Z3 Technology FVXK-13A-RPS User manual

1
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
FVXK-13A-RPS User Guide
Model Name: FVXK-13A-RPS
DOC-USR-0264-02
December 28, 2022
Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
Copyright © 2022 Z3 Technology, LLC. All rights reserved.
Z3 Technology and ZEUS are registered trademarks of Z3 Technology, LLC.
This document contains proprietary information of Z3 Technology, LLC ("Z3"). This document may not be used, reproduced, disclosed, or
disseminated to anyone without the prior written approval of an authorized representative of Z3. Z3 reserves the right to change this product at
any time and without notice. All product names, trademarks, trade names, service marks, or service names mentioned in this document are the
property of their respective owners.
Z3 Technology, LLC incorporates HDMI® technology. The terms of HDMI and HDMI High-Definition Multimedia Interface, and
the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

2
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
REVISION HISTORY
Version
Date
Change Note
Author
1.0
04/22/2022
Original Document
NC
1.1
12/28/2022
Updates to section on fresh Ubuntu install
NC

3
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
TABLE OF CONTENTS
1.0 FV2K, FV4K, AND FSDI................................................................................................... 8
2.0 GENERAL DESCRIPTION.................................................................................................. 8
3.0 FEATURES ................................................................................................................. 9
3.1 Supported Resolutions...............................................................................................10
4.0 QUICK START GUIDE ....................................................................................................11
4.2 Before Attaching A Camera Block .................................................................................11
4.3 If You Have Received a System from Z3 with the Software Preloaded.......................................11
4.4 If You Already Have a System from Z3 and Need to Update the Firmware..................................11
4.5 If You are Ready to Start Development...........................................................................11
5.0 PACKAGE CONTENTS ...................................................................................................12
6.0 OPERATING CONTROLS ...............................................................................................12
7.0 UART AND RS-485 PIN-OUTS...........................................................................................13
8.0 THERMAL MANAGEMENT ...............................................................................................13
9.0 UNTARRING AND BUILDING THE SAMPLE CODE ...................................................................14
9.1 Making the Directory and untarring the RPS code...............................................................14
9.2 Preparing the Linux Environment..................................................................................14
9.3 Running the Make Script ............................................................................................15
10.0 CODE OVERVIEW.......................................................................................................16
10.4 ambarella/out/cv22_walnut/images ............................................................................16
10.5 scripts/z3-img.......................................................................................................17
10.6 ambarella/z3........................................................................................................17
11.0 RUNNING THE CODE YOU BUILT ON THE BOARD ..................................................................18
11.7 Via User Interface ..................................................................................................18
12.0 KEL CONNECTIONS ....................................................................................................19
12.1 KEL Cable Warning .................................................................................................19
12.2 KEL Connection .....................................................................................................19
13.0 RUNNING THE ENCODER ..............................................................................................20
13.1 Set up the Video Source ...........................................................................................20
13.2 Connect the Encoder...............................................................................................20
13.3 Set up the Terminal Window......................................................................................21
13.4 Power on the Board ................................................................................................21
13.5 Verify your PC has the Proper IP Address .......................................................................22
13.6 Access the User Interface .........................................................................................23
13.7 Configure Channel 1 for Streaming UDP.........................................................................23

4
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13.8 Run VLC to View the UDP Stream ................................................................................25
13.9 Configure Channel 1 for Streaming RTP.........................................................................26
13.10 Run VLC to View the RTP Stream ...............................................................................27
13.11 Configure Channel 1 for Streaming RTSP ......................................................................28
13.12 Run VLC to View the RTSP Stream..............................................................................29
13.13 Configure Channel 1 for RTMP Streaming......................................................................30
13.14 View RTMP Streaming ............................................................................................31
13.15 Encoding Composite Video.......................................................................................33
13.16 Changing the Bitrate Dynamically ..............................................................................34
13.17 Tuning for Latency................................................................................................36
13.18 Stream Multiple Resolutions .....................................................................................36
13.19 Record to Micro-SD Card .........................................................................................36
13.20 Simultaneous Stream and Record...............................................................................37
13.21 Encoding with Forward Error Correction.......................................................................38
13.22 Encoding KLV Stream .............................................................................................39
14.0 PERFORMING OTHER OPERATIONS ..................................................................................40
14.1 Accessing the User Interface using ZFinder.....................................................................40
14.2 Saving Current Settings ............................................................................................41
14.3 Advanced Settings Mode...........................................................................................42
14.4 Changing the IP Address via the HTTP-based User Interface.................................................44
15.0 RUNNING THE CODE YOU BUILT ON THE BOARD ..................................................................46
15.1 Via User Interface ..................................................................................................46
15.2 Via USB using AmbaUSB............................................................................................47
15.2.2 Required Software ...............................................................................................47
15.2.3 Required Equipment .............................................................................................47
15.2.4 Programming Board ..............................................................................................48
16.0 SUMMARY OF OPTIONS................................................................................................51
16.1 The System Setup Tab .............................................................................................51
16.2 The User Presets Tab ..............................................................................................52
16.3 The Status Tab ......................................................................................................52
16.4 The CH1 Tab (Channel 1)..........................................................................................53
16.5 The CH2 & CH3 Tabs (Channels 2 & 3) ..........................................................................57
16.6 Values Appearing at the Bottom of All Tabs....................................................................58
APPENDIX A: Configuring the Wowza Server for RTMP ................................................................59
APPENDIX B: Speeding up the Build Process.......................................... Error! Bookmark not defined.

5
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
APPENDIX C: Support and Troubleshooting .............................................................................61
Appendix C: Support .....................................................................................................61
Appendix C: Troubleshooting ...........................................................................................61
Appendix C: Warranty ...................................................................................................64

6
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
LIST OF FIGURES
Figure 1 FVXK-13A-RPS (Front) Dimensions............................................................................ 8
Figure 2 FVXK-13A-RPS (Back) Dimensions............................................................................. 9
(2) Figure 3...................................................................................................................12
Figure 4 UART J5 pin-outs................................................................................................13
Figure 5 RS-485 J4 pin-outs........................................................... Error! Bookmark not defined.
Figure 6 Sample Content of Images Directory after Successful Build ...........................................15
Figure 7 Updating the Device Firmware from the Web Interface................................................18
Figure 8 Updater Screen .................................................................................................18
(3) Figure 9...................................................................................................................20
Figure 10 HDMI Encode Connections...................................................................................21
Figure 11 Serial Menu .....................................................................................................22
Figure 12 CH1 Tab UDP Configuration.................................................................................24
Figure 13 VLC Open Network Screen (UDP) ..........................................................................25
Figure 14 Example of Encoded Video Streaming to VLC (UDP) ...................................................25
Figure 15 CH1 Tab RTP Configuration .................................................................................26
Figure 16 Example of Encoded Video Streaming to VLC (RTP) ...................................................27
Figure 17 CH1 Tab RTSP Configuration................................................................................28
Figure 18 VLC Open Network Screen for RTSP ......................................................................29
Figure 19 Example of Encoded Video Streaming to VLC (RTSP) ..................................................29
Figure 20 Example Settings for RTMP Encode .......................................................................30
Figure 21 Getting to the Wowza Test Player.........................................................................31
Figure 22 Viewing Content on Wowza.................................................................................32
Figure 23 Composite Adapter Cable ...................................................................................33
Figure 24 Channel 1 Tab –Composite Encode .......................................................................33
Figure 25 Viewing Bitrate in VLC.......................................................................................34
Figure 26 Changing the Bitrate Dynamically .........................................................................35
Figure 27 Drop in Bitrate after Dynamic Bitrate Change ..........................................................35
Figure 28 Create Additional Output Channels .......................................................................36
Figure 29 Channel 1 Tab –.ts File Encode............................................................................37
Figure 30 Enabling Pro-MPEG FEC Encode ............................................................................38
Figure 31 Enabling KLV...................................................................................................39
Figure 32 ZFinder with Z3-FVXK-13A-RPS Selected ............................. Error! Bookmark not defined.
Figure 33 Creating a New User Preset Configuration...............................................................41
Figure 34 Entering a User Preset Name ...............................................................................41
Figure 35 Saving a User Preset .........................................................................................41
Figure 36 Accessing Advanced Settings ...............................................................................42
Figure 37 Default UDP Settings (Left) and Advanced UDP Settings (Right).....................................43
Figure 38 Saving Updated Network Settings .........................................................................44
Figure 39 Save Complete Message .....................................................................................45
Figure 40 Updating the Device Firmware from the Web Interface ..............................................46
Figure 41 Updater Screen ...............................................................................................46
Figure 42 USB Male A to Male A .........................................................................................47
Figure 43 AmbaUSB ........................................................................................................48
Figure 44 AmbaUSB ........................................................................................................49
Figure 45 Programmed AmbaUSB .......................................................................................50
Figure 46 Wowza Performance Settings ..............................................................................59

7
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 47 Wowza Security Settings ....................................................................................60

8
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
1.0 FV2K, FV4K, AND FSDI
The F SERIES comes in three different options:
•the FV2K which encodes and streams up to HD video
•the FV4K which encodes and streams up to 4Kp30 video
•the FSDI which encodes and streams to an SDI solution
This document contains general information for each of these products as well as specified information on
each of their setups and usages. Please be aware of the precautions especially with the KEL cables, and how
you’ll use them correctly. For more information, please contact your account manager.
NOTE ON FV4K-13A:
The FV4K-13A is similar to the FV2K-13A except for in a few specific ways. The FV4K can encode up to 4Kp30
video while the FV2K is made for encoding 1080p60 video. Also on the FV4K, one of the KEL jacks (J5) is
made for an HDMI camera and a new micro-HDMI jack (J10) was added for its input.
2.0 GENERAL DESCRIPTION
The FVXK-13A-RPS is designed for dual camera inspection, surveillance, industrial and UAV applications. The
flexibility of the system allows for a visible camera and an infrared or night vision camera. The hardware
consists of a 2-board set: Encoder and Connector PCB. The system is capable of encoding multiple channels
of H.265 and H.264 video in HD/4K resolutions. The Input board features flexible digital and analog input
ports. The encoder can be configured to stream over IP and simultaneously record to USB or micro SD card.
The FVXK-13A-RPS is available with either software preloaded or with an optional SDK starter kit.
Figure 1 FVXK-13A-RPS (Front) Dimensions
50 mm
75 mm

9
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
3.0 FEATURES
▪FVXK-13A-RPS Features:
oH.264/H.265 encode and stream up to HD at 60 fps(FV2K) /4K at 30 fps (FV4K)
oEncode modes of operation: H.265, H.264 and MJPEG
oLow bandwidth, low latency video encoding
oSimultaneously output two different resolutions from a single video source
oRemote camera control via HTTP-based interface or pass VISCA camera control commands over IP
oFV2K=13A Inputs: 2x KEL LVDS Camera, Composite, powered line audio
oFV4K=13A Inputs: 1x KEL 4K Camera, 1x KEL LVDS Camera, Micro HDMI, Composite, powered line
audio
oOutputs: Composite, Micro HDMI
oAdditional Interfaces include Gigabit Ethernet, USB 2.0, Micro SD Card and RS-232 Serial
oRS485, alarm input and output interfaces available internally
oSupports streaming in MPEG-2 TS (UDP), RTP, RTSP, RTMP* and TSRTP
oSupports unicast and multicast streaming
oCompatible with CDN’s including Wowza Streaming Engine™ *, YouTube Live* and Facebook Live*
oRecord a compressed .ts/.mp4 file to a USB/SD storage device
oONVIFprofile S & T compliant
oCompatible with the ZEUSDMD-4K and Z3-SME-01 H.264 decoder* (also available from Z3
Technology)
oHTTP-based configuration software for user-friendly configuration, control and update
oRS-232 serial port for technical configuration and control
oSupports Power over Ethernet (PoE) when present
75 mm
50 mm
Figure 2 FVXK-13A-RPS (Back) Dimensions

10
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
oOperating Temp: -5 to 70 °C in open air at 20-80% relative humidity (non-condensing)
oStorage Temp: -20 to 80 °C at 20-80% relative humidity (non-condensing)
oMeasurements 75mmx50mm (3 x 2in)
3.1 Supported Resolutions
The FVXK-13A-RPS supports simultaneous output of up to three streams encoded at different resolutions,
frame rates and bitrates. Supported stream resolutions are:
4K (FV4K-13A only), 1080p (2MP), 1280x1024, 720p (1MP), 480p, 576p, 1024x576, 704x576,
640x480, 640x360, 420x380, 352x576, 352x288, 352x240, 320x240, and 320x180
In addition to scaling the resolution, the camera is also capable of scaling down the frame rate to save
bandwidth. Each channel can select from full frame rate, half frame rate, quarter or sixth frame rate.
For example, it is possible to configure a primary stream of 1920x1080 at 60 fps simultaneously with a
secondary stream at 480p at 10 fps.

11
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
4.0 QUICK START GUIDE
4.2 Before Attaching A Camera Block
Before connecting a camera block, a thorough review of section 7.0 and section 12.0 is required.
4.3 If You Have Received a System from Z3 with the Software Preloaded
To start working with the encoder, you can go straight to Section 13.0 “RUNNING THE ENCODER” on page
21. This section describes how to quickly stream UDP, RTP, RTSP or RTMP as well as record to a Micro-
SD card. Enabling Pro-MPEG Forward Error Correction (FEC), Zixi Feeder™or KLV data are also described.
4.4 If You Already Have a System from Z3 and Need to Update the Firmware
There are several options for updating the firmware on your RPS by following the instructions in Section
15.0: “RUNNING THE CODE YOU BUILT ON THE BOARD”, on page 48.
4.5 If You are Ready to Start Development
Details on how to untar and build the code can be found in Section 10.0: ”, on page 15. A brief
overview of the code itself can be found in Section 11.0: “CODE OVERVIEW,” on page 17.
Details on how to set up your system to access the code you have built can be found in Section 15.0:
“RUNNING THE CODE YOU BUILT ON THE BOARD”, on page 48.
Please Note: Actual version numbers for your Z3 product may differ from those pictured in this document.

12
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Figure 3 FVXK-13A-RPS IOs
5.0 PACKAGE CONTENTS
▪1 x Z3-FVXK-13A-RPS
▪1 x 12V1A Power Supply
▪1 x Serial Cable
▪1 x Null Modem Adapter
6.0 OPERATING CONTROLS
1: UART Connection
1
5: Line level audio (MIC)
2: USB 2.0 6: Composite Output
3: 12V Power (optional)
4: GigE
*See section 6.0 for pin-out details
1
For advanced debugging purposes only. Not needed by typical users.
2
4
3

13
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
7.0 UART AND RS-485 PIN-OUTS
The UART interface, connector J5, connects to /dev/ttyS1 (RS232) and /dev/ttyS4 (RS485/RS422). See
figure below:
Figure 4 UART J5 pin-outs
8.0 THERMAL MANAGEMENT
The Z3-FVXK-13A-RPS system is comprised of a CPU module board, one Application board which contains the
hardware implementation of the input and output circuits and one Connector board which contains the
major I/O jacks such as Ethernet and power jacks.
The system requires that heat is removed from the CPU chip on the module board and from the FPGA chip
on the Application board and dissipated into the environment in order to maintain its operating temperature
specification. It may be necessary to also remove heat from other components on the module or application
boards depending on the environmental requirements of the final application. Keeping the CPU and FPGA
chips within their allowed operating temperatures is critical for the operation of the encoder system.
The system designer is responsible for implementing the cooling mechanisms necessary for any given
application.
RS485 A
RS485 B
RS422 Z
RS422 Y
GND
RS232 RX
RS232 TX

14
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
The Z3-FVXK-13A-RPS board set as provided from Z3 Technology includes a block of aluminum which is
thermally coupled to the CPU chip. This aluminum block is meant to be attached to a heat sink such as a
metal enclosure or other material capable of removing heat from the system.
Note that the aluminum block is a good thermal conductor but is a poor thermal sink. The aluminum block is
not efficient at radiating the heat from the CPU to air, it must be thermally connected to a device that can
dissipate the thermal energy.
9.0 UNTARRING AND BUILDING THE SAMPLE CODE
BEFORE you begin untarring the code, download the tools you need for compiling:
sudo apt-get install -y cmake automake libtool yodl libmnl-dev libmnl0 pkg-
config liblzo2-dev uuid-dev libpcre3-dev libarchive-zip-perl python
sudo dpkg-reconfigure dash
Then select "No" when it asks if "dash" should be the system shell (this will cause /bin/sh to be linked to
"bash" instead)
9.1 Making the Directory and untarring the RPS code
The software provided will allow you to re-create the pre-installed software of the FV2K-13A starting
from the included code.
On a PC running Linux, create a directory where the released materials are going to be located:
# mkdir /home/z3/fv2k-13a
Copy the released tar archive to that directory (note: the name may slightly vary).
# cp SW-A01-01026-03_20220303.tar.bz2 /home/z3/fv2k-13a
Untar the archive (name of tar file may slightly vary):
# tar -xvjf SW-A01-01026-03_20220303.tar.bz2
*Note: Untarring may take up to 10 minutes.
Go into the directory just created and run the build script (directory name may slightly vary):
# cd z3-AMB-2022_04_06-20220406
9.2 Preparing the Linux Environment

15
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
The Linux build environment must Ubuntu 18.04 or Ubuntu 20.04.
9.3 Running the Make Script
Go into the root directory
# cd /home/z3/fv2k-13a/-AMB-2022_04_06-20220406
# ./makeall.sh
*Note: Building can take around 45 minutes.
The outcome of the build process should be newly created image files in the image’s directory. You can
confirm this by doing the following:
# cd scripts/z3-img
# ls -alt
The output will look like the following note that filenames, dates, and times will differ. See section 15.0
for installation methods.
Figure 5 Sample Content of Images Directory after Successful Build
(1)

16
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
10.0 CODE OVERVIEW
Once you have untarred the code, you will see the following top-level directories:
ambarella Ambarella main code directory
external Opensource build of busybox
scripts Build scripts
Under the ambarella directory, you will see these directories:
ambarella/out/cv22_walnut Ambarella build products directory
ambarella/out/cv22_walnut/fakeroot Ambarella root filesystem install directory
ambarella/boards/cv22_walnut Ambarella global configuration/device tree setup
ambarella/amboot Ambarella bootloader
ambarella/kernel/linux Ambarella Linux kernel source code
ambarella/prebuild Ambarella open-source prebuilt components
ambarella/rootfs Ambarella root filesystem build scripts
ambarella/unit_test Ambarella unit test application source code
The Z3 applications are run by the systemd initialization scripts.
The systemctl application can stop, start, or restart the Z3 applications.
systemctl stop <service name>
systemctl start <service name>
systemctl restart <service name>
Note that once a service is started, you must run “systemctl restart <service name>” to start it again --
the start action will do nothing if it has already been started.
Service Name
Description
mcsenc.service
Z3 streaming encode application
z3_onvif.service
Z3 ONVIF server
haproxy.service
Z3 web proxy service
factory-console.service
Z3 functional test service
videodetect.service
Z3 video source mode detection service
webui.service
Z3 web interface service
boxd.service
Z3 LED control and reset to defaults service
finder.service
Z3 Finder service
10.4 ambarella/out/cv22_walnut/images
This directory contains the AmbaUSB factory flasher images

17
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
Filename
Description
bst_bld_kernel_lnx_release.bin
Factory update image via AmbaUSB utility
10.5 scripts/z3-img
This directory contains the Z3 images for WebUI upgrade
Filename
Description
z3-30-0139-upd.img
UPD image to upgrade SW via WebUI
z3-30-0139-mfr.img
MFR image to upgrade SW via WebUI and set
factory defaults (i.e. erase all configuration
and set model to default value)
10.6 ambarella/z3
This directory contains the code for the Z3 applications.
Recipes/ Subdirectory
Description
basefs
Z3 binary files
fixup_rootfs.sh
Script to modify rootfs before packaging

18
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
11.0 RUNNING THE CODE YOU BUILT ON THE BOARD
To take the image files you built in Section 9.0 and run them on the RPS, follow these instructions.
11.7 Via User Interface
(1) Run the Web Interface (See Section 13.6 or 14.1).
(2) Click the “Update device firmware” button from the System Setup tab.
(3) This brings you to the update image screen. In this screen, click on the “Choose File”button.
(4) This brings you to the File Selection Screen. Navigate to the .img file to update with and click
“Open”.
(5) Click on “Upload and Update”.
(6) You will see screens stating that the image is being uploaded and that the flash is being updated.
After about one minute, you should see the main menu again.
(7) Your encoder is now updated.
Figure 6 Updating the Device Firmware from the Web Interface
Figure 7 Updater Screen
Click Here

19
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
12.0 KEL CONNECTIONS
12.1 KEL Cable Warning
If you intend to use your FVXK-13A-RPS’s KEL connections, you will need to connect it to your chosen
Sony camera block. The FVXK-13A-RPS assembly has two 30-pin KEL connectors on J5 and J7 that allow a
flexible ribbon cable to be used to connect the encoder assembly to an identical connector on a 4K or
HD Sony block camera.
WARNING: If a 4K KEL camera is plugged into the LVDS ONLY KEL connector on the FVXK-
13A-RPS it will destroy the FVXK-13A-RPS and the camera. This is also true if a LVDS ONLY
KEL camera is plugged into the 4K KEL connector on the FVXK-13A-RPS. These actions VOID
warranty. It is also important to note that the FV4K-13A-RPS supports 4K camera ONLY on
J5 and HD only on J7.
12.2 KEL Connection
(1) Connect the KEL ribbon cable to the Sony block camera. (Gold teeth face up)
(2) Connect the other end of the KEL ribbon cable to the Interface Front PCB. (Gold teeth face away
from PCB’s)
WARNING: Only use a Z3 approved KEL ribbon cable to connect Z3’s boards to the Sony camera.
Using an incorrect cable (the cables provided by Sony) can permanently damage the boards or
camera.
The KEL cable is sold separately. Ordering part number: CBL-0028-01

20
DOC-USR-0264-02
____________________________________________________________________________________
Z3 Technology, LLC ♦100 N. 8th St. STE 250 ♦Lincoln, NE 68508-1369 USA ♦+1.402.323.0702
13.0 RUNNING THE ENCODER
This section gives step-by-step instructions on HEVC/H.265 encoding with the Z3-FVXK-13A-RPS and
streaming 2160p, 1080p or 1080i video to VLC media player running on your PC. In addition to the Z3-FVXK-
13A-RPS, you will need the following:
▪A 4K or HD video source with non-HDCP HDMI output.
▪A PC with VLC media player.
▪The SDP file(s) provided with your Z3 software release (see your customer support server account).
Please Note: Actual version numbers for your Z3 product may differ from those pictured in this document.
13.1 Set up the Video Source
(1) Select a 4K or HD source with non-HDCP HDMI output (in Z3’s testing, the Brite-View BV-5005HD is
used).
-Power on the 4K or HD Source.
-Connect HDMI to a monitor.
-Set the 4K or HD Source to 2160p, 1080p or 1080i output.
-If your source is a media player, select content you would like to stream.
If you see playback on the monitor, you’ve confirmed the source works.
13.2 Connect the Encoder
(2) Connect the supplied 2.5 mm serial cable and null modem adapter to the serial console of the
application board and to your PC. (A USB to Serial converter may be needed. If so, the FTDI
UC232R-10 (Digikey part #768-1014-ND) is recommended.)
(3) Take the HDMI cable connected to the monitor and now connect it to HDMI In on the board.
Figure 8 FVXK-13A-RPS Assembly
