Zennio IDAC User manual

IDAC
Access Controller for Installation in Door
ZVIIDAC
USER MANUAL
dsñkmfroi
Application Program Version: 2.0
User manual edition: [2.0]_a
www.zennio.com

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
2
CONTENTS
Contents........................................................................................................................................ 2
Document Updates ....................................................................................................................... 3
1 Introduction............................................................................................................................ 4
1.1 IDAC.................................................................................................................................. 4
1.2 Installation........................................................................................................................ 5
1.3 Start-Up and bus KNX power failure or open door.......................................................... 6
2 Configuration.......................................................................................................................... 7
2.1 General............................................................................................................................. 7
2.2 Indoor Module ................................................................................................................. 9
2.2.1 Configuration............................................................................................................. 9
2.2.2 Backlight .................................................................................................................. 11
2.2.3 Room State Buttons................................................................................................. 11
2.2.4 Touch Locking .......................................................................................................... 12
2.2.5 Sounds ..................................................................................................................... 13
2.2.6 Ambient Luminosity Sensor..................................................................................... 15
2.3 Outdoor Module ............................................................................................................ 16
2.3.1 Configuration........................................................................................................... 16
2.3.2 Access Control ......................................................................................................... 18
2.3.3 Backlight .................................................................................................................. 18
2.3.4 Doorbell button ....................................................................................................... 21
2.3.5 Touch Locking .......................................................................................................... 22
2.3.6 Sounds ..................................................................................................................... 22
2.3.7 Ambient Luminosity Sensor..................................................................................... 24
ANNEX I. Communication Objects............................................................................................... 25

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
3
DOCUMENT UPDATES
Version
Changes
Page(s)
[2.0]_a
Changes in the application program:
•Updating of the access control module:
oBLE (Buetooth Low Energy) module.
oNew object to inform the language and region after
the correct reading of a NFC card or BLE key data:
"[Access] Locale".
oNew binary object to inform if accesses granted
during a KNX bus failure: "[Access] Offline
access".
oPossibility to choose the action when one of the
groups with granted access tries to access an
occupied room.
oNew parameter to select the timeout for the
second access attempt.
oPossibility to restrict the use of the Make Up Room
state.
•Optimisation of modules: brightness and proximity
and luminosity sensor.
-

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
4
1INTRODUCTION
1.1 IDAC
IDAC from Zennio is a KNX interface presented as an access control system to rooms
or other parts of the installation through reading ID cards.
The most notable features of this device are:
Product consisting of:
➢Two Access modules installed in door.
➢Lock that will make possible the opening and closing of the door and the
power supply of the modules.
➢Metal element installed in the door frame that will receive direct power
from KNX bus.
Battery charging system and power supply to KNX bus by means of
retractable metal contacts.
Outdoor module with rooms access control functionality using:
➢Cards with NFC (Near Field Communication) technology of MIFARE
DESFire and MIFARE Classic types.
➢BLE (Buetooth Low Energy) keys provided through the Zennio ZenKey
application. Please refer to the “ZenKey” user manual, available under
the IDAC product section at www.zennio.com, for detailed information.
Buzzer for an audible acknowledgement of user actions (with the possibility
of disabling it by object).
Communication with Z-Access for the management and monitoring of
accesses.
Buttons and LED indicators on both modules.
Possibility of locking / unlocking the buttons of both modules.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
5
Possibility of setting a press detection delay.
Heartbeat.
1.2 INSTALLATION
IDAC connects to the KNX bus through the on-board KNX connector. This device
requires an external 24V DC power supply.
Figure 1. IDAC.
A short press on the Prog. /Test button (8) will make the device enter the
programming mode. The Prog. /Test LED (9) will then light in red. On the contrary, if
this button is held while the device gets connected to the bus, the device will enter the
safe mode. In such case, the programming LED will blink in red colour.
For detailed information about the technical features of the device and about the
installation process, please refer to the corresponding Datasheet bundled with the
original package of the device and the installation manual available at
www.zennio.com.
1. Access LED indicator.
2. Luminosity and proximity sensor.
3. Touch area.
4. NFC card reader.
5. Tamper switch.
6. 15-pin connector.
7. 12-pin connector.
8. Programming/Test button.
9. Programming/Test LED.
10. Interconnection cable (15-pin).
11. Screws and metal plate for flush
mounting on door.
12. Security screw.
13. Touch areas.
14. Luminosity and proximity sensor.
3
2
7
5
4
6
1
8
9
10
12
11
13
14
External view
Internal view

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
6
1.3 START-UP AND BUS KNX POWER FAILURE OR OPEN DOOR
After the device start-up (due to a device reset or programming), it requests date and
time through the object “[Access] Request Date and Time”. The group address of
this object is the one that must be indicated in Z-Access to respond to the request.
For proper operation of the buttons of both modules, it is recommended not to be
pressing them during the initialization, either after programming or after connecting the
external power supply.
On the other hand, in the event of a KNX bus power failure or door opening the
device will continue operating normally since it has power supply through a
rechargeable battery, although, of course, there will be no communication with the KNX
bus. Nevertheless, note that, to reduce the battery consumption:
All LED are turn off after 5 minutes of the KNX bus power failure or door
opening. They are only turn on after a presence detection, press or card
reading.
The BLE module and NFC reader on the external module are turned off when
the door opens. In the event of KNX bus power failure with the door closed
they will remain active, enabling access to the room.
Important: If the battery is drained out, it is essential that, when the device is restarted
during the charging process, the time is correctly received as a response to the object
request "[Access] Request Date and Time". A clock offset caused by the absence of
a battery can be critical for user access, as it depends on the date/time specified on
their cards.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
7
2CONFIGURATION
After importing the corresponding database in ETS and adding the device into the
topology of the desired project, the configuration process begins by entering
Parameters tab of the device.
2.1 GENERAL
The "General" tab contains general settings, those that are independent of the internal
and external modules.
ETS PARAMETERIZATION
Figure 2. General Configuration.
Heartbeat (Periodical Alive Notification) [disabled/enabled]
1
: incorporates a
one-bit object to the project (“[Heartbeat] Object to Send ‘1’”) that will be
sent periodically with a value of “1” to notify that the device is still working (still
alive).
Note: The first sending after download or bus failure takes place with a delay
of up to 255 seconds, to prevent bus overload. The following sendings match
the period set.
Update Objects: enables the sending of read requests to update status
objects. There are four options available, some of them with a configurable
delay:
➢[Disabled]: no read request, therefore objects are not updated.
1
The default values of each parameter will be highlighted in blue in this document, as follows:
[default/rest of options].

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
8
➢[After Programming/Reset]: read requests are sent after the parameterised
delay [1…10…65535] [s/min/h] when a restart (after battery depletion or
change), a download or a reset device from ETS occurs.
➢[After Reconnect]: read request are sent when the connection to the bus is
recovered, after the parameterised delay [1…10…65535] [s/min/h].
➢[After Programming/Reset and Reconnect]: combination of the two above
options.
Sound Type [Sound 1 / Sound 2]: determines the range of sounds the device
will incorporate for button, doorbell, and alarm acoustic signals.
The project topology shows by default, in addition to the objects of the access control
module, the following:
“[General] Scene: Receive”and “[General] Scene: Send”: objects for
respectively receiving and sending scene values from/to the KNX bus
whenever it is necessary.
“[General] Bolt – Alarm”: object which will report a mechanical trouble in
the bolt for revision.
“[General] Servomotor – Alarm”: object which will report a problem in the
servomotor that makes it possible to open the door. When this happens, it
must be checked.
“[General] Tampering – Alarm”: object which will notify that the enveloping
has been removed.
“[General] Tampering – Date and Time”: 8-byte object that is sent when
the enveloping is removed, informing the date and time of the action.
Please refer to the “Access Control” user manual, available under the IDAC
product section at www.zennio.com, for detailed information about the rest of the
available objects.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
9
2.2 INDOOR MODULE
This module is installed inside the room, embedded in the door.
It consists of a pair of pushbuttons or an individual pushbutton (depending on the
model) to control the state of the room.
In addition, it has a proximity sensor and an ambient luminosity sensor that will
allow the device to react to different situations of presence or illumination.
2.2.1 CONFIGURATION
In the "Configuration" tab of the Indoor Module, the general configurable parameters of
the module are displayed. Most of them are checkboxes to activate other
functionalities.
ETS PARAMETERIZATION
Figure 3. Indoor Module Configuration
Room State Buttons [disabled/enabled]: enables or disables the “Room
State Buttons” tab in the tree on the left. See section 2.2.3 for details.
Touch Locking [disabled/enabled]: enables or disables the “Touch Locking”
tab in the tree on the left. See section 2.2.4 for details.
Customize Sounds [disabled/enabled]: enables or disables the “Sounds” tab
in the tree on the left. See section 2.2.5 for details.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
10
Proximity Sensor [disabled/enabled]: enables the proximity sensor. This
functionality permits “waking up” the device when detecting presence through
the proximity sensor
Please refer to the user manual “Proximity and Luminosity Sensor”
(available in the IDAC product section at the Zennio homepage,
www.zennio.com) for detailed information about the functionality and the
configuration of the related parameters.
Ambient Luminosity Sensor [disabled/enabled]: enables or disables the
“Ambient Luminosity Sensor” tab in the tree on the left. See section 2.2.6 for
details.
Inactivity:
➢Initial State (After Download) [Inactivity / Activity]: determines whether
the internal module should be started in activity state after a download.
➢Time to Consider Inactivity [1…65535] [s/min/h]: time that must elapse
since the last press and/or proximity detection to consider inactivity state
and to set the configured brightness level. See section 2.2.2.
The project topology always shows the following objects:
“[In] Activity”: 1-bit object to force activity/inactivity state on the device. For
further information, please refer to the user manual “Proximity and
Luminosity Sensor” and “Brightness” (available in the IDAC product
section at the Zennio homepage, www.zennio.com).
"[In] Sounds - Disabling Button Sound": 1-bit object to mute the button
sounds.
“[In] Proximity Sensor”,“[In] External Proximity Detection” and “[In]
Proximity Detection”: 1-bit object whose functionality is tied to the proximity
sensor. For further information, please refer to the user manual “Proximity
and Luminosity Sensor” (available in the IDAC product section at the
Zennio homepage, www.zennio.com).

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
11
2.2.2 BACKLIGHT
The Indoor Module allows the brightness of its LED to be managed according to two
operating modes: normal and night mode.
Please refer to the specific manual “Brightness” (available in the IDAC product section
at the Zennio website, www.zennio.com) for detailed information about the functionality
and the configuration of the related parameters.
2.2.3 ROOM STATE BUTTONS
The buttons of the Indoor Module are intended to control the state of the room (normal,
do not disturb and make-up request).
Two types of control are available:
Do Not Disturb: a single button that switches between Normal and Do Not
Disturb.
➢If the current state of the room is Normal or Make-Up Request and the
button is pressed, it is activated Do Not Disturb.
➢If the current state of the room is Do Not Disturb and the button is pressed,
it is activated Normal.
Double: two buttons of which the right switches between Do Not Disturb and
Normal and the left between Make-Up Request and Normal.
Note: Please, note that the type of control must be selected according to the product
design.
ETS PARAMETERIZATION
When the function Room State Buttons in “Configuration” tab, in Indoor Module, a
new tab will be available in the left tree. In addition, three objects will appear and will
allow to monitor and control the state of the room: “[Access] Room State Indicator”
and “[Access] Room State”, “[Access] Room State: Make Up Room (Status)” and
“[Access] Room State: Do Not Disturb (Status)”.
Please refer to the “Access Control” user manual, available under the IDAC product
section at www.zennio.com, for detailed information.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
12
Figure 4. Room State Buttons
Control Type [Do Not Disturb / Double]: depending on the type of control
selected, one or two buttons will be enabled, located in the central area or on
both sides, respectively.
Press Detection Delay [1…2…255] [x 1 ds]: during this time, no press will be
considered.
LED Color: color of the LED associated to the button when the
corresponding state is selected.
2.2.4 TOUCH LOCKING
Buttons can optionally be locked or unlocked at any time by receiving a binary value
(configurable) addressed to the object provided for this purpose. It can also be done
through scene values.
ETS PARAMETERIZATION
After enabling Touch Locking from “Configuration” screen (see section 2.2.1), a new
tab will be incorporated into the tree on the left.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
13
Figure 5. Touch Locking
1-Bit Object [disabled/enabled]: enables the 1-bit object “[In] Touch
Locking” to trigger the touch lock.
➢Value [0 = Unlock, 1 = Lock / 0 = Lock, 1 = Unlock]: parameter to select
which value should trigger which action when received through the
indicated object.
Scene Object [disabled/enabled]: enables the touch locking and unlocking
when receiving the configured scene value through the object (“[General]
Scene: receive”).
➢Lock: Scene Number (0 = Disabled) [0/1…64]: scene number that locks
the buttons.
➢Unlock: Scene Number (0 = Disabled) [0/1…64]: scene number that
unlocks the buttons.
2.2.5 SOUNDS
The Indoor Module of IDAC emits two types of sounds, depending on the action
performed:
Sending Confirmation: a short and sharper beep that indicates the sending of
an object to the bus as a result of a press.
Alarm: sharp and longer beep than the previous one, high intensity, which is
typically used as alarm or doorbell.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
14
The range of sounds emitted when these actions are performing will be different
depending on the sound type selected (see section 2.1).
Enabling and disabling the button sounds can be done in parameters or through an
object, being also possible to set in parameters whether the button sounds should be
initially enabled or not.
Note: Under no circumstances the alarm or the ring tone will be muted.
ETS PARAMETERIZATION
After enabling the Customize Sounds in “Configuration” screen, in Indoor Module,
(see section 2.2.1), a new tab will be incorporated into the tree on the left.
Figure 6. Indoor Module Sounds
Disable Button Sounds [disabled/enabled]: enables or disables acoustic
signals when actions derived from button presses are executed.
➢Enable/Disable Button Sound Through a 1-bit Object
[disabled/enabled]: makes it possible to disable / resume the button
beeping function in runtime by writing to a specific object (“[In] Sounds –
Disabling Button Sound”).
•Button Sound (After Download) [enabled/disabled]: sets whether
the button beeping function should start up enabled or disabled after
an ETS download.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
15
•Value [0 = Disabled; 1 = Enabled / 0 = Enabled; 1 = Disabled]:
parameter to select which value should trigger which action when
received through the indicated object.
Object for Doorbell [disabled/enabled]: enables or disables the doorbell
function. If enabled, a specific object (“[In] Sounds - Doorbell”) will be
included into the project topology.
➢Value [0 = No Action; 1 = Doorbell / 0 = Doorbell; 1 = No Action]:
parameter to select which value should trigger which action when received
through the indicated object
Object for Alarm [disabled/enabled]: enables or disables the alarm function.
If enabled, a specific object (“[In] Sounds - Alarm”) will be included into the
project topology.
➢Value [0 = No Alarm; 1 = Alarm / 0 = Alarm; 1 = No Alarm]: parameter to
select which value should trigger which action when received through the
indicated object
2.2.6 AMBIENT LUMINOSITY SENSOR
Indoor Module includes a sensor to measure the ambient luminosity level, so that the
brightness of the LEDs can be adjusted according to the current luminosity of the room.
Please refer to the specific manual “Luminosity and Proximity Sensor” (available in
the IDAC product section at the Zennio homepage, www.zennio.com) for detailed
information about the functionality and the configuration of the related parameters.

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
16
2.3 OUTDOOR MODULE
This module will be installed outside the room, embedded in the door, to allow access
to authorized persons. For this purpose, it has an NFC reader and an BLE module for
reading the access cards and keys of the users.
It also has a button for doorbell functionality and, as in the case of the indoor module,
it is equipped with a proximity sensor and an ambient luminosity sensor that will
allow to adjust the backlight according to to different situations of presence or
illumination.
This module does not have the activity functionality; its LEDs will be always on
(provided that there is KNX bus connection).
2.3.1 CONFIGURATION
In the "Configuration" tab of the Outdoor Module, the general configurable parameters
of the module are displayed. Most of them are checkboxes to activate other
functionalities.
ETS PARAMETERIZATION
Figure 7. External Module Configuration

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
17
Access Control [enabled]: read-only parameter to make it evident that the
“Access Control” tab is always enabled in the tab tree on the left. See section
2.3.2 for details.
Doorbell Button [disabled/enabled]: enables or disables the “Doorbell
Button” tab in the tree on the left. See section 2.3.4 for details.
Touch Locking [disabled/enabled]: enables or disables the “Touch Locking”
tab in the tree on the left. See section 2.3.5 for details.
Customize Sounds [disabled/enabled]: enables or disables the “Sounds” tab
in the tree on the left. See section 2.3.6 for details.
Proximity Sensor [disabled/enabled]: enables the proximity sensor. This
functionality permits “waking up” the device when detecting presence through
the proximity sensor
Please refer to the user manual “Proximity and Luminosity Sensor”
(available in the IDAC product section at the Zennio homepage,
www.zennio.com) for detailed information about the functionality and the
configuration of the related parameters.
Ambient Luminosity Sensor [disabled/enabled]: enables or disables the
“Ambient Luminosity Sensor” tab in the tree on the left. See section 2.3.7 for
details.
The project topology always shows the following objects:
“[Out] Central Area LED”: 1-bit object that allows to force switch on or off of
the LEDs of the central area of the Outdoor Module.
"[Out] Sounds - Disable Sound": 1-bit object to mute the buttons and
access sounds.
“[Out][Doorbell] Switch: “0””: object associated to the Doorbell Button
enabled by default.
“[Out] Proximity Sensor”,“[Out] External Proximity Detection” and
“[Out] Proximity Detection”: 1-bit object whose functionality is tied to the
proximity sensor. For further information, please refer to the user manual

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
18
“Proximity and Luminosity Sensor” (available in the IDAC product section
at the Zennio homepage, www.zennio.com).
2.3.2 ACCESS CONTROL
IDAC incorporates a functional module for access control to rooms or other areas of a
building by reading identification elements (NFC cards and BLE keys) issued to each
user.
Please refer to the specific user manual "Access Control", available within the product
section of the IDAC at www.zennio.com, for detailed information about the functionality
and configuration of the related parameters
2.3.3 BACKLIGHT
The outdoor module has three LEDs, each of which has a specific functionality:
Figure 8. Outdoor Module Backlight.
Access LED: LED at the top of the
device that will light for a configurable
time after each attempt to access the
room. The colour can be selected
according to the access result and
the state of the room, and if desired,
blinking during notification.
Central Area LED: LED that illuminates the NFC card reader icon. If
enabled, will have a fixed level of illumination.
LED Indicator: LED associated with the doorbell button also with a fixed
level of illumination according to the mode of illumination.
Access LED
LED Indicator
Central Area LED

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
19
ETS PARAMETERIZATION
Figure 9. External Module Backlight –Access LED.
Access LED
➢Duration of Notifications [2…3…5] [x 1 s]: time that the access LEDs will
be on when trying to access the room.
➢States Configuration. For each state of the room, which will depend on
the value of the objects "[Access] Room State: Status"and "[Access]
Presence: Occupancy State", will be possible configuring the colour with
the LED will shine and if you want there to be blinking during notification.
A colour can be set for each of the following room states:
•Access Granted

IDAC
https://www.zennio.com/
Technical Support: https://support.zennio.com/
20
•Access Denied
•Read Error
•Do Not Disturb
•Make Up Room + Occupied
•Make Up Room + Not Occupied
•Normal + Occupied
•Normal + Not Occupied
In addition, considering the parameters set in Action When State is
"Do not disturb" and Action When Room is Occupied, the colour of
the access LED will be applied as follows.
Access LED Color
Allow
Allow on Second Attempt
Deny
1º Attempt
2º Attempt
Room State
Not
occupied
Make Up
Make Up + Not Occupied
Normal
Normal + Not Occupied
Do Not
Disturb
Access
Granted
Do Not Disturb
Access
Granted
Access
Denied
Occupied
Make Up
Make Up + Occupied
Normal
Make Up + Not Occupied
Table 1. State vs Access LED Color.
Central Area LED
➢Central Area [enabled/disabled]: enables or disables the LED guide. If
enabled, the binary object "[Out] Central Area LED" will allow it to be
turned on and off. In addition, the following parameters will appear:
•Initial State (After Download) [Off / On].
•Brightness Level [0…50…100] [%]: LED illumination level when is
on.
LED Indicator. The brightness of the doorbell button LED will be managed
according to two operating modes: normal mode and night mode.
