Zamel VP-817B User manual

VIDEO ENTRY PHONE DISPLAY
VP-817B / VP-817W
Thank you for buying this product from Zamel.
Zamel shall not accept any liability for any results of damage
and/or accidents caused by non-intended use of the product.
Before attempting installation of this product, please read and understand
the entire Operating Manual to comply with the intended use.
Do not open or tamper with the product without prior authorization.
Otherwise your warranty rights for this product will be void.

2
SAFETY
• Always follow this Manual for your safety and to prevent damage to the product.
• Do not connect more than one load to a single power outlet at a time. Risk
of overheating the wiring or re!
• Do not connect or interface this device with incompatible products. Otherwise
there is a risk of an electrical short circuit, resulting in damage to this product.
• Protect the display main board and screen from deformation by any stress.
Do not apply heavy loads. Otherwise there is a risk of re.
• Do not clean the display screen or housing with water or detergents. Risk
of damage to the display housing and/or screen, electrical short circuit, and/or
re! Clean the display with a soft, dry cloth made of cotton or microbre. This will
prevent scratching the display screen. Never use toilet paper or tissues.
• Do not install in a highly humid indoor environment. Risk of electrical short circuit
and re!
• Disconnect the power cord from the mains by holding the plug and not the cable.
Damage to the power cord cable may result in electric short circuit or a re.
• Do not plug the power cord to the mains with wet hands. Electrocution hazard!
• Do not attempt to disassemble, repair or alter this product on your own. Risk
of electrocution, damage to the product and/or re!
• Do not install a current breaker on the mains connection of the device.
Electrocution hazard!
PRODUCT DESCRIPTION
• 4.3” colour LCD touch screen
• 4-core wiring
• Intuitive interface
• Digital audio and video recorder (DVR)
• Internal calls (display-to-display intercom mode)
• Public Address mode
• Gate and wicket opening control
• Supports up to two CCTV feeds
• Supports up to two entrance panels
• Calendar mode
• Alarm clock
• Digital photo frame mode
• Media player
• Internal memory for up to 90 digital photos
• microSD card reader: supports up to 32 GB storage
• Gate entrance panel video feed recording and manual camera snapshot
functionality
• Leave Message (voice recorder) mode
• Automatic gate entrance panel camera snapshot at each Call button press
• Motion detection and automatic video feed sequence recording
• Automatic Away-from-Home Reply mode

3
• On-demand video feed monitoring from entrance panels and all connected
CCTV cameras
• Two-way voice communication
• High display screen resolution: 800 x 480
• Clear voice handset-free device
• 10-step voice volume control
• 10-step brightness, contrast and saturation control
• 10-step ringtone volume control
• 13 polyphonic ringtones
• Additional ringtones available from a microSD card
TECHNICAL DATA
• Operating temperature: -30°C to +60°C
• Supply voltage: 110-240 V AC / 50-60 Hz; 14.5 V DC / 0.8 A
• Power input: 9 W (max); 0.7 W (standby)
• Operating RH: 0% to 95%
• Display dimensions: 170 x 116 x 16 mm
• Weight: 206 g
WIRING PROFILE
• ≤ 50 m (4 x 0.5 mm2)
• ≤ 75 m (4 x 0.75 mm2)
• ≤ 100 m (4 x 1.0 mm2)
PRODUCT COMPONENTS
• 1 x Display unit
• 1 x Operating Manual
• 1 x Base stand
• 2 x Wall plugs
• 2 x M4 x 30 screws
• 2 x 5-pin male connector
• 1 x 4-pin male connector
• 1 x 4-pin male connector

4
WIRING CONNECTION DIAGRAM
AD: Audio
VD: Video
PWR: Power
GND: Ground
DATA: Data communication
CCTV: CCTV feed in
KEY1/KEY2: Control voltage
J4
J4
J4
J4
ROOM 1
ROOM 2
ROOM 3
ROOM 4
ELECTRIC
CATCH 2
ELECTRIC
CATCH 1
DISPLAY 1
DISPLAY 2

5
Note:
(a) Wiring connection diagram for an entrance panel
with electric catch no. 2 + extra external power supply.
(b) Wiring connection diagram for electric catch no. 1 with the display output power
(GND and KEY1 contacts).
(c) External power supply port J4 (optional)
(d) Wiring connection diagram for the NC06 gate control module
(Connector P3 GND and DATA to NC06; COM NO/NC to gate control)
AD: Audio
VD: Video
PWR: Power
GND: Ground
DATA: Data communication
CCTV: CCTV feed in
KEY1/KEY2: Control voltage
J4
J4
J4
J4
BLUE
YELLOW
WHITE
RED
ROOM 1
ROOM 2
ROOM 3
ROOM 4
ELECTRIC
CATCH 1
DISPLAY 1

6
• The second and each additional display may only output the video feeds from
the cameras to which they are connected.
• All displays can output the video feed of a CCTV camera connected
to the entrance panel port.
AD: Audio
VD: Video
PWR: Power
GND: Ground
DATA: Data communication
CCTV: CCTV feed in
KEY1/KEY2: Control voltage
J4
J4
J4
J4
ROOM 1
ROOM 2
ROOM 3
ROOM 4
DISPLAY 1

7
SYSTEM CONFIGURATION
The system can be installed in one of the congurations shown in the diagrams
below:
• 2 gate entrance panels + 4 displays + 2 CCTV cameras for each display
• 1 gate entrance panel + 1 CCTV camera + 4 displays + 2 CCTV cameras
for each display
MAIN DISPLAY DISPLAY 2 DISPLAY 3 DISPLAY 4
CAMERA 1 CAMERA 1 CAMERA 1 CAMERA 1
CAMERA 2 CAMERA 2 CAMERA 2 CAMERA 2
MAIN DISPLAY DISPLAY 2 DISPLAY 3 DISPLAY 4
CAMERA 1 CAMERA 1 CAMERA 1 CAMERA 1
CAMERA 2 CAMERA 2 CAMERA 2 CAMERA 2

8
PRODUCT DESCRIPTION
1. Power On / Off switch
2. Enter Menu / Conrm
3. Speaker
4. Left arrow button: Select / Adjust
5. Back / Hang Up
6. LED indicator
7. LCD
8. Microphone
9. Video feed display
10. Unlock electric catch / gate
11. Answer / Call
12. Right arrow button: Select / Adjust
13. microSD card slot (32 GB max.)
INSTALLING THE SYSTEM
1. Use the wiring connection diagram for the chosen system conguration
and verify that all wiring connections are correct.
2. Choose a suitable location in which to install the display unit. An installation
height between 1.5 and 1.6 m above the ground is recommended.
3. Verify that the power supply voltage is OFF before wiring the device.
4. Mount the back frame on the wall at the installation location.
5. Connect the wiring to the terminals, see the wiring connection diagram
for the chosen system conguration.
6. Install the display unit on the back frame.
Switch on the supply voltage of the device when completely installed.
12
3
4
5
6
7
8
9
10
11
12
13

150 cm

9
WIRING SPECIFICATIONS
The system supports two electric catch release congurations: with the open
command sent by (i) an entrance panel or (ii) a system display (the display open
command output wire must have the shield connected to earth). If the open
command is sent by an entrance panel, use this wiring specication:
• If the entrance panel is < 30 m away from the video entry phone display,
use YTDYw 4 x 0.5 mm2wiring.
RED
BLUE
YELLOW
WHITE
1
2
3
4
1
2
3
4
ENTRANCE PANEL
• If the entrance panel is > 30 m away from the video entry phone display,
use YTDYw 4 x 0.5 mm2wiring.
RED
BLUE
YELLOW
WHITE
1
2
3
4
1
2
3
4
RED
BLUE
YELLOW
WHITE
ENTRANCE PANEL
If the open command is sent by a display, use this wiring specication:
• If the entrance panel is < 30 m away from the video entry phone display,
use YTDYw 6 x 0.5 mm2wiring.
RED
BLUE
YELLOW
WHITE
RED
BLUE
YELLOW
WHITE
BROWN
ENTRANCE PANEL
ELECTRIC CATCH
BLACK
GREEN
• If the entrance panel is < 30 m away from the video entry phone display,
use YTDYw 6 x 0.8 mm2wiring.
RED
BLUE
YELLOW
WHITE
BROWN BLACK
GREEN
RED
BLUE
YELLOW
WHITE
ENTRANCE PANEL
ELECTRIC CATCH
DISPLAY
DISPLAY
DISPLAY
DISPLAY
RED
BLUE
YELLOW
WHITE
GREEN
BROWN
ELECTRIC
CATCH
GREEN
BROWN
ELECTRIC
CATCH
GREEN
GREEN

10
MENU OVERVIEW
When the display is in the sleep mode, press to open the menu
shown below:
PRZEGLĄD MENU
W trybie czuwania nacisnąć przycisk w celu aktywowania menu poniżej:
2
3
1
4
Nawiąż połączenie z innymi
monitorami / porozmawiaj z gościem
Nagraj wiadomość audio
Funkcja nasłuchiwania
Podgląd panelu zewnętrznego
lub kamery CCTV
Funkcja rozgłoszeniowa
Ustawienia
Podgląd i odtwarzanie plików
muzycznych
Podgląd oraz odtwarzanie plików
DVR
5
6
8
7
10
11
9Podgląd czasu oraz kalendarza
Podgląd oraz odtwarzanie
plików audio
Podgląd zapisanych zdjęć
wykonanych przez stację bramową
Podgląd oraz odtwarzanie
zdjęć dodatkowych
12
Uwaga.
Funkcje 2,7,8,10,11, 12,13 wymagają zainstalowania karty microSD (max. 32GB).
Długie przytrzymanie przycisku wybiera obcję
kasowania pliku, Długie przytrzymanie przycisku
aktywuje ustawienia dźwięku. Ponowne długie
przytrzymanie zamyka ustawienia.
Długie przytrzymanie przycisku wybiera obcję
kasowania pliku,
Długie przytrzymanie przycisku wybiera obcję
kasowania pliku, Długie przytrzymanie przycisku
aktywuje ustawienia dźwięku. Ponowne długie
przytrzymanie zamyka ustawienia.
16:06 JANUARY
27,2017
CALL RECORD MONITOR W AT C H BROADCAST SET
DVR MUSIC CLOCK MESSAGE CAMERA PHOTO
Lp. Ikona Funkcja Uwagi
9
Item Icon Function Note
1Call other displays / answer
the entrance panel call
2Record an away-from-home reply
message
3Listening mode
4Entrance panel / CCTV video
feed display
5Public Address mode
6Settings
7Browse and play back DVR les Touch and hold to delete a le. Touch
and hold to open the sound settings.
Touch and hold the same again to close
the settings.
8Browse and play back media les
9Time and calendar display
10 Browse and play back audio
les
Touch and hold to delete a le.
Touch and hold to open the sound
settings. Touch and hold the same again
to close the settings.
11 Display snapshots captured
by the gate entrance panel
Touch and hold to delete a le.
12 Browse and play back extra
photos
Note:
Function items 2, 7, 8, 10, 11, 12 and 13 require a microSD (max. 32 GB) card installed
in the display.

11
ANSWERING AN ENTRANCE PANEL CALL
When a visitor presses the Call button on the entrance panel, all connected indoor
displays will sound the call chime at the same time as displaying the INCOMING
CALL message on each display screen.
Touch the icon to answer the call. Touch again to send the calling entrance
panel camera feed to all other displays. If you touch before the call is switched
by a user of another display in the system, you will return to the calling visitor.
If the call is not answered by the time the call chime stops, the display will enter
the standby mode. Touch the icon to release the electric catch of the calling
entrance panel during the call. The display will show DOOR OPEN. Touch and hold
the icon for approx. 2 seconds to open the gate. The display will show GATE
OPEN.
If another user calls you during your call, the display will show
VISITOR AT DOOR 2. Touch the icon to answer and switch to the second call.
Note: Touch and hold the icon during an entrance call or an internal call
(display-to-display intercom mode) to mute your microphone. The display will show
MUTE. Touch and hold again to unmute your microphone, which the display will
conrm with SPEAK. Operating a gate requires the NC06 gate control module
in the system.
VIDEO FEED MONITORING
With the display on standby, touch to monitor the video feed from entrance
panel no. 1. Touch again to switch to the next video feed.
The CCTV camera video feeds can only be monitored this way if the Port 4 status
is Enabled (see Table SYSTEM SETTINGS, item 5). Touch to start a voice call
with the visitor at the entrance panel from which you are monitoring the video feed.
Touch to unlock the door of the same entrance panel.
When monitoring the video feed from Door1/Door2/CCTV1/CCTV2, touch and hold
to change the screen aspect from 16:9 to 4:3.
PUBLIC ADDRESS MODE
The Public Address mode allows you to speak through all displays connected
to the video entry phone system. Touch and hold with the display on standby
or in the Main Menu. The PUBLIC ADDRESS CALL message will be displayed.
All other displays in the system will display PUBLIC ADDRESS. You can now speak
and be received by other displays in the system.

12
INTERNAL CALLS (DISPLAY-TO-DISPLAY INTERCOM MODE)
The intercom mode allows two-way voice calls between two specic displays
in the video entry phone system. Touch on the display on standby to call
another display in the system. If you have more than 2 displays in the video entry
phone system, choose the display you wish to call with or . Next, touch
to conrm and make the call. The user at the display being called can touch
to answer the call or to reject the call.
MULTIMEDIA
allows uploading custom music les and voice messages.
CALENDAR
displays the time and the calendar.
MESSAGES
displays the last events logged by the system.
PHOTOS
opens the digital photo frame mode, which displays the photos you have
uploaded.
DISPLAY SOUND VOLUME / BRIGHTNESS / COLOUR
/ CONTRAST / IMAGE TYPE CONTROL
Touch or in the monitoring, incoming call, voice call, intercom, or public
address mode to open the sound volume menu. Next, touch to open
the Volume / Brightness / Colour / Contrast / Image Type menu. Operate
the controls with or .
DO NOT DISTURB MODE
You can enable or disable the DO NOT DISTURB mode in the display System
Settings menu. With the display on standby, touch and hold to enable
or disable the Do Not Disturb mode.

13
DISPLAY MICROPHONE MONITORING
With the display on standby, touch and hold to start listening through
the microphone of another display in the voice entry phone system. If you have
more than 2 displays in the video entry phone system, choose the display you wish
to listen to by touching or and conrm by touching the icon.
Note:
a) The user of the display that is listening will hear everything that the microphone
of the display being listened to captures. The display being listened to will not output
the sounds captured by the microphone of the display which is listening.
b) If you have more than 2 displays in the video entry phone system, verify that
the remote listening mode is enabled in the display to which you want to listen.
Go to System Settings and verify that Can Be Monitored is set to Enable.
MANUAL AUDIO RECORDING
Touch on the main screen; next, touch to record an audio sequence. Touch
again to stop recording. The recorded les are listed in the Messages menu .
SNAPSHOT CAPTURE
Manual capturing: Touch when displaying a video feed from an entrance panel
or monitoring a video feed. A snapshot of the video frame will be captured.
The display will show the message IMAGE CAPTURED.
Automatic capture: To have the display automatically capture snapshots, set
the AUTO CAPTURE QUANTITY in the System Settings to 1, 2 or 3. The display
system will then capture and save the set number of video snapshots
to the microSD card when a call is made with an entrance panel.
SYSTEM SETTINGS
With the display on standby, touch and open the System Settings menu.
Next, touch .
12
MANUALNE NAGRYWANIE DŹWIĘKU AUDIO
Z poziomu ekranu głównego wybrać przycisk , następnie nacisnąć w
celu nagrania sekwencji audio. Ponowne naciśnięcie przycisku zakończy
nagrywanie. Nagrane pliki znajdują się w Wiadomościach
PRZECHWYTYWANIE ZDJĘĆ
Przechwytywanie ręczne: W trybie aktywnego podglądu lub monitorowania
nacisnąć przycisk . Zdjęcie zostanie przechwycone a wyświetlaczu
zostanie wyświetlony komunikat OBRAZ PRZECHWYCONY.
Przechwytywanie automatyczne: W celu automatycznego przechwytywania
zdjęć należy ustawić w ustawieniach systemu ILOŚĆ AUTOMATYCZNIE
PRZECHWYTYWANYCH ZDJĘĆ jako 1, 2 lub 3. Wówczas system przechwyci
i zapisze na karcie pamięci wszystkie zdjęcia podczas wywołania z panelu
zewnętrznego.
USTAWIENIA SYSTEMOWE
W trybie gotowości, wybrać przycisk , aby przejść do menu ustawień
systemowych. Następnie wybrać :
ODSŁUCHIWANIE INNEGO MONITORA
W trybie gotowości, należy przytrzymać ikonę aby przejść do funkcji
odsłuchiwania innego monitora. Jeśli posiadamy więcej niż 2 wewnętrzne
monitory, należy wybrać monitor docelowy na ekranie za pomocą lub ,
a następnie wybór ten potwierdzić klikając w ikonę .
Uwaga:
a: Użytkownik przebywający w pomieszczeniu, z którego odbywa się nasłuch,
usłyszy dźwięki w pomieszczeniu monitorowanym. Użytkownicy z
pomieszczenia monitorowanego nie usłyszą dźwięków z pomieszczenia
monitorującego.
b: Jeżeli istnieją więcej niż dwa monitory w obrębie jednego systemu wówczas
należy sprawdzić czy funkcja odsłuchiwania innego monitora jest włączona
w ustawieniach systemu monitora docelowego. Prosimy o sprawdzenie w
ustawieniach systemu czy funkcję odsłuchiwania innego monitora jest
aktywna.

14
LEAVE MESSAGE MODE
The mode allows each visitor to leave a voice message with the entrance panel when
no one answers the call. Activate the mode by setting AUTO LEAVING MESSAGE
to Enable in the System Settings. When the Leave Message mode is active,
the caller at an entrance panel will hear a recorded Away-from-Home Reply if they press
the Call button and the call chime ends unanswered. The Away-from-Home
Reply playback will end with a tone, after which the visitor may leave a voice message.
The voice message recording time is limited to 20 seconds. The entrance panel will
revert to the standby mode after this time has counted down. The default Away-from-
Home Reply can be replaced with a custom one you can record on the microSD card.
Item System functions Options Note
1 LANGUAGE
Selects
the display
interface
language.
Choose the language: PL, EN, DE, FR, RU
2DO NOT DISTURB
ENABLE The LED will ash if this mode is enabled.
DISABLE
The mode is disabled by default during a call from
an entrance panel, display-to-display intercom
(internal) calls and the public address mode.
3CAN BE MONITORED ENABLE
This display can be monitored (listened to)
by other displays in the video entry phone
system if this option is set to ENABLE.
DISABLE The mode is disabled by default.
4OPENING
ENABLE
Touch to unlock the electric catch linked
to the entrance panel. Touch to open
the gate linked to the entrance panel.
DISABLE When this function is disabled, touching
followed by / will open the door
or the gate linked to the entrance panel.
5PORT STATE None / CCTV1 / CCTV1&2
6DEVICE ADDRESS Room
1 / 2 / 3 / 4
Choose ROOM 1 on the display that should be the
main (master) display of the system. The setting
will be yellow if the same device address is set in
two displays in the video entry phone system.
7RESTORE DEFAULT Restores the default factory settings
of this display.
8 FORMAT FLASH Formats the embedded ash memory
of this display.
9 FORMAT SD CARD Formats the microSD card installed in the display.
10 COPY FILE TO SD
CARD
Copies all les from the embedded ash memory
to the microSD card in the display.
11 AUTO CAPTURE
QUANTITY 01, 02, 03 Automatically captures 1, 2 or 3 video feed snapshots during a call from an entrance panel.

15
12 AUTO LEAVING
MESSAGE
ENABLE
The visitor calling with an entrance panel
can leave a voice message after
an Away-from-Home Reply and tone.
DISABLE Disables this mode.
13 SCREENSAVER TIME 30 s, 1-3 min, 5, 10, 20, 30, 40, 50, 60 min
14 FIRMWARE VERSION Displays the version of the rmware installed
on the display.
DVR (DIGITAL VIDEO RECORDER)
Touch to open the Main Menu. Touch the DVR icon.
Touch to open the DVR Settings.
Lp. Funkcje systemu Opcje Uwagi
11
12
13
14
ILOŚĆ AUTOMATYCZNE
PRZECHWYTYWANYCH
ZDJĘĆ
Automatycznie przechwytuje 1, 2 lub 3
zdjęcia podczas wywołania.
01, 02, 03
AUTOMATYCZNE
POZOSTAWIENIE
WIADOMOŚCI
CZAS WYGASZACZA EKRANU 30s, 1-3 min, 5, 10 , 20, 30, 40, 50, 60 min
WERSJA OPROGRAMOWANIA
WYŁĄCZONE
WŁĄCZONE Można pozostawić wiadomość po
usłyszeniu tonu.
Funkcja wyłączona.
Pokazuje wersję wgranego
oprogramowania.
14
FUNKCJA DVR
Nacisnąć przycisk w celu wejścia do głównego menu. Wybrać ikonę DVR.
Nacisnąć przycisk w celu przejścia do ustawień DVR.
Automatyczna funkcja DVR:
Aktywować DVR w Ustawieniach Systemu. Dzięki tej funkcji istnieje możliwość
nagrywania sekwencji wideo z dowolnego panelu zewnętrznego oraz kamery
CCTV.
Gdy detekcja ruchu jest aktywna system automatycznie nagra obraz przez
maksymalnie 7 minut w trybie cyklicznym. Sekwencja nagrywania cyklicznego
wynosi 1 minuta – 1 minuta – 5 minut. Po wykryciu ruchu kamera rejestruje
obraz przez 1 minutę po czym sprawdza czy ruch nadal istnieje. Jeżeli nie,
nagrywanie jest zakończone. Jeżeli ruch nadal trwa wówczas kamera nagrywa
kolejną minutę. Po tym czasie kamera ponownie sprawdza czy ruch jest
wykrywany. Jeżeli nie, nagrywanie jest zakończone. Jeżeli ruch nadal trwa
wówczas kamera nagrywa kolejne 5 minut po czym nagrywanie jest
zakończone.
Funkcja DVR nie będzie działała jeżeli karta microSD ma pojemność m
niejszą jak 2GB.
Automatic DVR operation:
Set DVR to Enable in the System Settings. DVR can record video sequences from
each entrance panel and CCTV camera connected to the video entry phone system.
If motion detection is enabled, the system will automatically record a video
sequence up to 7 minutes long in a cycle mode. The cycles of video sequence
recording are 1 minute + 1 minute + 5 minutes. If a camera detects movement
in its eld of view, its video feed will be recorded for 1 minute. Next, the video feed
is again scanned for motion. If there is no motion detected, the video feed recording
stops. If there is motion detected, the video feed is recorded for another 1 minute.
Next, the video feed is again scanned for motion. If there is no motion detected,
the video feed recording stops. If there is motion detected, the video feed is
recorded for another 5 minutes, and then the recording stops.
DVR will not work if the microSD card in the display has less than 2 GB capacity.
The minimum recommended capacity of the microSD card is 8 GB for the DVR
to work smoothly.
Set the Resolution to 640x480 for a high video quality.
If the Begin and End Times have the same setting values, DVR will record without
interruption.

16
VIDEO SNAPSHOT CAPTURE SETTINGS
Storage type Resolution Number of snapshots
Embedded ash memory 640 x 480 / 320 x 240,
as set in Resolution 100 snapshots max.
microSD card 640 x 480 / 320 x 240,
as set in Resolution
Depends
on the microSD card
capacity
DVR RECORDING SETTINGS
microSD card capacity Resolution Frame rate
2 GB-32 GB 640 x 480 / 320 x 240,
as set in Resolution
2 / 4 / 6 / 8 / 10,
as set in Frame Rate
MANUAL VIDEO FEED RECORDING
When an entrance panel call is incoming, touch and hold to start recording
the video feed from the entrance panel. Touch again to stop recording.
DVR SETTINGS
Item Settings Options Note
1 DVR Enable DVR is enabled.
Disable DVR is disabled.
2 FRAME RATE 2 / 4 / 6 / 8 / 10
frame/s
3RESOLUTION 640 x 480 / 320 x 240
4
MOTION
DETECT
SENSITIVITY
High / Normal / Low
Detects motion
in the camera FOV
according to a pre-set
sensitivity.
Disable No motion is detected.
5 BEGIN TIME The time the DVR starts recording and detecting
motion.
6 END TIME The time the DVR stops recording and detecting
motion.
7RECORD
LOCATION
DOOR 1 / DOOR 2
/ CCTV1 / CCTV2
The video feed and motion
detection signal source
for the DVR.

17
ALARM CLOCK
Touch in the Main Menu. Touch , and touch to open the Alarm Clock
settings.
ALARM ZEGAROWY
Nacisnąć przycisk w menu głównym, wybrać następnie przyciskając
wejść do ustawieni Alarmu Zegarowego.
16
Lp. Ustawienia Opcje Uwagi
1
2
3
4
USTAWIENIA
CZASU
USTAWIENIA DATY Dzień/Miesiąc/Rok
TYP
DZWONKA ALARMU 01 - 13
DŹWIĘK ALARMU
1/2/3/4
WYŁĄCZONY
ALARMUJE KAŻDEGO DNIA
PRZEZ 1 MINUTĘ O USTAWIONEJ
GODZINIE
ZAWSZE AKTYWNY
ALARMUJE W USTAWIONE DNI
PRZEZ 1 MINUTĘ O USTAWIONEJ
GODZINIE
Godzina/Minuta/
Sekunda
AKTYWNY W
OKREŚLONE DNI
USTAWIENIA DZWONKA
Nacisnąć przycisk w menu głównym, wybrać następnie przyciskając
wejść do ustawień Dzwonków.
Item Settings Options Note
1Hour / Minutes /
Seconds
2SYSTEM DATE
SETTING Day / Month / Year
3ALARM RING TYPE 01 – 13
4
ALARM CLOCK
1 / 2 / 3 / 4
DISABLE
ALWAYS ACTIVE
Rings the alarm every
day for 1 minute
at the pre-set time.
ACTIVE
ON SPECIFIC
DAYS
Rings the alarm for
1 minute at the pre-set
time on the specic days
set.

18
CHIME SETTINGS
Touch in the Main Menu. Touch , and touch to open the Chime settings.
ALARM ZEGAROWY
Nacisnąć przycisk w menu głównym, wybrać następnie przyciskając
wejść do ustawieni Alarmu Zegarowego.
16
Lp. Ustawienia Opcje Uwagi
1
2
3
4
USTAWIENIA
CZASU
USTAWIENIA DATY Dzień/Miesiąc/Rok
TYP
DZWONKA ALARMU 01 - 13
DŹWIĘK ALARMU
1/2/3/4
WYŁĄCZONY
ALARMUJE KAŻDEGO DNIA
PRZEZ 1 MINUTĘ O USTAWIONEJ
GODZINIE
ZAWSZE AKTYWNY
ALARMUJE W USTAWIONE DNI
PRZEZ 1 MINUTĘ O USTAWIONEJ
GODZINIE
Godzina/Minuta/
Sekunda
AKTYWNY W
OKREŚLONE DNI
USTAWIENIA DZWONKA
Nacisnąć przycisk w menu głównym, wybrać następnie przyciskając
wejść do ustawień Dzwonków.
Item Settings Options Note
1CHIME TIME
0, 15, 20, 25, 30,
35, 40, 45, 50,
55, 60 s
The chime will stop after
the time set here.
2CHIME VOLUME 00 – 09 00 - Chime muted
09 - Highest chime volume
3RING TYPE DOOR 1 / DOOR
2 / INTERCOM 01 – 13
4RING REPEAT ENABLE The ringtone will sound
repeatedly for a pre-set time.
DISABLE The ringtone will sound once.
5 NIGHT MODE 00 – 05 The ringtone will be automatically
muted between 22:00 and 07:00.
DISABLE

19
ADVANCED SETTINGS
The Advanced Settings can be accessed by pressing and holding
while powering on the display. The Advances Settings include:
• Door unlock time
1-10; 20, 30, 40, 50, 60, 70, 80, 90, 99 s
• Gate status
Normally open electric catch contact (NO)
Normally closed electric catch contact (NC)
• Gate unlock time
0.2, 0.5, 1-5 s
• System type
Single-family
Multi-family
The System Type setting applies to the P1 connector of the display linked to Door 1.
WARRANTY
24-month commercial warranty by the manufacturer
Reseller’s stamp and signature
with date of sale
1. ZAMEL Sp. z o.o. Gives a 24-month warranty for
the goods it sells.
2. The warranty given by ZAMEL Sp. z o.o. does not cover:
a) mechanical damage caused by transport,
loading/unloading or other circumstances;
b) damage caused by improper installation or operation
of the goods manufactured by ZAMEL Sp. z o.o.;
c) damage caused by any modications made by the BUYER
or any third party to the sold goods or to the equipment
required for the proper functioning of the sold goods;
d) damage caused by any force majeure
event or another fortuitous event beyond
any reasonable control of ZAMEL Sp. z o.o.;
e) the power supply (batteries) included (if any) with the
device as sold.
3. The BUYER shall make all warranty claims in writing at the point of sale or to ZAMEL Sp. z o.o.
4. ZAMEL Sp. z o.o. will examine each warranty claim as regulated by the applicable provisions of the Polish law.
5. The form of warranty claim resolution, i.e. replacement, repair or refund of the price of purchase, shall
be decided by ZAMEL Sp. z o.o.
6. This warranty does not exclude, limit or suspend any rights of the BUYER arising from the statutory
or regulatory laws concerning implied warranty for defects of sold goods.

20
