ABL WALLBOX eMH2 EN User manual

Article No.: 0301772_EN_a
EN
WALLBOX eMH2
Installation and Operating manual

| Service
II
Service
For technical support, please contact the specialist electrical contractor who has carried out the installation of your
wallbox and any accessories.
Downloads
Further information and documents regarding your wallbox and accessories are available at:
https://www.toyota-tech.eu https://www.lexus-tech.eu
Revision/Date: 0301772_EN_a, Version: 23.07.20
T
h
i
n
k
b
e
f
o
r
e
y
o
u
p
r
i
n
t

Contents | III
Contents
Service II
Downloads II
Safety and user information 4
General 4
Safety information 4
User information 5
Introduction to the Wallbox eMH2 6
Identifying your wallbox 6
Components included with the wallbox 6
Accessories 7
Installation 8
Installation site requirements 8
Tools and accessories required 9
Preparing the mounting site 10
Preparing and fixing the wallbox in place 11
Electrical connection of the wallbox 12
Data cable connections 14
Commissioning the wallbox 15
Configuring the Wallbox eMH2 17
Stand-alone operation of a Master wallbox 17
Stand-alone operation of a Slave wallbox 17
Charging procedure 22
Error resolution and maintenance 24
Identifying errors 24
General operational malfunctions 28
Testing the internal RCCB 28
Taking the Wallbox eMH2 out of operation 29
Appendix 31
Technical specifications 31
Dimensions 32
Standards and guidelines 32
Data cable recommendations 33
CE certification and compliance declaration 33
Trademarks 34
Definitions 34
Copyright and disclaimer 34
Disposal advice 34

| Safety and user information – General
4
Safety and user information
General
This manual describes all working steps required to install and/or operate the product it concerns.
Certain sections of this manual are specially formatted for quick and easy reference.
Descriptions listing equally valid options are indicated by bullet points.
1 Descriptions listing operating steps are numbered in chronological order.
Actions marked with this symbol must not be carried out under any circumstances.
Actions marked with this symbol must be carried out with special care.
Actions marked with this symbol should be carried out as required.
Passages containing additional information.
Safety information
The safety notices serve to ensure the proper and safe installation, as well as subsequent safe operation of the
device.
Disregard of or actions contrary to the safety information and instructions contained in this manual may
lead to electric shock, fire, severe injury and/or death.
Please pay attention to the following points:
Please read this manual carefully.
Heed all warnings and follow all instructions.
Keep this manual in a safe place where it can be accessed at all times: The contents of this manual, and the
safety notices in particular, must be available to all users of the product.
Only use accessories intended and sold for the product by ABL.
Do not install this device in close vicinity to running water, water jets or areas subject to flooding.
The product must not be installed in explosive atmosphere areas (EX areas).
Mechanical installation should be carried out by qualified specialist personnel.
Electrical installation and testing must be carried out with reference to local rules by a qualified specialist
electrical contractor, who, on the basis of their specialist training and experience, as well as their knowledge of
the relevant standards, is able to assess and carry out the working steps described in this manual and recognise
potential hazards.
Please note that electrical grid operators, energy suppliers or national regulations may require notifica-
tion of or approval for the installation or operation of a charging station.
The product must only be operated after final approval by a qualified specialist electrical contractor.
In case of installation faults, or malfunctions that can be traced back to faulty installation, always contact the
contractor who carried out the installation first.
The product must not be covered with stickers or other objects or materials.
No liquids or receptacles containing liquids must be placed on the product.
Please note that operating a radio transmitter in the immediate vicinity (< 20 cm) of the product may lead to
malfunctions.

Safety and user information – User information | 5
This device is not intended to be used by persons (including children) with limited physical, sensory or mental
abilities or lack of experience and/or knowledge, unless they are supervised by someone responsible for their
safety or have received instructions on how to use the device.
Children must be supervised so that they do not play with the device.
Do not under any circumstances make alterations to the product. Any disregard of this instruction represents a
safety risk, fundamentally breaches the guarantee provisions and may void the warranty with immediate effect.
Malfunctions affecting the safety of persons, connected electric devices or the device itself must be resolved by a
qualified specialist electrical contractor.
Should one of the following malfunctions occur, please contact the specialist electrical contractor who has carried
out the installation of your wallbox and accessories:
yThe product housing has been damaged mechanically, or the housing cover has been removed or can no longer
be closed.
ySufficient protection against splashing water and/or foreign objects is no longer provided.
yThe product does not function properly or has been otherwise damaged.
User information
Ensure that the rated voltage and rated current of the product comply with the parameters of your local electricity
grid and that the rated output is not exceeded during operation.
Local safety regulations regarding the operation of electrical devices for the country in which you operate the
product always apply.
To disconnect the product completely from the electricity grid, the power supply must be interrupted using the
upstream safety switches and fault current protection devices (if present) in the domestic power distribution.
Never operate the product in a confined space.
Ensure that the product can be operated without any strain pulling on its components.
Make sure that the product is always closed and locked when in use. All authorized users must be aware of the
'unlock' position of the key.
You must under no circumstances make any changes to the housing or the internal wiring of the device: Any
disregard of this instruction fundamentally breaches the guarantee provisions and voids the warranty with imme-
diate effect.
Only have the product repaired by a qualified specialist electrical company.
Please note that all technical details, specifications and design characteristics of the product may be
changed without prior notice.

| Introduction to the Wallbox eMH2 – Identifying your wallbox
6
Introduction to the Wallbox eMH2
Congratulations on the purchase of your new Wallbox eMH2 by ABL! Our smart all-rounder with billing function for
domestic and commercial applications is the ideal solution for charging your private or company vehicle in your own
garage, or for group installations in company or hotel carparks. With a charging capacity of 22kW, the wallbox is
configured for the especially rapid charging of electric vehicles, which can be connected to the device in a flexible
manner – either via an integrated charging cable with Type 2 charging connector (fixed cable variant), or an integrat-
ed Type 2 charging socket (socket variant) and a separately available charging cable.
Further information on technical data are available in the appendix from page 31.
Identifying your wallbox
The model variant of the Wallbox eMH2 can be unambiguously identified on
the rating plate located on the inside of the housing cover. Please verify the
information listed below on the rating plate.
The following information is especially relevant:
Model number and Master or Slave configuration
External power supply
AModel number and category
(Master or Slave) EStandards I'Read instructions' advice
BPower supply (voltage,
frequency, current) FCountry of manufacture and manufacturer JCE label
COperating temperature GManufacturer KBarcode/serial number
DIP rating HDisposal advice LDate printed
Components included with the wallbox
The product is delivered including the following components:
Wallbox eMH2, 1pc Housing cover key, 1pc
× 1 × 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
× 1
Wall plugs 8×40mm,
4pcs
T20 panhead screws,
6×60mm, 4pcs
Drilling template, 1pc
× 1 × 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
× 1
Safety notices & quick start
guide (multilingual), 1pc
× 1 × 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
× 1
Check immediately after unpacking whether all components are included: should any components be
missing, please contact the dealer from whom you purchased the wallbox.
2WXXXX Master
~230/400V 50Hz 32A
-25°C bis 40°C
IP55
IEC 61851-1
IEC 61439-7 ACSEV
MADE IN GERMANY
ABL SURSUM
Bayer. Elektrozubehör GmbH & Co. KG
Albert-Büttner-Straße 11
D-91207 Lauf / Pegnitz
2WXXXX00484
2020-06-06
2WXXXX00484
A
E
D
B
F
G
H
I
J
K
L
C

Introduction to the Wallbox eMH2 – Accessories | 7
Accessories
The following accessories for the Wallbox eMH2 are available separately:
STEMHX0 / PZ42D-00B01
Anodised aluminium mounting pole for fixing wallboxes using suitable adapter
plates
h = 1,495 mm, b = 150 mm, t = 150 mm
ADPEMH2 / PZ42D-00C07
Mounting plate for fixing the Wallbox eMH2 to the pole
h = 365 mm, b = 265 mm, t = 3 mm
LAK32B3 / PZ42D00B04
Type 2 charging cable according to IEC 62196-2, up to 32A 240/415VAC,
3-phase,
length ca. 5m
LAK32C3 / PZ42D00B05
Type 2 charging cable according to IEC 62196-2, up to 32A 240/415VAC,
3-phase,
length ca. 7.5m
LAK32D3 / PZ42D00B06
Type 2 charging cable according to IEC 62196-2, up to 32A 240/415VAC,
3-phase,
length ca. 10m
Further information and documents regarding your wallbox and accessories are available at:
https://www.toyota-tech.eu https://www.lexus-tech.eu

| Installation – Installation site requirements
8
Installation
It is recommended to have the entire installation of the wallbox carried out by a qualified specialist electrical con-
tractor.
Electrical installation, as well as final testing and certification for operation must be carried out by a
qualified specialist electrical contractor, who, on the basis of their specialist training and experience,
as well as their knowledge of the relevant standards, is able to assess and carry out the working steps
described in this manual and recognise potential hazards.
Installation site requirements
The installation site must be freely accessible.
The mounting surface must be level and solid.
The mounting surface must measure at least
437x 328mm (height x width).
328 mm
437 mm
The installation height should be between 120
and 140 cm (ground to bottom edge of housing).
Minimum distances to other technical installa-
tions must be observed.
A minimum distance of 50cm is recommended.
120
to
140 cm

Installation – Tools and accessories required | 9
Ideally, the installation site should provide a ready
connection to the electricity grid. Otherwise, a
separate power supply cable must be installed.
In order to operate group installations, suitable
data cables must also be installed in the instal-
lation site (see also "Preparing and fixing the
wallbox in place" on page 11 as well as "Data
cable connections" on page 14).
Tools and accessories required
For mechanical installation, you will need the following components included with the wallbox:
Drilling template,
1pc
× 1 × 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
× 1
T20 panhead screws,
6×60mm, 4pcs
Wall plugs
8×40mm, 4pcs
Housing cover key,
1pc
× 1 × 1
× 4
× 1
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
Artikelnummer: 0301771_a
Wallbox eMH2
DE Sicherheitshinweise
Kurzanleitung FR Consignes de sécurité Guide de prise en main
DK Sikkerhedsanvisninger
Kort vejledning IS Öryggisleiðbeiningar Stuttur leiðarvísir
EN Safety information
Quick Start Guide IT Avvertenze di sicurezza Brevi istruzioni
ES Indicaciones de seguridad
Guía rápida NL Veiligheidsinstructies Verkorte handleiding
FI Turvallisuusohjeet
Pikaopas NO Sikkerhetsanvisninger Hurtigreferanse
× 1
In addition, you will need the following tools
Electric drill Bit (Torx T20)
8 mm ∅drill bit
suitable for the
respective mounting
surface
Pencil
Spirit level Tape measure
Screwdriver (Phillips
head) Screwdriver (Torx)
Pliers Hammer
Utility knife Wire stripper
Voltmeter

| Installation – Preparing the mounting site
10
Preparing the mounting site
As a matter of principle, the electrical supply cable in the domestic power distribution must be switched off for the
entire duration of mechanical and electrical installation. The connection to the power grid must only be made live for
the purpose of commissioning, after electrical installation is complete.
Always observe the 5 safety rules:
1Cut power source
2Secure all cut-off devices
3Verify absence of voltage
4Ground and short-circuit
5Cover or bar access to adjacent components under voltage
Proceed as follows:
1 Cut crosswise into the marks for the fixing points
on the drilling template using the utility knife.
2 Using the spirit level, align the drilling template
level and plumb on the mounting surface.
3 With the pencil, mark the fixing points in the
mounting position.
4 Pre-drill the marked fixing points with the electric
drill and drill bit (∅8 mm).
5 Drive the wall plugs into the fixing points with the
hammer.
4
5

Installation – Preparing and fixing the wallbox in place | 11
6 Insert two of the included panhead screws into
the two upper fixing points using the screwdriver
(Torx) or the electric drill and Torx bit.
yThe distance between screw head and wall
must measure 4mm.
4 mm
Preparing and fixing the wallbox in place
Continue to prepare the wallbox:
7 Open the housing cover of the wallbox with the
housing cover key and put it aside.
8 Loosen the screw of the internal electronic com-
ponents cover using the screwdriver (Torx) and put
it aside.
yKeep the screw in a safe place.
9 Use the utility knife to cut an opening for the
power supply cable into the large rubber grommet
in the housing base.
yFor wiring up group installations, you must also
make cuts into the two smaller grommets for
the data cables (see "Data cable connections"
on page 14).

| Installation – Electrical connection of the wallbox
12
10 Insert the power supply cable through the large
rubber grommet into the housing base.
yThe back of the housing has a cable guide for
surface-mounted power supply cables.
yFor wiring up group installations, you must
insert the data cables through the small grom-
mets in the housing base.
11 Hang the housing base onto the panhead screws
you inserted at the installation site in Step 6.
12 Fix the housing base to the mounting surface by
inserting the two remaining panhead screws into
the two lower fixing points using the screwdriver
or electric drill with Torx bit.
ySelect a torque that will not distort the housing
base.
Electrical connection of the wallbox
Electrical connection must be carried out by a qualified specialist electrical contractor!
Ensure that the power supply cable remains disconnected from the electricity grid.
Deactivate the RCCB in the wallbox and/or in the domestic power supply.

Installation – Electrical connection of the wallbox | 13
Proceed as follows to connect the power supply cable inside the wallbox:
1 Cut the supply cable to the required length with
the pliers.
yFor wiring up group installations (see next
section), you must also cut the data cables to
the required length.
2 Insert the individual conductors of the power
supply cable into the respective terminals of the
RCCB and tighten them using the screwdriver
(torque: 2.5 to 3 Nm).
yEnd ferrules must be fitted on flexible
conductors.
yOperate the spring-loaded mechanism of the
PE terminal and attach the protective earth
conductor.
yUse the connection patterns listed below to
allocate the individual conductors.
Connection pattern for 3-phase TN system
Designation Conductor color Marks for
Phase 1 current-carrying conductor Brown 5– L1
Phase 2 current-carrying conductor Black 3– L2
Phase 3 current-carrying conductor Gray 1– L3
Neutral Blue N
Protective earth Green-Yellow PE
Connection pattern for 1-phase TN system
Designation Conductor color Marks for
Phase 1 current-carrying conductor Brown 5– L1
Neutral Blue N
Protective earth Green-Yellow PE
Please note that the colour-coding convention used above is not internationally standardised.
Please ensure that the conductors that are pre-fixed to the RCCB terminals remain attached correctly
after connecting the power supply cable.
If desired, the 3-phase Wallbox eMH2 model variant can also be connected and operated on a single
phase at terminal 5– L1: However, in this case the rated output for the wallbox will not be achieved.
The electronic components of your wallbox will be damaged if a voltage above 250V is applied between
the 5– L1 current-carrying conductor and the neutral conductor!

| Installation – Data cable connections
14
Data cable connections
In group installations, a Master wallbox can control up to 15 Slave wallboxes after connecting the respective data
cables. The Master wallbox then centrally manages backend communication, charge current distribution and many
other functions.
To connect up a group installation, data cables must be attached to the internal spring terminals of the Wallbox
eMH2. You can find information regarding recommended data cables in section "Data cable recommendations" on
page 33.
Proceed as follows to connect the wallboxes using data cables:
1 Using the wire stripper, strip the data cables you
inserted into the housing base in Step 10 of Sec-
tion "Electrical connection of the wallbox".
yCut the data cables to the required length with
the pliers if necessary.
2 Connect the twisted wire strands of the first data
cable with the right hand spring terminal in the
Master wallbox and route the cable to the first
Slave wallbox.
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER

Define a pattern for allocating the colour coded wire strands to the bus system of the spring
terminals.
Make sure you always keep to this defined allocation pattern for the entire data wiring process!
Otherwise, malfunctions will result.
SLAVE 2 SLAVE X
(max. 15)
MASTER SLAVE 1
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER

Installation – Commissioning the wallbox | 15
3 Connect the twisted wire strands of the entering
data cable with the left hand spring terminal of
the first Slave wallbox.
yConnect the twisted wire strands of the exiting
data cable with the right hand spring terminal
in the Slave wallbox and route the cable to the
next Slave wallbox (if used). A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
Connect all subsequent Slave wallboxes according to this method, except the last Slave wallbox.
4 Connect the twisted wire strands of the entering
data cable with the left hand spring terminal of
the last Slave wallbox.
yFor correct functioning of the group installa-
tion, the end of the data wiring chain must be
terminated using two terminating resistors
(120Ohm). A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
Commissioning the wallbox
To commission the wallbox, the power supply cable must be connected to the electricity grid.
The following working steps must be carried out with the utmost care: There is a risk of electric shock if
conductive components are touched.
1 Switch on the MCB in the domestic power distri-
bution box.
yAs soon as the wallbox is connected to the
electricity grid, the green LED will begin to
pulsate, the other LEDs will remain OFF.
Should the LED not pulsate, check the RCCB and the MCB inside the Wallbox eMH2 and switch the pivot
levers to position Iif necessary.
2 Measure the voltage at the RCCB terminals.
yIn single phase installations, the voltage is
measured between the phase and neutral
conductors.
yIn 3-phase systems, all phases are measured
against each other (400 V) and all phases
are measured against the neutral conductor
(230V).

| Installation – Commissioning the wallbox
16
Now conduct all locally required checks and testing of the wallbox and its electrical installation. These
include the following tests:
Effectiveness of protective earth conductor connections
Insulation resistance
Loop impedance
Voltage drop
RCCB tripping current and tripping time
Rotating field testing
as well as additional tests according to local regulations.
3 Replace the electronic components cover onto the
housing base and fix it into place with the screw
you removed in Step 8 of Section "Preparing and
fixing the wallbox in place" on page 11.
4 Hook the housing cover onto the upper edge of
the housing base and lock it using the housing
cover key.
The installation of the Wallbox eMH2 is now complete and the wallbox is ready for operation.

Configuring the Wallbox eMH2 – Stand-alone operation of a Master wallbox | 17
Configuring the Wallbox eMH2
The Wallbox eMH2 is delivered preconfigured for operation as either a Master or Slave wallbox within a group instal-
lation. However, you can also operate the Wallbox eMH2 as a stand-alone charging station.
Stand-alone operation of a Master wallbox
The Master wallbox is delivered preconfigured for operation as a single charging station, but in this case without the
option of authorising charging procedures via RFID.
Should you wish to bar or allow the charging function via RFID registration, you must configure and operate the wall-
box using a suitable backend. ABL recommends the backend product by the provider reev, who is offering solutions
that are specifically tailored to the Wallbox eMH2.
For further information, please visit:
https://reev.com
Your Wallbox eMH2 can also be integrated into the charging infrastructure systems of other backend
providers.
You can obtain further information from the dealer where your purchased your wallbox.
Stand-alone operation of a Slave wallbox
In principle, Slave wallboxes are factory preconfigured to operate in combination with a Master wallbox.
However, with the ABL Configuration Software you can set up a Slave wallbox for stand-alone operation without
Master or backend. You can download the ABL Configuration Software free of charge in the Service > All down-
loads > Software section at www.ablmobility.de.
You will need the following separately available accessories to configure the wallbox for stand-alone operation:
Windows PC (laptop recommended) with at least one free USB port
Commercially available Type A to Type A USB extension cable
or
LOMK218 cable set (available as an optional accessory from ABL Sursum, see "Accessories" on page 7).
The following working steps must always be carried out by a qualified specialist electrical contractor!
Proceed as follows to configure a Slave wallbox for stand-alone operation:
1 Disconnect the Slave wallbox from the electricity
supply.
2 Open the housing cover of the wallbox with the
housing cover key and put it aside.

| Configuring the Wallbox eMH2 – Stand-alone operation of a Slave wallbox
18
3 Loosen the screw of the internal electronic com-
ponents cover using the screwdriver (Torx) and put
it aside.
yKeep the screw in a safe place.
4 Connect the computer to the wallbox.
yConnection via USB interface:
Using the USB extension cable, connect the
USB port in the upper section of the housing
base with a free USB port on your computer.
yConnection via LOMK218:
Connect the RS485-RJ12 adapter with the
spring terminals for the CONTROL bus of the
wallbox.
»The CONTROL bus is always assigned
to the left three spring terminals of each
terminal block.
»Using the USB-RS485 cable, connect the
USB-RS485 adapter to your computer. A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
You can find further information in the manual for the LOMK218 cable set, which you can download
from www.ablmobility.de in the Service > All downloads > Operation manuals > Accessories
section.
5 Switch the Slave wallbox on.
6 Open the Configuration Software application
on your computer.
yThe application opens.
Configuration
Software
7 From the Select COM Port drop-down list,
select the highest COM port available.

Configuring the Wallbox eMH2 – Stand-alone operation of a Slave wallbox | 19
8 From the Device Type drop-down list, select
Charge controller.
9 Click the Scan bus button.
yA device is now listed in the Devices field.
10 Select the discovered device Charge Controller
(the Slave wallbox).
yThe charge controller's device parameters are
now retrieved and displayed in the Controller
settings window.
11 From the Controller settings > Address drop-
down list, select value 1.
12 Click the Device specification > Write button
to transfer the designation to the wallbox.
13 In the confirmation window, click the Close
button.
14 From the Device Type drop-down list, select
RFID Online.
15 Click the Scan bus button.
yDiscovered devices are now listed in the
Devices field.
16 Select the RFIDM60 - online device.
17 Click the Device specification > Set to stan-
dalone button.

| Configuring the Wallbox eMH2 – Stand-alone operation of a Slave wallbox
20
18 In the dialog box that pops up, click OK.
yThe new setting is now being transferred to
the wallbox.
yThe Devices field now shows the device
RFIDM60 - standalone CONFIG MODE.
19 In the Devices field, click on the device
RFIDM60 - standalone CONFIG MODE.
20 Click the Device specification > Leave config
mode button.
21 In the dialog box that pops up, click OK.
yThe new setting is now being transferred to
the wallbox.
yThe Devices field now shows the device
RFIDM60 - standalone CONFIG MODE.
22 Close the Configuration Software application using the Xbutton in the top right corner of the application
window and click OK in the dialog box that pops up.
23 Disconnect the computer from the wallbox.
yIf connected via USB interface:
Unplug the USB extension cable from the USB
port in the wallbox and from your computer's
USB port.
yIf connected via LOMK218:
Disconnect the RS485-RJ12 adapter from the
spring terminals in the wallbox. You can also
unplug the USB-RS485 cable from the RS485-
RJ12 adapter and from your computer's USB
port.
A M B
CONTROL
A M B
METER
A M B
CONTROL
A M B
METER
