Aaeon EMB-B75A User manual

Industrial Motherboard
EMB-B75A

ii
E11479
Revised Edition V2
March 2016
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described
in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted
in any form or by any means without the prior written permission of the original
manufacturer. Information provided in this manual is intended to be accurate and
reliable. However, the original manufacturer assumes no responsibility for its use,
or for any infringements upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to
change without notice. While reasonable efforts have been made in the preparation
of this document to assure its accuracy, the original manufacturer assumes no
liabilities resulting from errors or omissions in this document, or from the use of the
information contained herein.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
Acknowledgments
All other products’ name or trademarks are properties of their respective owners.
• AMI is a trademark of American Megatrends Inc.
• Intel®, Core™ are trademarks of Intel® Corporation.
• Microsoft Windows®is a registered trademark of Microsoft Corp.
• ITE is a trademark of Integrated Technology Express, Inc.
• IBM, PC/AT, PS/2, and VGA are trademarks of International Business
Machines Corporation.
The original manufacturer reserves the right to make changes in the product
design without notice to its users.
All other product names or trademarks are properties of their respective owners.

iii
Contents
Chapter 1: Product overview
1.1 Package contents......................................................................... 1-1
1.2 Features ........................................................................................ 1-1
1.3 Specifications............................................................................... 1-2
Chapter 2: Motherboard information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard layout...................................................................... 2-2
2.3 Screw size..................................................................................... 2-4
2.3.1 Component side.............................................................. 2-4
2.3.2 Solder side ...................................................................... 2-5
2.4 Central Processing Unit (CPU) ................................................... 2-6
2.4.1 Installing the CPU ........................................................... 2-7
2.4.2 CPU heatsink and fan assembly installation................... 2-9
2.5 System memory ......................................................................... 2-11
2.5.1 Installing a DIMM .......................................................... 2-11
2.6 Jumpers ...................................................................................... 2-12
2.7 Connectors ................................................................................. 2-14
2.7.1 Rear panel connectors.................................................. 2-14
2.7.2 Internal connectors ....................................................... 2-16
Chapter 3: BIOS setup
3.1 BIOS setup program .................................................................... 3-1
3.1.1 BIOS menu screen.......................................................... 3-2
3.1.2 Menu bar......................................................................... 3-2
3.1.3 Navigation keys............................................................... 3-3
3.1.4 Menu items ..................................................................... 3-3
3.1.5 Submenu items ............................................................... 3-3
3.1.6 Congurationelds ......................................................... 3-3
3.1.7 Pop-up window ............................................................... 3-3
3.1.8 Scroll bar......................................................................... 3-3
3.1.9 General help ................................................................... 3-3
3.2 Main menu .................................................................................... 3-4
3.2.1 System Time [xx:xx:xx] ................................................... 3-4
3.2.2 System Date [Day xx/xx/xxxx]......................................... 3-4

iv
Contents
3.3 Advanced menu ........................................................................... 3-5
3.3.1 ACPI Setting ................................................................... 3-5
3.3.2 Trusted Computing ......................................................... 3-5
3.3.3 CPUConguration .......................................................... 3-5
3.3.4 Digital IO ......................................................................... 3-6
3.3.5 SATAConguration ........................................................ 3-6
3.3.6 USBConguration .......................................................... 3-7
3.3.7 SuperIOConguration ................................................... 3-7
3.3.8 H/W Monitor .................................................................... 3-8
3.4 Chipset.......................................................................................... 3-8
3.4.1 PCH-IOConguration ..................................................... 3-8
3.4.2 SystemAgent(SA)Conguration ................................. 3-10
3.5 Boot menu .................................................................................. 3-11
3.5.1 BootConguration ........................................................ 3-11
3.5.2 CSM parameters........................................................... 3-11
3.6 Security menu ............................................................................ 3-12
Administrator Password ............................................................... 3-12
User Password............................................................................. 3-13
3.7 Save & Exit menu ....................................................................... 3-13
Save Changes & Reset................................................................ 3-13
Appendix
Notices.......................................................................................................A-1

1-1
Chapter 1: General information
1.1 Package contents
Check your industrial motherboard package for the following items.
1 x Industrial Motherboard
1 x Cable Kit
1 x I/O Shield
1 x DVD-ROM for manual (in PDF format) and drivers
NOTE: If any of the above items is damaged or missing, contact your
distributor or sales representative immediately.
1.2 Features
• Intel®Socket 1155 For 2nd Generation Core™ i7/Core™ i5/Core™ i3
Processors Up To 95W
• Two 240-pin Dual Channel DDR3 1066/1333MHz (1600 MHz for 3rd
Generation Core™ Processors) DIMM Up To 16GB
• Three Independent Display: VGA x 1 , HDMI x 3
• 10/100/1000Base-T x 2
• SATA 6.0 Gb/s x 1, SATA 3.0 Gb/s x 2, USB3.0 x 4, USB2.0 x 10, COM x 2
• PCI-Express[x16] x 1
• Onboad TPM Function
• EuP/ErP Compliance
Chapter 1
Product overview

EMB-B75A
1-2
1.3 Specifications
SYSTEM
Form factor Mini-ITX
CPU LGA1155 socket for Intel®2nd Generation Core™ i7 / Core™ i5 /Core™ i3
processors
Supports Intel®22nm CPU up to 95W
Supports Intel®Turbo Boost Technology 2.0
• TheIntel®TurboBoostTechnology2.0supportdependsontheCPUtypes.
Memory 2 x DIMM (8GB per DIMM), max. 16GB, DDR3 1333 / 1066 (DDR3 1600 for
Ivy Bridge processors) MHz
Dual-channel memory architecture
Chipset
Intel®B75
I/OChipset
ITE IT8728F
Ethernet
Realtek® 8111F-VB-CG, 10/100/1000Base-TX
2 x RJ-45 ports
BIOS
AMI Plug & Play SPI BIOS – 1 x 64MB ROM
Wake on LAN
Yes
Watchdog Timer
1~255 steps by software program
H/WStatusMonitor
Monitors CPU/system temperature
Monitors Vcore, 5V/3.3/5Vsb voltages
Monitors CPU/system fan speed
Expansionslot
1 x PCI Express 3.0 x16 slot
Battery
Lithium battery
Power requirement
1 x 24-pin ATX connector
1 x 4-pin ATX 12V power connector
1 x CPU fan
1 x System fan with 4-pin wafer for Smart FAN support
Board size
6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Gross weight
1.1 lb (0.5 Kg)
Operating
temperature
32oF~140oF (0oC~60oC)
Storage temperature
-40oF~176oF (-40oC~80oC)
Operatinghumidity
0%~90% relative humidity, non-condensing
Powercompliance
Compliant with Eup/ErP
Certificate
CE/FCC Class A
(continued on the next page)

1-3
Chapter 1: General information
DISPLAY
Chipset
Intel®Ivy Bridge +B75
Resolution
Up to 1920x1200@60Hz for CRT
Up to 1920x1080@60Hz for HDMI
Maximum shared system memory up to 1748MB
Output interface
1 x VGA port
3 x HDMI ports (1 x HDMI ports; 3 x DP to HDMI ports) on rear I/O
I/O
Storage
1 x SATA 6.0Gb/s port
2 x SATA 3.0Gb/s ports
Serialport
1 x RS-232/422/485 (Box header)
1 x RS-232 (Box header)
USB
2 x USB3.0 (Type A port ) on rear I/O
2 x USB3.0 (Box header)
2 x USB2.0 (Type A port) on rear I/O
4 x USB2.0 (Pin header)
DIO
8-bit Digital I/O interface (4-in/4-out)
TPM
OnboardInneonSLB9635TT1.2
RTC
Internal RTC
Keyboard/Mouse
1 x PS/2 Keyboard on rear I/O
1 x PS/2 Mouse on rear I/O
Audio
Realtek ALC887-VD2-CG ,MIC-in/Line-in/ Line-out
Ethernet
2 x RJ-45 ports on rear I/O
Display
1 x VGA port on rear I/O
3 x HDMI ports on rear I/O
Others
1 x Front panel connector (Pin header)
NOTE: Specicationsaresubjecttochangewithoutnotice.

EMB-B75A
1-4

2-1
Chapter 2: Motherboard information
Chapter 2
Motherboard information
2.1 Before you proceed
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
CAUTION!
• Unplugthepowercordfromthewallsocketbeforetouchingany
component.
• Beforehandlingcomponents,useagroundedwriststraportouchasafely
groundedobjectorametalobject,suchasthepowersupplycase,toavoid
damaging them due to static electricity.
• HoldcomponentsbytheedgestoavoidtouchingtheICsonthem.
• Wheneveryouuninstallanycomponent,placeitonagroundedantistatic
pad or in the bag that came with the component.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpower
supply is switched off or the power cord is detached from the power
supply.Failuretodosomaycauseseveredamagetothemotherboard,
peripherals,orcomponents.
Main and Standby Power LEDs
The motherboard comes with one standby power LED and main power LED that
lightuptoindicatethatthesystemisON,insleepmode,orinsoft-offmode.This
is a reminder that you should shut down the system and unplug the power cable
beforeremovingorplugginginanymotherboardcomponent.Theillustrationbelow
shows the location of the onboard LEDs.
LED1
ON
Main Power Powered Off
OFF
LED2
ON
Standby Power Powered Off
OFF
EMB-B75A Onboard LED

EMB-B75A
2-2
2.2 Motherboard layout
HDMI3HDMI2
EATX_PWR2
ALC
887
RTL
8111E
RTL
8111F
ASM
1442
EPU
PS161
PS161
Super
I/O
CLRTC1
ATMODE
17.0cm(6.7in)
17.0cm(6.7in)
EATXPWR1
DDR3_A0_U1 (64bit, 240-pin module)
Intel®
B75
DDR3_B0_U1 (64bit, 240-pin module)
SATA6G_1
SATA3G_1 SATA3G_2
KBMS1
VGA1
HDMI1
AUDIO
LAN1_USB3
LAN2_USB2
F_PANEL
LED2
LED1
BZ1
USB89
USB3_23 USB1011
Dio1
COM2 COM1
SYS_FAN1
CPU_FAN1
SATA_PWR1
COM1
_VSET1
DEBUG1
LGA1155
PCIEX16_1
Lithium Cell
CMOS Power
41 2
13
12
9 118 10
15 1416
1
573 46
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION!Donotovertightenthescrews!Doingsocandamagethe
motherboard.

2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots Page
1. ATXpowerconnectors(24-pinEATX_PWR1,4-pinEATX_PWR2) 2-16
2. SATAPowerconnector(SATA_POWER) 2-23
3. CPUandsystemfanconnectors(4-pinCPU_FAN1,4-pinSYS_FAN1) 2-17
4. Intel®B75SerialATA6.0Gb/sconnector(7-pinSATA6G_1) 2-19
5. Intel®B75SerialATA3.0Gb/sconnectors(7-pinSATA3G_1~2) 2-19
6. USB3.0connector(20-1pinUSB3_23) 2-20
7. USB2.0connectors(10-pinUSB89,USB1011) 2-21
8. ClearRTCRAM(3-pinCLRTC) 2-12
9. Serialportconnector(10-pinCOM1,COM2) 2-22
10. DDR3DIMMslots 2-11
11. Systempanelconnector(10-1pinF_PANEL) 2-18
12. COM1Ring/+5V/+12Vselection(COM1_VSET1) 2-13
13. MainandStandbyPowerLEDs(LED1,LED2) 2-1
14. ATMode(ATMODE) 2-13
15. Intel®LGA1155CPUsocket 2-6
16. DIOconnector(DIO1) 2-22

EMB-B75A
2-4
2.3 Screw size
2.3.1 Component side
9.70
30.27 51.34 78.00
107.46 131.31 150.04 170.00
0.00
79.79
36.92
171.58
8.86
30.00
35.99
41.19
48.25
55.31
0.00
52.05
81.37
89.12
74.96
92.74
104.61
103.66
111.79
125.35
161.51
168.54
162.31
124.30
142.42
152.94
46.94
10.96 27.60
36.61
43.60 29.90
3.48 4.59
18.66 34.45 88.42 142.37
160.92
82.30
103.94 127.85 149.04
0.00
20.23
13.54 12.29
4.86
107.23
30.14
36.49
51.15
8.42 24.40
141.58
7.46
36.92

2-5
Chapter 2: Motherboard information
2.3.2 Solder side
10.07
50.04
57.35
32.93
69.54
87.54
105.54
100.60
125.04
165.01
170.00
0.00
6.26 14.79
45.29 70.34 81.42
142.43
145.35
163.74
0.00

EMB-B75A
2-6
IMPORTANT:UnplugallpowercablesbeforeinstallingtheCPU.
CAUTION!
• Uponpurchaseofthemotherboard,ensurethatthePnPcapison
thesocketandthesocketcontactsarenotbent.Contactyourretailer
immediatelyifthePnPcapismissing,orifyouseeanydamagetothe
PnPcap/socketcontacts/motherboardcomponents.Themanufacturerwill
shoulderthecostofrepaironlyifthedamageisshipment/transit-related.
• Keepthecapafterinstallingthemotherboard.Themanufacturerwill
processReturnMerchandiseAuthorization(RMA)requestsonlyifthe
motherboardcomeswiththecapontheLGA1155socket.
• Theproductwarrantydoesnotcoverdamagetothesocketcontacts
resultingfromincorrectCPUinstallation/removal,ormisplacement/loss/
incorrectremovalofthePnPcap.
2.4 Central Processing Unit (CPU)
ThemotherboardcomeswithasurfacemountLGA1155socketdesignedforthe
Intel®2ndGenerationCore™i7/Core™i5/Core™i3processors.
EMB-B75A CPU socket LGA1155

2-7
Chapter 2: Motherboard information
2.4.1 Installing the CPU
1
CAUTION!TheLGA1156CPUisincompatiblewiththeLGA1155socket.DO
NOTinstallaLGA1156CPUontheLGA1155socket.
A
B
2 3

EMB-B75A
2-8
A
B
C
4
5

2-9
Chapter 2: Motherboard information
2.4.2 CPU heatsink and fan assembly installation
CAUTION!ApplytheThermal
InterfaceMaterialtotheCPU
heatsinkandCPUbeforeyou
install the heatsink and fan if
necessary.
To install the CPU heatsink and fan assembly
B
A
A
B
1
2
3 4

EMB-B75A
2-10
A
B
B
A
To uninstall the CPU heatsink and fan assembly
2
1

2-11
Chapter 2: Motherboard information
2.5 System memory
2.5.1 Installing a DIMM
To remove a DIMM
1
2
3
A
B

EMB-B75A
2-12
2.6 Jumpers
1. Clear RTC RAM (CLRTC)
ThisjumperallowsyoutocleartheRealTimeClock(RTC)RAMin
CMOS.YoucancleartheCMOSmemoryofdate,time,andsystemsetup
parametersbyerasingtheCMOSRTCRAMdata.Theonboardbutton
cellbatterypowerstheRAMdatainCMOS,whichincludesystemsetup
information such as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Movethejumpercapfrompins1-2(default)topins2-3.Keepthecapon
pins2-3forabout5~10seconds,thenmovethecapbacktopins1-2.
3. Plug the power cord and turn ON the computer.
4. Holddownthe<Del>keyduringthebootprocessandenterBIOSsetup
to reenter data.
CAUTION!ExceptwhenclearingtheRTCRAM,neverremovethecapon
CLRTCjumperdefaultposition.Removingthecapwillcausesystemboot
failure!
NOTES:
• Ifthestepsabovedonothelp,removetheonboardbatteryandmovethe
jumperagaintocleartheCMOSRTCRAMdata.AfterclearingtheCMOS,
reinstall the battery.
• YoudonotneedtocleartheRTCwhenthesystemhangsdueto
overclocking.Forsystemfailureduetooverclocking,usetheCPU
ParameterRecall(C.P.R)feature.Shutdownandrebootthesystemsothe
BIOScanautomaticallyresetparametersettingstodefaultvalues.
EMB-B75A Clear RTC RAM
1 2 2 3
Normal
(Default)
Clear RTC
CLRTC
