Section 1 Introduction
1.1 This manual
The application manual contains application descriptions and setting guidelines
sorted per function. The manual can be used to find out when and for what purpose a
typical protection function can be used. The manual can also be used when calculating
settings.
1.2 Intended audience
This manual addresses the protection and control engineer responsible for planning,
pre-engineering and engineering.
The protection and control engineer must be experienced in electrical power
engineering and have knowledge of related technology, such as protection schemes
and principles.
1MRS758127 C Section 1
Introduction
RED615 5
Application Manual

1.3 Product documentation
1.3.1 Product documentation set
Planning & purchase Engineering Installation Commissioning Operation Maintenance Decommissioning, deinstallation & disposal
Quick start guide
Quick installation guide
Brochure
Product guide
Operation manual
Installation manual
Connection diagram
Engineering manual
Technical manual
Application manual
Communication protocol manual
IEC 61850 engineering guide
Point list manual
Cyber security deployment guideline
GUID-12DC16B2-2DC1-48DF-8734-0C8B7116124C V2 EN
Figure 1: The intended use of documents during the product life cycle
Product series- and product-specific manuals can be downloaded
from the ABB Web site http://www.abb.com/relion.
1.3.2 Document revision history
Document revision/date Product version History
A/2014-05-14 4.1 First release
B/2014-09-12 4.1.1 Content updated to correspond to the
product version
C/2019-04-30 5.0 FP1 Content updated
Download the latest documents from the ABB Web site
http://www.abb.com/substationautomation.
Section 1 1MRS758127 C
Introduction
6RED615
Application Manual

1.3.3 Related documentation
Name of the document Document ID
Modbus Communication Protocol Manual 1MRS759002
IEC 60870-5-103 Communication Protocol Manual 1MRS759001
IEC 61850 Engineering Guide 1MRS759000
Engineering Manual 1MRS758999
Installation Manual 1MRS758997
Operation Manual 1MRS758998
Technical Manual 1YHT530004D05
1.4 Symbols and conventions
1.4.1 Symbols
The electrical warning icon indicates the presence of a hazard which
could result in electrical shock.
The warning icon indicates the presence of a hazard which could
result in personal injury.
The caution icon indicates important information or warning related
to the concept discussed in the text. It might indicate the presence of
a hazard which could result in corruption of software or damage to
equipment or property.
The information icon alerts the reader of important facts and
conditions.
The tip icon indicates advice on, for example, how to design your
project or how to use a certain function.
Although warning hazards are related to personal injury, it is necessary to understand
that under certain operational conditions, operation of damaged equipment may result
in degraded process performance leading to personal injury or death. Therefore,
comply fully with all warning and caution notices.
1MRS758127 C Section 1
Introduction
RED615 7
Application Manual

1.4.2 Document conventions
A particular convention may not be used in this manual.
• Abbreviations and acronyms are spelled out in the glossary. The glossary also
contains definitions of important terms.
• Push button navigation in the LHMI menu structure is presented by using the
push button icons.
To navigate between the options, use and .
• Menu paths are presented in bold.
Select Main menu/Settings.
• LHMI messages are shown in Courier font.
To save the changes in nonvolatile memory, select Yes and press .
• Parameter names are shown in italics.
The function can be enabled and disabled with the Operation setting.
• Parameter values are indicated with quotation marks.
The corresponding parameter values are "On" and "Off".
• Input/output messages and monitored data names are shown in Courier font.
When the function starts, the START output is set to TRUE.
• This document assumes that the parameter setting visibility is "Advanced".
1.4.3 Functions, codes and symbols
Table 1: RED615 functions, codes and symbols
Function IEC 61850 IEC 60617 IEC-ANSI
Protection
Three-phase non-directional
overcurrent protection, low stage
PHLPTOC1 3I> (1) 51P-1 (1)
Three-phase non-directional
overcurrent protection, high stage
PHHPTOC1 3I>> (1) 51P-2 (1)
PHHPTOC2 3I>> (2) 51P-2 (2)
Three-phase non-directional
overcurrent protection,
instantaneous stage
PHIPTOC1 3I>>> (1) 50P/51P (1)
Three-phase directional overcurrent
protection, low stage
DPHLPDOC1 3I> -> (1) 67-1 (1)
DPHLPDOC2 3I> -> (2) 67-1 (2)
Three-phase directional overcurrent
protection, high stage
DPHHPDOC1 3I>> -> (1) 67-2 (1)
Non-directional earth-fault
protection, low stage
EFLPTOC1 Io> (1) 51N-1 (1)
EFLPTOC2 Io> (2) 51N-1 (2)
Non-directional earth-fault
protection, high stage
EFHPTOC1 Io>> (1) 51N-2 (1)
Non-directional earth-fault
protection, instantaneous stage
EFIPTOC1 Io>>> (1) 50N/51N (1)
Directional earth-fault protection, low
stage
DEFLPDEF1 Io> -> (1) 67N-1 (1)
DEFLPDEF2 Io> -> (2) 67N-1 (2)
Table continues on next page
Section 1 1MRS758127 C
Introduction
8RED615
Application Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Directional earth-fault protection,
high stage
DEFHPDEF1 Io>> -> (1) 67N-2 (1)
Admittance-based earth-fault
protection
EFPADM1 Yo> -> (1) 21YN (1)
EFPADM2 Yo> -> (2) 21YN (2)
EFPADM3 Yo> -> (3) 21YN (3)
Wattmetric-based earth-fault
protection
WPWDE1 Po> -> (1) 32N (1)
WPWDE2 Po> -> (2) 32N (2)
WPWDE3 Po> -> (3) 32N (3)
Transient/intermittent earth-fault
protection
INTRPTEF1 Io> -> IEF (1) 67NIEF (1)
Harmonics-based earth-fault
protection
HAEFPTOC1 Io>HA (1) 51NHA (1)
Non-directional (cross-country)
earth-fault protection, using
calculated Io
EFHPTOC1 Io>> (1) 51N-2 (1)
Negative-sequence overcurrent
protection
NSPTOC1 I2> (1) 46 (1)
NSPTOC2 I2> (2) 46 (2)
Phase discontinuity protection PDNSPTOC1 I2/I1> (1) 46PD (1)
Residual overvoltage protection ROVPTOV1 Uo> (1) 59G (1)
ROVPTOV2 Uo> (2) 59G (2)
ROVPTOV3 Uo> (3) 59G (3)
Three-phase undervoltage protection PHPTUV1 3U< (1) 27 (1)
PHPTUV2 3U< (2) 27 (2)
PHPTUV3 3U< (3) 27 (3)
Three-phase overvoltage protection PHPTOV1 3U> (1) 59 (1)
PHPTOV2 3U> (2) 59 (2)
PHPTOV3 3U> (3) 59 (3)
Positive-sequence undervoltage
protection
PSPTUV1 U1< (1) 47U+ (1)
Negative-sequence overvoltage
protection
NSPTOV1 U2> (1) 47O- (1)
Frequency protection FRPFRQ1 f>/f<,df/dt (1) 81 (1)
FRPFRQ2 f>/f<,df/dt (2) 81 (2)
FRPFRQ3 f>/f<,df/dt (3) 81 (3)
FRPFRQ4 f>/f<,df/dt (4) 81 (4)
Three-phase thermal protection for
feeders, cables and distribution
transformers
T1PTTR1 3Ith>F (1) 49F (1)
Three-phase thermal overload
protection, two time constants
T2PTTR1 3Ith>T/G/C (1) 49T/G/C (1)
Binary signal transfer BSTGGIO1 BST (1) BST (1)
Circuit breaker failure protection CCBRBRF1 3I>/Io>BF (1) 51BF/51NBF (1)
Three-phase inrush detector INRPHAR1 3I2f> (1) 68 (1)
Table continues on next page
1MRS758127 C Section 1
Introduction
RED615 9
Application Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Switch onto fault control CBPSOF1 SOTF (1) SOTF (1)
Master trip TRPPTRC1 Master Trip (1) 94/86 (1)
TRPPTRC2 Master Trip (2) 94/86 (2)
Multipurpose protection MAPGAPC1 MAP (1) MAP (1)
MAPGAPC2 MAP (2) MAP (2)
MAPGAPC3 MAP (3) MAP (3)
MAPGAPC4 MAP (4) MAP (4)
MAPGAPC5 MAP (5) MAP (5)
MAPGAPC6 MAP (6) MAP (6)
MAPGAPC7 MAP (7) MAP (7)
MAPGAPC8 MAP (8) MAP (8)
MAPGAPC9 MAP (9) MAP (9)
MAPGAPC10 MAP (10) MAP (10)
MAPGAPC11 MAP (11) MAP (11)
MAPGAPC12 MAP (12) MAP (12)
MAPGAPC13 MAP (13) MAP (13)
MAPGAPC14 MAP (14) MAP (14)
MAPGAPC15 MAP (15) MAP (15)
MAPGAPC16 MAP (16) MAP (16)
MAPGAPC17 MAP (17) MAP (17)
MAPGAPC18 MAP (18) MAP (18)
Fault locator SCEFRFLO1 FLOC (1) 21FL (1)
Line differential protection with in-
zone power transformer
LNPLDF1 3Id/I> (1) 87L (1)
High-impedance fault detection PHIZ1 HIF (1) HIZ (1)
Power quality
Current total demand distortion CMHAI1 PQM3I (1) PQM3I (1)
Voltage total harmonic distortion VMHAI1 PQM3U (1) PQM3V (1)
Voltage variation PHQVVR1 PQMU (1) PQMV (1)
Voltage unbalance VSQVUB1 PQUUB (1) PQVUB (1)
Control
Circuit-breaker control CBXCBR1 I <-> O CB (1) I <-> O CB (1)
Disconnector control DCXSWI1 I <-> O DCC (1) I <-> O DCC (1)
DCXSWI2 I <-> O DCC (2) I <-> O DCC (2)
Earthing switch control ESXSWI1 I <-> O ESC (1) I <-> O ESC (1)
Disconnector position indication DCSXSWI1 I <-> O DC (1) I <-> O DC (1)
DCSXSWI2 I <-> O DC (2) I <-> O DC (2)
DCSXSWI3 I <-> O DC (3) I <-> O DC (3)
Earthing switch indication ESSXSWI1 I <-> O ES (1) I <-> O ES (1)
ESSXSWI2 I <-> O ES (2) I <-> O ES (2)
Table continues on next page
Section 1 1MRS758127 C
Introduction
10 RED615
Application Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Autoreclosing DARREC1 O -> I (1) 79 (1)
Synchronism and energizing check SECRSYN1 SYNC (1) 25 (1)
Condition monitoring
Circuit-breaker condition monitoring SSCBR1 CBCM (1) CBCM (1)
Trip circuit supervision TCSSCBR1 TCS (1) TCM (1)
TCSSCBR2 TCS (2) TCM (2)
Current circuit supervision CCSPVC1 MCS 3I (1) MCS 3I (1)
Advanced current circuit supervision
for line differential
LNCTSRCTF1 CCM_L 3I, I2(1) CCM_L 3I, I2(1)
Fuse failure supervision SEQSPVC1 FUSEF (1) 60 (1)
Protection communication
supervision
PCSITPC1 PCS (1) PCS (1)
Runtime counter for machines and
devices
MDSOPT1 OPTS (1) OPTM (1)
Measurement
Disturbance recorder RDRE1 DR (1) DFR (1)
Load profile record LDPRLRC1 LOADPROF (1) LOADPROF (1)
Fault record FLTRFRC1 FAULTREC (1) FAULTREC (1)
Three-phase current measurement CMMXU1 3I (1) 3I (1)
Sequence current measurement CSMSQI1 I1, I2, I0 (1) I1, I2, I0 (1)
Residual current measurement RESCMMXU1 Io (1) In (1)
Three-phase voltage measurement VMMXU1 3U (1) 3V (1)
VMMXU2 3U (2) 3V (2)
Residual voltage measurement RESVMMXU1 Uo (1) Vn (1)
Sequence voltage measurement VSMSQI1 U1, U2, U0 (1) V1, V2, V0 (1)
Three-phase power and energy
measurement
PEMMXU1 P, E (1) P, E (1)
RTD/mA measurement XRGGIO130 X130 (RTD) (1) X130 (RTD) (1)
Frequency measurement FMMXU1 f (1) f (1)
IEC 61850-9-2 LE sampled value
sending
SMVSENDER SMVSENDER SMVSENDER
IEC 61850-9-2 LE sampled value
receiving (voltage sharing)
SMVRECEIVER SMVRECEIVER SMVRECEIVER
Other
Minimum pulse timer (2 pcs) TPGAPC1 TP (1) TP (1)
TPGAPC2 TP (2) TP (2)
TPGAPC3 TP (3) TP (3)
TPGAPC4 TP (4) TP (4)
Minimum pulse timer (2 pcs, second
resolution)
TPSGAPC1 TPS (1) TPS (1)
Minimum pulse timer (2 pcs, minute
resolution)
TPMGAPC1 TPM (1) TPM (1)
Table continues on next page
1MRS758127 C Section 1
Introduction
RED615 11
Application Manual

Function IEC 61850 IEC 60617 IEC-ANSI
Pulse timer (8 pcs) PTGAPC1 PT (1) PT (1)
PTGAPC2 PT (2) PT (2)
Time delay off (8 pcs) TOFGAPC1 TOF (1) TOF (1)
TOFGAPC2 TOF (2) TOF (2)
TOFGAPC3 TOF (3) TOF (3)
TOFGAPC4 TOF (4) TOF (4)
Time delay on (8 pcs) TONGAPC1 TON (1) TON (1)
TONGAPC2 TON (2) TON (2)
TONGAPC3 TON (3) TON (3)
TONGAPC4 TON (4) TON (4)
Set-reset (8 pcs) SRGAPC1 SR (1) SR (1)
SRGAPC2 SR (2) SR (2)
SRGAPC3 SR (3) SR (3)
SRGAPC4 SR (4) SR (4)
Move (8 pcs) MVGAPC1 MV (1) MV (1)
MVGAPC2 MV (2) MV (2)
Generic control point (16 pcs) SPCGAPC1 SPC (1) SPC (1)
SPCGAPC2 SPC (2) SPC (2)
Analog value scaling SCA4GAPC1 SCA4 (1) SCA4 (1)
SCA4GAPC2 SCA4 (2) SCA4 (2)
SCA4GAPC3 SCA4 (3) SCA4 (3)
SCA4GAPC4 SCA4 (4) SCA4 (4)
Integer value move MVI4GAPC1 MVI4 (1) MVI4 (1)
Section 1 1MRS758127 C
Introduction
12 RED615
Application Manual

Section 2 RED615 overview
2.1 Overview
RED615 is a phase-segregated two-end line differential protection and control relay
designed for utility and industrial power systems, including radial, looped and meshed
distribution networks with or without distributed power generation. RED615 is also
designed for the protection of line differential applications with a transformer within
the protection zone. RED615 relays communicate between substations over a fiber
optic link or a galvanic pilot wire connection. RED615 is a member of ABB’s Relion®
product family and part of its 615 protection and control product series. The 615 series
relays are characterized by their compactness and withdrawable-unit design. Re-
engineered from the ground up, the 615 series has been guided by the IEC 61850
standard for communication and interoperability of substation automation equipment.
The relay provides unit type main protection for overhead lines and cable feeders in
distribution networks. The relay also features current-based protection functions for
remote back-up for down-stream protection relays and local back-up for the line
differential main protection. Further, standard configurations B and C also include
earth-fault protection. Standard configurations D and E include directional
overcurrent and voltage based protection functions.
The relay is adapted for the protection of overhead line and cable feeders in isolated
neutral, resistance earthed, compensated (impedance earthed) and solidly earthed
networks. Once the relay has been given the application-specific settings, it can
directly be put into service.
The 615 series relays support a range of communication protocols including IEC
61850 with Edition 2 support, process bus according to IEC 61850-9-2 LE, IEC
60870-5-103 and Modbus®. Profibus DPV1 communication protocol is supported by
using the protocol converter SPA-ZC 302.
1MRS758127 C Section 2
RED615 overview
RED615 13
Application Manual

2.1.1 Product version history
Product version Product history
4.1 Product released
4.1.1 • In-zone transformer application support
5.0 FP1 • New configuration D
• New layout in Application Configuration for all configurations
• Fault locator
• Load profile recorder
• Optional RTD/mA inputs
• Profibus adapter support
• Support for multiple SLD pages
• Import/export of settings via WHMI
• Setting usability improvements
• HMI event filtering tool
• IEC 61850 Edition 2
• Currents sending support with IEC 61850-9-2 LE
• Support for synchronism and energizing check with IEC 61850-9-2 LE
• Software closable Ethernet ports
• Report summary via WHMI
• Voltage unbalance power quality option
• Switch onto fault
• Additional timer, set-reset and analog value scaling functions
2.1.2 PCM600 and relay connectivity package version
• Protection and Control IED Manager PCM600 2.9 Hotfix 1 or later
• RED615 Connectivity Package Ver.5.1 or later
• Parameter Setting
• Signal Monitoring
• Event Viewer
• Disturbance Handling
• Application Configuration
• Signal Matrix
• Graphical Display Editor
• Communication Management
• IED User Management
• IED Compare
• Firmware Update
• Fault Record tool
• Load Record Profile
• Lifecycle Traceability
• Configuration Wizard
• AR Sequence Visualizer
• Label Printing
• IEC 61850 Configuration
• Differential Characteristics Tool
Section 2 1MRS758127 C
RED615 overview
14 RED615
Application Manual
