If possible read out the parameter settings of the old unit and
perform a parameter transformation to the new parameters
following part 6 of this book.
∗ If there is special software installed or parameters that are not
mentioned in this book appear, contact your dealer.

Communi-
cation
Option
＜Is an option card is installed? ＞
∗ Check if any communication option is installed。
 If a communication option is installed, get the equivalent part
for the J1000.
 Never try to apply J7 options to J1000 unit.
 Communication cable connectors from J7 options can be
used on J1000 options without rewiring.
＜Is an AC or DC reactor installed? ＞
∗ AC or DC chokes installed with a J7 can be used with a J1000
and have not to be changed (only for same capacity like the
installed J7). Before connecting it, make sure that it works
properly.
＜Is an EMC Filter installed? ＞
∗ EMC filters installed with a J7 can partially used with a J1000.
For details on filter replacement contact your sales agent.
Before using the old J7 filter in combination with the J1000,
make sure the filter is free from any damage.
Options,
Others
＜Extension Cables ＞
∗ The extension cables for remote operation can continued to be
used, but the remote operator and the remote operator interface
have to be replaced!
○Refer to the instruction manual for questions about installation, parameter settings or detailed parameter /
function descriptions
VAN-V07007E [J7→J1000] Replacement Instructions 3/16
○In case of technical questions regarding the replacement please contact your dealer.

3 Terminals
3.1 Main circuit terminals
・ As the VS mini J7 and J1000 may have different terminals sizes (depending on capacity), this point
has to be carefully checked before the replacement (see 3.4).
J7
Main terminals
J1000
Main terminals Note
R/L1 R/L1
S/L2 S/L2
T/L3 T/L3
Power supply connection.
Note:
In the J7 the power supply terminals are located at the top
of the drive. In the J1000 they are located at the bottom.
Make sure the cables fit without tension. Replace or extend
them if needed.
U/T1 U/T1
V/T2 V/T2
W/T3 W/T3
Drive output
- B1 Braking resistor or external braking chopper connection
- B2 Braking resistor connection
+1 +1 DC Reactor connection, DC power supply input
+2 +2 DC Reactor connection
−−DC power supply input, external braking chopper connection
Ground connector (ground with <100Ohm for 200 V class
and < 10 Ohm for 400 V class)
3.2 Control Terminals, Signal Levels
Te r m i n a l Signal Level
J7 J1000
Function
J7 J1000
S1 Multi function input 1
(1: Run forward 0: Stop）
S2 Multi function input 2
(1: Run reverse 0: Stop）
S3 Multi function input 3
(J7: Fault Reset / J1000: Ext. Fault)
S4 Multi function input 4
(J7: Ext. Fault / J1000: Fault Reset)
S5 Multi function input 5 (Multi speed 1）
Photo coupler isolation
24 Vdc，8 mA
Photo coupler
24 Vdc，8 mA
SC Multi function input common - -
FS +V Analog input power supply +12 Vdc, max. 20 mA +10.5 Vdc, max. 20 mA
FR A1 Analog input 1
(frequency reference)
0-10 Vdc (20 kΩ)，
0 or 4-20 mA (250 Ω)，
0-10 Vdc (20 kΩ)，
0 or 4-20 mA (250 Ω)
FC AC Analog input common 0V
MA Change over contact output (NO)
(Fault）
MB Change over contact output (NC)
(Fault）
MC Change over contact output common
Max. load
250 Vac 1 A max.
30 Vdc 1 A max.
Max. load
250 Vac 10 mA〜1A
30 Vdc 10 mA〜1A
AM Analog output
AC Analog output GND
0-10 Vdc，max. 2 mA
Resolution 8 Bit
0-10 Vdc，max. 2 mA
Resolution 8 Bit
3.3 DIP Switches
When replacing a J7, make sure to set the DIP switches S1 and S3 on the J1000 properly.
VAN-V07007E [J7→J1000] Replacement Instructions 4/16
J7 J1000
Function
Switch Default Switch Default
NPN/PNP selection SW7 NPN S3 NPN
Analog input 1 level sel. SW8 Voltage S1 Voltage

3.4 Main Terminal Size/ Electric Wire Differences
The J7 has main terminals at the top and at the bottom whereas the J1000 has all main terminals at the
bottom. When replacing a J7 by a J1000 make sure that all wires are long enough and can be connected to
the J1000 with out tension.
= Ground terminal
Voltage
class Drive CIMR- JATerminal Symbol Screw Size
Tightening
Torque (Nm)
Wire Size
(mm²)
Recommended
Wire Size
(mm²)
R/L1,S/L2,T/L3,
−,+1, +2, 0.8〜1.0
J7
20P1
20P2
20P4
20P7 U/T1,V/T2,W/T3, 1.24
J1000
2A0001
2A0002
2A0004
2A0006
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M3.5
0.8〜1.0
0.75〜2.0 2
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1,+2
J7 21P5 M3.5 0.8〜1.0 2.0〜5.5 2
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
2
J1000 2A0010
(2 terminals)
M4 1.2〜1.5 2.0〜5.5
3.5
J7 22P2
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,
M3.5 0.8〜1.0
J1000 2A0012
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M4 1.2〜1.5
2.0〜5.5 3.5
J7 23P7
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,
Three-
Phase
200V
J1000 2A0020
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M4 1.2〜1.5 2.0〜5.5 5.5
R/L1,S/L2,
−,+1, +2, 0.8〜1.0
J7
B0P1
B0P2
B0P4 U/T1,V/T2,W/T3, 1.24
J1000
BA0001
BA0002
BA0003
R/L1,S/L2,
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M3.5
0.8〜1.0
0.75〜2.0 2
R/L1,S/L2,
U/T1,V/T2,W/T3,
−,+1,+2,
3.5
J7 B0P7 M3.5 0.8〜1.0
2
J1000 BA0006
R/L1,S/L2,
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M4 1.2〜1.5
2.0〜5.5
2
R/L1,S/L2,
U/T1,V/T2,W/T3,
−,+1,+2,
5.5
J7 B1P5
M3.5 0.8〜1.0
2
R/L1,S/L2,
U/T1,V/T2,W/T3,
(2 terminals)
3.5
Single-
Phase
200V
J1000 BA0010
−,+1, +2,B1,B2
M4 1.2〜1.5
2.0〜5.5
5.5
VAN-V07007E [J7→J1000] Replacement Instructions 5/16

Voltage
class Drive CIMR- JATerminal Symbol Screw Size
Tightening
Torque (Nm)
Wire Size
(mm²)
Recommended
Wire Size
(mm²)
J7
40P2
40P4
40P7
41P5
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,
M3.5 0.8〜1.0
J1000
4A0001
4A0002
4A0004
4A0005
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M4 1.2〜1.5
2.0〜5.5 2
J7 42P2
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1,+2,
J1000 4A0007
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
(2 terminals)
M4 1.2〜1.5 2.0〜5.5 2
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1,+2
2
J7 43P0
43P7
M4 1.2〜1.5 2.0〜5.5
3.5
R/L1,S/L2,T/L3
U/T1,V/T2,W/T3,
−,+1, +2,B1,B2，
2
Three-
Phase
400V
J1000 4A0009
4A0011
(2 terminals)
M4 1.2〜1.5 2.0〜5.5
3.5
3.5 Control terminal sizes and wire sizes
Voltage
class Drive Terminal Symbol Screw Size Tightening Torque (Nm) Wire Size (mm²)
Recommended
Wire Size
(mm²)
J7 S1-S5, SC, FS,
FR, FC, AM,AC
flexible: 0.5 〜0.75
solid: 0.5 〜1.25
J1000 S1-S5, SC, V+,
A1, AC, AM,AC
M2 0.22〜0.25 flexible: 0.25 〜1.0
solid: 0.25 〜1.5
0.75
J7 flexible: 0.5 〜1.25
solid: 0.5 〜1.25
All
J1000
MA,MB,MC M3 0.5〜0.6 flexible: 0.25 〜1.5
solid: 0.25 〜1.5
0.75
VAN-V07007E [J7→J1000] Replacement Instructions 6/16

4 Dimensions
The table below shows differences in the dimensions of J7 and J1000 and required parts for drive
replacement. (J7 dimensions are without potentiometer knob).
J7 (unit: mm) J1000 (unit: mm)
Voltage
class
J7
CIMR-
J7xA□
J1000
CIMR-
JAW H D W H D
Mechanical Mounting
Adapter
B0P10 BA0001B
B0P20 BA0002B
70 76
B0P40 BA0003B
68
112
68
118
B0P70 BA0006B 129 137.5
Single
Phase
200V
B1P50 BA0010B
108
128
154
108
128
154
Not required
20P10 2A0001B
20P20 2A0002B
70 76
20P40 2A0004B 102 108
20P70 2A0006B
68
122
68
128
21P50 2A0010B 129 129
22P20 2A0012B
108
154
108
137.5
Three
Phase
200V
23P70 2A0020B 140
128
161 140
128
143
Not required
40P20 4A0001B 81 81
40P40 4A0002B 99 99
40P70 4A0004B 129 137.5
41P50 4A0005B
42P20 4A0007B
108
154
Not required
43P00 4A0009B
108
154
100-036-355
Three
Phase
400V
43P70 4A0011B
140
128
161
140
128
143 Not required
VAN-V07007E [J7→J1000] Replacement Instructions 7/16

5 Options Replacement
Refer to the table below for an overview about the replacement of options, which might be installed at the
drive that has to be replaced. Replace an option only by the appropriate new type and never try to apply
any not mentioned option or J7 option to the J1000.
Type Description J7 J1000
Interface for Remote operator SI-232/J7 SI-232/J
Interface for RS-232 PC
communication (Memobus) SI-232/J7C SI-232/JC
Serial
communications Interface for RS-422/485
communication (Memobus) SI-485/J7 SI-485/J
Remote operator without
potentiometer JVOP-146 JVOP-182
Remote operator with
potentiometer JVOP-144 not available
Extension cable 1 m WV001 WV001
Operator panel
Extension cable 3m WV003 WV003
Potentiometer
Option
To use a potentiometer on the
drive for setting up the frequency
reference.
Built in AI-V3/J
DIN rail
mounting
Used to mount the drive on a DIN
rail. EZZ08122x
Use the same.
When replacing a J7xA43P0
by a JA4A0009 a different
DIN rail mounting kit is
required!
AC reactors UZBA-B same as J7
DC reactors UZDA-B same as J7
VAN-V07007E [J7→J1000] Replacement Instructions 8/16

6 Parameter Settings
6.1 J7 to J1000 Parameter Correspondence for Drive Replacement
・ Before setting up other parameters, make sure that C6-01 is set to “0” (Heavy Duty). Refer to the
Technical manual for details on the Normal and Heavy Duty selection.
・ The given voltage values are valid for 200 V units. For 400 V units the values have to be doubled.
VAN-V07007E [J7→J1000] Replacement Instructions 9/16
J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
Parameter access
level A1-01 2
Initialization A1-03 0
Run Command in
Programming Mode b1-08 0
Fault history U2
initialization
n01 1
o4-11 0
J7 J1000
n01→0 A1-01→0
n01→1 A1-01→2
n01→5 A1-01→2
b1-08→1
n01→6 o4-11→1
n01→8 A1-03→2220
n01→9 A1-03→3330
RUN command source
selection n02 0 b1-02 1
J7 J1000
n02→0 b1-02→0
n02→1 b1-02→1
n02→2 b1-02→2
Frequency reference
source selection n03 0 b1-01 1
J7 J1000
n03→0b1-01→3 (AI-V3/J
option required)
n03→1 b1-01→0
n03→2 b1-01→1 and H3-01→0
n03→3 b1-01→1 and H3-01→2
n03→4 b1-01→1 and H3-01→3
n03→6b1-01→2 (SI-485/J)
option required)
When using A1 as frequency reference
input, make sure to set DIP switch S1
properly (voltage or current input).
Stop method selection n04 0 b1-03 0
J7 J1000
n04→0 b1-03→0
n04→1 b1-03→1
Reverse run prohibit
selection n05 0 b1-04 0
J7 J1000
n05→0 b1-04→0
n05→1 b1-04→1
Digital Operator STOP
key function n06 0 o2-02 1
J7 J1000
n06→0 o2-02→1
n06→1 o2-02→0
Frequency reference in
local mode n07 0 - - - (no operator panel potentiometer)
Frequency reference
from operator ENTER
key selection
n08 0 o2-05 0
J7 J1000
n08→0 o2-05→0
n08→1 o2-05→1
Max. output frequency n09 60.0 Hz E1-04 60.0 Hz
Max. output voltage n10 200 V * E1-05 200 V * * Values for a 400 V class drive are double.
Base frequency n11 60.0Hz E1-06 60.0 Hz
Mid. output frequency n12 1.5Hz E1-07 3.0 Hz
Mid. output voltage n13 12 V * E1-08 16.0 V * * Values for a 400 V class drive are double.

VAN-V07007E [J7→J1000] Replacement Instructions 10/16
J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
Min. output frequency n14 1.5Hz E1-09 1.5 Hz
Min. output voltage n15 12 V * E1-10 12.0 V * * Values for a 400 V class drive are double.
Acceleration time 1 n16 10.0 s C1-01 10.0 s
Deceleration time 1 n17 10.0 s C1-02 10.0 s
Acceleration time 2 n18 10.0 s C1-03 10.0 s
Deceleration time 2 n19 10.0 s C1-04 10.0 s
S-curve at accel. Start 0 (0 s) C2-01 0.2 s
S-curve at accel. End 0 (0 s) C2-02 0.2 s
S-curve at decel. start 0 (0 s) C2-03 0.2 s
S-curve at decel. end
n20
0 (0 s) C2-04 0.0 s
J7:
Selection parameter (setting 0,1,2, and 3).
Same setting for all conditions.
J1000:
Numerical parameter (time must be set in
seconds). S-curve set separately for each
ride profile section.
Multi speed ref. 1 n21 0.0Hz d1-01 0.00 Hz
Multi speed ref. 2 n22 0.0Hz d1-02 0.00 Hz
Multi speed ref. 3 n23 0.0Hz d1-03 0.00 Hz
Multi speed ref. 4 n24 0.0Hz d1-04 0.00 Hz
Multi speed ref. 5 n25 0.0Hz d1-05 0.00 Hz
Multi speed ref. 6 n26 0.0Hz d1-06 0.00 Hz
Multi speed ref. 7 n27 0.0Hz d1-07 0.00 Hz
Multi speed ref. 8 n28 0.0Hz d1-08 0.00 Hz
Jog frequency n29 6.0Hz d1-17 6.00Hz
Frequency reference
upper limit n30 100% d2-01 100.0%
Frequency reference
lower limit n31 0% d2-02 0.0%
Motor rated current n32 - E2-01 -.
Depends on the drive capacity
Motor overheat
protection n33 0 L1-01 1
J7 J1000
n33→0 L1-01→1
n33→1 L1-01→2
n33→2 L1-01→0
Motor protection time
constant n34 8min L1-02 1.0 min
Set L1-02 = n34 / 8.
Drive cooling fan
operation selection n35 0 L8-10 0
J7 J1000
n35→0 L8-10→0
n35→1 L8-10→1
Terminal S1 function
selection - - H1-01 40
The function of S1 is fixed to Fwd Run in
the J7. The equivalent setting in the
J1000 is H1-01=40 (default).

VAN-V07007E [J7→J1000] Replacement Instructions 11/16
J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
Terminal S2 function
selection n36 2 H1-02 41
Terminal S3 function
selection n37 5 H1-03 24
Terminal S4 function
selection n38 3 H1-04 14
Terminal S5 function
selection n39 6 H1-05 3
J7 J1000
n36〜39→2 H1-02〜H1-05→41
n36〜39→3 H1-02〜H1-05→24
n36〜39→4 H1-02〜H1-05→25
n36〜39→5H1-02〜H1-05→14
n36〜39→6H1-02〜H1-05→3
n36〜39→7H1-02〜H1-05→4
n36〜39→8H1-02〜H1-05→5
n36〜39→10 H1-02〜H1-05→6
n36〜39→11 H1-02〜H1-05→7
n36〜39→12 H1-02〜H1-05→8
n36〜39→13 H1-02〜H1-05→9
n36〜39→14 H1-02〜H1-05→61
n36〜39→15 H1-02〜H1-05→62
n36〜39→16 H1-02〜H1-05→A
n36〜39→17 H1-02〜H1-05→1
n36〜39→18 H1-02〜H1-05→2
n36〜39→19
n04→0
H1-02〜H1-05→28
set the stop time C1-09
n36〜39→19
n04→1H1-02〜H1-05→24
n36〜39→20
n04→0
H1-02〜H1-05→15
set the stop time C1-09
no alarm message
n36〜39→20
n04→1 can not be set
n36〜39→21
n04→0
H1-02〜H1-05→29
set the stop time C1-09
n36〜39→21
n04→1H1-02〜H1-05→25
n36〜39→22
n04→0
H1-02〜H1-05→17
set the stop time C1-09
no alarm message
n36〜39→22
n04→1 can not be set
n37→0 H1-03→0
n39→34
H1-04→10
H1-05→11
(b1-01 must be set to 0
or 1 and b1-02 must be
set to 1)
n39→35 H1-05→67

VAN-V07007E [J7→J1000] Replacement Instructions 12/16
J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
Te r m i n a l M A, M B , M C
function selection n40 1 H2-01 E
J7 J1000
n40→0 H2-01→E
n40→1 H2-01→0
n40→2 H2-01→2
n40→3 H2-01→1
n40→4 H2-01→5
n40→5 H2-01→4
n40→6 H2-01→B
n40→7 H2-01→17
n40→10 H2-01→10
n40→11 H2-01→8
n40→12 H2-01→3C
n40→13 H2-01→6
n40→14 H2-01→1E
n40→15 H2-01→7
n40→16 H2-01→1A
n40→17 H2-01→3D
n40→18 F (through mode)
Analog input FR gain n41 100% H3-03 100.0 %
Analog input FR bias n42 0% H3-04 0.0 %
Analog input filter time
constant n43 0.10 s H3-13 0.03 s
Analog output AM
function selection n44 0 H4-01 102
J7 J1000
n44→0 H4-01→102
n44→1 H4-01→103
Analog output AM gain n45 1.00 H4-02 100.0%
Set H4-02 = n45 * 100
Carrier frequency
selection C6-02 o2-04
dep.
Carrier frequency
upper limit C6-03 C6-02 dep.
Carrier frequency
lower limit C6-04 C6-02 dep.
Carrier frequency
proportional gain
n46
4
(depending
on drive
size)
C6-05 0
J7 J1000
n46→1 C6-02→1 (2kHz)
n46→2 C6-02→2 (5kHz)
n46→3 C6-02→3 (8kHz)
n46→4 C6-02→4 (10kHz)
n46→7 C6-03 = 2.5
C6-04 = 1.0
C6-05 = 12
n46→8 C6-03 = 2.5
C6-04 = 1.0
C6-05 = 24
n46→9 C6-03 = 2.5
C6-04 = 1.0
C6-05 = 36
Momentary power loss
detection selection n47 0 L2-01 0
J7 J1000
n47→0 L2-01→0
n47→1 L2-01→1
n47→2 L2-01→2
Automatic fault reset
attempts n48 0 L5-01 0
Jump frequency 1 n49 0.0Hz d3-01 0.0Hz
Jump frequency 2 n50 0.0Hz d3-02 0.0Hz
Jump frequency
bandwidth n51 0.0 Hz d3-04 1.0 Hz

VAN-V07007E [J7→J1000] Replacement Instructions 13/16
J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
DC injection braking
current n52 50% b2-02 50%
DC injection time at
stop n53 0.5 s b2-04 0.50 s
DC injection time at
start n54 0.0 s b2-03 0.00 s
Stall prevention during
deceleration n55 0 L3-04 1
J7 J1000
n55→0 L3-04→1
n55→1 L3-04→0
Stall prevention level
during acceleration n56 170% L3-02 - Initial value of J1000 depends on Duty
mode selection (C6-01).
Stall prevention level
during run n57 160% L3-06 - Initial value of J1000 depends on Duty
mode selection (C6-01)
Output frequency
detection level (DO) n58 0.0 Hz L4-01 0.0 Hz
Over torque detection n59 0 L6-01 0
J7 J1000
n59→0 L6-01→0
n59→1 L6-01→1
n59→2 L6-01→3
n59→3 L6-01→2
n59→4 L6-01→4
Over torque detection
level n60 160% L6-02 150%
Over torque detection
time n61 0.1 s L6-03 0.1 s
Frequency reference
hold selection
(up/down function)
n62 0 d4-01 0
J7 J1000
n62→0 d4-01→0
n62→1 d4-01→1
Torque compensation
gain n63 1.0 C4-01 1.00
Motor rated slip n64 E2-02 -
Default value depends on the drive rating.
Motor no-load current n65 E2-03 -
Default value depends on the drive
capacity.
Set E2-03 = n32 * n65 / 100%
Slip compensation
gain n66 0.0 C3-01 0.0
Slip compensation
time constant n67 2.0 s C3-02 2000 ms
J7: Setting unit is 1.0 s
J1000: Setting unit is 1 ms
H5-04 3
H5-05 0
C1-02 10.0
Memobus
communication error
behavior selection
n68 0
C1-09 100
J1000
J7
H5-04 H5-05
n68→01
n68→10 (C1-02)
n68→22 (C1-09)
n68→33
1
n68→4No effect 0
Memobus
communication error
detection
H5-05 1
Memobus frequency
reference and monitor
units
n69 0
H5-13 0
J7 J1000
n69→0 H5-13→0
n69→1 H5-13→1 and
o1-03→0
n69→2 H5-13→2
n69→3 H5-13→3

J7 J1000
Drive
Function/
Parameter
Parameter
No. Initial Value Parameter No. Initial Value
Comments
Memobus slave
address n70 0 H5-01 1F
J7: set as decimal value
J1000: set as hexadecimal value
Memobus
communication Speed
selection
n71 2 H5-02 3
J7 J1000
n71→0 H5-02→1
n71→1 H5-02→2
n71→2 H5-02→3
n71→3 H5-02→4
Memobus parity
selection n72 0 H5-03 0
J7 J1000
n72→0 H5-03→1
n72→1 H5-03→2
n72→2 H5-03→0
Transmission wait time n73 10ms H5-06 10 ms
RTS flow control on/off n74 0 H5-07 1
J7 J1000
n74→0 H5-07→1
n74→1 H5-07→0
Low speed carrier
frequency reduction n75 0 L8-38
depends on
drive
capacity
J7 J1000
n75→0 L8-38→0
n75→1 L8-38→1
COPY function
selection n76 rdy o3-01 0
Possible with copy unit or remote
operator.
READ prohibit
selection n77 0 o3-02 0
Fault History n78 - U2-01/02 -
In the J1000 the last current fault and the
last fault can be seen in parameter U2-01
and U2-02
Software Version n79 - U1-25/26 -
6.2 J7 and J1000 Differences in Parameter Settings
- Maximum carrier frequency
 J7: n46, max. 10 kHz
 J1000: C6-02, max. 15 kHz
- S-Curve setting
 J7: fixed settings
 J1000: set in seconds
- Stall Prevention Level
The stall prevention level during acceleration and constant speed run depends on the duty
mode setting.
J7: The maximum setting of n56/57 is 200%
J1000: Heavy Duty, The maximum setting of L3-02 and L3-06 is 150%
Normal Duty, The maximum setting of L3-02 and L3-06 is 120%
VAN-V07007E [J7→J1000] Replacement Instructions 14/16

6.3 Replacement of J7 Drives with Special Software
The table below gives a reference how to replace J7 drives with special software installed.
The software ID number of the J7 drive that has to be replaced is printed on the name plate.
J7
Software Number Description J1000
001x, 002x J7 Standard drive software Covered by standard software functionality
506x High Carrier Frequency Covered by standard software functionality
others - Contact your sales office.
7 Rated Power, Current and Carrier Frequency
VAN-V07007E [J7→J1000] Replacement Instructions 15/16
J7 J1000
Voltage
class
Max.
Motor
power
(kW)
J7 type
J7xAx
J1000
type
JAx
Output
power
（kVA）
Output
current
（A）
Carrier
frequency
（kHz）
Output
power
（kVA）
Output
current
（A）
Carrier
frequency
（kHz）
0.1 B0P1 BA0001 0.3 0.8 0.3 0.8
0.2 B0P2 BA0002 0.6 1.6 0.6 1.6
0.4 B0P4 BA0003 1.1 3.0 1.1 3.0
0.75 B0P7 BA0006 1.9 5.0
10
1.9 5.0
10
Single
phase
200V
1.5 B1P5 BA0010 3.0 8.0 7.5 3.0 8.0 8
0.1 20P1 2A0001 0.3 0.8 0.3 0.8
0.2 20P2 2A0002 0.6 1.6 0.6 1.6
0.4 20P4 2A0004 1.1 3.0 1.1 3.0
0.75 20P7 2A0006 1.9 5.0
10
1.9 5.0
10
1.5 21P5 2A0010 3.0 8.0 3.0 8.0
2.2 22P2 2A0012 4.2 11.0 4.2 11.0
3 phase
200V
3.7 23P7 2A0020 6.7 17.5
7.5
6.7 17.5
8
0.2 40P2 4A0001 0.9 1.2 0.9 1.2
0.4 40P4 4A0002 1.4 1.8 1.4 1.8
0.75 40P7 4A0004 2.6 3.4 2.6 3.4
1.5 41P5 4A0005 3.7 4.8 3.7 4.8
2.2 42P2 4A0007 4.2 5.5 4.2 5.5
3.0 43P0 4A0009 5.5 7.2 5.5 7.2
3 phase
400V
3.7 43P7 4A0011 6.6 8.6
7.5
7.0 9.2
8

Revision History
Rev. No. Date Modification
- 21.Dec. 07 First Edition
VAN-V07007E [J7→J1000] Replacement Instructions 16/16
