— CMS 700 User manual
—
CIRCUIT MONITORING SYSTEM
CMS-700
User manual
• Energy transparency at branch level for optimal load distribution
• Measurements of all kinds of currents (DC,AC, or mixed) up to 160A
• Simplified installation thanks to quick mounting of sensors
• Smart commissioning in only a few minutes
• Easy retrofitting and upgrades thanks to the flexible, modular design

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
3
005 Use and storage of the manual
006 General information
007 Packaging contents
008–011 Product overview
012–013 Measurements and Events definition
014 Memory architecture
015–018 Components of CMS system
019–022 Installation Guide
023–024 Wiring diagrams
025–028 Initial Commissioning
029–031 Web User Interface Overview
031–045 WEB UI - Settings Menu
046–050 WEB UI - Home Menu
051–055 Modbus
056–058 Simple Network Management
Protocol – SNMP
059–063 Modbus and SNMP Mapping
064 FAQ
—
Table of contents

4
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
5
—
Storing
The manual must be stored close to the device; safe from liquids and anything else which may
compromise its leggibility. The manual and the declaration of conformity are both an integral part
of the device until it is dismantled. If the manual is lost or illegible please request a copy from the
manufacturer.
Copyright
The copyright of this manual is the property of ABB Ltd. This manual contains texts, designs and
illustrations of a technical nature which must not be disclosed or transmitted to third parties, even
partially, without the written authorisation of ABB Ltd.
Liability disclaimer
The information contained in this document is subject to change without notice and cannot be
considered as an obligation by ABB Ltd. ABB Ltd. is not liable for any errors that may appear in this
document. ABB Ltd. is not liable under any circumstances for any direct, indirect, special, incidental
or consequential damage of any kind that may arise from using this document. ABB Ltd. is also not
liable for incidental or consequential damage that may arise from using the software or hardware
mentioned in this document.
Brand
ABB Ltd. is a registered trademark of ABB Group. All other brands or product names mentioned
in this document are trademarks or registered trademarks of their respective owners.
Meaning of symbols
Warning – can result in death or
serious personal injury
Non-safety related, but useful
and important information
CE conformity mark Torque
Observe the accompanying
documents
Disposal
Installation,
electrotechnical expertise
Equipment protected throughout
by reinforced insulation
—
Use and storage of the manual
This manual contains all of the safety information, the technical
aspects and the operating necessary to ensure the correct use of
the device and maintain it in safe conditions.

6
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
—
General information
—
Safety warnings
—
Cleaning
Attention: Non-adherence to the
following points can lead to serious injury or death.
Use the suitable personal protection devices and adhere to the current
regulations governing electrical safety.
This device must be installed exclusively by qualified personnel who have
read all of the information relative to the installation.
Check that the voltage on the main side is compatible with the range permitted by the device.
Ensure that all current and voltage supplies are disconnected prior to carrying
out any controls, visual inspections and tests on the device.
Always assume that all circuits are under voltage until they are completely
disconnected, subjected to tests and labelled.
Disconnect all of the power supply prior to working on the device.
Always use a suitable voltage detection device to check that the supply is interrupted.
Pay attention to any dangers and carefully check the work area ensuring that no instruments or foreign
objects have been left inside the compartment in which the device is housed.
The correct use of this device depends on a correct manipulation, installation and use.
Failure to adhere to the basic installation information can lead to injuries as well
as damage to the electric instruments or to any other product.
The tests carried out at a high voltage can damage the device's electronic components.
Disposal
Defective devices must be disposed of as special waste at the appropriate collection
points set up for this purpose. National or regional regulations on the disposal of special
waste must be followed.
Service and maintenance
The device undergoes several safety assessments before shipment and will be sealed. If
a device is opened, the safety assessments have to be repeated. A warranty will be provided
for unopened devices only.
Use a dry cloth.
Installation to mains
Installation of CMS-700 to mains shall include a switch or circuit breaker for the connection
to mains. The switch or circuit breaker must be suitably located and easily reachable and must be
marked as the disconnecting device for the CMS-700.
Disconnection from mains or connection to mains
Switch off circuit breaker or switch before disconnecting from the mains supply or connecting
to the mains supply. Same applies for all other connections (L1, L2, L3, N).

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
7
—
Packaging contents
Attention: The following items are not
included in the delivery of the product
1) CMS-Sensors
2) Current transformer (CT)
3) CMS-BUS
4) Connector set
- Control unit (CMS-700)
- Installation manual
CMS-700
control unit
Energy Monitor 96

8CMS-700 SYSTEM CIRCUIT MONITORING SYSTEMS (CMS)
CMS-700
control unit
Energy Monitor 96
1
ethernet
L1/supply
I1
L2
I2
L3
I3
L4/N
I4/N serial
2 3
96 CMS Sensors
Serial: RS485 Modbus RTU
Ethernet: Modbus TCP, SNMP
Webserver for configuration
& visualization
Integrated power supply
Input for current transformer
Input for voltage supply
and measurement
—
Product overview
Intended use
The system consists of a control unit and sensors with different measurement ranges.
The sensors measure alternating, direct and mixed currents (TRMS) and get connected to the control
unit by a flat cable, the CMS-Bus. The measurement data can be displayed or analyzed via LAN interface
with the integrated web server or Modbus TCP or SNMP protocols or via RS485 interface, such as
Modbus RTU.
The CMS-700 control unit is a measuring instrument for recording
the performance and energy of mains and of up to 96 branch sensors.

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
9
—
Product overview
—
Reset button
There is a recessed button to restart the device or for resetting it to a defined as-delivered condition.
• Pressing the button for 3 to less than 6 seconds restarts the device with current settings
• Pressing the button for more than 10 seconds resets the device to the factory settings
Do not switch off the device during the reset process.
—
LEDs
Two LEDs indicate respectively the status of the device and the one of the network.
1. LED Status
Display Function
Off Device is off
Green on Device is ready
Green flashing slowly Firmware is ready, Web server is loading
Orange flashing slowly Firmware update ongoing
Orange on Booting
Red on Booting error
2. LED Network
Display Function
Off LAN is not connected
Green on LAN is connected
Green flashing Network traffic

10
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
—
Product overview
Technical specifications
CMS-700 Control Unit
IEC61010-1
Supply voltage [VAC] 90-240 (L1-N)
Voltage measurement range [VAC] 90-240 (L1-N, L2-N, L3-N)
UL 508 / CSA C22.2 No. 14
Supply voltage [VAC] 80-277 (L1-N)
Voltage measurement range [VAC] 80-277 (L1-N, L2-N, L3-N)
General
Frequency [Hz] 50 / 60
Power consumption (L1-N) [VA] 5 .. 40
(depending on number of sensors)
Current measurement range, [A] nominal: 5
Current transformer max.: 6
(secondary wire of CT)
  
Operating temperature [°C] -25 .. +60
Storage temperature [°C] -40 .. +85
LAN (RJ45 connector) [Mbit/s] 100
Modbus RTU [Baud] RS485 2-wire, 2400..115200
Cable cross section 1.0.. 2.5 mm², max. 0.8 Nm *)
Stripping length [mm] 10
Tightening torque of screws [Nm] 0.5..0.8
Mounting DIN-rail 35 mm DIN50022
Dimensions [mm] 160.0 x 87.0 x 64.9 (9 DIN modules)
Overvoltage category II
Pollution degree 2
Altitude m 2000
Safety class IP20
Main circuit accuracy
Voltage ± 1%
Current ± 1%
Harmonic component (up to 2500Hz) ± 1%
Active power ± 2 %
Apparent power ± 2 %
Reactive power ± 2 %
Power factor ± 2 %
Standards
Electrical safety IEC 61010-1, UL 508, CSA C22.2 No.14
EMC IEC61326-1
*) Line protection is recommended (acc. IEC61439) min. 6A, max 8A for 1mm2, 12A for 1.5mm2, 20A for 2.5mm2
—
CMS-700

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
11
—
Product overview
Overall dimensions
162
87
61.2
25
20 45
722
43.6
58.1
6.1
3

12
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
—
Measurements and Events definition
—
Principle of measurement
The principle of measurement for AC of the CMS-700 control unit includes measurement on the
mains and branches. On the mains side, all values are measured directly. On the branches, current is
measured while voltage, power factor as well as active power and energy are calculated using
measured mains values.
For further information, please refer to the following table
Mains Branches/Sensors
Measurement of
IMAINS (Current) [A] ITRMS, IAC, IDC (Current TRMS, AC, DC) [A]
Measured mains values used for calculation
UMAINS (Voltage) [V] UMAINS (Voltage) [V]
PF (Power Factor) PF (Power Factor) (manual configuration is possible)
THD (Voltage, Current) (%)
Calculation of
Power:
– active [W]
– apparent [VA]
– reactive [var]
PSENS (Active power) [W]
PSENS= UMAINS · IAC · PF
Energy [kWh] EnergySENS [kWh]
Attention: Referring to the
diagram in the figure aside,
please note that N on the
supply has to be connected
in order to avoid damage
of the device. Twisting
the phase and neutral
can damage the device.
Voltage-Input
Supply & Measurement
SMS-Bus,
3 x32 Sensors
Branches
CMS-Bus
Flat Cable
Mains Branches
Sensors
CMS 700
CT-Input
Current Measurement
L1/Supply
L2
L3
N/Supply
I1
A
B
A
B
A
B
A
B
I2
I3
14/N

13
—
Measurements and Events definition
—
Events
If a measurement object (e.g. TRMS current of a branch) crosses predefined threshold conditions
(value, direction and delay time) then an event is registered.
Following options linked to events logging are available:
• Visualization of all detected events in WebUi
• Reading event/alarm status through Modbus register
• Export via FTP and Email
In order to configure an event, specifications of the following are required:
• The threshold value
• Indication of cross direction (cross up, cross down)
• Indication of delay time
Events can be linked both to mains and branches object values:
Branches
Object Unit Alarm cross Resolution Format
Status up/down Threshold
no Alarm 0
Current TRMS A 11 up 0.01 unsigned
Current TRMS A 12 down 0.01 unsigned
Active power P W 41 up 1 unsigned
Active power P W 42 down 1 unsigned
Mains
Objekt Unit Alarm cross Resolution Format L1 L2 L3 N
Status up/down Threshold
no Alarm 0 x x x x
I A 11 up 0.01 unsigned x x x x
I A 12 down 0.01 unsigned x x x x
THD-I % 21 up 0.01 unsigned x x x x
THD-I % 22 down 0.01 unsigned x x x x
U V 31 up 0.01 unsigned x x x
U V 32 down 0.01 unsigned x x x
THD-U % 41 up 0.01 unsigned x x x
THD-U % 42 down 0.01 unsigned x x x
P W 51 up 1 singed x x x
P W 52 down 1 singed x x x
S VA 61 up 1 unsigned x x x
S VA 62 down 1 unsigned x x x
Q var 71 up 1 signed x x x
Q var 72 down 1 signed x x x
Power factor - 81 up 0.01 singed x x x
Power factor - 82 down 0.01 singed x x x
Active Energy Wh 121 up 10 singed x x x
Active Energy Wh 122 down 10 singed x x x
The type of event is available on Modbus map as Alarm Status. Resolution refers to the accuracy with
which the value is defined. If several events occur for the same main or branch, the newest one will be
given out via Modbus.
Three register blocks are available in the Modbus register map:
• only object type with alarm code
• object type with alarm code and threshold value
• number of currently active alarms

14
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
—
Memory architecture
The measured values of the main power network and those of the 96 outputs
are stored in the following memory areas:
Stored values
Mains
• Voltage [V]: L1, L2, L3
• Current [A]: L1, L2, L3, N
• Power factor [-]: L1,L2,L3
• THD U [%]: L1, L2, L3
• THD I [%]: L1, L2, L3, N
• Active power[W]: L1, L2, L3
• Apparent power [VA]: L1, L2, L3
• Reactive power [VAR]: L1, L2, L3
• Active power summation [W]
• Apparent power summation [VA]
• Reactive power summation [VAR]
• Active energy [Wh]: L1, L2, L3
• Apparent energy [VAh]: L1, L2, L3
Branches
• Current (TRMS, AC, DC) [A]
• Active power [W]
• Active energy [Wh]
These values of the respective stacks can be exported as a CSV-file
and pulled into an FTP or sent by e-mail.
Time reference
The measured values are provided with a UTC time stamp. UTC (Universal Coordinated Time)
stands for the location-independent world time in seconds.

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
15
Pushbutton
Solid-core sensor
Open-core sensor
CMS-Bus
LED
Opening for the electrical
conductor
LEDs
Reset button
Terminal RS-4 85
Modbus (RTU)
CMS-Bus up to 96 sensors
RJ45-socket for LAN
connection
Terminals L1, L2, L3, N
• Wire gauge max 2.5 mm2
• Voltage 80-277 VAC 50/60 Hz
Terminal Current Transformer
for secondary winding,
nominal 5 A, max 6 A
—
Control Unit
—
CMS Sensor
—
Components of CMS system
Sensor LED Status:
ON
Sensor is online and in measurement mode. There is a feature in the configuration
to switch off the LED after a specified time
OFF
Sensor is not connected to CMS-Bus or is switched off in the configuration
Flashing slowly
Sensor is not assigned
Flashing fast
Sensor in assign process or in "setting/branches" mode. This sensor is the sensor
corresponding to the yellow-marked row on the screen for webserver settings.

16
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
System Pro M, SMISSLINE S800 DIN rail Cable tie
Mounting method for all MCBs, RCDs,
RCBOs with
twin terminals
for MCBs

RCBOs (SMISSLINE)
for fuse



with cage terminals
universally
usable
universally
usable
Open-core sensors

The laying method
influences the accuracy.
18-mm overall width
   - 
       
        
Solid-core sensors

18-mm overall width
     
    
      
25-mm overall width
   
   
   
* All accuracy specifications refer to the relevant full scale value and apply to 25°C
—
Sensors overview
—
Components of CMS system

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
17
System Pro M, SMISSLINE S800 DIN rail Cable tie
Mounting method for all MCBs, RCDs,
RCBOs with
twin terminals
for MCBs

RCBOs (SMISSLINE)
for fuse



with cage terminals
universally
usable
universally
usable
Open-core sensors

The laying method
influences the accuracy.
18-mm overall width
   - 
       
        
Solid-core sensors

18-mm overall width
     
    
      
25-mm overall width
   
   
   
* All accuracy specifications refer to the relevant full scale value and apply to 25°C
—
Current Transformer
Example: CT PRO XT 250
—
Components of CMS system
—
CMS Flat Cable
The CMS flat cable is a 4-pin cable for connecting multiple sensors to one control unit. The cable
is available in the following four lengths: 2m (CMS-800), 5m (CMS-802), 10m (CMS-803),
and 30m (CMS-805).
Please take into account the following information on the possible cable length of the CMS flat cable
depending on the number and shape of sensors:
Maximum flat cable length in m
Number of sensors Solid-core sensors Open-core sensors
  
  
  
  
  
  
 
• Do not exceed a total flat cable length of 32m for all CMS-Bus lines for each control unit.
• 
wires at the far end.
• For the flat cable, please consider:
- Use within closed housings only
- Keep a distance of min. 5.5 mm to uninsulated live parts
- Where necessary, additional protection against mechanical stress or UV radiation must be ensured.

18
CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
—
Components of CMS system
—
Connector Set
The CMS-820 connector set contains connector housings and connectors to connect
the flat cable to the sensors.
35 x connector housing 35 x connector

CMS-700 SYSTEM CIRCUIT MONITORING SYSTEM (CMS)
19
To assemble of the control unit, perform steps 1 and 2. The device can be mounted
horizontally or vertically. To disconnect, perform steps 3 and 4.
—
Warranty
Safe operation is ensured if assembly work has been carried out according to these user instructions.
Furthermore, the instructions in the manual must be observed.
Authorized Personnel
Assembly, connection, and removal work should only be carried out by authorized and qualified
personnel.
—
Assembly on 35mm DIN-Rail
• The CMS-700 can be mounted on all 35mm DIN rails (DIN50022)
• The device can be installed for single or three phase use
• When available, connect the LAN cable of the local network
—
Installation Guide
