MAXinBOX 66 v2
Multifunction actuator with 6 outputs and 6 inputs
ZIOMB66V2 TECHNICAL DOCUMENTATION
FEATURES
•3 different configurable channels:shutter channels (up to3) and individual
outputs (up to 6)
•Outputs suitable for capacitive loads, maximum 140 µF.
•6 analog/digital inputs.
•Manual output operation with push button and LED Status indicator.
•10 logic functions.
•Output timing.
•Total data saving on KNX bus failure.
•Integrated KNX BCU.
•Dimensions 67 x 90 x 79 mm (4.5 DIN units).
•DIN rail mounting (EN 50022), with fixing clamp.
•Possibility of connecting different phases in adjacent outputs.
•Conformity with the CE directives (CE-mark on the right side).
1. Analog/Digital inputs
2. Upper outputs
3. Output status LED indicator
4. Output control button
5. Programming/test
LED
6. Lower outputs
7. KNX Connector
8. Programming/test
button
9. Fixing clamp
4
1
7
8
3
5
2
6
9
Figure 1: MAXinBOX 66 v2
Programming/Test button: short press to set programming mode. If this button is held while plugging the device into the KNX bus, it enters the safe
mode. If this button is held for more than 3 seconds, the device enters the test mode.
Programming/Test LED: programming mode indicator (red). When the device enters the safe mode, it blinks (red) every half second. The manual mode
is indicated by the green color. During the start-up (reset or after KNX bus failure)and ifthe device is not in safe mode, it starts a blue blinking sequence.
GENERAL SPECIFICATIONS
CONCEPT
DESCRIPTION
Type of device
Electric operation control device
KNX supply
Voltage (typical)
29VDC SELV
Voltage range
21..31VDC
Maximum
consumption
Voltage
mA
mW
29VDC (typical)
4.57
132.53
24VDC¹
10
240
Connection type
Typical TP1 bus connector for 0.80mm Ø rigid cable
External power supply
Not required
Operation temperature
0°C .. +55°C
Storage temperature
-20°C .. +55°C
Operation humidity
5 .. 95% (No condens.)
Storage humidity
5 .. 95% (No condens.)
Complementary characteristics
Class B
Protection class
II
Operation type
Continuous operation
Device action type
Type 1
Electrical stress period
Long
Degree of protection
IP20, clean environment
Installation
Independent device to be mounted inside electrical panels with DIN rail (EN
50022)
Minimum clearances
Not required
Response on KNX bus failure
Data saving according to parameterization
Response on KNX bus restart
Data recovery according to parameterization
Operation indicator
The programming LED indicates programming mode (red) and test mode
(green). Each output LED indicates its status
Weight
172g
PCB CTI index
175V
Housing material
PC FR V0 halogen free
¹ Maximum consumption in the worst case scenario (KNX Fan-In model)

© Zennio Avance y Tecnología S.L. Edition 1 Futher information www.zennio.com Page 2/2
SAFETY INSTRUCTIONS
•Installation should only be performed by qualified professionals according to the laws and regulations applicable in each country.
•Do not connect the mains voltage nor any other external voltage to any point of the KNX bus; it would represent a risk for the entire
KNX system. The facility must have enough insulation between the mains (or auxiliary) voltage and the KNX bus or the wires of other
accessories, in case of being installed.
•Once the device is installed (in the panel or box), it must not be accessible from outside.
•Keep the device away from water and do not cover it with clothes, paper or any other material while in use.
•The WEEE logo means that this device contains electronic parts and it must be properly disposed of by following the instructions at
http://zennio.com/weee-regulation.
OUTPUTS SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Number of outputs
6
Output type / Disconnection type
Potential-free outputs through bistable relays with
tungsten pre-contact / Micro-disconnection
Rated current per output
AC 16(6)A @ 250VAC (4000VA)
DC 7A @ 30VDC (210W)
Maximum load
per output
Resistive
4000W
Inductive
1500VA
Maximum inrush current
800A/200μs
165A/20ms
Connections in adjacent outputs
Possibility of connecting different phases. It is not
allowed to connect power supplies of different
order, SELV with NO SELV, in the same block
Maximum current per block
60A
Short-circuit protection
NO
Overload protection
NO
Connection method
Screw terminal block
Cable cross-section
1.5-4mm² (IEC) / 26-10AWG (UL)
Outputs per common
1
Maximum response time
10ms
Mechanical lifetime (min. cycles)
3 000 000
INPUTS SPECIFICATIONS AND CONNECTIONS
CONCEPT
DESCRIPTION
Number of inputs
6
Inputs per common
6
Operation voltage
+3.3VDC in the common
Operation current
1mA @ 3.3VDC (per input)
Switching type
Dry voltage contacts between input and common
Connection method
Screw terminal block
Cable cross-section
0.5-2.5mm² (IEC) / 26-12AWG (UL)
Maximum cable length
30m
NTC probe length
1.5m (up to 30m)
NTC accuracy (@ 25°C) ²
±0.5°C
Temperature resolution
0.1°C
Maximum response time
10ms
² For Zennio temperature probes.
⚠In order to ensure the expected status of the
relays, please check that the device is connected to
the KNX bus before energizing the power circuit.
WIRINGDIAGRAMS
Figure 2: Wiring example (from left to
right, and up to down): 2 loads, 2 loads
connected to different phases and shutter
* The micro switch number 2 in the ZN1IO-DETEC-P must be in Type B position to work properly.
** Zennio temperature probe or any NTC with known resistance values at three points in the range [-55, 150ºC].
INPUTSCONNECTION
Any combination of the following accessories is allowed on the inputs:
Zennio temperature
probe.
Up to two motion sensors
can be plugged into the
same device input (parallel
wiring)
Motion sensor screw
terminal.
Motion sensor references:
ZN1IO-DETEC-X
ZN1IO-DETEC-P*
Temperature Probe**
Motion Sensor
Switch/Sensor/
Push button
CIN CIN
C I
CIN
CIN CIN
C I
CIN
CIN CIN
C I
CIN
Attaching MAXinBOX 66 v2 to DIN rail:
Removing MAXinBOX 66 v2 from DIN rail:
