Prestige 2000W_V2
VoIP Wi-Fi Phone
Quick Start Guide
Version WV.00.01
4/2005

Prestige 2000W_V2 Quick Start Guide
2
Overview
The Prestige 2000W_V2 is a wireless Voice
over IP (VoIP) telephone. It combines the
benefits of Internet telephony, like cheaper
calls, with mobility. Make and receive calls as
long you are within range of an IEEE 802.11b
or IEEE 802.11g wireless network. This guide
covers how to configure and use your Prestige
to make phone calls through the Internet. See
the User’s Guide for more information on all
features.
Note: You should have Internet access and a voice account already set up.

Prestige 2000W_V2 Quick Start Guide
3
This guide is divided into the following sections.
NAME DESCRIPTION
1LCD Screen Use this screen to display information and navigate the phone’s menus.
2Left Key Use the Left key to open the on-screen menus and select options.
3Right Key Use the Right key to return to the previous menu. It is also a shortcut to the phone book.
4Arrow Keys Use the arrow keys to navigate between menus and move the cursor. Use the left arrow
key to clear text in an editable field.
5OK Key Use this key to select menu options from the LCD screen.
6Call Key Use the Call key to make and receive calls.
7Power/End Use the Power/End key to finish or reject calls. Press and hold it for approximately 2
seconds to turn the Prestige on or off.
8Alphanumeric
Keypad
Use these keys to enter numbers, letters and symbols.
9Headset Jack Use this jack (located underneath rubber cover) to connect an optional headset.
10 Volume Keys Use these keys to increase or decrease the ear piece volume.
11 Power Jack Connect the phone’s power adaptor here to charge the battery.
1Charging Your Phone
2Connecting to a Wireless Network
3Connecting to the Internet
4Setting the Prestige to Use Your Voice
Account
5Phonebook
6Using the Prestige
7Accessing the Web Configurator
8Troubleshooting

Prestige 2000W_V2 Quick Start Guide
4
1 Charging Your Phone
Do the following to charge the Prestige for use.
Note: Charge the battery for two hours before using your Prestige.
The battery provides approximately 3.5 hours of talk time and 21-22 hours of standby time when fully charged.
Remember to reconnect the phone to the power adaptor when not in use.
1Remove the battery cover. Press the silver
button on the back of the Prestige and slide the
battery cover with your other hand.
2Insert the battery. With the battery’s CE label facing
up, put the end with the contacts in first and press the
battery down into place.
3Place the battery cover back on. Slide the
cover towards the top until it clicks into place.
4Remove the gray rubber cover from the bottom of
your phone. Use the included power adaptor (use
only this adaptor) to connect the phone to an
appropriate power outlet.
The OK key turns on bright red.

Prestige 2000W_V2 Quick Start Guide
5
2 Connecting to a Wireless Network
Press the Power/End key for two seconds to turn on the Prestige. The Prestige searches for the available
wireless network with the best signal. It then restarts and attempts to connect to the wireless network.
If the LCD screen displays Not Registered, the Prestige is connected to the Internet
and you can skip to Section 4.
Note: If the LCD screen displays Registered, skip to Section 5.
If any other message displays or you want to select a specific network, please
continue with the following steps.
12:00
ZyXEL
Not registered
Menu Names
1In the main screen, press the Left key to enter the menus. 12:00
ZyXEL
Net failed (DHCP)
Menu Names
2Use the down arrow key to scroll to Wireless and press the OK key.
8. Restart
1. Information
Select Back
3Use the down arrow key to scroll to Site Survey and press the OK key.
The Prestige checks for and displays a list of available wireless networks and
each one’s signal strength. 2. SSID
3. Network Mode
Select Back
4Scroll to the name of the wireless network that you want to use and press the
OK key. If a “W” appears next to the network name, or if you know WEP
encryption is required for your network, then continue with Section 2.1,
Otherwise, skip to Section 2.2.
ABC123 90
123ABC 85
Select Back
7. Wireless
1. Site Survey
ZyXEL USA 99 W

Prestige 2000W_V2 Quick Start Guide
6
2.1 Setting the Prestige to Use a WEP Key
WEP (Wired Equivalent Privacy) encryption scrambles wireless communications to keep them private. Do the
following if you were given a WEP key to use, otherwise skip to Section 2.2.
1Use the down arrow key to scroll to WEP Select and press the OK key.
7. Profiles
8. Auth Type
Select Back
2Scroll to the length of WEP keys (64-bit or 128-bit) that the wireless network
uses and press the OK key
[3] 128bit
[1] None
Select Back
3Use the down arrow key and the OK key to select a WEP key to configure (most
networks use WEP key 1 by default).
8. WEP key 2
9. WEP key 3
Select Back
4You will enter the WEP key for your wireless network here.
The bottom center of the screen shows the keypad mode Aa1@, with the A
mode highlighted. Use the up and down arrows to select capital letters (A),
lowercase letters (a), numbers (1), or symbols (@).
WEP key 1
**********
Ok a1@ Clear
5Use the keypad to enter the WEP key. Use the Power/End key to clear the
default text and remove typos. You may need multiple keypad presses to enter
letters. For example, to enter a lowercase “b”, press the down arrow key to
select lowercase mode (a), then press the “2” key twice.
6Press the OK key when you are done.
WEP key 1
mykey
Ok A 1@ Clear
7You can configure up to four WEP keys (in the same manner as the first) but
only one key can be selected (enabled) at any one time.
9. WEP key 3
10. WEP key 4
Select Back
6. WEP Select
[2] 64bit
7. WEP key 1
A
a
8. WEP key 2

Prestige 2000W_V2 Quick Start Guide
7
2.2 Restarting Your Prestige
Press the Right key twice to save your settings and return to the main screen. An hourglass appears on the
LCD screen and the Prestige restarts.
Note: If the LCD screen displays Not Registered, the Prestige is connected to the Internet and you
can skip to Section 4.
If the LCD screen displays Registered, skip to Section 5.
Otherwise continue with the next section.
3 Connecting to the Internet
Use this section to configure your Prestige to access the Internet.
8Scroll to Key Select and press the OK key.
12. Profiles
13. Auth Type
Select Back
9Use the down arrow key and the OK key to select the key that the wireless
network is using.
Key 2
Key 3
Select Back
1In the main screen, press the Left key to enter the menus. 12:00
ZyXEL
Net failed (DHCP)
Menu Names
11. Key Select
Key 1

Prestige 2000W_V2 Quick Start Guide
8
3.1 Fixed IP
With this option you have to manually enter an IP address, subnet mask and gateway IP address. These are
given to you by the network administrator.
2Use the down arrow key to scroll to Net Settings and press the Left key).
5. SIP Settings
6. Settings
Select Back
3Scroll to Network Mode and press the OK key.
If you were given an IP address and subnet mask, go to Section 3.1.
If you were given a user name and password for Internet access, go to Section
3.2.
2. IP Address
3. Subnet Mask
Select Back
1Use the down arrow key to scroll to Fixed IP and press the OK key.
[2] DHCP
[3] PPPoE
Select Back
2Scroll to IP Address and press the OK key.
3. Subnet Mask
4. Gateway
Select Back
3Use the keypad to enter your IP address. Use the Power/End key to clear the
default text and remove typos. Press the OK key when you are done.
IP Address
192.168.1.71
Ok Aa @
Clear
4Scroll to Subnet Mask and press the OK key.
4. Gateway
1. Network Mode
Select Back
4. Net Settings
1. Network Mode
[1] Fixed IP
2. IP Address
1
3. Subnet Mask

Prestige 2000W_V2 Quick Start Guide
9
3.2 PPPoE
Point-to-Point Protocol over Ethernet (PPPoE) functions as a dial-up connection. You need a user name
(PPPoE name) and password from your ISP.
5Use the keypad to enter your subnet mask. Use the Power/End key to clear the
default text and remove typos. Press the OK key when you are done.
Subnet Mask
255.255.255.0
Ok Aa @ Clear
6Scroll to Gateway and press the OK key.
1. Network Mode
2. IP Address
Select Back
7Use the keypad to enter the IP address of your gateway. Use the Power/End
key to clear the default text and remove typos. Press the OK key when you are
done.
8The Prestige restarts when you return to the main screen.
Gateway
192.168.1.2
Ok Aa @ Clear
1Use the down arrow key to scroll to PPPoE and press the OK key.
[1] Fixed IP
[2] DHCP
Select Back
2Scroll to PPPoE Name and press the OK key.
3. PPPoE Pwd
1. Network Mode
Select Back
3You will enter your PPPoE name here.
The bottom center of the screen shows the keypad mode Aa1@, with the A
mode highlighted. Use the up and down arrows to select capital letters (A),
lowercase letters (a), numbers (1), or symbols (@).
PPPoE Name
my_username
Ok a1@ Clear
1
4. Gateway
1
[3] PPPoE
2. PPPoE Name
A

Prestige 2000W_V2 Quick Start Guide
10
4 Setting the Prestige to Use Your Voice Account
Use these sections to register your Prestige with your voice service provider’s SIP server.
4.1 Configuring Registrar Server Settings
Configure the Registrar settings to have the Prestige register with your provider’s SIP registrar server.
Note: If you have no registrar server information, use the SIP server IP address and port number.
4Use the keypad to enter your PPPoE name. Use the Power/End key to clear
the default text and remove typos. You may need multiple keypad presses to
enter letters. For example, to enter a lowercase “b”, press the down arrow key
to select lowercase mode (a), then press the “2” key twice.
5Press the OK key when you are done.
PPPoE Name
my_username
Ok A 1@ Clear
6Scroll to PPPoE Pwd and press the OK key.
1. Network Mode
2. PPPoE Name
Select Back
7Select a keypad mode and use the keypad to enter your PPPoE password.
Press the OK key when you are done.
8Press the Right key twice to save your settings and return to the main screen.
An hourglass appears on the LCD screen and the Prestige restarts.
PPPoE Pwd
my_password
Ok A 1@ Clear
1In the main screen, press the Left key to enter the menus. 12:00
ZyXEL
Not registered
Menu Names
2Use the down arrow key to scroll to SIP Settings and press the OK key.
6. Settings
7. Wireless
Select Back
a
3. PPPoE Pwd
a
5. SIP Settings

Prestige 2000W_V2 Quick Start Guide
11
3Scroll to Registrar and press the OK key.
2. OutboundProxy
3. Proxy Server
Select Back
4Scroll to Registrar IP and press the OK key.
2. Port
3. Expiry Time
Select Back
5You will enter your registrar server’s IP address or domain name here.
The bottom center of the screen shows the keypad mode Aa1@, with the A
mode highlighted. Use the up and down arrows to select capital letters (A),
lowercase letters (a), numbers (1), or symbols (@).
Registrar IP
mysip.proxy.com
Ok A 1@ Clear
6Use the keypad to enter your registrar server’s IP address or domain name.
Use the Power/End key to clear the default text and remove typos. You may
need multiple keypad presses to enter letters. For example, to enter a
lowercase “b”, press the down arrow key to select lowercase mode (a), then
press the “2” key twice. Press the OK key when you are done.
Registrar IP
mysipprovider.com
Ok A 1@ Clear
7Scroll to Port and press the OK key.
3. Expiry Time
1. Registrar IP
Select Back
8Use the keypad to enter the registrar server’s listening port number if you were
given one. Use the Power/End key to clear the default text and remove typos.
Leave the default port number if you were not given one to use.
9Press the OK key when you are done.
Port
5060
Ok Aa @ Clear
1. Registrar
1. Registrar IP
a
a
2. Port
1

Prestige 2000W_V2 Quick Start Guide
12
4.2 Configuring Outbound Proxy Server Settings
If your voice service provider gave you an outbound proxy server address and port, you can enter them here.
You only need to configure the Prestige to use an outbound proxy server if your LAN is behind a NAT router
that does not support SIP.
10 Scroll to Expiry Time and press the OK key.
1. Registrar IP
2. Port
Select Back
11 Use the keypad to enter the expiration time if you were given one to use. Use
the Power/End key to clear the default text and remove typos. Leave the
default expiration time if you were not given one to use. Press the OK key
when you are done.
12 Stay in the SIP Settings menu and continue with the next section.
Expiry Time
300
Ok Aa @ Clear
1Use the down arrow key to scroll to Outbound Proxy and press the OK key.
3. Proxy Server
4. User Account
Select Back
2Scroll to Proxy IP and press the OK key.
2. Port
Select Back
3Select a keypad mode and use the keypad to enter the outbound proxy
server’s IP address or domain name. Use the Power/End key to clear the
default text and remove typos. Press the OK key when you are done.
Proxy IP
my_sip.proxy.com
Ok A 1@ Clear
3. Expiry Time
1
2. OutboundProxy
1. Proxy IP
a

Prestige 2000W_V2 Quick Start Guide
13
4.3 Configuring Your Proxy Server Settings
Configure Proxy Server settings to have the Prestige use your voice provider’s SIP server.
4Scroll to Port and press the OK key.
1. Proxy IP
Select Back
5Use the keypad to enter the SIP outbound proxy server’s listening port number.
Use the Power/End key to clear the default text and remove typos. Leave the
default port number if you were not given one to use.
Press the OK key when you are done.
Port
5060
Ok Aa @ Clear
1Use the down arrow key to scroll to Proxy Server and press the OK key.
4. User Account
1. Registrar
Select Back
2Scroll to Proxy IP and press the OK key.
2. Port
Select Back
3Select a keypad mode and use the keypad to enter the SIP server’s IP address
or domain name.
4Press the OK key when you are done.
Proxy IP
mysip.proxy.com
Ok A 1@ Clear
5Scroll to Port and press the OK key.
1. Proxy IP
Select Back
6Use the keypad to enter the SIP server’s listening port number. Use the Power/
End key to clear the default text and remove typos. Leave the default port
number if you were not given one to use.
Press the OK key when you are done.
Port
5060
Ok Aa @ Clear
2. Port
1
3. Proxy Server
1. Proxy IP
a
2. Port
1

Prestige 2000W_V2 Quick Start Guide
14
4.4 Configuring Your User Account Settings
When you registered for your voice account, you should have been given a telephone number, user name and
password. Do the following to enter them into the Prestige.
1Use the down arrow key to scroll to User Account and press the OK key.
1. Registrar
2. OutboundProxy
Select Back
2Scroll to Phone Number and press the OK key.
2. Username
3. User Pwd
Select Back
3Select a keypad mode and use the keypad to enter your SIP number.
For a SIP account like [e-mail], “1234” would be the SIP
number.
Press the OK key when you are done.
Phone Number
my_number
Ok A 1@ Clear
4Scroll to Username and press the OK key.
3. User Pwd
1. Phone Number
Select Back
5Select a keypad mode and use the keypad to enter your user name.
Press the OK key when you are done.
Username
my_username
Ok A 1@ Clear
4. User Account
1. Phone Number
a
2. Username
a

Prestige 2000W_V2 Quick Start Guide
15
5 Phonebook
Use the phonebook feature to store telephone numbers.
5.1 Calling Methods
The Prestige can dial a telephone number by using the SIP proxy server or an IP address.
Select Proxy to use your SIP account to have the SIP server make the connection. You do not have to
configure the host IP address and port.
Select P2P to make calls directly to the callee’s VoIP phone (IP to IP or peer-to-peer) or using a different SIP
server. You need to enter the IP address of the callee or another SIP proxy server as well as the callee’s
telephone number in the Prestige’s phonebook.
5.2 Adding a Phonebook Entry
Use the following instructions to add an entry to your phonebook.
Note: Only enter the host IP address and port when calls to this party need to use a different
SIP proxy server and/or you want to place a direct IP to IP call. Otherwise the telephone
number is sufficient to make your call.
You must use a phonebook entry to make an IP to IP call.
6Scroll to User Pwd and press the OK key.
1. Phone Number
2. Username
Select Back
7Select a keypad mode and use the keypad to enter your password.
Press the OK key when you are done.
8Press the Right key three times to save your settings and return to the main
screen. An hourglass appears on the LCD screen and the Prestige restarts.
User Pwd
my_password
Ok A 1@ Clear
3. User Pwd
a

Prestige 2000W_V2 Quick Start Guide
16
1In the main screen, press the Left key to enter the menus. 12:00
ZyXEL
Registered
Menu Names
2Use the down arrow key to scroll to Phonebook and press the OK key.
4. Net Settings
5. SIP Settings
Select Back
3Use the down arrow key to scroll to Add Entry and press the OK key.
3. Erase
1. Search
Select Back
4Select a keypad mode and use the keypad to enter the callee’s name. Use the
Power/End key to clear the default text and remove typos. Press the OK key
when you are done.
Display Name:
my_friend
Ok A 1@ Clear
5Select a keypad mode and use the keypad to enter the callee’s telephone
number. Press the OK key when you are done.
User Info:
1234
Ok Aa @ Clear
6Select a keypad mode and use the keypad to enter the callee’s IP address or
domain name. Use the Power/End key to clear the default text and remove
typos. Leave this blank if you will use the SIP proxy server to call this number.
Press the OK key when you are done.
Host IP:
Ok Aa @ Clear
3. Phonebook
2. Add Entry
a
1
1

Prestige 2000W_V2 Quick Start Guide
17
6 Using the Prestige
7 Accessing the Web Configurator
This section describes how to log into the Prestige’s web configurator.
7.1 Accounts
The web configurator has two accounts. The user account lets you configure the Prestige’s basic settings. The
administrator’s account allows you to alter the way the Prestige makes and receives calls, for example
selecting a voice codec.
Note: Do not attempt to change the administrator settings unless you know what you are doing. These
settings affect the way your Prestige makes and receives calls and are already configured for
best performance.
7Select a keypad mode and use the keypad to enter the callee’s listening port
number. Use the Power/End key to clear the default text and remove typos.
Leave this blank if you will use the SIP proxy server to call this number or you
were not given a port number to use. Press the OK key when you are done.
Port:
Ok Aa @ Clear
8Select Proxy if calls to this party use your SIP account.
Select P2P if calls to this party use a different SIP server or go directly to the
callee’s VoIP phone (peer-to-peer).
9Press the Right key twice to save your settings and return to the main screen.
P2P
Select Back
To make or receive calls, first ensure that the main screen displays Registered.
• Dial the desired number using the keypad and press the green Call key.
• If the phone number is in the Prestige’s phonebook, press the Right key to enter
the phonebook. Use the up or down arrow key to choose the name and then press
the Call key.
• Use the volume keys on the left side of the phone to adjust the volume.
12:00
ZyXEL
Registered
Menu Names
• Press the red Power/ End key to terminate a call.
• To receive a call, press the green Call key.
• To reject a call, press red Power/ End key.
1
Proxy

Prestige 2000W_V2 Quick Start Guide
18
1Make sure your Prestige is connected to the wireless LAN and record its IP address (you can use the
Information menu to check your phone’s IP address).
8 Troubleshooting
2Launch your web browser.
3Type "http://<IP address>" as the URL. Where “IP
address” is the Prestige’s IP address.
4Enter your user name and password and
click OK to login.
• For user-level access: Type the default user
ame: admin and password: 1234 the first time
you login.
• For administrator access: Type the default
user name: zyxeladmin and password: 1234
the first time you login.
PROBLEM CORRECTIVE ACTION
The Prestige does
not turn on.
Make sure you have the battery installed and charged.
The Prestige is on
but the keys do
not work.
Press and hold the # key for approximately 2 seconds to lock or unlock the keypad.
The battery icon
( ) is blinking.
The battery’s power is low. Recharge the battery.
The signal icon
()isblinking
The signal quality is low or the Prestige cannot connect to the wireless network.
Connect to another wireless network or move your Prestige closer to the wireless network’s
access point.
There may be radio interference (for example a microwave or another wireless network using
the same channel). Relocate or reduce the radio interference.

Prestige 2000W_V2 Quick Start Guide
19
Procedure to View a Product’s Certification(s)
1Go to www.zyxel.com.
2Select your product from the drop-down list box on the ZyXEL home page to go to that product's page.
3Select the certification you wish to view from this page.
“Net Fail!
(DHCP)”
displays.
The Prestige failed to obtain an IP address from a DHCP server.
Make sure your wireless LAN settings are correct. You may need to select a different
wireless network or make sure your wireless network’s DHCP server is operating properly.
Restart the Prestige.
“Net Fail!
(PPPoE)”
displays.
The Prestige failed to obtain an IP address from the ISP.
Make sure your PPPoE settings are correct and restart the Prestige.
“Not Registered”
displays
The Prestige failed to register with the SIP proxy server.
It is still possible to place a direct IP to IP call without the SIP proxy server. You must create
and use a phonebook entry (see Section 5).
Check your SIP settings.
Contact your voice service provider.
PROBLEM CORRECTIVE ACTION
