Zontes ZT350E User manual

1 / 108
ZT350E
Maintenance Manual
2023-04-11

2 / 109
Introduction
All the materials, illustrations, photos, etc. collected in this manual are compiled according to the latest products of ZT350-
D National IV. However, due to the continuous improvement of the product and other changes, there may be some
inconsistencies between your motorcycle and this manual. For colors or upgrades, please refer to the part codes on the official
website of Zontes. This manual will not be listed in detail; if the part names in this manual are inconsistent with the official
website of Zontes, please refer to the official website of Zontes.Individual parts of different displacements that differ in shape or
size but are disassembled and assembled in the same way, will not listed in this manual.
If part of the content of this manual is insufficient, please refer to the "Driver's Manual" included with the bike. The latest
version of the driver's manual can be downloaded as a PDF in the model introduction corresponding to the official website of
Zontes.
©GUANG DONG TAYO MOTORCYCLE TECHNOLOGY Co.,Ltd
All rights reserved

3 / 109
User notice
This manual is compiled by Guangdong Tayo Motorcycle Technology Co., Ltd. to guide dealers or service personnel to use it. This
manual cannot provide more detailed knowledge about motorcycles, and is only for reference for maintenance. If you do not
have the corresponding knowledge such as electrician, machine repair, etc., improper assembly or repair failure may occur
during repair.
If you need to clean or wash the body parts of the motorcycle, you should use neutral car wash fluid or tap water, diesel,
kerosene, etc. Acidic or alkaline car wash liquid will cause irreversible corrosion of the surface paint, electroplating surface, and
anodized surface of the parts; gasoline will cause premature aging or hardening of sealants, gaskets, and rubber parts, reducing
the service life. Non-woven fabrics should be used for wiping with no residue. Ordinary rags may leave cloth scraps or wool, etc.,
which may affect the assembly or cause other adverse effects.
Our company will update this manual as soon as possible after the product changes.
The following is the meaning of the icons marked in this manual：
Failure to observe will cause personal injury or death of the driver or maintenance
personnel; or cause serious damage to parts and shorten the service life, etc.
Failure to comply may result in personal injury or death of the driver or maintenance
personnel; or damage to parts, abnormalities, etc.
Failure to observe the warning will cause personal injury to the driver or
maintenance personnel; or matters requiring special attention during disassembly
and assembly
Indicates that there is a requirement for torque there
Indicates that the piece needs to be replaced after disassembly
