ABB NETA-21 Manual

—
ABB INDUSTRIAL DRIVES
Digital services for NETA-21
Set-up instructions

—
List of related manuals
*Available inside Remote Condition Monitoring tool
You can find manuals and other product documents in PDF format on the Internet. See section
Document library on the Internet on the inside of the back cover. For manuals not available in the
Document library, contact your local ABB representative.
Hardware manuals and guides Code (English)
NETA-21 User’s manual 3AUA0000096939
NETA-21 Installation and start-up guide 3AUA0000096881
Digital services for NETA-21 set-up instructions 3AXD50000336234
Option manuals and guides
ABB AbilityTM Condition Monitoring for drives On-premises User’s
manual
3AXD50000451524
ABB AbilityTM Condition Monitoring for drives On-premises Deployment
guide
3AXD50000451531
Condition monitoring for drives Online help* 3AXD50000316458
Gateway administration in condition
monitoring for drives
3AXD50000534890
RMDE-01 reliability monitoring device Product manual 3AXD50000199686
ABB Ability(TM) digital services for drives - Cloud cybersecurity 9AKK106930A8297

Digital services for NETA-21
Set-up instructions
3AXD50000336234 Rev D
EN
EFFECTIVE: 2020-08-17
2020 ABB. All Rights Reserved.
7. Digital services portal package
installation and use
1. Introduction to the manual
4. Quick start-up guide
Table of contents
5. Installation of NETA-21 and
environmental sensor
6. Network and drive connectivity
configuration

5
Table of contents
1. Introduction to the manual
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Applicability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Target audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Prerequisites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Use of warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Safety in installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Contents of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Related documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Cybersecurity disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2. Overview
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. Preparation for installation
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
List of required materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Software and network requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
ServIS requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Hardware requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Drive specific requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To connect ACS800 drives: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To connect ACS880/DCS880 drives: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To connect MV Drives ACS1000, ACS2000, ACS5000 and ACS 6000 . . . . . . . . 19
To connect MV drives ACS580MV and ACS6080 . . . . . . . . . . . . . . . . . . . . . . . . . 20
To connect PEC/LCI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
To connect DCS800 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Supported fieldbus adapter modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4. Quick start-up guide
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
List of required materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
NETA-21 start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5. First access to the NETA-21 User interface and Firmware update
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting a local PC to NETA-21 operating as a DHCP server . . . . . . . . . . . . . . . . . . 24
Logging on to NETA-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6
Updating NETA-21 time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Updating NETA-21 Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6. Installation of NETA-21 and environmental sensor
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Installation of NETA-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Installation of the environmental sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7. Network and drive connectivity configuration
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring connectivity via customer LAN network . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Configure proxy settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Configuring DDCS drives (ACS800/DCS 800/ACSx000) . . . . . . . . . . . . . . . . . . . . . . . 37
Single control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Multiple control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Enabling Data Logger for DDCS connected drives (ACS800, ACS1000, ACS2000,
ACS5000, ACS6000) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Configuring Ethernet drives (ACx580/ACS880/ACS580MV/ACS6080) . . . . . . . . . . . . 40
Connecting multiple ACS880 devices to NETA -21 . . . . . . . . . . . . . . . . . . . . . . . . . 42
Connecting multiple ACS880 devices to multiple NETA-21 . . . . . . . . . . . . . . . . . . . 42
Connecting via panel bus communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8. Digital services portal package installation and use
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Installing IPS package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Verifying IPS Package installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Verifying that NETA-21 communicates with Yocto Meteo environmental sensor . . . . . 47
Verifying that NETA-21 communicates with Ability Cloud and the Portal . . . . . . . . . . . 48
Configure NETA in CMD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Using ABB Ability cloud with NETA-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
9. Configuring a cellular modem
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Quick installation guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Configuring eWON Cosy 131 modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Collected data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
10. Installation troubleshooting (optional)
Contents of this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Problem example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Issues covered in this chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Issue when connecting locally to the NETA-21 web UI . . . . . . . . . . . . . . . . . . . . . . . . . 58
NETA-21 does not send parameter history logging to the digital services . . . . . . . . . . 59
Warnings or faults show up in the Tool settings/Events tab after installation . . . . . . . . 59
The RSP user account import failed during IPS package installation . . . . . . . . . . . . . . 60

7
DDCS devices are not detected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Connected fieldbus adapter module is also used by PC tool . . . . . . . . . . . . . . . . . . . . . 62
PC tool requires DDCS CH3 but used by NETA-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Network error codes and their resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Further information

8

Introduction to the manual 9
1
Introduction to the manual
Contents of this chapter
This chapter describes the contents of the manual. It also contains information on the
applicability, safety and intended audience.
Applicability
This manual applies to the NETA-21 remote monitoring tool.
It gives you basic information on how to install the NETA-21 configure NETA-21 and
communication with ACS800 / ACS880 and other various ABB drives for connecting
NETA-21 to Ability cloud.
Target audience
This manual is intended for users who are involved in the set up of the NETA-21 for remote
monitoring of ABB drives.
Prerequisites
The user is expected to have basic knowledge of NETA-21 and ABB drives. The user
should be familiar with concepts such as IP address configuration, proxy servers and their
authentications.
ABB recommends that you practice the procedures in this manual before you do them at
the site.
For information about NETA, refer to:
•Installation and Start up Guide (3AUA0000096881 [English])
•NETA-21 User’s Manual (3AUA0000096939 [English])

10 Introduction to the manual
Safety instructions
Use of warnings
Warnings tell you about conditions which can cause injury or death, or damage to the
equipment. They also tell you how to prevent the danger. The manual uses these warning
symbols:
WARNING! Only qualified electricians can do the work described in this
document. Obey the Safety instructions on the first pages of this manual. If you
ignore the safety instructions, you can cause injury or death.
General warning tells you about conditions, other than those caused by
electricity, which can cause injury or death, or damage to the equipment.
Safety in installation
These warnings are intended for all who install or connect an optional module to a drive,
converter or inverter, and need to open its front cover or door to do the work.
WARNING! Obey these instructions. If you ignore them, injury or death, or
damage to the equipment can occur.
•If you are not a qualified electrician, do not do installation or maintenance work.
•Disconnect the drive, converter or inverter from all possible power sources. After you
have disconnected the drive, converter or inverter, wait for 5 minutes to let the
intermediate circuit capacitors discharge before you continue.
•Disconnect all dangerous voltages connected to any control signal connectors in
reach. For example, it is possible that 230 V AC is connected from outside to a relay
output of the drive, converter or inverter.
•Use a multimeter to make sure that there are no parts under voltage in reach. The
impedance of the multimeter must be at least 1 Mohm.

Introduction to the manual 11
Contents of the manual
This manual contains the following chapters:
•Introduction to the manual contains information on the applicability, licensing, and
safety instructions. The chapter also includes the list of terms and abbreviations used
in this manual.
•Overview provides a before introduction on NETA-21 cloud based services.
•Preparation for installation provides the check list for installing and configuring the
NETA-21.
•Quick start-up guide contains the basic start-up sequence of NETA-21.
•First access to the NETA-21 User interface and Firmware update contains instructions
to access NETA-21 and update it.
•Installation of NETA-21 and environmental sensor contains instructions to install
NETA-21 and environmental sensor.
•Network and drive connectivity configuration contains instructions on network
configuration.
•Digital services portal package installation and use contains instructions on digital
service package installation.
•Configuring a cellular modem contains instructions on configuring a cellular modem.
•Installation troubleshooting (optional) provides basis trouble shooting steps.
Related documents
See List of related manuals on the inside of front cover.

12 Introduction to the manual
Terms and abbreviations
Terms
Abbreviations
Term Explanation
Data logger Data logger inside a monitored device
DDCS Distributed Drives Communication System, an optical fiber device access
method for drives and inverters (for example, ACS800 and PVS800)
Device interface Software component that enables access to certain types of drives
NETA-21 Hardware product for accessing drives remotely – typically off-site access
over public Internet, local/private Ethernet or modem connection.
Network interface Any defined interface to the connected data network
Network service Any inbound or outbound data connection provider in the NETA-21.
Parameter Operating instruction for the drive. Parameters are typically adjusted with a
control panel or a PC tool. Parameter browsing, monitoring and writing can
be done also with the NETA-21.
User account A user name that in combination with a password can be used to access the
NETA-21 web user interface or some other services of the NETA-21.
Web UI Web-based user interface of the NETA-21
Abbreviation Explanation
CM Condition monitoring (service)
CMD Condition monitoring for drives (portal)
DDCS Distributed Drives Communication System, an optical fiber device access
method for drives and inverters (for example, ACS800 and PVS800)
DHCP Dynamic Host Configuration Protocol, a protocol for configuring servers in a
network
HTTP Hypertext Transfer Protocol is an application protocol used between data cli-
ents and web servers
HTTPS Hypertext Transfer Protocol Secure is a combination of the HTTP and
SSL/TLS protocols. Provides secure communication with web servers.
RCM Remote Condition Monitoring, old version of CMD
RSP Old cloud portal, replaced by CMD version 4
SD Secure Digital memory card
SSL/TLS Transport Layer Security (previously Secure Sockets Layer) protocol is used
to encrypt data between clients and servers
TCP Transmission Control Protocol, used together with Internet Protocol (IP) as
the transport protocol for the Internet
UI User interface

Introduction to the manual 13
Cybersecurity disclaimer
This product is designed to be connected to and to communicate information and data via
a network interface. It is Customer's sole responsibility to provide and continuously ensure
a secure connection between the product and Customer network or any other network (as
the case may be). Customer shall establish and maintain any appropriate measures (such
as but not limited to the installation of firewalls, application of authentication measures,
encryption of data, installation of anti-virus programs, etc) to protect the product, the
network, its system and the interface against any kind of security breaches, unauthorized
access, interference, intrusion, leakage and/or theft of data or information. ABB and its
affiliates are not liable for damages and/or losses related to such security breaches, any
unauthorized access, interference, intrusion, leakage and/or theft of data or information.
Pre-requisite training for ABB commissioning engineers:
•SDIP151E - CYBER SECURITY - WORKING WITH CUSTOMER SYSTEMS - for
non-ABB commissioning engineers, check separately for similar applicable
cybersecurity training.
•Commissioning engineer should be also familiar with the cybersecurity guidelines
regarding NETA-21 installation and networks services hardening. See Technical Guide
Cybersecurity for ABB Drives (3AXD10000492137 [English]) and ABB Ability(TM)
digital services for drives - Cloud cybersecurity (9AKK106930A8297 [English]).
•ABB engineers supporting customers with cybersecurity questions can refer to
cybersecurity FAQ internal document Cybersecurity for ABB Ability digital services
FAQ (3AXD50000530472 [English]).

14 Introduction to the manual

Overview 15
2
Overview
Contents of this chapter
The chapter provides an overview of NETA-21 based services.
Overview
ABB Ability services provide faster fault tracing for ABB Drives. The service helps the
customer to minimize unplanned downtime in failure cases. The service offers automatic
and continuous collection of drive performance data into a centralized database. The data,
such as, drive events, selected signals, dataloggers (called as TripRecorder /
StartRecorder / ConfigurableTransientRecorder / GndFltRecorder in PEC), parameter files
and troubleshooting instructions enable fast fault tracing. The service engineers use the
remote data to provide technical support for customers.
The set up of monitored signals is loaded and updated in NETA-21 and transferred into
ABB cloud environment. The data is recorded and available for analysis and is the basis
for several digital services for drives. Services include:
•ABB Ability™ Condition Monitoring for drives
•ABB Ability™ Remote Assistance for Drives
•ABB Ability™ Condition Based Maintenance
Note: For users who do not want to use cloud services, it is recommended to use ABB
Ability™ Condition Monitoring for drives On-premises tool. ABB Ability™ Condition
Monitoring drives On-premises is a simplified version of ABB Ability™ Condition

16 Overview
Monitoring for drives. For more information, see Ability™ Condition Monitoring for drives
On-premises User’s manual (3AXD50000451524[English]).

Preparation for installation 17
3
Preparation for installation
Contents of this chapter
This chapter describes the required preparations that should be done before you install a
NETA-21 unit.
List of required materials
Make sure that you have the necessary equipment and materials for the commissioning.
The required materials are listed in this chapter. For any installation, make sure that you
have the usual tools for installation, such as, suitable power supplies, MCB connectors,
screw drivers, a wire cutter, a wire stripper, a crimping tool, cable lugs, and so on.

18 Preparation for installation
Software and network requirements
Make sure that:
1. Internet connectivity is available for NETA-21.
2. Proxy details are available, if necessary.
3. Fixed IP address details are available, if necessary.
4. Drive and NETA-21 serial numbers are available. Record the serial numbers for future
purpose.
5. Network requirement data sheet is filled. For the network requirement data sheet, see
Network Requirement Data Sheet. If no customer network is available, make sure that
modem is configured with SIM card.
6. NETA-21 is updated with latest firmware.
7. TCP Port 443 outbound from customer network (from NETA-21) to Internet is open.
Note: No Inbound ports are required from Internet.
ServIS requirements
Make sure that:
1. The customer site exists in ServIS and has a proper GUID assigned.
2. The drive is registered under the correct customer site.
3. The drive is set to be externally visible.
4. You have sufficient ServIS access to see the drive in the CMD (at least “other roles
(read)” profile access to 4159 division in the country where the drive is registered).
5. The ServIS ID/site is marked as favorite.
If you are not an ABB employee, contact your local ABB representative to finalize the
ServIS actions
Hardware requirements
1. NETA-21 Remote monitoring tool with a compatible firmware version
2. Sufficient space in the cabinet to install NETA-21, cellular modem and antenna (if
required).
3. Ethernet cabling for communication between NETA-21 and the network
4. USB environmental sensor
5. NEXA-21 for external environmental sensor and DDCS optical fiber applications
6. Cellular modem, if the cellular Internet connection is used. Otherwise approvals and
technical details for connection to a customer network. Port TCP/443 (HTTPS)
outbound access without a proxy is needed
7. 2.5 SQMM cable of sufficient length for NETA-21, power supply and NDBU-95c (if
used) cabling
8. For UL-certified installations, separate limited power supply according to
IEC/UL60950-1 or class 2 per NEC. For example, UNO-PS/1AC/24DC/90W/C2LPS
(produce code 3AXD50000191048, Power supply)
9. For configuring cellular modem, eWON Cosy 131 antenna (3AXD50000120406) and
eWON modem (3AXD50000131686).

Preparation for installation 19
Drive specific requirements
To connect ACS800 drives:
1. DDCS communication option module (RDCO-01C/-04C) installed in slot 3 of
RDCU-xx/RMIO-xx control unit
Note: RDCO-03C and old models of RDCO-02C (for example, Rev. A and B of
RDCO-02C) are not recommended due to limited capacity of the optical fiber
connectors on CH3.
2. Optical fiber for connections between NEXA-21 and the drive (RDCO-01C option)
3. NDBU-95C Branching unit for multi drive setups
Note: Use CH3 channel for connecting NETA-21 to the drive.
To connect ACS880/DCS880 drives:
1. Fieldbus adapter module to connect ACS880 to NETA-21 via an Ethernet cable. For
supported fieldbus modules, see section Supported fieldbus adapter modules on page
20.
Notes:
•The adapters are not required if you connect through a panel port
•Remove the panel from the drive if you monitor through the Panel bus.
2. Ethernet switch, if more than one ACS880 is connected via an Ethernet port
3. Sufficient Ethernet cables to connect drive to NETA-21
Note: ABB cybersecurity guidelines recommend that Internet connectivity should use
a separate Ethernet interface to the cellular modem or customer network. It is
recommended to use:
•ETH1 connection for local connectivity to the drives.
•Fixed IP address on ETH1 and no gateway access
•ETH2 connection for connectivity to the Internet.
ETH1 port has full 100Mbit/s capacity and is used to communicate efficiently in real
time with ACSx80 drives using Ethernet cable. The ETH2 port Internet connectivity
uses only limited bandwidth (typically less than 1 Mbit/s effective speed) to send
compressed data to cloud every 1.5 minutes.
4. Optional materials:
•FDPI-02 panel bus extension adapter, if you are using panel bus adapter and
connecting more than one control unit
•FEA-03 extension board (requires FDCO-02 optical fiber extension) if you want to
install IO and encoder options away from the main control unit. This allows to
connect two parallel fieldbus modules. For example, one FENA-21 for PC tool and
another FENA-21 for NETA-21 connection.
To connect MV Drives ACS1000, ACS2000, ACS5000 and ACS 6000
1. Optical fiber for connections between NEXA-21 and the drive
2. NDBU-95C Branching unit for multi drive setups.
Note: Use CH3 channel for connecting NETA-21 to the drive.

20 Preparation for installation
To connect MV drives ACS580MV and ACS6080
1. Refer to the connection of ACS880 (using supported fieldbus adapter module,
Ethernet module or Panel bus).
2. These drives also provide Ethernet tool network monitoring over the embedded
Ethernet (XETH) port.
To connect PEC/LCI
AC800PEC PC tool with appropriate license
PEC3 generation control unit. Old generation control units, such as PEC 2 needs to be
upgraded to PEC3.
To connect DCS800
SDCS-COM-8 communication module.
Note: Use CH3 channel for connecting NETA-21 to the drive.
Supported fieldbus adapter modules
The NETA-21 supports below fieldbus adapter modules:
•FENA -11
•FENA -21
•FEIP-21
•FMBT-21
•FPBA-21
