Ziton ZP755V Assembly instructions

© 2014 UTC Fire & Security. All rights reserved. 1 / 4 P/N 501-1782ZE-1-07 • REV 07 • ISS 23JAN14
ZP755V Addressable Visual Indicator
Installation Sheet
Description
The ZP755V is an addressable visual indicator designed for
use in Ziton analogue addressable fire detection and alarm
systems. The visual indicator provides visual warnings from a
single, addressable, loop-wired unit.
Note: The visual indicator of this product does not comply with
EN 54-23 and must not be used in fire alarm installations
where fire notification beacons are required.
The visual indicator includes an address-setting switch and a
pair of jumpers to select the operating power — from the
analogue addressable loop or an external supply. See Table 1
for a list of models.
Table 1: Models
Model Description
Visual indicator
ZP755V-W
ZP755V-P
Visual indicator, White
Visual indicator, Polar white
Base
ZP7-SSB-W
ZP7-SSB-P
Base, White
Base, Polar white
Installation
To install the visual indicator;
1. Wire the base
2. Set the operating power
3. Set the address
4. Set the device mode
5. Mount the visual indicator onto the base
The details of each step are given below.
Wiring the base
Connect loop wiring for the base as shown in Figure 1. There
is no wiring between the visual indicator and base. The base is
supplied separately.
Figure 1: Loop wiring for the plug-in base
1. Ext. 24 VDC+ IN/OUT
4. Ext. 24 VDC ground IN/OUT
5. Loop+ IN/OUT
7. Shield
8. Loop− IN/OUT
Setting the operating power
The visual indicator includes a pair of power selection jumpers,
J1 and J2. To select the source of the sounder operating
power, position the jumpers as shown in Figure 2.
Figure 2: Power selection jumper configuration
1. Loop powered 2. External 24 VDC
Note: When using an external power supply, use only one that
is CE and EN 54-4 compliant to power all the visual indicators
on the same loop.
3498 01
4
7
8
1
5
24V
0V
EXT
POWERED
24V
0V
EXT
POWERED EXT POWERED
LINE
POWERED
LINE
POWERED

2 / 4 P/N 501-1782ZE-1-07 • REV 07 • ISS 23JAN14
Setting the address
The visual indicator includes an eight-segment DIP switch
(SW1). Switch SW1-1 though SW1-7 are used to assign device
addresses. Each switch segment has a decimal value as
shown in Figure 3. The address is the sum of all the switch
segments (SW1-1 though SW1-7) in the ON position. The
switch may be set to represent any address from 1 to 127.
For example, to select a device address of 007, set SW1-1,
SW1-2, and SW1-3 to the ON position and the remaining
switch segments to the OFF position.
Figure 3: Address switch setting
1. Device mode
Setting the device mode
SW1-8 selects whether the visual indicator operates as a
stand-alone visual indicator or in ZP755 sounder emulation
mode as described in Table 1. Refer to Figure 3.
Table 1: SW1-8 mode selection switch
Mode SW1-8 Output Signal Requirement
ZP755V OFF Stand-alone
visual indicator This setting is not currently supported
ZP755
emulation ON ZP755 sounder ZP3 panel
Mounting the visual indicator onto the base
Align the addressable visual indicator to the plug-in base. Push
up, and then turn the visual indicator until it clicks into place.
Push the visual indicator up once more to engage.
Note: To prevent unauthorized removal, a plastic breakout tab
is provided in the addressable visual indicator housing. Once
the breakout tab is removed, the sensor can only be released
by use of a small flat screwdriver.
Visual indicators per loop
The visual indicator can be powered directly from the loop of a
ZP3 panel. Use Figure 4, in conjunction with Table 2, to
determine the quantity of detectors and visual indicators that
can be connected to a two-core shielded loop.
Figure 4: Visual indicators per loop
A. Cable length panel to first visual indicator
B. Cable length first to last visual indicator
C. Cable length last visual indicator to panel
1. Detectors and visual indicators
Table 2: Maximum detectors and visual indicators per loop
A B C Quantity allowed [1]
10 m 980 m 10 m 60 detectors and 60 visual
indicators
80 detectors and 40 visual
indicators
100 m 800 m 100 m 60 detectors and 60 visual
indicators
80 detectors and 40 visual
indicators
200 m 600 m 200 m 60 detectors and 60 visual
indicators
80 detectors and 40 visual
indicators
300 m 400 m 300 m 60 detectors and 60 visual
indicators
80 detectors and 40 visual
indicators
[1] Using a two-core shielded loop of 1000 meters cable size 1.5 mm²
ON
1234567
OFF
ON
DIPSWITCH
1 2 4 8 16 32 64
8
12 8 41632
64 1

P/N 501-1782ZE-1-07 • REV 07 • ISS 23JAN14 3 / 4
Specifications
Operating voltage
External supply
Loop supply, ZP protocol
18 to 30 VDC
19.5 to 20.5 V pulsed, max. 4 V line loss
Current (line powered)
Quiescent (RMS)
Alarm (RMS)
Alarm maximum start of
flash
400 μA
2.5 mA
9 mA
Current (externally powered)
Quiescent (RMS)
Alarm (RMS)
Maximum number
350 μA
360 μA
60 per 1 km loop (subject to cable
size and visual indicator spacing)
Light output Equivalent to 1J xenon element
Strobe frequency Flash rate 1.1 seconds
Monitoring
ZP loop Operating power level tested
continuously
Compatibility Compatible with ZP3 panels only
Addressing method 8-segment DIP switch
Mounting Surface with stand-alone visual
indicator base
Wiring Two-core shielded loop
Construction
Material
Colour
Weight
Dimensions (Ø × D)
Moulded thermoplastic
White, polar white
95 g
106 × 49 mm
Operating environment
Temperature
Relative humidity
−10 to +60°C
10 to 95% noncondensing
Storage temperature −20 to +70°C
Regulatory information
Certification
Product Identification ZP755V
Manufacturer Gulf Security Technology Co.,Ltd
80, Changjiang East Road,
QETDZ, Qinhuangdao,
Hebei Province, China 066004
Authorized EU manufacturing
representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert,
Netherlands
European Union directives 1999/5/EC (R&TTE directive): Hereby,
UTC Fire & Security declares that this
device is in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
2002/96/EC (WEEE directive): Products
marked with this symbol cannot be
disposed of as unsorted municipal waste
in the European Union. For proper
recycling, return this product to your local
supplier upon the purchase of equivalent
new equipment, or dispose of it at
designated collection points. For more
information see: www.recyclethis.info.
Contact information
For contact information, see www.utcfssecurityproducts.eu.
