Zippie Zippie Z-Bop User manual

Z-Bop
Improving People’s Lives
Owner’s Manual
Zippie®Z-Bop
SUPPLIER: This manual must be given to the rider of this wheelchair.
RIDER: Before using this wheelchair read this entire manual and save
for future reference.
Mode d’emploi
Zippie®Z-Bop
FOURNISSEUR: Ce manuel doit être remis à l’utilisateur / utilisatrice de ce
fauteuil roulant.
UTILISATEUR / UTILISATRICE : Avant d’utiliser ce fauteuil roulant, lisez
entièrement ce manuel et conservez le pour le consulter ultérieurement.
Manual de
Instrucciones
Zippie®Z-Bop
DISTRIBUIDOR: Este manual debe ser entregado al pasajero de esta silla
de ruedas.
PASAJERO: Antes de usar esta silla de ruedas, lea este manual en su totali-
dad y guárdelo para futura referencia.

932213 Rev. C 2
ENGLISH
I. INTRODUCTION
USER WARNING
WARNING
Attention wheelchair users, do not operate this wheel-
chair without first reading the owner’s manual. If you do
not understand the instructions and warnings of this
owner’s manual please contact your dealer or qualified
technician before operating this Quickie wheelchair.
Failure to do so may result in damage and/or injury.
DEALER/TECHNICIAN WARNING
WARNING
Attention dealers and qualified technicians, do not
operate or service this wheelchair without first reading
this owners manual. If you do not understand the
instructions and warnings of this owners manual please
contact the Quickie Technical Service Department
before operating and/or servicing this Quickie wheel-
chair. Failure to do so may result in damage and/or
injury.
WARNING
In addition, power wheelchairs may contain printed cir-
cuit boards.
Careful attention should be given to the Printed Circuit
Board Handling Techniques insert supplied with the
chair.
Related Documents
Listed below are additional documents which are referenced in this
owners manual.
• Quickie QR Owners Manual
• Quickie Hand Held Programmer Owners Manual
• Quickie PC Setup-Up Station Owners Manual
• Quickie Enhanced Display Owners Manual
• Quickie Specialty Control Owners Manual
I. INTRODUCTION
SUNRISE LISTENS
Thank you for choosing a Zippie wheelchair. We want to hear your
questions or comments about this manual, the safety and reliability
of your chair, and the service you receive from your Sunrise suppli-
er. Please feel free to write or call us at the address and telephone
number below:
SUNRISE MEDICAL
Customer Service Department
7477 East Dry Creek Parkway
Longmont, Colorado 80503
[phone] or [phone]
FOR ANSWERS TO YOUR QUESTIONS
Your authorized supplier knows your wheelchair best and can
answer most of your questions about chair safety, use and mainte-
nance. For future reference, fill in the following:
Supplier:_______________________________________________________________
Address: _______________________________________________________________
______________________________________________________________________
Telephone: _____________________________________________________________
Serial #: _______________________________________ Date/Purchased:_________

932213 Rev. C
3
ENGLISH
II. TABLE OF CONTENTS
II. TABLE OF CONTENTS
I. INTRODUCTION ....................................................... 2
II. TABLE OF CONTENTS............................................. 3
III. YOUR CHAIR AND ITS PARTS .............................. 4
IV
. NOTICE - READ BEFORE USE................................ 5
V. EMI (ELECTROMAGNETIC INTERFERENCE) ...... 5
VI. GENERAL WARNINGS ............................................. 7
A.Notice to User and Attendants ................................. 7
B. Weight Limit............................................................... 7
C.Controller Settings..................................................... 7
D.EMI............................................................................. 7
E. Safety Check-List ....................................................... 7
F. Changes & Adjustments............................................. 8
G.When Seated in a Parked Wheelchair........................ 8
H.Environmental Conditions ......................................... 8
I. Terrain ........................................................................ 8
J. Street Use.................................................................. 8
K.Motor Vehicle Safety.................................................. 8
L. Center of Balance ...................................................... 8
M.Transfers..................................................................... 9
N.Reaching or Leaning................................................... 9
O.Dressing or Changing Clothes ................................... 9
P. Obstacles ................................................................... 9
Q.Driving in Reverse or Moving Backward ................... 9
R. Ramps, Slopes & Sidehills........................................... 10
S. To Reduce the Risk of Falls, Tip-over or
Loss of Control .......................................................... 10
T. Ramps at Home & Work............................................ 10
U.Wheelchair Lifts ......................................................... 10
V. Curbs & Single Steps.................................................. 10
W.Stairs .......................................................................... 10
Z.Escalators ................................................................... 10
VII. WARNINGS: COMPONENTS & OPTIONS .......... 11
A.Anti-tip Tubes (Manual Carrier Only) ........................ 11
B. Armrests .................................................................... 11
C.Batteries..................................................................... 11
D.Cushions..................................................................... 11
E. Fasteners.................................................................... 11
F
.Footrests.................................................................... 11
G.Motor Locks............................................................... 11
H.On/Off Switch............................................................ 11
I. Pneumatic Tires ......................................................... 11
J. Positioning Belts......................................................... 12
K.Push Handles.............................................................. 12
L. Seating Systems.......................................................... 12
M.Upholstery Fabric ...................................................... 12
N.Suspension (Power Base Only).................................. 12
O.Wiring......................................................................... 12
P. Manual Tilt ................................................................. 12
Q.Transit Use ................................................................. 12
R. Transit Option ............................................................ 13
S. Rear Wheel Locks...................................................... 13
T. Modified Seat Systems ............................................... 13
U.Anti-Tip Tubes (Rear Std) (Manual Carrier) ............... 13
VIII. SET UP
, ADJUSTMENT & USE ................................ 14
Notes ............................................................................. 14
T
ools You Will Need ...................................................... 14
A.Battery Removal......................................................... 15
B. Power Base Seat Height Adjustment......................... 15
C.Power Base Seat Removal.......................................... 15
D.Power Base Shroud Removal..................................... 16
E. Check-Out................................................................. 16
F. Backrest ..................................................................... 17
G.Swing-Away Hangers ................................................. 17
H.Articulating Legrest .................................................... 17
I. Elevating and 90° Elevating Legrest ........................... 17
J. Composite Footplate................................................. 18
K.Kids and Adult Angle Adjustable Footplate................ 18
L. Aluminum Footplate .................................................. 18
M.90° Footboard............................................................ 18
N.Platform Flip-Up Footplate........................................ 19
O.Height Adjustable Armrests....................................... 19
P. Joystick and Enhanced Display................................... 19
Q.To Adjust the Height of the Joystick
or Enhanced Display.................................................. 20
R. Joystick or Enhanced Display Swing-Away
Retractable Mount ..................................................... 20
S. Wheel Locks .............................................................. 20
T. Anti-Tip Tubes– Rear (Manual Carrier)...................... 20
U.Seat Removal.............................................................. 20
V. Manual Carrier........................................................... 21
W.Check-Out................................................................. 21
IX. POWER BASE OPERATING GUIDE ....................... 22
A.Circuit Breakers......................................................... 22
B. Motor Locks............................................................... 22
C.Performance Control Settings ................................... 22
D.Quickie Hand Held Programmer
or Quickie PC Setup Station...................................... 22
E. Thermal Roll-Back...................................................... 23
F. Circuit Breakers......................................................... 23
G.joystick Assembly....................................................... 23
H.Enhanced Display....................................................... 24
I. Motor Locks............................................................... 24
X. BATTERIES.................................................................. 25
A.Introduction ............................................................... 25
B. Battery Charger ......................................................... 25
C.Acid Burns.................................................................. 25
D.Connecting Batteries in Battery Well......................... 25
E. Charging Batteries...................................................... 26
F. Disposing of Batteries ................................................ 26
XI. MAINTENANCE ......................................................... 27
A.Notes ......................................................................... 27
B. Cleaning ..................................................................... 27
C.Storage Tips ............................................................... 27
D.Battery Maintenance .................................................. 27
E. Pneumatic Tires ......................................................... 27
F
.T
o Repair or Replace a Tire ....................................... 27
G.Motor Brushes ........................................................... 28
H.Ordering Parts ........................................................... 28
I. Maintenance Chart..................................................... 28
J. Tools You Will Need .................................................. 28
XII. SUNRISE LIMITED WARRANTY............................. 29
FRANÇAIS................................................................... 30
ESPAÑOL..................................................................... 59

932213 Rev. C 4
ENGLISH
III. YOUR CHAIR AND ITS PARTS
III. YOUR CHAIR AND ITS PARTS
1. Single-post, height-adjustable armrest
2. Controller joystick
3. Seat frame
4. Front caster 6"
5. Rear stabilizing caster 5"
6. Swing-away with angle-adjustable
footplates
7. Angle-adjustable back
8. Battery deck lid
9. 10" drive wheels
10. Freewheel release
11. Caster Fork (front)
12. Caster Fork (rear)
13. Shroud
14. Readi-align caster assist (not shown)
Weight
105 lbs (base), 35 lbs (seat)
140 lbs (base & seat w/out footplate or
batteries)
Drive Wheels
10" Mag: Standard airless insert,
option - pneumatic
Joystick
QR3-Btn (right-hand or left-hand mount)
Batteries
(2 deep cycle batteries required to
operate chair)
optional U1 Gel or 50 Ahr (AGM)
Battery Charger
Option - off board 8 AMP
Colors (all standard)
Standard - red, blue, champagne, black
Option - blue marble, pink carbon,
yellow carbon
Seat Frame
Width: 10" - 18"
Depth: 13" - 20"
Footrest
Standard - swing-away with composite
footplates and heel loops.
Option - elevating legrests
Casters (front)
Standard - 6" solid
Casters (rear)
Standard - 5" solid
Armrests
Standard - fixed height, single post
Height-adjust, flip back (Seat Frame)
Single post, height-adjustable
(Seat Frame)
Suspension
Standard - all wheel independent
All features may not be available with some
chair setups or in conjunction with another
chair feature. Please consult your supplier
for more information. Your authorized sup-
plier can also provide you with more infor-
mation on accessories.
ZIPPIE Z-BOP
1
3
6
7
8
9
11
12
13
4
5
10
2

V. EMI (ELECTROMAGNETIC INTERFERENCE
V. EMI (ELECTROMAGNETIC INTERFERENCE)
WARNING
Heed all warnings to reduce the risk of unintended
brake release or chair movement:
1. Beware of the danger from hand-held transceivers.
Never turn on or use a hand-held transceiver while
power to your chair is on. Use extra care if you believe
that such a device may be in use near your chair.
2. Be aware of nearby radio or TV stations, and avoid
coming close to them.
3. If unintended movement occurs, turn your chair off as
soon as it is safe to do so.
A. WHAT IS EMI?
WARNING
1. EMI means: electromagnetic (EM) interference (I). EMI
comes from radio wave sources such as radio transmitters
and transceivers. (A “transceiver” is a device that both sends
and receives radio wave signals).
2. There are a number of sources of intense EMI in your daily
environment. Some of these are obvious and easy to avoid.
Others are not, and you may not be able to avoid them.
3. Powered wheelchairs may be susceptible to electromagnetic
interference (EMI) emitted from sources such as radio sta-
tions, TV stations, amateur radio (HAM) transmitters, two
way radios, and cellular phones.
4. EMI can also be produced by conducted sources or electro-
static discharge (ESD).
932213 Rev. C
5
ENGLISH
IV. NOTICE– READ BEFORE USE
IV. NOTICE– READ BEFORE USE
A. CHOOSE THE RIGHT CHAIR & SAFETY
OPTIONS
Sunrise provides a choice of many power wheelchair styles, sizes
and adjustments to meet the needs of the rider. However, final
selection of a wheelchair rests solely with you and your health care
professional. Choosing the best chair for you depends on such
things as:
1. Your size, disability, strength, balance and coordination.
2. Your intended use, and your level of activity.
3. The types of hazards you must overcome in daily use (in
areas where you are likely to use your chair).
4. The need for options for your safety and comfort (such as
positioning belts or special seat systems).
B. ADJUST CHAIR TO YOUR ABILITY
You need to work with your doctor, nurse or therapist, and your
supplier, to fit this chair and adjust the controller settings for your
level of function and ability.
C. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you,
should read this entire Manual and make sure to follow all instruc-
tions. Review the warnings often, until they are second nature to
you.
D. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that
may cause severe injury or death to you or to other persons. The
“Warnings” are in four main sections, as follows:
1. V — EMI
Here you will learn about electromagnetic interference and
how it can affect your chair.
2. VI — GENERAL WARNINGS
Here you will find a safety checklist and a summary of risks
you need to be aware of before you ride this chair.
3. VII — WARNINGS — COMPONENTS & OPTIONS
Here you will learn about your chair. Consult your supplier
and your health care professional to help you choose the
best set-up and options for your safety.
4. XI — BATTERIES
Here you will learn about battery and charger safety, and how to
avoid injury.
Q-NOTE– Where they apply, you will also find “Warnings” in other
sections of this Manual.
Throughout this owner’s manual and on the wheelchair you will
see the icons listed below to identify warnings and potential haz-
ards. It is important to read and understand all of them and under-
stand them.
WARNING! These warnings must be followed, failure to do
so may cause personal injury or may damage
the wheelchair.
PROHIBITED! Prohibited actions must never be per-
formed. Performing an action that is
prohibited can cause personal injury
or may damage the wheelchair.
Q-NOTE: Q-Notes are informative statements to help
further explain actions, warnings or product
detail.
ESD: Electrostatic Discharge has a potential to dam-
age printed circuit boards unless handled cor-
rectly. When the ESD symbol is shown through-
out the owner manual, use the Proper Handling
Techniques Insert supplied with the chair to
properly handle printed circuit board.

932213 Rev. C 6
ENGLISH V.
2. The higher the immunity level, the less the risk of EMI. It is
believed that a 20 V/m immunity level will protect the power
wheelchair user from the more common sources of radio
waves.
3. The configurations tested and found to be immune to at least
20 V/m are:
a. Zippie Z-Bop power wheelchair with a right-hand
mounted Quickie controller, highback seat, flip-back arm-
rests, solid flip-up footplate and U1 gel cell batteries.
b. Zippie Z-Bop power wheelchair with a right-hand
mounted Quickie controller, highback seat, flip-back arm-
rests, solid flip-up footplate and 40Amh gel cell batteries.
4. The following specialty import devices have an unknown
effect on the immunity level because they have not been
tested on the Zippie Z-Bop with the Quickie controller:
• Breath Control
•Ribbon Switch
• Disc Switch
• Proportional Head Control
• Proportional Mini-Joystick/Chin Control
• Buddy Button
• Micro Light
• Penta Switch
• Wobble Switch
• ASL Head Array
•HMC Mini-Joystick
• Egg Switch
•Switch-It head Array
WARNING
Individuals with physical limitations requiring the use of
a specialty control input device known not to be
immune to 20V/m, or not known, should exercise extra
care around known sources of EMI.
WARNING
There is no way to know the effect on EMI if you add
accessories or modify this chair. Any change to your
chair may increase the risk of EMI. Parts from other
suppliers have unknown EMI properties.
F. REPORT ALL SUSPECTED EMI
INCIDENTS
WARNING
You should promptly report any unintended movement
or brake release. Be sure to indicate whether there was
a radio wave source near your chair at the time.
Contact: Sunrise Medical Customer Service
Department at [phone].
B. WHAT EFFECT CAN EMI HAVE?
WARNING
1. EMI can cause your chair, without warning, to:
• Release its brakes
• Move by itself
• Move in unintended directions
If any of these occurs, it could result in severe injury to
you or others.
2. EMI can damage the control system of your chair. This could
create a safety hazard, and lead to costly repairs.
C. SOURCES OF EMI
WARNING
The sources of EMI fall into three broad types:
1. Hand-Held Transceivers:
The antenna is usually mounted directly on the unit. These
include:
• Citizens band (CB) radios
•“Walkie-talkies”
• Security, fire and police radios
•Cellular phones
•Lap-top computers with phone or fax
• Other personal communication devices
Q-NOTE– These devices can transmit signals while they are on, even
if not in use.
2. Medium-Range Mobile Transceivers:
These include two-way radios used in police cars, fire trucks,
ambulances and taxi cabs. The antenna is usually mounted on the
outside of the vehicle.
3. Long-Range Transceivers:
These include commercial radio and TV broadcast antenna towers
and amateur (HAM) radios. Note: The following are not likely to
cause EMI problems: Lap-top computers (without phone or fax),
Cordless phones, TV sets or AM/FM radios, CD or tape players.
D. DISTANCE FROM THE SOURCE
WARNING
EM energy rapidly becomes more intense as you get
closer to the source. For this reason, EMI from hand-
held devices is of special concern. (See C.1) A person
using one of these devices can bring high levels of EM
energy very close to your chair without you knowing it.
E. IMMUNITY LEVEL
WARNING
1. The level of EM energy is measured in volts per meter (V/m).
Every power wheelchair can resist EMI up to a certain level.
This is called its “immunity level”.

932213 Rev. C
7
ENGLISH
VI. GENERAL WARNINGS
VI. GENERAL WARNINGS
WARNING
Heed all warnings in this section. If you fail to do so a
fall, tip-over or loss of control may occur and cause
severe injury to you or others.
A. NOTICE TO USER AND ATTENDANTS
WARNING
User
1. Before using this chair, you should be trained in its safe use
by your health care professional.
2. Every wheelchair is different. Take the time to learn the feel
of this chair before you begin riding.
3. Be aware that you must develop your own methods for the
safe use of this chair, that are best suited to your level of
function and ability.
4. Have someone help you practice bending, reaching and
transfers until you learn how to do them safely.
5. Never try a new maneuver on your own unless you are sure
it is safe.
6. Get to know the areas where you plan to use your chair.
Look for hazards
and learn how to avoid them.
7. Always wear a positioning strap.
8. Do not use a wheelchair if the joystick does not spring back
to the neutral position.
9. Do not use your wheelchair if the joystick boot is ripped or
damaged.
10. Do not try to tip this wheelchair without an attendant pres-
ent.
User and Attendants
1. When transferring the user in or out of the wheelchair never
use the footplate as a platform.
2. Do not lift this wheelchair by any parts that are removable,
doing so may result in damage to the wheelchair or injury to
the user.
3. Never try to stop or slow this wheelchair with the wheel
locks (if applicable). Wheel locks are designed to prevent the
chair from moving when stopped. They are not brakes.
4. Always keep your hands and body parts clear of moving parts
to help prevent injuries.
Attendants
WARNING
Make sure you heed all warnings and follow all instruc-
tions in each section of this manual. Be aware that warn-
ings that apply to the user also apply to you.
1. Do not stand or sit on any portion of this wheelchair.
1. You need to work with the user, and the user’s doctor, nurse
or therapist, to develop safe methods best suited to your
abilities and those of the user.
2. T
o manually push the chair you must release the motor locks.
•Make sure you have full control over the chair when you
release the motor locks. When you do so the chair will
not have brakes.
•Make sure the chair is on level ground before you release
the motor locks.
B. WEIGHT LIMIT
WARNING
1. NEVER exceed the weight limit of 165 pounds (74.8 kilo-
grams), for combined weight of rider and items carried.
2. Never use this chair for weight training if the total weight
(rider plus additional weights) exceeds the weight limits out-
lined above.
3. Exceeding the weight limit is likely to damage the seat,
frame, or fasteners and may cause severe injury to you or
others from chair failure.
4. Exceeding the weight limit will void the warranty.
C. CONTROLLER SETTINGS
WARNING
Be aware that you may need to adjust the controller
settings of your chair to reduce the risk of a collision,
fall or tip-over.
1. Check and adjust the settings every six to twelve months (or
more often, if needed).
2. Consult your supplier to adjust the control settings immedi-
ately if you notice any change in your ability to:
• Control the joystick.
• Hold your torso erect.
• Avoid running into objects.
D. EMI
WARNING
Read Section V to learn about EMI. To reduce the risk
of unintended brake release or chair movement:
1. Never turn on or use a hand-held transceiver while power to
your chair is on. Use extra care if you believe that such a
device may be in use near your chair.
2. Be aware of nearby radio or TV stations, and avoid coming
close to them.
3. If unintended movement or brake release occurs, turn your
chair off as soon as it is safe.
E. SAFETY CHECK-LIST
WARNING
Before each use of this chair:
1. Make sure the chair operates smoothly. Check for noise,
vibration, or a change in ease of use. (They may indicate low
tire pressure, loose fasteners, or damage to your chair). If
you detect a problem, make sure to repair or adjust the
chair. Deferring repair or adjustment could increase the risk
for injury. Your supplier can help you find and correct the
problem.
2. Make sure batteries are charged. Green lights on charge indi-
cator will light up when charge is full. Yellow lights indicate
battery charge level is getting low. Red lights indicate batter-
ies are in immediate need of charging.
3. If your chair has anti-tip tubes, lock them into place (manual
carrier only).

932213 Rev. C 8
ENGLISH VI.
WARNING
Extra caution should be used when employing the disc
switch or the proximity head array as control devices.
These two devices are susceptible to malfunction when
wet.
I. TERRAIN
WARNING
1. This chair is designed for use on firm, even surfaces such as
concrete, asphalt and indoor flooring.
2. Do not operate your chair in sand, loose soil or over rough
terrain. Doing so may damage wheels, bearings, axles or
motors, or loosen fasteners.
J. STREET USE
WARNING
In most states, power chairs are not legal for use on
public roads. Be alert to the danger of motor vehicles
on roads or in parking lots.
1. At night, or when it is hard to see, use reflective tape on
your chair and clothing.
2. It may be hard for drivers to see you. Make eye contact with
drivers before you proceed. When in doubt, yield until you
are sure it is safe.
K. MOTOR VEHICLE SAFETY
WARNING
To date, the U.S. Department of Transportation has not
approved any tie down system for transporting this
wheelchair in a motor vehicle.
1. Never sit in this chair while in a moving vehicle. In an acci-
dent or sudden stop you may be thrown from the chair.
• Wheelchair belts are designed to position the rider
only and will not protect you in an accident; further
injury may result from the belts.
2. Always move to an approved vehicle seat. You must be
secured with proper motor vehicle restraints.
3. Never transport this chair in the front seat of a vehicle. It
may shift and interfere with the driver.
4. Always secure this chair so that it cannot roll or shift.
L. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back or to
the side depends on its center of balance and stability.
The Center Of Balance Is Affected By:
1. The seat height and seat angle.
2. A change in your body position, posture or weight distribution.
3. Using this chair on a ramp or slope.
4. The use of a back pack or other options, and the amount of
added weight.
T
o Reduce The Risk Of A Fall Or Tip-Over:
1. Consult your supplier for information on modifications
authorized by Sunrise before you modify or adjust this chair.
Q-NOTE– You may need to make additional changes to correct the
center of balance.
F. CHANGES & ADJUSTMENTS
WARNING
Never use non-Zippie parts or make changes to your
chair unless authorized by Sunrise. (Doing so will void
the Warranty and may create a safety hazard).
1. If you modify or adjust this chair it may increase the risk of a
fall or tip-over.
2. Modifications to the chair, seating system, or other compo-
nents which are unauthorized by Sunrise constitutes remanu-
facturing of the wheelchair. This voids the warranty. The
rider then assumes all future liability for the wheelchair.
3. We recomment that you use anti-tip tubes until you adopt to
the change and are sure you are not at risk to tip over (man-
ual carrier only).
G. WHEN SEATED IN A PARKED
WHEELCHAIR
WARNING
1. Always turn off all power to your chair when you are parked,
even for a moment. This will prevent:
• Accidental movement from contact with the joystick by
you or others.
• Unintended brake release or movement from EMI
sources. (See Section V)
2. Make sure that persons who help you (for example, store
clerks) are aware of the joystick and do not touch it. If they
do, your chair may move suddenly when you do not expect it.
H. ENVIRONMENTAL CONDITIONS
WARNING
Your chair is not designed for use in a heavy rain storm,
or in snowy or icy conditions.
1. Contact with water or excessive moisture can cause an elec-
trical malfunction. The frame, motors and other chair parts
are not watertight and may rust or corrode from the inside.
To avoid a chair failure:
• Minimize exposure of your chair to a rain storm or very
wet conditions.
• Never take your chair into a shower, tub, pool or sauna.
• Do not use your chair in fresh or salt water (such as at
the edge of a stream, lake, or ocean).
• Make sure shroud cover and deck lid are secure.
• Replace joystick boot if it becomes torn or cracked.
• Make sure all electrical connections are secure.
• Dry the chair as soon as you can if it gets wet, or if you
use water to clean it.
2. Proceed slowly and use extra care if you must operate your
chair on a wet or slick surface.
• Do so only if you are sure it is safe.
• Stop if one or both main wheels lose traction. If this
occurs, you may lose control of your chair or fall.
• Never operate your chair on a slope or ramp if there is
snow, ice, water or oil film present.
• When in doubt, have someone help you.
3. When not in use, keep your chair in a clean, dry place.

932213 Rev. C
9
ENGLISH VI.
2. Use extreme care until you know the balance points of this
chair and how to avoid a fall or tip-over.
3. Use anti-tip tubes (manual carrier).
4. have someone help you until you know the balance points of
your chair and how to avoid tip-over.
M. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires
good balance and agility. Be aware that there is a point
during every transfer when the wheelchair seat is not
below you. To avoid a fall:
1. Always turn off power before you transfer to or from your
chair. If you fail to do so you may touch the joystick and
cause your chair to move when you do not expect it.
2. Make sure motor locks are engaged. This keeps the chair
from moving when you transfer.
3. Work with your health care professional to learn safe methods.
• Learn how to position your body and how to support
yourself during a transfer.
• Have someone help you until you are sure you can do a
safe transfer on your own.
4. Move your chair as close as you can to the seat you are
transferring to. If possible, use a transfer board.
5. Rotate the front casters until they are as far forward as possi-
ble.
6. Be careful of the foot platform. If you can, remove or swing
it out of the way.
• Never stand on footrests when you transfer. Doing so
may damage them or cause your chair to tip.
• Make sure your feet do not “hang up” or get caught in
the space between the footrests.
7. Make sure armrests do not interfere.
8. Transfer as far back onto the seat surface as you can. This
will reduce the risk that you will miss the seat or fall.
N. REACHING OR LEANING
WARNING
Reaching or leaning affects the center of balance of your
chair. If done improperly, a fall or tip-over is likely.
When in doubt, ask for help or use a device to extend
your reach.
To Reduce the Risk of injury and/or Damage to the Chair:
1. Never reach or lean if you must shift your weight sideways
or rise up off the seat.
2. Never reach or lean if you must move forward in your seat
to do so. Always keep your buttocks in contact with the
backrest.
3. Never reach with both hands (you may not be able to catch
yourself to prevent a fall if you lose your balance).
4. Never try to pick up an object from the floor by reaching
down between your knees.
5. Never put pressure on the footrest while reaching. This may
cause the chair to tip if you lean too far.
6. Never reach or lean over the top of the seat back. This may
damage the backrest and cause you to fall.
7. Never reach or lean to the rear unless your chair has anti-tip
tubes locked in place (manual carrier).
IF YOU MUST REACH OR LEAN, DO SO AT
YOUR OWN RISK.
Remember to:
1. Move your chair as close as you can to the object you wish
to reach.
2. Rotate the front casters until they are as far forward as possi-
ble. This makes the chair more stable.
Q-NOTE– To do this: Move your chair past the object you want to
reach, then back up alongside it. Backing up will rotate the casters
forward.
3. Turn off all power to your chair. If you fail to do so, you may
touch the joystick and cause your chair to move when you
do not expect it.
4. Firmly grasp an armrest with one hand. This will help to pre-
vent a fall if the chair tips.
O. DRESSING OR CHANGING CLOTHES
WARNING
Be aware that your weight will shift if you dress or
change clothes while seated in this chair. To make the
chair more stable, rotate the front casters until they are
forward and lock anti-tip tubes in place when applicable.
P. OBSTACLES
WARNING
Obstacles you may have to overcome in daily use
include door thresholds, lifts, ramps and hazards such as
potholes and broken pavement. These can damage your
chair and may cause a fall, tip-over or loss of control.
1. Be aware that thresholds are very dangerous. (Even a small
change in height may stop a caster wheel and cause your
chair to tip). You may need to:
• Remove or cover threshold strips between rooms.
• Install a ramp at entry or exit doors.
2. Keep your eyes moving when you ride; scan the area well
ahead of your chair.
3. Make sure the floor areas where you use this chair are level
and free of obstacles.
4. To help correct your center of balance:
• Lean your upper body forward slightly as you go up over
an obstacle.
• Press your upper body backward as you go down from a
higher to a lower level.
5. If your chair has anti-tip tubes, lock them in place before you
go up over an obstacle.
Q. DRIVING IN REVERSE OR MOVING
BACKWARD
WARNING
Use extra care when you drive your chair in reverse.
You may lose control or fall if one of the rear wheels
hits an object.
1. Operate your chair slowly and at an even speed.
2. Stop often and check to make sure your path is clear of
obstacles.
3. If your chair has anti-tip tubes, make sure to lock them into
place.

932213 Rev. C 10
ENGLISH VI.
U. WHEELCHAIR LIFTS
WARNING
Wheelchair lifts are used in vans, buses, and buildings to
help you move from one level to another.
1. Always turn off all power to your chair when you are on a
lift. If you fail to do so, you may touch the joystick by acci-
dent and cause your chair to drive off the platform. (Be
aware that a “roll-stop” at the end of the platform may not
prevent this).
2. Make sure there is not a lip or drop-off at the top or bottom
of the platform. These may cause a fall or tip-over. When in
doubt, have someone help you.
3. Always secure the rider with a positioning belt to help pre-
vent falls during transfers.
4. Avoid moving forward if a wheel is “hung up” on the lip of
the ramp. Backup, reposition the caster for a more direct
approach and slowly try again.
V. CURBS & SINGLE STEPS
WARNING
1. It is recommended to climb and/or descend a curb, single step,
or other obstacle that a ramp or curb cutout is always used.
2. If you must climb or descend a curb, single step, or other
obstacle that is greater than 2.5", it is recommended to have
a person assist you in doing so.
3. In no case should you try to climb a curb, single step, or
other obstacle greater than 4" high.
4. If you must climb or descend a curb or step alone do so at
your own risk using extreme care and follow the following
procedure:
• Proceed slowly, at a steady speed
• Go as straight up or down as you can over the obstacle.
Never turn when trying to climb or descend and obstacle,
doing so may result in a fall or tip-over.
5. Failure to follow the above procedures may cause:
• A Fall or Tip Over
• Damage to the frame, wheels, axles or other parts, or
loose fasteners.
W. STAIRS
WARNING
Never use this chair to go up or down stairs, even with
an attendant. Doing so is likely to cause a fall or tip-over.
X. ESCALATORS
WARNING
Never take this chair on an escalator, even with an
attendant. Doing so is likely to cause a fall or tip-over.
R. RAMPS, SLOPES & SIDEHILLS
WARNING
The center of balance of your chair changes when you
are on a slope.
Q-NOTE– “Slope” includes a ramp or sidehill. Your chair is less stable
when it is at an angle. Never use this chair on a slope unless you are
sure it is safe. When in doubt, have someone help you.
Beware Of:
1. Steep slopes. Do Not use this chair on a slope steeper than
10%. (A 10% slope means one foot in elevation for every
ten feet of slope length.)
2. Wet or slippery surfaces (such as when ice, snow, water or oil
film is present). A loss of traction may cause a fall or tip-over.
3. A change in grade on a slope (or a lip, bump or depression).
These may cause a fall or tip-over.
4. A drop-off at the bottom of a slope. (A drop-off of as small
as 3/4 inch can stop a front caster and cause the chair to tip
forward).
S. TO REDUCE THE RISK OF A FALL, TIP-
OVER OR LOSS OF CONTROL
WARNING
1. Never use your chair on a slope unless you are sure you can
do so without losing traction.
2. Always go as straight up and as straight down as you can.
• Do not “cut the corner” on a slope or ramp.
• Do not turn or change direction on a slope.
3. Always stay in the center of the ramp. Make sure ramp is
wide enough that you are not at risk that a wheel may roll off
the side.
4. Lean or press your body uphill. This will help adjust for a
change in the center of balance caused by the slope.
5. Keep your chair moving at a slow, steady speed. Keep control
over the chair at all times.
• On a descent, do not let your chair accelerate beyond its
normal speed.
• If the chair picks up speed, center the joystick to slow
down or stop.
• If you stop, re-start slowly.
T. RAMPS AT HOME & WORK
WARNING
Make sure ramps meet all Building Codes for your area.
1. For your safety, have a licensed contractor build or remodel
ramp to meet all standards.
Q-NOTE– The proper design will vary, depending on such things as:
the length and height of the ramp; the need for an intermediate
platform; landing size; doors and the direction of swing; and whether
the ramp includes a turn or angle.
At A Minimum:
1. Open sides of ramp must have side rails to prevent your
chair from going over the edge.
2. Slope must not be steeper than one inch in height for every
one foot of slope length.
3. Ramp surface must be even, and have a non-skid surface.
4. You may need to add a section at the top or bottom to avoid
a lip or drop-off.
5. Ramp must be sturdy. Add bracing if needed, so ramp does
not “bow” when you ride on it.

932213 Rev. C
11
ENGLISH
VII. WARNINGS: COMPONENTS & OPTIONS
VII. WARNINGS: COMPONENTS & OPTIONS
WARNING
Note: If you use parts or make changes not authorized
by Sunrise it may create a safety hazard and will void
the Warranty.
A. ANTI-TIP TUBES
(manual carrier only)
Never remove or alter anti-tip tubes. They help keep your chair
from tipping over backward in normal use. Make sure rubber
rollers are in good condition.
B. ARMRESTS
WARNING
Armrests cannot be used to lift chair or the seat.
PROHIBITED!
1. Never lift this chair by its armrests.
2. Lift this chair only by non-detachable parts of the main frame.
C. BATTERIES
WARNING
1. Only deep cycle sealed case construction batteries should be
used in this device.
2. To prevent an acid spill, always keep batteries upright (wet
cell batteries only).
PROHIBITED!
1. Never smoke or hold an open flame near batteries. They are
a known explosion hazard.
2. Always wear rubber gloves and safety glasses when you han-
dle batteries.
3. Read all of section XI Batteries before attempting to change
or charge batteries.
4. Always remove batteries using straps or handle provided.
Pinched fingers may occur if the batteries are removed by
grasping the battery casings.
D. CUSHIONS
WARNING
If you suffer from pressure sores, or if you are at risk that they will
occur, you may need a special seat system such as can be provided
by the Seat Frame, or a device to control your posture.
• Consult your doctor, nurse or therapist to find out if you
need such a device for your well-being.
E. FASTENERS
WARNING
Many of the screws, bolts and nuts on this chair are spe-
cial high-strength fasteners. Use of improper fasteners
may cause your chair to fail.
1. Only use fasteners provided by Sunrise.
2. If fasteners become loose, tighten them as soon as you can.
3. Over- or under-tightened fasteners may fail or cause damage
to chair parts.
• See Section IX, “Set-Up, Adjustment & Use”, for proper
torque settings.
F. FOOTRESTS
WARNING
1. At the lowest point, the foot platform and footrests should
be at least 2 1/2" off the ground. If set too LOW, it may “hang
up” on obstacles you can expect to find in normal use. This
may cause the chair to stop suddenly and tip forward.
2. To avoid a trip or fall when you transfer:
• Make sure your feet do not “hang up” or get caught in
the space surrounding or in between the footrests.
• Avoid putting weight on the footrests, as the chair may
tip forward.
• Swing the footrests out of the way, if possible.
PROHIBITED!
3. Never lift this chair by the footrests. Footrests fold or detach
and will not bear the weight of this chair. Lift this chair only
by non-detachable parts of the main frame.
G. MOTOR LOCKS
WARNING
1. Do not engage or disengage motor locks unless power to the
chair is off.
2. Be aware that the chair will not have brakes when motor
locks are in the free-wheel position, unless the chair is
equipped wih optional power base wheel locks.
3. Make sure that the person pushing the chair has full control
when motor locks are disengaged.
H. ON/OFF SWITCH
WARNING
1. Never use the ON/OFF switch to stop the chair except in an
emergency. This will result in an abrupt stop and may cause
you to fall.
2. To slow your chair to a stop, return the joystick to neutral.
I. PNEUMATIC TIRES
WARNING
Proper inflation extends the life of your tires and makes
your chair easier to use.
1. Do not use this chair if any of the tires are under- or over-
inflated. Check weekly for proper inflation level, as listed on
the tire sidewall.
2. Low pressure in a tire may cause the chair to veer to one
side and result in a loss of control.
3. An over-inflated tire may burst.
4. Never use a gas station air pump to inflate a tire. Such pumps
provide air at high volume, and could cause the tire to burst.
T
o prevent tire damage:
• Use a hand pump (or a low volume air pump) to inflate
tires.
• Use a tire gauge to check pressure.
5. Driving over sharp objects may cause damage to pneumatic
tires and tubes.

932213 Rev. C 12
ENGLISH VII.
O. WIRING
WARNING
Never pull on cables directly. This can result in wires
breaking inside the connector or harness. To remove a
plug or connector, always grasp the plug or connector
itself.
P. MANUAL TILT
WARNING
1. Operation
• While driving this wheelchair in the tilted position use cau-
tion.
• Do Not attempt to operate the tilt while positioned on an
incline.
2. Pinch points
Pinch points may occur when operating the tilt on this chair.
Ensure all hands and body parts are clear of all tilt compo-
nents that may result in pinch points before operating the tilt.
3. Maximum User Weight
Do not exceed the weight capacity for your specific
chair/seating system configuration. Doing so could result in
premature failure or injury.
Q. TRANSIT USE
WARNING
1. If possible and feasible, the rider should transfer to the
Original Equipment Manufacturer vehicle seat and use the
vehicle restraint.
2. If the wheelchair is used for transport, it must be used in a
forward-facing seating position.
3. The rider must not weigh more than 165 lbs.
4. Figure 1 shows the location of the wheelchair securement
points.
5. Use only with Wheelchair Tiedown and Occupant Restraint
Systems (WTORS) that have been installed in accordance
with the manufacturer’s instructions and SAE J2249.
6. Attach WTORS to securement points in accordance with the
manufacturer’s instructions and SAE J2249.
7. Attach occupant restraints in accordance with the manufac-
turer’s instructions and SAE J2249.
Q-NOTE– To obtain a copy of SAE J2249 Wheelchair Tiedown and
Occupant Restraint Systems for Use in Motor Vehicles, please con-
tact: SAE International - 400 Commonwealth Drive - Warrendale,
PA 15096 - 412.776.4970
If you fail to heed these warnings damage to your chair, a fall, tip-
over or loss of control may occur and cause severe injury to the
rider or others.
J. POSITIONING BELTS
WARNING
Use a positioning belt only to help support your pos-
ture. Improper use of such belts may cause severe
injury or death.
1. Make sure you are not at risk to slide down in the wheelchair
seat. If this occurs, you may suffer chest compression or suf-
focate due to pressure from the belt.
2. A pelvic wedge or a similar device can help you from sliding
down in the seat. Consult your health care professional to
find out if you need such a device.
3. The belt must be snug, but must not be so tight that it inter-
feres with breathing. You should be able to slide your open
hand, flat, between the belt and your stomach.
4. Make sure you can easily remove the belt in an emergency.
5. Never use a positioning belt:
• In place of a motor vehicle seat belt. In an accident or
sudden stop you may be thrown from the chair. A posi-
tioning belt will not prevent this, and further injury may
result from the belt.
• As a restraint. A restraint requires a doctor’s order.
• On a rider who is comatose or agitated.
K. PUSH HANDLES (seat frame only)
WARNING
1. Push handles provide secure points for an attendant to propel
and control the chair. This helps to prevent a fall or tip-over.
2. Check to make sure push handle grips will not rotate or slip off.
L. SEATING SYSTEMS
WARNING
1. Use of a seating system not approved by Sunrise may alter
the center of balance of this chair. This may cause a fall or
tip-over.
2. Never change the seating system of your chair unless you
consult your supplier first.
M. UPHOLSTERY FABRIC
WARNING
1. Replace worn or torn fabric of the seat as soon as you can. If
you fail to do so, the seat may fail and cause you to fall. Worn
fabrics may increase the potential for a fire hazard.
2. Fabric will deteriorate with age and use. Look for fraying,
thin spots, or stretching of fabric at rivet holes. Replace fabric
as required.
3. Be aware that washing may reduce flame retardation of the
fabric.
N. SUSPENSION (Power base only)
WARNING
The suspension system does contain Dry Natural
Rubber. The suspension, or any other component on the
chair, does not contain any latex based product. The
suspension components are enclosed and inaccessible to
the user.

932213 Rev. C
13
ENGLISH VII.
R. TRANSIT OPTION
WARNING
1. Use only Wheelchair Tiedown
and Occupant Restraint
Systems (WTORS) which
meet the requirements of SAE
J2249 Recommended Practice
- Wheelchair Tiedown and
Occupant Restraint Systems
For Use in Motor Vehicles.
Do not use WTORS designed
to rely on the wheelchair
structure to transfer occupant
restraint loads to the vehicle.
2. The wheelchair has been
dynamically tested in a for-
ward-facing mode for a 48-
km/h frontal impact test. The
wheelchair must be forward-
facing during transport.
3. In order to reduce the potential of injury to vehicle occu-
pants, wheelchair-mounted accessories, such as trays and
respiratory equipment, should be removed and secured sep-
arately.
4. Postural supports and positioning devices should not be
relied on for occupant restraint.
5. Do not alter or substitute wheelchair frame parts, compo-
nents or seating.
6. Sudden stops or impacts can structurally damage your chair.
Chairs involved in such incidents should be replaced.
S. REAR WHEEL LOCKS
WARNING
Rear wheel locks are NOT designed to slow or stop a
moving wheelchair. Use the only to keep the rear wheels
from rolling when your chair is at a complete stop.
1. NEVER use rear wheel locks to try to slow or stop your
chair when it is moving. Doing so may cause you to veer out
of control.
2. To keep the rear wheels from rolling, always set both rear
wheel locks when you transfer to or from your chair.
3. Low pressure in a rear tire may cause the wheel lock on that
side to slip and may allow the wheel to turn when you do
not expect it.
4. Make sure lock arms embed in tires at least 1/8 inch when
locked. If you fail to do so, the locks may not work.
If you fail to heed these warnings damage to your chair, a fall, tip-
over or loss of control may occur and cause severe injury to the
rider or others.
T. MODIFIED SEAT SYSTEMS
WARNING
Use of a seat system not approved by Sunrise may alter
the center of balance of this chair. This may cause the
chair to tip over.
1. Do not change the seat system of your chair UNLESS you
consult your authorized supplier first.
2. Use of a seat system not approved by Sunrise may affect the
folding mechanism of this chair.
3. Use of a seating system not provided by Sunrise is prohibited
for transit use.
If you fail to heed these warnings damage to your chair, a fall, tip-
over or loss of control may occur and cause severe injury to the
rider or others.
U. ANTI-TIP TUBES (optional) (Manual Carrier)
WARNING
Anti-tip tubes can help keep your chair from tipping over backward
in most normal conditions.
1. Sunrise Recommends Use Of Anti-Tip Tubes:
a. UNLESS you are a skilled rider of this chair and are sure
you are not at risk to tip over.
b. Each time you modify or adjust your chair. The change
may make it easier to tip backward. Use anti-tip tubes
until you adapt to the change, and are sure you are not at
risk to tip over.
2. When locked in place (in the “down” position) anti-tip tubes
should be BETWEEN 1 1/2 to 2 inches off the ground.
a. If set too HIGH, they may not prevent a tip-over.
b. If set too LOW, they may “hang up” on obstacles you can
expect in normal use. If this occurs, you may fall or your
chair may tip over.
3. Keep Anti-Tip Tubes Locked In Place UNLESS:
a. You have an attendant; or
b. You have to climb or descend a curb, or overcome an
obstacle, and can safely do so without them. At these
times, make sure anti-tip tubes are up, out of the way.
Front securement
point
Rear securement point

932213 Rev. C 14
ENGLISH
VIII. SET-UP, ADJUSTMENT & USE
VIII. SET-UP, ADJUSTMENT & USE
NOTES:
1. Work Surface For Set-Up:
Use a flat surface, such as a table, to assemble, adjust and check your chair. This makes the
steps easier and helps ensure a correct set-up.
2. Fasteners:
•Many of the screws and bolts on this chair are special high-strength fasteners and may
have special coatings.
• Many nuts are of the Nylock type. They have a plastic insert to help prevent loosening.
WARNING
1. Use of improper fasteners may cause the chair to fail.
2. Over- or under-tightened fasteners may fail or cause damage to chair parts.
3. If bolts or screws become loose, tighten them as soon as you can. Loose bolts
or screws can cause damage to other chair parts causing them to fail.
3. Washers & Spacers:
• Note the position of washers and spacers before disassembly.
• To avoid damage to the frame, replace all washers and spacers when you reassemble
parts.
4. Torque Settings:
•A torque setting is the optimal tightening for a particular fastener. Use a torque wrench
that measures 120 inch-pounds to secure screws, nuts and bolts on this chair.
Q-NOTE– Unless otherwise noted, use a torque setting of 120 inch-pounds for all fasteners.
TOOLS YOU WILL NEED
1. Basic Tool Kit:
To set-up, adjust and maintain your chair you will need the following tools:
•3mm Allen Wrench •13mm Socket Wrench •7/16" box and open-end wrench
•5mm Allen Wrench •16mm Open-end Wrench •1/2" box and open-end wrench
•6mm Allen Wrench •19mm Open-end Wrench •3/4" box and open-end wrench
•8mm Allen Wrench •Flat Head Screwdriver •5/32" Allen wrench
•13mm Open-end Wrench•Phillips screwdriver #2 •Custom axle wrench
•17mm Socket Wrench •Standard Tools
You can obtain a multi-purpose tool kit from Sunrise, or buy the tools you need from a hardware store.
2. Torque Wrench:
If you plan to adjust and maintain this chair yourself, Sunrise recommends that you use a
torque wrench.
Q-NOTE– The wrench must measure inch-pounds. You can buy a torque wrench and proper sockets
from a hardware store.

932213 Rev. C
15
ENGLISH VIII.
A. BATTERY REMOVAL (Figures 1, 2 & 3)
T
o remove the batteries for transporting or servicing:
1. Remove Batteries
a. Remove seat following instructions in section “C. Power Base Seat Removal.”
b. Remove battery access panel by inserting a flat head screw driver between the panel
and main shroud toward the back of the panel at the word “open”.
c. Push the screw driver forward until the panel lifts off.
d. Unplug and remove batteries from rear of chair.
e. Lift up batteries by lifting up on battery straps.
2. Battery Installation
See Section XI. Batteries, D for installation and wiring diagram.
WARNING
Batteries may weigh up to 55 lbs. Care must be taken to avoid injury when lift-
ing up on battery straps.
B. POWER BASE SEAT HEIGHT ADJUSTMENT
(Figure 4–Mount for power tilt shown)
1. Remove pins (A) from all four seat mount posts.
2. Select the desired seat height (rear seat mount should never be more then one posi-
tion lower then the front).
3. Reinsert the pins.
WARNING
Ensure both front seat posts are positioned to the same height. Rear seat posts
should also be set to the same height.
C. POWER BASE SEAT REMOVAL (Seat Frame)
1. Remove Seat
(Figures 5 & 6)
a. Remove safety lock-out pin (B).
b. Pull the two seat release levers upward
c. Tilt seat backward slightly
d. Pull the forward seat and remove.
e. When replacing the seat into the mounts, ensure you do not pinch your fingers.
4
A
5
6
B
1
2
3

932213 Rev. C 16
ENGLISH VIII.
D. POWER BASE SHROUD REMOVAL
The plastic protective shroud can be removed for adjustment or servicing.
1. Remove Colored Shroud
T
wo removable colored shroud covers are Velcro®-ed on to the sides of the main shroud. T o
remove, simply peel the colored shroud off of the main shroud as shown in Figure 7.
2. Remove Main Shroud
a. Remove both brake releases by unscrewing the front connection and pulling them out.
(Figure 8)
b. Lift the middle shroud assembly off.
3. Replace Main Shroud
Replace shroud by reversing above instructions.
E. CHECK-OUT
Once the wheelchair is assembled and adjusted, it should roll smoothly and easily. All acces-
sories should also perform smoothly.
After the wheelchair has been set up be sure the chair performs to your specified operational
settings (see Operating Guide). If the chair does not perform to specifications, turn the wheel-
chair OFF immediately and reprogram operational specifications using the Quickie Hand Held
Programmer.
Repeat this procedure until the wheelchair performs to specifications before
attempting active use of the wheelchair.
If you have any problems, follow these procedures:
1. Review the Set-up, Adjustment & Use section and Operating Guide to make sure chair
was properly prepared.
2. If your problem persists, contact your authorized supplier. If you still have a problem
after contacting your authorized supplier, contact Sunrise customer service. See the
introduction page for details on how to contact your authorized supplier or Sunrise
customer service.
WARNING
When properly set up, this chair will operate smoothly. Check to see that all
components work properly. If you detect a problem, be sure to correct it
before use.
7
8

932213 Rev. C
17
ENGLISH VIII.
F. BACKREST
1. To Secure The Backrest For Operation:
a) Lift backrest to upright position.
b) When secured, backrest pin will lock into place.
Q-NOTE– Zippie series wheelchairs are shipped with the backrest in a folded position.
G. SWING-AWAY HANGERS (60º, 70º, or 90º)
(Fig. 9)
1. Attaching/Removal
a) Place swing-away pivot saddle (A) into the receiver on front frame tube with the
footrest facing outward from the frame.
b) Rotate the footrest inward until it locks into place on locking bolt.
c) To remove hanger, push release latch (B) toward the frame, rotate footrest outward,
and lift.
H. ARTICULATING LEGREST (Optional)
(Fig. 10)
1. Attaching/Removal
a) Place swing-away pivot saddle (A) into the receiver on front frame tube with the
footrest facing outward from the frame.
b) Rotate the footrest inward until it locks into place on locking bolt.
c) To remove hanger, push release latch (B) toward the frame, rotate footrest outward,
and lift.
2. Elevating
a) To raise legrest, lift to desired position. Legrest will automatically lock in place.
b) To lower legrest, while seated in chair hold lever (C) down, lower legrest to desired
position, then release lever. Legrest will automatically lock in place.
I. ELEVATING AND 90º ELEVATING LEGRESTS (Optional)
(Fig. 11)
1. Attaching/Removal
a) Place swing-away pivot saddle (A) into the receiver on front frame tube with the
footrest facing outward from the frame.
b) Rotate the footrest inward until it locks into place on locking bolt.
c) To remove hanger, push release latch (B) toward the frame, rotate footrest outward,
and lift.
2. Elevating
a) To raise legrest, lift to desired position. Legrest will automatically lock in place.
b) To lower legrest, while seated in chair hold lever (C) down, lower legrest to desired
position, then release lever. Legrest will automatically lock in place.
Articulating Legrest
Swing-Away Hanger
90º Elevating Legrest
B
A
C
B
A
9
B
A
C10
11

932213 Rev. C 18
ENGLISH VIII.
J. COMPOSITE FOOTPLATE (Fig. 12)
1. Height Adjustment
a) Remove retaining bolts in the frame tube (A).
b) Slide footplate and extension tubes to desired height.
c) Left and right footrest will normally be at equal height.
d) Replace and tighten bolts.
K. KIDS & ADULT ANGLE ADJUSTABLE FOOTPLATE
(Figs. 13 & 14)
1. Height Adjustment (Fig. 13)
a) Remove the retaining bolt from the frame tube (A).
b) Move footplate assembly to desired height.
c) Left and right footrest will normally be at equal height.
d) Replace and tighten bolt.
2. Angle Adjustment (Fig. 14)
a) Loosen fasteners (B) until the adjustable clamp and footplate rotate freely on the
mounting tube.
b) Adjust the angle of the footplate.
c) Tighten nuts.
3. Position Adjustment (Fig. 14)
a) Remove footplate fasteners (B).
b) Move footplate to the desired location.
c) Replace and tighten fasteners.
L. ALUMINUM FOOTPLATE (Fig. 15)
1. Height Adjustment
a) Remove set screws (A) from frame tube.
b) Slide footplate to desired height.
c) The adjustment on each side of the footrest will normally be of equal height.
d) Replace and tighten set screws.
M. 90º FOOTBOARD (Fig. 16)
1. Height Adjustment
a) Loosen the nuts on the footplate clamp assembly (A).
b) Slide footplate clamps to desired height.
c) Tighten nuts.
2. Angle Adjustment
a) Loosen nuts under the footplate assembly (B) until the adjustable clamp rotates freely
on the supporting tube.
b) Adjust the angle of the footplate.
c) Slide it forward or back for
correct placement.
d) Tighten nuts.
3. Removing Footboard
a) Unscrew the lock knobs (C) and lift out of clamp assembly.
Composite Footplate
A
Angle Adjustable
Footplate
A
Footplate Angle &
Position Adjustment
B
Aluminum Footplate
A
90º Footboard
A
B
C
12
13
14
15
16

932213 Rev. C
19
ENGLISH VIII.
N. PLATFORM FLIP-UP FOOTPLATE (Fig. 17)
1. Height Adjustment
a) Remove retaining bolts in the frame tube (A).
b) Slide footplate and extension tubes to desired height.
c) The adjustment on each side of the footrest should be of equal height.
d) Replace and tighten bolts.
2. Angle Adjustment
a) Loosen the nuts under the footplate clamp (B) until the adjustable clamp and footplate
rotate freely on the mounting tube.
b) Adjust the angle of the footplate.
c) Tighten nuts.
O. HEIGHT-ADJUSTABLE ARMRESTS (Optional) (Fig. 18)
1. Installation
a) Slide the outer armpost into the receiver mounted to the wheelchair frame.
b) The armrest should lock in place automatically.
2. Removing Armrest
a) Press release lever (A) and remove the armrest.
Q-NOTE– Release lever should move freely. Do not force or over rotate.
3. Height Adjustment
a) Rotate release lever (A) to second stop.
Q-NOTE– Release lever should move freely. Do not force.
b) Slide armrest pad up or down.
c) Return lever to locked position against armpost.
d) Push arm pad until upper armpost locks firmly into place.
e) A snap lock is engaged if the armrest is raised to its highest adjustment. To disconnect
the snap lock, press in on the button head and press the armrest down.
4. Replacing Armrest
a) Slide armrest back into receiver until it stops.
Q-NOTE– Check to make sure release lever is engaged by pulling up on armrest.
5. Adjusting Armrest Receiver Fit
To tighten or loosen the fit of the outer armpost in the receiver:
a) Loosen the four bolts on the side of the receiver.
b) With the armrest in the receiver, squeeze the receiver to achieve the desired fit.
c) Tighten the four bolts.
6. Adjusting Inner Armpost Fit
a) Two set screws (C) are installed in the outer armpost.
b) Turn the set screws in or out until the desired fit is achieved.
P. JOYSTICK & ENHANCED DISPLAY (Figs 19, 20, 21, 22)
1. To Connect (Fig. 21)
a. Line up the groove on the joystick cable (A) with the groove on the wing of the wheel-
chair cable (B).
b. Push the connectors together and then turn the wing of the wheelchair cable until the
two wings line up (C).
2. To Disconnect (Fig. 22)
a. Turn the wing (D) so that both the groove on the wing of the wheelchair cable and the
groove on the joystick cable line up.
b. Pull apart the two connectors.
Platform Flip-up
Footplate
B
A
Height Adjustable
Armrest
A
B
C
AB
C
D
Enhanced Display
Qr3 Remote Joystick
17
18
19
20
21
22

932213 Rev. C 20
ENGLISH VIII.
Q. TO ADJUST THE HEIGHT OF THE JOYSTICK
OR ENHANCED DISPLAY (Fig. 23)
1. Loosen the two Socket Head screws (E).
2. Slide the clamp (F) up or down until in desired position.
3. Retighten the two Socket Head Screws (E).
R. JOYSTICK OR ENHANCED DISPLAY SWING-AWAY
RETRACTABLE MOUNT (Optional) (Fig. 24)
The joystick or Enhanced Display is mounted with a mechanism which allows the control to
be locked in a forward or retracted position using magnets.
Adjustment
a. To retract the joystick or Enhanced Display, push outward on the inside of joystick.
b. Push the joystick or Enhanced Display away from front of armrest until it locks into
retracted position.
c. To return to forward position, push the joystick or Enhanced Display forward until it
locks into place.
S. WHEEL LOCKS
Zippie wheelchairs are shipped with wheel locks. Wheel locks are installed at Sunrise unless
you have requested otherwise.
Use a torque setting of 100 in./lbs when setting-up wheel locks.
1. Wheel Lock
a. Loosen the screws on the top of each clamp. Do not attempt to remove one screw at
a time.
b. Slide assembly toward drive wheel until clamp embeds into tire to prevent wheel
movement when in locked position.
c. Adjust angle position.
d. Tighten screws.
T. ANTI-TIP TUBES - REAR (Manual carrier) (Fig. 25)
1. To Insert Anti-Tip Tubes into Receivers
a) Press the anti-tip release button on the anti-tip tube so that the release pin is drawn
inside.
b) Insert the tube into the anti-tip receiver.
c) Turn the anti-tip tube until release pin is positively engaged in the receiver mounting
hole.
d) Insert second anti-tip tube the same way.
2. To Adjust Anti-Tip Height
a) Press the anti-tip wheel release button (A) so the release pin is drawn inside.
b) Raise or lower to one of the three pre-drilled holes.
c) Turn the anti-tip tube until release pin is positively engaged in the receiving hole (B).
d) Adjust the second anti-tip tube wheel the same way. Both wheels should be exactly the
same height.
U. SEAT REMOVAL (Figs. 26 & 27)
1. Disconnect joystick.
2. Pull out the safety pin from the left front seat post (Fig. 26).
3. Lift up on both front seat latches (Fig. 27).
4. Tilt the seat back, slide it forward, and remove from the base.
Anti-Tip Height
A
B
EF
23
24
25
26
27
