3MTM EVM Series Environmental Monitor
Particulate
Simultaneous
and Gas
User Manual
Concentration Measurement
Distributed by:
Air-Met Scientic Pty Ltd
Work with Confidence
Air-Met Sales/Service
P: 1800 000 744
F: 1800 000 774
E: [email protected]
Air-Met Rental
P: 1300 137 067
E: [email protected]
W: www.airmet.com.au

Dangers, warnings, & cautions
ii
3MTM EVM series environmental monitor
Dangers, warnings, & cautions
Danger!
Failure to observe the following procedures may result in serious personal injury:
 Not for use in Explosive or Hazardous locations. This product is NOT Intrinsically Safe.
 Contains built-in lithium ion battery pack. Do not incinerate or dispose of in fire.
 Do not disassemble, alter, or re-construct the li-ion battery.
 Contains Class 3b visible laser radiation source (658 nm, nominal 5 mW). Do not look directly into
beam or view with telescopic devices.
 This instrument will NOT detect natural gas.
Warning!
 Read the manual before operation.
 Do not store in temperatures exceeding 60°C (140°F) and in direct sunlight.
 Do not immerse in liquids.
 The Sensors and batteries in this instrument have limited shelf-life, even if never used.
 Do not disassemble, service, or clean the optical engine internal components while power is applied.
The laser source can hurt you.
Caution!
General
 Condensation may damage your instrument and its sensors.
 A non-condensing environment is required for proper measurements.
 Do not charge batteries outside the range of 0°C to 40°C (32°F to 104°F).
 Battery run-time may be somewhat reduced at lower than 20°C (68°F) temperatures.
Temp/RH/Dew Point
 The internal Temp/RH sensor in this instrument is not designed for use in bright sunlight or in the
presence of a strong radiant heat sources. It is intended primarily for indoor use. It is not equivalent to
a protected dry-bulb thermometer.
PM/dust
 Clean the optical engine mirror with a soft cloth, if it is dirty. Scratches will affect performance.
 Avoid measuring wet particles, fogs, and liquid mists that will tend to cling to the impactor, optical engine,
tubing, and pump surfaces.
 Avoid oily mists as found near some machining operations.
 This monitor is designed to measure dry particulates, not filaments.
 Do not attempt to measure Asbestos with this instrument.
 Keep a "Pump Protection Filter" or other gravimetric filter in place to help prolong the life of the pump.
 You must check & calibrate the flow rate, when using this device as a (gravimetric) sampling pump.

Dangers, warnings, & cautions (continued)
iii
Dangers, warnings, & cautions (continued)
Caution!
CO2
 Avoid exposure to condensation, fogs, and liquid mists, that can contaminate the optical path inside the
CO2 sensor.
PID
 This instrument cannot detect methane gas.
 For best sensor life, avoid acidic condensing gases.
 The presence of moisture can affect performance of the PID.
Toxic
 Beware of certain cross-sensitivities when measuring toxic gas levels. Readings can be nonspecific in
the presence of certain cross-contaminant gases.
Air velocity
 The tip of the Air velocity probe is very fragile.
FCC Compliance Statement
 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial or residential environment. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. If harmful interference
occurs, the user will be required to correct the interference at his or her expense.

Table of Contents
iv
Table of Contents
