ActronAir Easyconnect OSK105 Assembly instructions

ActronAir Easyconnect
Installation and Setup Guide for Wall Hung
Systems
IMPORTANT NOTE:
Please read this manual carefully before installing or operating your air conditioning unit.
That’s better. That’s Actron.
Compatible with:
Serene Serene 2
WRE-026AS WRE-026CS
WRE-035AS WRE-035CS
WRE-050AS WRE-050CS
WRE-071AS WRE-072CS
WRE-080AS WRE-085CS

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
3
Table of Contents
01. Specification and Precautions ..............................4
02. Installation ........................................................... 5
03. Download and Install the Easyconnect App ..........6
04. Create an Account................................................ 7
05. Network Configuration ........................................ 8
05.01. Bluetooth Scanning 8
05.02. Manual Selection of Device 12
06. Operation and Control ........................................16
07. Operating Functions ...........................................18

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
4
01. Specification and Precautions
Model: OSK105
Standard: IEEE 802.11b/g/n
Antenna Type: External omnidirectional Antenna
Frequency: Wi-Fi 2.4G
Maximum Transmitted Power: 15dBm Max
Operation Temperature: 0 °C ~45 °C/32 °F~113 °F
Operation Humidity: 10%~85%
Power Input: DC 5V/300mA
Applicable system: iOS, Android
NOTE
Easyconnect App will require software updates from time to time to ensure
compatibility with the latest Android and iOS operating versions. ActronAir will
ensure updates are made quickly but will ultimately not be responsible for any
issues relating to Android and iOS operating systems.
Wireless safety strategy:
Smart kit only supports WPA-PSK/WPA2-PSK encryption and non encryption.
WPA-PSK/WPA2-PSK encryption is recommended.
NOTE
• The Smart phone camera needs to be 5 megapixels or more to scan the QR
code.
• Network encryption may need to be reconfigured, when necessary, to
ensure connectivity.
• Where issues in connectivity arise from the wireless network, there may
be some differences in the display between the Easyconnect App and
connected controllers.
NOTE
ActronAir will not be liable for any issues and problems caused by network
connections, Wi-Fi router and smart devices. Please contact the product
supplier of these third party devices directly to get further assistance.

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
5
02. Installation
BEFORE STARTING:
Isolate the power to the indoor unit and ensure power is not being
supplied to the system to prevent electric shock. Ensure correct lockout/
tag out procedures are adhered to.
Remove the Easyconnect USB kit from the box and take off the protective cap.
1. Open the front panel of the indoor unit and insert the Easyconnect USB
kit into the USB port on the display receiver PCB. If the port is not present,
install the supplied USB port cable plug into the vacant CN3 plug which is
provided in the WUK-WH1 bag.
NOTE
USB ports are factory standard for all units manufactured after February,
2018. Check the serial number to identify the correct manufacturing date.
2. Please place the QR code sticker on the side of the indoor unit near the
manufacturing label, providing sufficient access to the side of the unit.
Serene Serene 2
Open the receiver board
by unscrewing the screw.
Open the receiver board
by unscrewing the screw.

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
6
Serene Serene 2
Install the Wi-Fi USB cable
into CN03 if required.
Install the Wi-Fi USB cable
into CN03 if required.
Serene Serene 2
Ensure that the Easyconnect Module is secured into the receiver panel.
3. Close the panel and reset power to the Air conditioner.
03. Download and Install the Easyconnect
App
Search Easyconnect on your compatible mobile phone, tap download and
then open the app to create a new account.
(Refer to Section 04, for new account setup)

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
7
04. Create an Account
●Please ensure that you have a secure and operational internet
connection readily available for the creation of your account and
system setup.
●You will also require an active e-mail address which will be used as
your username when creating an account, logging into and using the
Easyconnect app.
1. Tap on Create Account.
2. Enter your e-mail address, create and
confirm a unique password, confirm
the terms and conditions and tap on
Registration.

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
8
05. Network Configuration
NOTE
•Ensure that the Android or iOS device can be automatically connected
to the Wi-Fi network - you can adjust this in your phone settings.
•To configure Easyconnect, a wireless remote controller must be used -
these are supplied as standard with all ActronAir wall hung systems.
There are two ways to configure the network connection. This may be done
via Bluetooth, scanning for available devices or by manual selection of the
device.
05.01. Bluetooth Scanning
Ensure that blue-tooth on the mobile device is ON
1. Tap on + Add Device.
2. Power the Air conditioner off from the power supply for 15 seconds, then back
on again.
3. Within 8 minutes of power being reset, press the LED button on the remote
control 7 times (within 10 seconds) - this will initiate access point mode and
allow your phone to link with the Easyconnect app setup process.

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
9
4. Tap on Scan for nearby devices.
5. Wait smart devices to find,
then click to add it.
Note: If no device is found, go straight to manual configuration Section 05.02,
step 2.

Installation Guide Easyconnect App
Installation Guide - Easyconnect App
Document: 9590-4008 Ver. 4 220211
10
6. Select home Wi-Fi,
enter the password.
7. Wait to connect to the
network.
