Aaeon ACD-515R User manual

Remote Touch Display
ACD - 515 R
ACD-515R
15.6” WXGA Infotainment Touch Display
With Remote Display Technology
IP-65 Front Bezel
Multi-Touch Window Design (Two-Point)
ACD-515R Manual 2nd Ed
June 19, 2014

Remote Touch Display
ACD - 515 R
i
Copyright Notice
This document is copyrighted, 2014. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

Remote Touch Display
ACD - 515 R
ii
Acknowledgments
Intel®is registered trademarks of Intel®Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft®Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIATechnology, Inc.
All other product names or trademarks are properties of their
respective owners.

Remote Touch Display
ACD - 515 R
iii
Packing List
The LCD monitor comes with the following standard parts shown as
below. Check and make sure they are included and in good condition.
If anything is missing or damaged, contact the dealer immediately.
1 ACD-515R
1 Utility CD-ROM
Contains User’s Manual (in PDF format), Drivers and
Utilities
1 AC/DC 12V Power Adapter with Lock
If any of these items are missing or damaged, you should contact your
distributor or sales representative immediately.

Remote Touch Display
ACD - 515 R
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.

Remote Touch Display
ACD - 515 R
v
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). IT MAY
DAMAGE THE EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received
including interference that may cause
undesired operation.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon
incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé
par le constructeur. Recycler les batteries usées en accord avec les
instructions du fabricant et les directives gouvernementales de
recyclage.

Remote Touch Display
ACD - 515 R
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Display
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质触控模块为选购品。

Remote Touch Display
ACD - 515 R
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................ 1-2
1.2 Features ....................................................................1-3
1.3 General Specification................................................ 1-4
1.4 Dimension .................................................................1-7
1.5 Network Topology .....................................................1-8
Chapter 2 Hardware Installation
2.1 Before Unpacking...................................................... 2-2
2.2 Connecting Power and Cables.................................. 2-3
2.3 VESA Wall Mounting.................................................2-4
2.4 LED Definitions.......................................................... 2-5
2.5 Button Definitions ......................................................2-5
2.6 DIP Switch.................................................................2-7
2.7 Connecting Power of Remote Display ......................2-8
2.8 Connecting I/O Connectors of Remote Display ........2-8
2.9 Connection Debugging.............................................. 2-8
2.10 The Matching of the Remote Box and Remote
Display.............................................................................2-9
Chapter 3 On Screen Display Control
3.1 On Screen Display (OSD) Board Description. .......... 3-2
3.2 OSD Main Menu: Push The MENU Keys..................3-3

Remote Touch Display
ACD - 515 R
viii
3.3 Select Input Source................................................... 3-4
3.4 Contrast/ Brightness- Submenu................................ 3-5
3.5 Geometry Menu.........................................................3-6
3.6 Color Temperature- Submenu OSD Main Menu: Push
The MENU Keys.............................................................. 3-7
3.7 RGB Color- Submenu. ..............................................3-8
3.8 Language- Submenu................................................. 3-9
3.9 Auto Config- Submenu.............................................. 3-10
3.10 Mode Resolution- Submenu Chapter......................3-11
3.11 Exit Menu- Submenu...............................................3-12
Chapter 4 Touch Screen Driver Installation
4.1 Introduction................................................................ 4-2
4.2 Installing Driver for Windows® XP/ Windows® 7 / Linux
.........................................................................................4-2

Remote Touch Display
A C D - 515 R
Chapter 1 General Information 1-1
General
Information
Chapter
1

Remote Touch Display
A C D - 515R
Chapter 1 General Information 1-2
1.1 Introduction
Thank you for purchasing of the Infotainment Touch Display with
Remote Display Technology - a marvelous contribution of
cutting-edge technology.
The LCD monitor has been designed with serious thoughts to
present the best performance for most applications. Symbol of
elegance, its compact and slim profile are well suited in working
locations where space is at a premium.
The TFT LCD monitor displays sharper, more brilliant, crisper and
flicker-free images. Complying with the power management
regulations of VESA DPMS, the LCD monitor is extremely energy
efficient and a power saver. Plus, the LCD monitor has extremely
low radiation emissions and near zero electromagnetic fields which
are supreme benefits.
Fully compatible with PC system, the LCD monitor provides full
interface for all sorts of related standards. Supported by “Plug &
Play” complying with DDC1/DDC2B, installing the LCD monitor is
absolutely trouble free.
The On Screen Display menu provides user a convenient interface
to make right adjustment for optimum display performance.

Remote Touch Display
A C D - 515 R
Chapter 1 General Information 1-3
1.2 Features
15.6”WXGA (1366 x 768) Fanless TFT LCD Display
Supports Remote Display Technology
Easy-To-Clean: Multi-Touch Window Design (Two-Point)
IP65 Front Bezel & IPx1 Back Chassis Protection
Anti-Scratch Surface (7H Hardness)

Remote Touch Display
A C D - 515R
Chapter 1 General Information 1-4
1.3 General Specification
System
Input signal
VGA, DVI
Control
OSD (On Screen Display) on the panel
I/O connector
USB x 3 (optional 2 on front, 1 on rear), LAN
x 2, Line-out x 1, 2W speaker x 2
OS Support
Windows®XP (T/S: Single point), Linux
Fedora (T/S: Single point), Windows®7 (T/S:
Single point)
Mechanical
Construction
IP65/NEMA4 for plastic front bezel, IPx1 for
plastic chassis
Mounting
VESA 75/100
Dimension
15.51”x 10.71”x 2.2”(394mm x 272mm x
56mm)
Carton
Dimension
20.47”x 18.5”x 9.06”(520mm x 470mm x
230mm)
Gross Weight
11 lb (5 Kg)
Net Weight
6.6 lb (3 Kg)
Environmental
Operating
32°F~ 104°F (0°C to 40°C)

Remote Touch Display
A C D - 515 R
Chapter 1 General Information 1-5
Temperature
Storage
Temperature
-4°F~ 140°F (-20°C to 60°C)
Storage
Humidity
10%~95% @ 40°C, non-condensing
Vibration
1g rms/5-500Hz/random operation
Shock
15 G peak acceleration (11 msec. duration)
EMC
CE/FCC Class A
Power Supply
DC Input
DC 12V, w/AC power adapter w/lock
LCD
Display Type
15.6”TFT-LCD, CCFL
Max.
Resolution
1366x768
Max. Colors
16.7M colors (6/8-bit for R, G, B)
Luminance
300 cd/m2
Brightness
300 cd/m2(TYP.)
Viewing Angle
170°(H)/ 160°(V)
Backlight
CCFL
Backlight
MTBF (hours)
50,000

Remote Touch Display
A C D - 515R
Chapter 1 General Information 1-6
Touchscreen
Type
Projected Capacitive Multi-Touch
(Windows®7)
Light
Transmission
90%

Remote Touch Display
A C D - 515 R
Chapter 1 General Information 1-7
1.4 Dimension

Remote Touch Display
A C D - 515R
Chapter 1 General Information 1-8
1.5 Network Topology
1. One-to-one Network
The purpose of a one-to-one network is to allow a display to be used
anywhere away from the host PC. The display can be placed at any
location with Ethernet access. The entire VGA/DVI signal will be
transmitted from a host PC to a remote display via the Ethernet.
2. One-to-Multiple Network
The one-to-multiple network is a special design for digital signage
applications to show the same screen/audio in different display monitors.
The display can be placed in any area where you can get an Ethernet
connection. The screen & audio which is from the host PC can be shown in
remote displays via Ethernet

Remote Touch Display
A C D - 515 R
Chapter 1 General Information 1-9
3. Cascade Network
The purpose of a cascade network is to save on cabling installation costs. It
is specially designed for digital signage applications with limited space
such as trains, buses and airports. With a cascade network set up, an end
user can deploy digital signage displays easily and save on installation
costs.

Remote Touch Display ACD-515R
Chapter2HardwareInstallation2-1
H
ardware
Chapter
2
Installation

Remote Touch Display ACD-515R
Chapter 2 Hardware Installation 2-2
2.1 Before Unpacking
It is very important to place the LCD Display in a suitable
environment.
The surface for placing the LCD Display should be
stable and level.
Make sure the place has good ventilation, and out of
direct sunlight; away form sources of excessive dust,
dirt, heat, water, moisture and vibration.
Convenience for connecting the LCD Display the
related facilities should be well considered too.
