ZyXEL Communications V-630 User manual

www.zyxel.com
V630
VoIP Wi-Fi Phone
User’s Guide
Version 1.00
6/2008
Edition 1

About This User's Guide
V630 User’s Guide 3
About This User's Guide
Intended Audience
This manual is intended for people who want to configure the V630 using the keypad or web
configurator.
Related Documentation
• Quick Start Guide
The Quick Start Guide is designed to help you connect and make wireless VoIP calls right
away.
See the web configurator sections of this User’s Guide for background
information on features that you can configure in the web configurator.
• Supporting Disc
Refer to the included CD for support documents.
• ZyXEL Web Site
Please refer to www.zyxel.com for additional support documentation and product
certifications.
User’s Guide Feedback
Help us help you. Send all User’s Guide-related comments, questions or suggestions for
improvement to the following address, or use e-mail instead. Thank you!
The Technical Writing Team,
ZyXEL Communications Corp.,
6 Innovation Road II,
Science-Based Industrial Park,
Hsinchu, 300, Taiwan.
E-mail: [email protected]
Disclaimer
Graphics in this book may differ slightly from the product due to differences in operating
systems, operating system versions, or if you installed updated firmware/software for your
device. Every effort has been made to ensure that the information in this manual is accurate.

Document Conventions
V630 User’s Guide
4
Document Conventions
Warnings and Notes
These are how warnings and notes are shown in this User’s Guide.
Warnings tell you about things that could harm you or your V630.
Notes tell you other important information (for example, other things you may
need to configure or helpful tips) or recommendations.
Syntax Conventions
• The V630 may be referred to as the “V630”, the “device”, the “system” or the “product” in
this User’s Guide.
• Product labels, screen names, field labels and field choices are all in bold font.
• A key stroke is denoted by square brackets and uppercase text, for example, [ENTER]
means the “enter” or “return” key on your keyboard.
• “Enter” means for you to type one or more characters and then press the [ENTER] key.
“Select” or “choose” means for you to use one of the predefined choices.
• A right angle bracket ( > ) within a screen name denotes a mouse click. For example,
Maintenance > Log > Log Setting means you first click Maintenance in the navigation
panel, then the Log sub menu and finally the Log Setting tab to get to that screen.
• Units of measurement may denote the “metric” value or the “scientific” value. For
example, “k” for kilo may denote “1000” or “1024”, “M” for mega may denote “1000000”
or “1048576” and so on.
• “e.g.,” is a shorthand for “for instance”, and “i.e.,” means “that is” or “in other words”.
Icons Used in Figures
Figures in this User’s Guide may use the following generic icons. The V630 icon is not an
exact representation of your V630.

Document Conventions
V630 User’s Guide 5
Tips for Reading User’s Guides On-Screen
When reading a ZyXEL User’s Guide On-Screen, keep the following in mind:
• If you don’t already have the latest version of Adobe Reader, you can download it from
http://www.adobe.com.
• Use the PDF’s bookmarks to quickly navigate to the areas that interest you. Adobe
Reader’s bookmarks pane opens by default in all ZyXEL User’s Guide PDFs.
• If you know the page number or know vaguely which page-range you want to view, you
can enter a number in the toolbar in Reader, then press [ENTER] to jump directly to that
page.
• Type [CTRL]+[F] to open the Adobe Reader search utility and enter a word or phrase.
This can help you quickly pinpoint the information you require. You can also enter text
directly into the toolbar in Reader.
• To quickly move around within a page, press the [SPACE] bar. This turns your cursor
into a “hand” with which you can grab the page and move it around freely on your screen.
• Embedded hyperlinks are actually cross-references to related text. Click them to jump to
the corresponding section of the User’s Guide PDF.
Table 1 Common Icons
V630 Computer Notebook
Server Printer Telephone
Switch Router Internet Cloud
Firewall Modem Wireless Signal

Safety Warnings
V630 User’s Guide
6
Safety Warnings
For your safety, be sure to read and follow all warning notices and instructions.
• Do NOT use this product near water, for example, in a wet basement or near a swimming
pool.
• Do NOT expose your device to dampness, dust or corrosive liquids.
• Do NOT store things on the device.
• Do NOT install, use, or service this device during a thunderstorm. There is a remote risk
of electric shock from lightning.
• Connect ONLY suitable accessories to the device.
• Do NOT open the device or unit. Opening or removing covers can expose you to
dangerous high voltage points or other risks. ONLY qualified service personnel should
service or disassemble this device. Please contact your vendor for further information.
• Use ONLY an appropriate power adaptor or cord for your device. Connect it to the right
supply voltage (for example, 110V AC in North America or 230V AC in Europe).
• Do NOT allow anything to rest on the power adaptor or cord and do NOT place the
product where anyone can walk on the power adaptor or cord.
• Do NOT use the device if the power adaptor or cord is damaged as it might cause
electrocution.
• If the power adaptor or cord is damaged, remove it from the device and the power source.
• CAUTION: RISK OF EXPLOSION IF BATTERY (on the motherboard) IS REPLACED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS. Dispose them at the applicable collection point for the recycling
of electrical and electronic equipment. For detailed information about recycling of this
product, please contact your local city office, your household waste disposal service or the
store where you purchased the product.
• Do NOT attempt to repair the power adaptor or cord. Contact your local vendor to order a
new one.
This product is recyclable. Dispose of it properly.

Safety Warnings
V630 User’s Guide 7

Safety Warnings
V630 User’s Guide
8

Contents Overview
V630 User’s Guide 9
Contents Overview
Introduction ............................................................................................................................27
Introducing the V630 ................................................................................................................. 29
LCD Screen Menus ................................................................................................................33
Using the LCD Screen ............................................................................................................... 35
Call Log LCD Menus ................................................................................................................. 41
Profiles LCD Menus ................................................................................................................... 43
General Setup LCD Menus ....................................................................................................... 49
Network LCD Menus ................................................................................................................. 69
The Phonebook ......................................................................................................................... 97
Call Options ............................................................................................................................. 107
The Web Configurator .........................................................................................................109
Introducing the Web Configurator .............................................................................................111
Information Screen ...................................................................................................................115
WLAN Profile ............................................................................................................................117
Call Setting .............................................................................................................................. 123
Phone Book ............................................................................................................................. 125
SIP Account Setup ..................................................................................................................127
Auto Provision ......................................................................................................................... 135
System, Troubleshooting, and Specifications ..................................................................137
System ..................................................................................................................................... 139
Troubleshooting ....................................................................................................................... 141
Product Specifications ............................................................................................................. 147
Appendices and Index .........................................................................................................151

Contents Overview
V630 User’s Guide
10
