ZOLL aed pro Manual

AED Pro®
AED Pro®A-W
Operator’s Guide
9650-0350-01 Rev. J

This issue date for the ZOLL AED Pro Operator’s Guide, (REF 9650-0350-01 Rev J) is October, 2012.
If more than three years have elapsed since this date, contact ZOLL Medical Corporation to determine if
additional product information updates are available.
Copyright © 2012 ZOLL Medical Corporation. All rights reserved. AED Plus, AED Pro, CPR-D-padz, M
Series, pedi-padz, PowerCharger, Real CPR Help, Rectilinear Biphasic, RescueNet, See-Thru CPR, stat-
padz, SurePower and ZOLL are trademarks or registered trademarks of ZOLL Medical Corporation in the
United States and/or other countries.
All other trademarks and registered trademarks are property of their respective owners.
0123
ZOLL Medical Corporation
269 Mill Road
Chelmsford, MA USA
01824-4105
ZOLL International Holding B.V.
Newtonweg 18
6662 PV ELST
The Netherlands

9650-0350-01 Rev. J ZOLL AED Pro Operator’s Guide i
Table of Contents
Chapter 1 Product Overview
Defibrillation........................................................................................................................1-2
Defibrillation Modes ....................................................................................................1-2
Semiautomatic Mode Defibrillation and CPR Monitoring....................................................1-2
Manual Mode Defibrillation.................................................................................................1-3
ECG Monitoring ..................................................................................................................1-3
Audio Recording.................................................................................................................1-4
Nonrescue Mode ................................................................................................................1-5
Data Transfer ..............................................................................................................1-5
Device Configuration ..................................................................................................1-5
Standby State......................................................................................................................1-5
Automatic Shutoff................................................................................................................1-5
Accessories ........................................................................................................................1-6
A-W Accessories ........................................................................................................1-7
The Front Panel..................................................................................................................1-8
Display Screen ..........................................................................................................1-10
Chapter 2 Getting Started
Installing a Battery Pack.....................................................................................................2-2
CHANGE BATTERY Warning ....................................................................................2-4
Preparing the Unit for Clinical Use......................................................................................2-5
Performing a Self-Test ........................................................................................................2-6
Automatic Self-Tests ...................................................................................................2-6
Manual Self-Test .........................................................................................................2-6
Preconnecting the Defibrillation Electrodes Cable..............................................................2-7
Messages ...........................................................................................................................2-8
Chapter 3 Semiautomatic Mode
Applying Defibrillation Electrode Pads................................................................................3-2
Applying Defibrillation Electrode Pads — Adult CPR-D•padz.....................................3-3
Applying Defibrillation Electrode Pads — Adult CPR stat•padz.................................3-5
CPR Monitoring with CPR-D•padzand CPR stat•padz..............................................3-6
Applying Defibrillation Electrode Pads — Adult stat•padz II .......................................3-7
Applying Defibrillation Electrode Pads — Infant/Child pedi•padzII............................3-8
Semiautomatic Defibrillation ...............................................................................................3-9
Start with CPR Option ...............................................................................................3-12
Messages in Semiautomatic Mode ...........................................................................3-12

TABLE OF CONTENTS
ii www.zoll.com 9650-0350-01 Rev. J
Chapter 4 Manual Mode
About Manual Mode............................................................................................................4-2
Switching to Manual Mode..................................................................................................4-3
Manual Defibrillation ...........................................................................................................4-4
See-Thru CPR ....................................................................................................................4-5
Messages in Manual Mode...............................................................................................4-10
Chapter 5 ECG Monitoring Mode
About ECG Monitoring........................................................................................................5-2
ECG Electrode Placement..................................................................................................5-3
Applying ECG Electrodes...................................................................................................5-4
Monitoring the ECG Rhythm...............................................................................................5-6
Monitoring with ECG Electrodes .................................................................................5-6
Monitoring with Defibrillation Electrodes .....................................................................5-7
Messages in ECG Monitoring Mode...................................................................................5-8
Chapter 6 Nonrescue Mode
Entering Nonrescue Mode..................................................................................................6-2
Data Storage.......................................................................................................................6-3
Device History .............................................................................................................6-3
Patient Clinical Data ...................................................................................................6-3
Communicating with an External Device ............................................................................6-4
Setting Up Data Communications with an IrDA Connection .......................................6-4
Downloading Data to a USB Device ...........................................................................6-4
Setting the Date and Time..................................................................................................6-5
Device Configuration ..........................................................................................................6-6
ZOLL Administration Software............................................................................................6-6
Installing ZOLL Administration Software .....................................................................6-6
RescueNet Code Review Software ............................................................................6-7
Messages in Nonrescue Mode...........................................................................................6-8
Chapter 7 Troubleshooting and Maintenance
General Troubleshooting ....................................................................................................7-2
ECG Monitoring Troubleshooting........................................................................................7-4
Defibrillator Troubleshooting...............................................................................................7-5
Cleaning the Unit ................................................................................................................7-6
Optional Maintenance for Technical Professionals.............................................................7-7
Appendix A Specifications
Device Specifications..........................................................................................................A-2

9650-0350-01 Rev. J ZOLL AED Pro Operator’s Guide iii
Battery Pack Specifications ................................................................................................A-5
Guidance and Manufacturer’s Declaration — Electromagnetic Emissions.........................A-6
Electromagnetic Immunity Declaration (EID) ..............................................................A-7
Rectilinear Biphasic Waveform Characteristics................................................................A-10
Clinical Trial Results for the M Series Biphasic Waveform...............................................A-13
Randomized Multicenter Clinical Trial for Defibrillation of Ventricular Fibrillation
(VF) and Ventricular Tachycardia (VT) .....................................................................A-13
ECG Analysis Algorithm Accuracy....................................................................................A-15
Appendix B Rechargeable Battery Packs
Managing Rechargeable Battery Packs .............................................................................B-2
Recharging and Testing Battery Packs...............................................................................B-2
Achieving Optimal Performance with Rechargeable Batteries...........................................B-3
Appendix C Configurable Settings
Descriptions of AED Pro Configurable Settings..................................................................C-2

TABLE OF CONTENTS
iv www.zoll.com 9650-0350-01 Rev. J

9650-0350-01 Rev. J ZOLL AED Pro Operator’s Guide v
Preface
The AED Pro®and AED Pro®A-W from ZOLL Medical Corporation is a portable, automated
external defibrillator (AED) intended for use by trained rescuers to provide emergency
defibrillation and to monitor patient ECG during treatment.
This Preface contains the following sections:
•“How To Use This Guide” on page vi
•“Safety Considerations” on page vii
•“Equipment” on page xi
•“Intended Use” on page xvi

PREFACE
vi www.zoll.com 9650-0350-01 Rev. J
How To Use This Guide
The AED Pro Operator’s Guide provides information that operators need for the safe and
effective use and care of the AED Pro device. Before operating this device, be sure to read and
understand all the information contained within.
This guide also describes device setup and maintenance procedures.
Separate chapters in this document describe use of the device in either semiautomatic or
manual mode.
Manual Updates
ZOLL Medical Corporation provides manual updates to inform customers of changes in device
information and use. Customers should carefully review each update to understand its
significance, and then file the update in its appropriate section within the manual for subsequent
reference.
Product documentation is available through the ZOLL website at www.zoll.com. From the
Products menu, choose Product Documentation.
Related Manuals
In addition to this manual, the following ZOLL publications provide information about this
product and related products and accessories:
Conventions
This guide uses the following conventions:
Within text, the names and labels for physical buttons and softkeys appear in boldface type (for
example, “Press the Shock button or the DISARM softkey”).
This guide uses uppercase italics for audible prompts and for text messages displayed on the
screen (for example, DON’T TOUCH PATIENT, ANALYZING).
WARNING! Warning statements alert you to conditions or actions that can result in personal injury
or death.
Caution Caution statements alert you to conditions or actions that can result in damage to the unit.
REF Title
9650-0054-01 ZOLL Base PowerCharger 4x4 Operator’s Manual
9650-0120-01 ZOLL Base PowerCharger 1x1 Operator’s Manual
9651-0801-01 AED Pro Simulator Operator’s Guide
9650-0535-01 SurePower™ Charger Station Operator’s Guide
9650-0536-01 SurePower Battery Pack Guide

Safety Considerations
9650-0350-01 Rev. J ZOLL AED Pro Operator’s Guide vii
Safety Considerations
All operators should review these safety considerations before placing the AED Pro unit into
service.
These operating instructions describe the functions and proper operation of the AED Pro unit.
This manual does not substitute for a formal training course. Operators must obtain formal
training from an appropriate authority before using this device for patient care.
Follow all recommended maintenance instructions. If a problem occurs, obtain service
immediately. Do not use the device until it has been inspected by appropriate personnel.
Do not disassemble the unit. A shock hazard exists. Refer all problems to authorized service
personnel.
The AED Pro unit is capable of delivering 200 joules. To completely deactivate the unit, turn it
off and remove the battery pack.
To manually disarm a charged (or charging) defibrillator, do one of the following:
•Turn the unit off for at least 3 seconds.
•Press the DISARM softkey (manual mode only).
For safety, the AED Pro unit automatically disarms a fully charged defibrillator after
60 seconds in manual mode or 30 seconds in semiautomatic mode if the Shock button is not
pressed.
General
Federal (U.S.A.) law restricts this device to use by or on the order of a physician.
Proper operation of the unit and correct electrode placement are critical to obtaining optimal
results. Operators must be thoroughly familiar with proper device operation.
The use of external defibrillation electrodes or adapter devices from sources other than ZOLL
is not recommended. ZOLL Medical Corporation makes no representations or warranties
regarding the performance or effectiveness of its products when used with defibrillation
electrodes or adapter devices from other sources. Device failures attributable to the use of
defibrillation electrodes or adapters not manufactured by ZOLL might void the warranty on the
ZOLL equipment.
This device is protected against interference from radio frequency emissions typical of the
two-way radios and cellular phones (digital and analog) used in emergency service or public
safety activities. You should assess the device’s performance in your typical operating
environment to determine the likelihood of radio frequency interference (RFI) from high-power
sources. Radio frequency interference can cause shifts in the monitor baseline, trace
compression, changes to brightness of the display, or transient spikes on the screen.
The AED Pro unit might not perform to specifications when stored at the upper or lower
extreme limits of storage temperature and then immediately put into use.
Do not use or stack the unit with other equipment. If the unit is used or stacked with other
electrical equipment, verify proper operation before using it.
Do not use or place the unit in service if it beeps while turned off.
The use of accessories or cables other than those specified in this manual may result in
increased emissions or decreased immunity of the AED Pro.

PREFACE
viii www.zoll.com 9650-0350-01 Rev. J
Do not use or place the unit in service if the Ready indicator (at the upper right of the front
panel) shows a red “X”.
Defibrillation
Emergency defibrillation should be performed only by appropriately trained, skilled personnel
who are familiar with the operation of the equipment. The prescribing physician should
determine what training, such as Advanced Cardiac Life Support (ACLS) or Basic Life Support
(BLS) certification, is appropriate for operating this device.
ECG analysis
A patient must be motionless during ECG analysis. Do not touch the patient during analysis.
Cease all patient movement by stretcher or vehicle before beginning ECG analysis in
semiautomatic mode.
Cardiopulmonary resuscitation (CPR)
Before performing CPR, place the patient on a firm surface.
Battery care
Keep a fully charged spare battery pack with the device at all times.
When the unit displays the message CHANGE BATTERY, immediately replace the battery pack
with a fully charged one.
Regular use of a partially charged battery pack without fully recharging it between uses might
permanently reduce the battery’s capacity and result in early failure.
Regularly test rechargeable battery packs. A rechargeable battery pack that does not pass its test
could fail without warning.
Do not disassemble a battery pack or dispose of it in fire. Do not try to recharge a
nonrechargeable battery pack. If mistreated, a battery pack might explode.
Dispose of battery packs in accordance with federal, state, and local regulations. Battery packs
should be shipped to a reclamation facility for recovery of metal and plastic compounds as the
proper method of waste management.
Operator Safety
Do not use the unit near oxygen-rich atmospheres, flammable anesthetics, or other flammable
agents (such as gasoline).
Do not use the unit within standing water.
Before discharging the defibrillator, warn everyone to stand clear of the patient.
Do not discharge the defibrillator except as indicated in the instructions. Discharge the
defibrillator only when defibrillation pads are properly attached to the patient. Never discharge
the unit with the defibrillation pads shorted together or in open air.
