ZOLL Propaq M User manual

Propaq
®
M Service Manual
9650-0804-01 Rev. ADecember 2010

ZOLL is a registered trademark, and SurePower is a trademark of ZOLL Medical Corporation. Propaq is a
registered trademark of Welch Allyn, Inc. Nellcor is a trademark of Covidien. Oridion, Microstream, and
FilterLine are registered trademarks of Oridion Systems, Ltd. All other trademarks and registered trademarks
are property of their respective owners.
Copyright © 2010
ZOLL Medical Corporation. All rights reserved.

9650-0804-01 Rev. A ZOLL Propaq M Service Manual i
Table of Contents
Preface
Overview................................................................................................................................ 1
Safety Considerations............................................................................................................ 2
Additional Reference Material................................................................................................ 2
Conventions........................................................................................................................... 3
Service Policy Warranty.........................................................................................................3
Technical Service................................................................................................................... 3
Technical Service for International Customers ......................................................................4
Chapter 1 Maintenance Tests
Propaq M Overview...............................................................................................................5
Calibration and Calibration Checks .......................................................................................7
NIBP Valve, Pump, and Tubing Integrity Tests .....................................................................11
Operational Tests................................................................................................................. 14
Functional Verification Tests ................................................................................................ 21
Chapter 2 Troubleshooting
Overview.............................................................................................................................. 33
Propaq M Error Messages...................................................................................................33
Chapter 3 Disassembly Procedures
Overview.............................................................................................................................. 41
Required Equipment............................................................................................................ 41
Safety Precautions............................................................................................................... 42
Modules ............................................................................................................................... 42
Removing the Handle .......................................................................................................... 43
Disassembling the Main Unit ............................................................................................... 44
Removing the Front Enclosure Module ............................................................................... 47
Removing the Display Module............................................................................................. 49
Removing the EtCO2 and NIBP Modules............................................................................ 51
Removing the Monitor Board and SpO2 Modules ............................................................... 55
Chapter 4 Life Cycle Counters
Overview.............................................................................................................................. 57

TABLE OF CONTENTS
ii 9650-0804-01 Rev. A
Chapter 5 Replacement Parts
Overview.............................................................................................................................. 59
Replacement Parts ..............................................................................................................60
Chapter 6 Functional Description
Overview.............................................................................................................................. 63
Appendix A
Overview.............................................................................................................................. 67
Propaq M Electrical Hardware Interconnect Diagram.......................................................... 68
Propaq M Signal and Power Interconnect Schematic..........................................................69
Appendix B
Overview.............................................................................................................................. 71

9650-0804-01 Rev. A ZOLL Propaq M Service Manual 1
Preface
Overview
ZOLL®Medical Corporation’s Propaq®M Service Manual is intended for the trained
biomedical technician whose responsibility is to identify malfunctions and/or make repairs at
the subassembly level. The Propaq M Service Manual has six main sections and two
appendixes.
Preface—Contains safety warnings and an overview of the manual’s contents. Be sure to
review this section thoroughly before attempting to use or service the Propaq M unit.
Chapter 1—Maintenance Tests describes the Annual Calibration Tests for NIBP and EtCO2
modules, Functional Tests that need to be run when a module has been repaired, and
Operational Tests that need to be performed at regular intervals to augment the automatic
testing the Propaq M does to ensure readiness.
Chapter 2—Troubleshooting provides a listing of error messages to help the service
technician detect faults and repair them.
Chapter 3—Disassembly Procedures describes step-by-step procedures for removing
subassemblies from the Propaq M unit.
Chapter 4—Life Cycle Counters describes step-by-step procedures for setting life cycle
counters after replacing modules in the Propaq M unit.
Chapter 5—Replacement Parts List displays a complete list of ZOLL part numbers for field
replaceable parts available for the Propaq M unit, allowing the service person to identify and
order replacement parts from ZOLL.

PREFACE
29650-0804-01 Rev. A
Chapter 6—Functional Description provides technical descriptions for the Propaq M major
subassembly modules.
Appendix A—Propaq M Electrical Hardware Interconnect Diagram and Propaq M Signal and
Power Interconnect Schematic.
Appendix B—Contains simulators and settings that may be used to assess the performance of
the NIBP module.
Safety Considerations
The following section describes general warnings and safety considerations for operators and
patients. Service technicians should review the safety considerations prior to servicing any
equipment and read the manual carefully before attempting to disassemble the unit. Only
qualified personnel should service the Propaq M unit.
Federal (U.S.A.) law restricts this unit for use by or on the order of a physician.
Safety and effectiveness data submitted by ZOLL Medical Corporation to the Food and Drug
Administration (FDA) under section 510(K) of the Medical Device Act to obtain approval to
market is based upon the use of ZOLL accessories such as patient cables and batteries.
Only qualified personnel should disassemble the Propaq M unit.
Do not discharge a battery pack except in a ZOLL SurePowerTM Charging Station.
Do not use the Propaq M in the presence of flammable agents (such as gasoline), oxygen-rich
atmospheres, or flammable anesthetics. Using the unit near the site of a gasoline spill may
cause an explosion.
Do not use the unit near or within puddles of water.
Additional Reference Material
In addition to this guide, there is a Propaq M Operator’s Guide which is a comprehensive
reference work that describes all the user tasks needed to operate the Propaq M.

Conventions
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 3
Conventions
WARNING! Warning statements describe conditions or actions that can result in personal injury or death.
Caution Caution statements describe conditions or actions that can result in damage to the unit.
Note: Notes contain additional information on using the monitor.
Service Policy Warranty
In North America: Consult your purchasing agreement for terms and conditions associated with
your warranty. Outside of North America, consult ZOLL authorized representative.
In order to maintain this warranty, the instructions and procedures contained in this manual
must be strictly followed. For additional information, please call the ZOLL Technical Service
Department 1-800-348-9011 in North America.
Technical Service
If the ZOLL Propaq M unit requires service, contact the ZOLL Technical Service Department:
Telephone: [phone]
Fax [phone]
Have the following information available for the Technical Service representative:
•Unit serial number.
•Description of the problem.
•Department where equipment is used.
•Sample chart recorder strips or electronic log files documenting the problem, if applicable.
•Purchase Order to allow tracking of loan equipment.
•Purchase Order for a unit with an expired warranty.
If the unit needs to be sent to ZOLL Medical Corporation, obtain a service request number
(SR#) from the Technical Service representative. Return the unit in its original container to:
ZOLL Medical Corporation
269 Mill Road
Chelmsford, Massachusetts 01824-4105
Attn: Technical Service Department (SR#)
Telephone: [phone] FAX: [phone]

PREFACE
49650-0804-01 Rev. A
Technical Service for International Customers
International customers should return the unit in its original container to the nearest authorized
ZOLL Medical Corporation Service Center. To locate an authorized service center, contact the
International Sales Department at ZOLL Medical at the above address.

9650-0804-01 Rev. A ZOLL Propaq M Service Manual 5
Chapter 1
Maintenance Tests
Propaq M Overview
This chapter includes step-by-step procedures for the following types of maintenance tests:
•Calibration and Calibration Checks
•NIBP Valve, Pump, and Tubing Integrity Tests
•Operational Tests
•Functional Verification Tests
At a minimum, a trained biomedical technician must perform a CO2calibration and an NIBP
calibration check once per year. A CO2calibration check may be performed at any time to
verify the CO2calibration.
The Troubleshooting chapter in this manual may recommend performing one of more of the
NIBP valve, pump, and tubing integrity tests to help identify and correct potential issues with
the NIBP valve, pump, and/or tubing.
It is necessary to perform Functional Verification Tests after a module is repaired to ensure that
the functions of the Propaq M unit work properly.
Because the Propaq M units must be maintained ready for immediate use, it is important for
users to conduct the Operator’s Shift Checklist procedure at the beginning of every shift. This
procedure can be completed in a few minutes and requires no additional test equipment. (See
the ZOLL Propaq M Operator’s Guide for the Operator’s Shift Checklist.) It is highly
recommended that the Operational Tests be performed at regular intervals to augment the
automatic testing the Propaq M does to ensure readiness.

CHAPTER 1MAINTENANCE TESTS
69650-0804-01 Rev. A
This chapter describes the following maintenance tests:
Calibration and Calibration Checks
•NIBP Calibration Check
•CO2Calibration Procedure
•CO2Calibration Check
NIBP Valve, Pump, and Tubing Integrity Tests
•Leak Test
•Deflation Test
•Inflation Test
Operational Tests
•Physical Inspection of the Unit
•Keypad Test
•LED Test
•LCD Test
•RFU Indicator Test
•Audio Test
•Battery Test
•Fan Test
•NIBP Test
Functional Verification Tests
•Leads Test
•Heart Rate Display Test
•Heart Rate Alarm Test
•Leakage Current Test
•SpO2 Monitor Test
•EtCO2 Monitor Test
•IBP Monitor Test
•NIBP Monitor Test
•Temperature Test

Calibration and Calibration Checks
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 7
Calibration and Calibration Checks
NIBP Calibration Check
Equipment Single lumen BP hose, a 500 cc volume, and a calibrated manometer or pressure gauge
(< = 1mmHg accuracy). If a 500 cc volume is not available, an Adult BP cuff wrapped around a
rigid cylinder (such as a glass jar) will suffice.
Note: This test is to be performed for the following target pressures: 50 +/- 5 mmHg,
150 +/- 5 mmHg, and 250 +/- 5 mmHg.
Procedure
1. Power on the Propaq M.
2. Connect the Propaq M to the single lumen hose and the 500 cc volume. Alternatively, replace
the 500 cc volume with a standard Adult cuff wrapped around a rigid cylinder, such as a glass
jar. Connect a calibrated manometer to the air line using a T-fitting.
3. On the Propaq M, do the following to enter the NIBP Test control panel:
•Press the Setup quick access key ().
•Use the navigation keys to select Supervisor>Service>Device Tests>NIBP Test.
4. From the Propaq M NIBP Test control panel, use the navigation keys to select:
•Close Valve
•Turn Pump On
5. Monitor the pressure reported by the external pressure standard.
6. Once the pressure reaches the target pressure of 50 +/- 5 mmHg, use the navigation keys to
select Turn Pump Off.
7. Allow the system to stabilize for at least 10 seconds.
8. Record the pressure reported by the external pressure standard as Pa.
9. Record the pressures reported by the primary and safety transducers (displayed in the NIBP
Test control panel) as Ppand Ps, respectively
10.Calculate the absolute pressure differences between the applied pressure (Pa) and each of the
transducer pressures.
•Pd-Primary = abs(Pa-Pp)
•Pd-safety = abs(Pa-PS)
11. From the NIBP Test control panel, select Open Valve to release the pressure
12.Repeat steps 3 to 11 to test for the remaining target pressures of 150 +/- 5 mmHg and 250 +/
- 5 mmHg.
13.Once complete, use the navigation keys to select Update NIBP Cal Check Date to save the
date of the most recent calibration check.

CHAPTER 1MAINTENANCE TESTS
89650-0804-01 Rev. A
Acceptable Results
The unit passes the test if Pd-Primary is less than or equal to 3.0 mmHg and Pd-Safety is less than
or equal to 4.0 mmHg for all three target pressures.
Corrective Action
If readings fail to meet the required accuracy, the NIBP module requires replacement or factory
analysis and realignment.

Calibration and Calibration Checks
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 9
CO2Calibration Procedure (required for annual calibration)
Equipment 5% CO2calibration gas cylinder with CO2sample line (kit available from Scott Medical
Products, PN 4653ORF-BD)
Procedure
1. On the Propaq M, do the following to enter the CO2Calibration control panel:
•Press the CO2quick access key ().
•Use the navigation keys to select Supervisor>Service>Diagnostic>CO2>Calibration.
2. Connect the Propaq M to the 5% CO2calibration gas cylinder using the sample lineincluded
with the calibration kit.
3. From the CO2Calibration Menu, select Calibration.
4. Activate the calibration gas flow by pressing the top valve on the calibration gas canister.
5. Continue to apply the calibration gas until the status in the CO2Calibration control panel
displays: CALIBRATION GAS CAN BE REMOVED.
•When the calibration is complete, the status in the CO2Calibration control panel
displays: CALIBRATION DONE - OK OR CALIBRATION DONE - ERROR.
6. To verify calibration, perform the CO2Calibration Check Procedure on page 10.
Acceptable Results
The status in the CO2Calibration control panel displays: CALIBRATION DONE - OK.
Perform the above calibration check procedure to verify CO2accuracy.
The calibration date will be updated upon exiting the CO2Test control panel.
Corrective Action
If an error is reported, refer to the table below for possible causes.
If readings fail to meet the required accuracy, the CO2module requires replacement or factory
analysis and realignment.
The following table describes possible calibration errors and likely causes.
Table 1-1. Calibration Errors
Error Message Cause
No gas or wrong gas
concentration The concentration of supplied gas is not close to the expected value.
No stable gas flow and
Calibration failure The gas sample is not stable, i.e. due to leak or noise.
Measurement error Occlusion detection during known gas sampling.
Measurement error Sample line disconnection during gas sampling.
AZ fail The Auto Zero that is part of the calibration process failed.
Calibration aborted by
user Calibration mode canceled during gas sampling.
CO2
CO2

CHAPTER 1MAINTENANCE TESTS
10 9650-0804-01 Rev. A
CO2Calibration Check Procedure
Equipment 5% CO2calibration gas cylinder with CO2sample line (kit available from Scott Medical
Products, PN 4653ORF-BD)
Procedure
1. On the Propaq M, do the following to enter the CO2Calibration control panel:
•Press the CO2quick access key ().
•Use the navigation keys to select Supervisor>Service>Diagnostic>CO2>Calibration.
2. Connect the Propaq M to the 5% CO2calibration gas cylinder using the sample lineincluded
with the calibration kit.
3. From the CO2Calibration control panel, select Verify Calibration.
4. Activate the calibration gas flow by pressing the top valve on the calibration gas canister.
5. Continue to apply the calibration gas until the status in the CO2Calibration control panel
displays: CALIBRATION GAS CAN BE REMOVED.
•When the calibration check is complete, the status in the CO2Calibration control panel
displays: VERIFICATION DONE - OK OR VERIFICATION DONE - ERROR.
•When the calibration check completes successfully, the measured gas value displays in
the CO2Calibration control panel.
Acceptable Results
The message displays: VERIFICATION DONE - OK.
The measured gas reading passes if it is between 4.8 and 5.2 (Vol%).
Corrective Action
If an error is reported, refer to Table 1-1 on page 9 for possible causes.
If the measured gas reading is outside the acceptable range, or if calibration is due, complete
the “CO2 Calibration Procedure (required for annual calibration)” on page 9.
CO2
CO2

NIBP Valve, Pump, and Tubing Integrity Tests
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 11
NIBP Valve, Pump, and Tubing Integrity Tests
NIBP Leak Test
Equipment Single lumen BP hose, a 500 cc volume, and a calibrated manometer.
Note: If a 500 cc volume is not available, an Adult BP cuff wrapped around a rigid cylinder
(such as a glass jar) will suffice
Procedure
1. Power on the Propaq M.
2. Connect the Propaq M to the single lumen hose and the 100 cc volume. Alternatively, replace
the 100 cc volume with a standard Adult cuff wrapped around a rigid cylinder, such as a glass
jar. If available, connect a calibrated manometer to the air line using a T-fitting.
3. On the Propaq M, do the following to enter the NIBP Test control panel:
•Press the Setup quick access key ().
•Use the navigation keys to select Supervisor>Service>Device Tests>NIBP Test.
4. From the Propaq M NIBP Test control panel, use the navigation keys to select:
•Close Valve
•Turn Pump On
5. Monitor the pressure reported by NIBP Test control panel or the external pressure standard.
6. Select Turn Pump Off as soon as the pressure reaches the target pressure of 250 +/- 5 mmHg.
7. Allow the system to stabilize for 10 seconds.
8. Select Mark P1 to mark the starting pressure. If available, measure the starting pressure
reported by the external pressure standard. Record the starting pressure as PS.
9. Wait 15 seconds.
10..Select Mark P2 to mark the ending pressure. If available, measure the ending pressure
reported by the external pressure standard. Record the ending pressure as PE.
11. From the NIBP Test control panel, select Open Valve to release the pressure.
12.Calculate the leak rate: L = (Ps- Pe) / (15 seconds).
Note: If using the pressure reported in the NIBP Test control panel, calculate the Leak Rate
using the Primary transducer pressures.
Acceptable Results
The unit passes the test if the system leaks less than 5 mmHg over the 15-second time interval
(Leak Rate is less than 1/3).

CHAPTER 1MAINTENANCE TESTS
12 9650-0804-01 Rev. A
Corrective Action
If the unit fails the test, the most likely cause is damaged or disconnected internal tubing. The
device needs to be disassembled to replace or reattach the appropriate segment of NIBP tubing.
The NIBP valves should also be inspected.

NIBP Valve, Pump, and Tubing Integrity Tests
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 13
NIBP Deflation Test
Equipment Single lumen BP hose, a 500 cc volume, a timer, and a calibrated manometer (optional).
Note: Note: If a 500 cc volume is not available, an Adult BP cuff wrapped around a rigid
cylinder (such as a glass jar) will suffice.
Procedure
1. Power on the Propaq M.
2. Connect the Propaq M to the single lumen hose and the 500 cc volume. Alternatively, replace
the 500 cc volume with a standard Adult cuff wrapped around a rigid cylinder, such as a glass
jar. If available, connect a calibrated manometer to the air line using a T-fitting.
3. On the Propaq M, do the following to enter the NIBP Test control panel:
•Press the Setup quick access key ( ).
•Use the navigation keys to select Supervisor>Service>Device Tests>NIBP Test.
4. From the Propaq M NIBP Test control panel, use the navigation keys to select:
•Close Valve
•Turn Pump On
5. Monitor the pressure reported by the NIBP Test control panel or the external pressure
standard.
6. Select Turn Pump Off as soon as the pressure reaches the target pressure of 265 +/- 5 mmHg.
7. Allow the system to stabilize for 5 seconds.
8. Use the navigation keys to select Open Valve and immediately start the timer.
9. Stop the timer as soon as pressure drops below 15 mmHg.
10.Record the Deflation Time as TD.
Acceptable Results
The unit passes the test if the time to release pressure from 265 +/- 5 mmHg to 15 mmHg is less
than 10 seconds.
Corrective Action
If the unit fails the test, the most likely cause is kinked or obstructed internal tubing, or
obstructed filter. The device needs to be disassembled to replace or reposition the appropriate
segment of NIBP tubing.

CHAPTER 1MAINTENANCE TESTS
14 9650-0804-01 Rev. A
NIBP Inflation Test
Equipment Single lumen BP hose, a 250 cc volume, a timer, and a calibrated manometer (optional).
Procedure
1. Power on the Propaq M.
2. Connect the Propaq M to the single lumen hose and the 250 cc volume. If available, connect
a calibrated manometer to the air line using a T-fitting.
3. In the Propaq M, do the following to enter the NIBP Test control panel:
4. Press the Setup quick access key ( ).
5. Use the navigation keys to select Supervisor>Service>Device Tests>NIBP Test.
6. Wait 10 seconds to allow the system to vent any residual pressure.
7. Verify that the pressure reported by the NIBP Test control panel or the external pressure
standard system is less than 5 mmHg.
8. From the NIBP Test control panel, use the navigation keys to select Close Valve.
9. Select Turn Pump On and immediately start the timer.
10.Stop the timer as soon as pressure exceeds 210 mmHg.
11. Select Turn Pump Off, then Open Valve.
12.Record the Inflation Time as TI.
Note: Note: The pump will automatically turn off if pressure exceeds 310 mmHg during this
test.
Acceptable Results
The unit passes the test if the time to increase pressure to 210 mmHg is less than 7 seconds.
Corrective Action
If the unit fails the test, the most likely cause is a faulty pump or a kinked internal hose. The
device needs to be disassembled to replace the pump or reposition the appropriate segment of
NIBP tubing.

Operational Tests
9650-0804-01 Rev. A ZOLL Propaq M Service Manual 15
Operational Tests
The Propaq M comes equipped with routine operational tests that can be performed
periodically. With the exception of the Physical Inspection of the Unit test, these tests contain
instructions within them provide guidance during the tests.
Physical Inspection of the Unit
Tools Needed None
Test Setup None
Observe this... Pass/Fail
1.
Housing
Is the unit clean and undamaged? oo
2. Does the unit show signs of excessive wear? oo
3. Does the handle work properly? oo
4. Does the recorder drawer open and close properly? oo
5. Are input connectors clean and undamaged? oo
6. Are there any cracks in the housing? oo
7. Do the front panel or selector switches have any damage or cracks? oo
8. Are there any loose housing parts? oo
12.
Cables
Are all cables free of cracks, cuts, exposed or broken wires? oo
13. Are all bend/strain reliefs undamaged and free of excessive cable wear? oo
14.
Battery
Is the Propaq battery fully charged? oo
15. Is the battery seated in the battery well correctly? oo
16. Is battery housing free of cracks and damage? oo
17. Are connectors free of damage and excessive wear? oo

CHAPTER 1MAINTENANCE TESTS
16 9650-0804-01 Rev. A
Accessing the Operational Tests
The operational tests on the unit can be accessed by doing the following:
1. Press the Setup quick access key ().
2. Use the navigation keys to select Supervisor>Service>Device Tests. The operational tests
are displayed. Use the navigation keys to select one of the tests.
