ActronAir LC7-2W User manual

Model Numbers
LC7-2W(White)
LC7-2G (Grey)
IMPORTANT NOTE:
Please read this manual carefully before installing or
operating your air conditioning unit.
WALL
CONTROL
Operation Manual

Operation Manual LC7-2 Wall Control
Page 2
Return to Home Page
Table of Contents
01. General Information............................................... 3
02. Waste Electrical and Electronic
Equipment Disposal Guideline ............................... 5
03. Maintenance.......................................................... 5
04. Operational Precaution.......................................... 5
05. System Information ............................................... 6
06. Features................................................................. 7
07. Wall Control Functions .......................................... 8
08. Turning Air Conditioner On/Off ...........................10
09. Adjusting Set Temperature ...................................10
10. Changing Operating Mode ...................................10
11. Timer Operation ...................................................12
12. Backlight Function ............................................... 13
13. Program Menu .....................................................14
14. Filter Timer ...........................................................32
15. Near Field Communication (NFC) Tag ...................33

Operation Manual LC7-2 Wall Control
Page 3
Return to Home Page
01. General Information
CONGRATULATIONS! The LC7-2 Control Interface is
manufactured from the highest quality materials and
designed to ensure years of satisfactory operation.
IN THIS MANUAL,you will find instructions on how
to program and utilise the many advanced features
this control interface has to offer. Please take time to
familiarise yourself with all these features, apply their
functions to suit your optimum comfort requirement
and achieve energy cost savings at the same time.
Thoroughly read this manual in order to ensure correct
utilisation of your ActronAir air conditioner.
IMPORTANT NOTICE, ActronAir base the development
of its air conditioning products on more than 30
years of experience in HVAC, sound and continuous
investments in technological innovations and product
improvements, advancement in manufacturing
processes and quality control through 100% functional
product testing. However, ActronAir cannot guarantee
that all the aspects of the product and the software
included with the product respond to the requirements
of final application, despite the product being
developed according to state of the art technology. The
customer, both end user/specifier and installer, assume
all liability and risks relating to the configuration of
the product in order to reach the expected results in
relation to the specific design and system installation.
ActronAir, based on specific agreements, may be
consulted for the positive commissioning, installation
and application of the unit, however in no case does
ActronAir accept liability for the correct operation of
the final equipment / system.
Your ActronAir air conditioning unit is one of the
most advanced and innovative products in the
market. Its operation is specified in the technical
documentation supplied with the product or which can
be downloaded from our website: www.actronair.com.
au. Your air conditioner requires set-up/configuration/
programming in order to be able to operate in the
best possible way to suit your requirement. Failure to
complete such operations, may result in malfunction
and/or damage to the unit, for which ActronAir accepts
no liability.
Installation, commissioning and other technical
services must only be carried out by a qualified
technician. Ensure that the unit installation complies
with all relevant council regulations and building code
standards. All electrical wiring must be in accordance

Operation Manual LC7-2 Wall Control
Page 4
Return to Home Page
with current electrical authority regulations and all
wiring connections to be as per electrical diagram
provided. Always use appropriate PPE for your safety
and protection. Make sure that any safety guards and
covers are always firmly secured and not damaged.
WH&S rules and regulations must be observed at all
times and will take precedence during installation
process and operation of the unit.
In addition, the following instructions must be
observed:
•Prevent the electrical components and electronic
circuits from getting wet.
•Do not install the controlling devices in a particularly
hot environment as extreme temperatures may
damage the electronic equipment.
•Do not attempt to open the control and other
electronic devices in any way other than described in
this manual.
•Do not drop, shake or hit the devices, which can
cause irreparable damage to its internal circuits and
mechanisms.
•Do not use corrosive chemicals, solvents or other
aggressive detergents to clean the unit and the
control interface.
•Do not use the unit for applications other than those
specified in the technical manual.
•Do not install the unit in environment with highly
flammable, combustible and/or explosive articles
and materials.
•This control interface must be installed in a location
that complies with the temperature and humidity
limits specified in this manual.
ActronAir is constantly seeking ways to improve the
design of its products, therefore specifications are
subject to change without prior notice. Please check
with ActronAir Service Department on toll free number:
1800 119 229.
SPECIFICATIONS:
•Voltage: 12VDC +10% (LC7-2 control connects
directly to the Indoor board)
•Data: RS485/Cat5e Twisted Pair 7/0/20 (AWG24)
Shielded Data Cable, Maximum Cable Length up to
200 m
•Storage conditions: -20 to 70oC, < 90% RH non-
condensing
•Operating conditions: -10 to 60oC, < 90% RH non-
condensing

Operation Manual LC7-2 Wall Control
Page 5
Return to Home Page
02.Waste Electrical and Electronic Equipment
Disposal Guideline
03.Maintenance
1. Keep the control interface clean with the use of a
soft dry cloth only. If a cleaning solution is needed,
use a very mild soap solution to dampen the cloth.
Do not spray or squirt any liquid onto your control
interface.
2. Do not use solvent base cleaner, which can cause
damage to the control interface.
3. When cleaning, be careful not to accidentally press
any Buttons, TURN-OFF the unit to ensure that no
adverse unit operation is initiated by accidentally
pressing any buttons.
4. Be careful not to press hard into the display screen,
as it may get damaged.
5. Ensure that the temperature sensor is always clean
and free of dust or dirt build-up to maintain sensor
accuracy.
6. Do not pull apart or attempt to service the
control interface, should you need service to the
device, contact ActronAir Service Department on
1800 119 229.
04. Operational Precautions
Read all instructions in this manual before operating
the air conditioning unit. Failure to do so may result in
damage to the unit and void your warranty.
ACCESS PANELS AND GUARDS: NEVER remove any
access panels or guards as this could cause injury
from electric shock and burns from extremely hot
components. Never allow any bodily parts such as
fingers or objects to protrude through the fan guards
or any other opening as they could cause personal
injury and damage the air conditioner.
SUPERVISION OF CHILDREN AND INFIRM PERSONS:
This appliance is not intended for use by young children
or infirm person unless they have been adequately
supervised by a responsible person to ensure that they
can use the appliance safely. Young children should
1. Do not dispose off the waste electrical and electronic
equipment with local council waste. These must be
disposed off through the council designated hazardous
waste collection centre.
2.The equipment may contain hazardous substances,
improper or incorrect disposal may have a negative effect
on human health and on the environment.

Operation Manual LC7-2 Wall Control
Page 6
Return to Home Page
be supervised to ensure that they do not play with the
appliance.
RETURN AIR FILTER: The air conditioner must never
be operated without a return air filter as this will allow a
build up of dust and other contaminantson the indoor
coil. This is very difficult to clean and causes the system
to operate inefficiently or even fail.
CRANKCASE HEATER PRECAUTION: The main
power (Outside switch board) to the system must
be kept ON at all times to prevent damage to the
outdoor compressor unit. Should the main power be
disconnected or interrupted for 6 hours or longer, then
no attempt should be made to start the system for 2
hours after the power has been restored to outdoor
unit. This allows the compressor to warm up, and
remove any liquid refrigerant that may cause damage.
05.System Information
Air Conditioner
Model No.
Serial No.
The air conditioner model and serial number is situated on the access
panel of the outdoor unit bottom left corner.
Wall Control
Model No.
The wall control model number is situated in front of the wall control.
Installer
Company Name
Phone Number
Technicians Name

Operation Manual LC7-2 Wall Control
Page 7
Return to Home Page
06.Features
1
Auto-Restart After Power Failure
Should a power failure occur whilst the air conditioner is running,
the wall control will restart the air conditioner in the same mode
when the power is restored, if this option is selected.
2
Dual/Triple Wall Control Operation (Optional)
Up to three wall controls can be installed on one system. This is
particularly useful on larger buildings, where you can have up
to three wall controllers in different locations. All connected
controllers will mimic any adjustment made in one controller
(restrictions apply).
3
Room Temperature Display with One Touch
Press the or button and the set temperature display will
change to show the room temperature for 10 seconds.
4
Auto Defrost Function (Heating Mode)
At certain outdoor conditions (low temperature) there may be a
build up of frost on the outdoor heat exchanger. This gradual build
up of frost reduces the performance of the air conditioner. The
system detects this frost build up and will automatically activate the
defrost mode.
The defrost mode is displayed on the wall control by flashing the
DEFROST indicator every 10 seconds.
5
Hot Start Function (Heating Mode)
When the air conditioner starts in heating mode, the indoor fan is
delayed for a short period of time, this allows the heat exchanger
to warm up before the air flow starts, thus minimising cold drafts.
The hot start feature also activates itself when the system finishes
defrosting.
6
Filter Clean Light
The system monitors the accumulated run time of the air
conditioner and after a preset number of hours have expired,
the FILTER indicator will flash, indicating it’s time to check if filter
requires cleaning.
7
Self Diagnosis
In the unlikely event that a fault develops with the air conditioner
the system will detect a fault and displays the relevant fault code on
the wall control.
NOTE
Some applications may require cleaning of the filter at more regular
intervals.

Operation Manual LC7-2 Wall Control
Page 8
Return to Home Page
07. Wall Control Functions
1LCD Display
Displays the setting and operation conditions (See next page for
details).
2AFTER HRS
For setting after hours timer.
3PROG Button*
For setting the clock and for entering the 7-Day time clock menu.
4FAN Control Button
Changes fan speed (high, medium and low). Selects continuous and
non continuous fan operation.
5Temperature-Up Setting Button
Increases room temperature setting.
6Temperature-Down Setting Button
Decreases room temperature setting.
7EXIT Button
Quick exit from time clock programming menu.
8Zone 1 Button with On/Off Indicator
9Zone 5 Button with On/Off Indicator
10 Zone 2 Button with On/Off Indicator
11 Zone 6 Button with On/Off Indicator
12 Zone 3 Button with On/Off Indicator
13 Zone 7 Button with On/Off Indicator
14 Zone 4 Button with On/Off Indicator
15 Zone 8 Button with On/Off Indicator
16 Repeat / Backlight Button
• Repeats the previous day settings to the current day.
• Adjust and Turn On/Off backlight.
17 Select/Clock-Down Setting and Room Temp Display Button
18 NFC Tag
19 Select/Clock-Up Setting and Room Temp Display Button
20
Operation MODE Button
For setting the mode of operation (auto, heat, cool and fan-only
mode).
21 TIMER Operation Button*
Activates timer function.
DISP
Displays the indoor temperature, day and set temperature.
Power On/Off Button
* Setting up 7-Day time clock and Timer Operation are only possible through
Wall Control 1 (C-1).
1
2
3
4
5
6
7
8910 11 12 13 14 15
16
17
18
19
20
21
22
23
22
23

Operation Manual LC7-2 Wall Control
Page 9
Return to Home Page
31
33
36
35
47
32
48
25 29 30
24 27 28
34
37
38
39
41
46 45
44
43
42 40
24 Day Indicator
Display the day of the week when the time is shown and which day is
selected for programming.
25 Time Clock Indicator
26 After Hours Indicator
27 Event Indicator
Indicates which event of the Time Clock is being set.
28 Prog Indicator
Indicates when controller is currently in Program Menu.
29 On Indicator
30 Off Indicator
31 Power On/Off Button Backlight
32 1 and 2 Indicator
Illuminates together with Event to show the programming event.
33 Filter Indicator
34 Fan Only Indicator
35 Cooling Mode Indicator
36 Heating Mode Indicator
37 Defrost Indicator
38 Auto Mode Indicator
Indicates the system will automatically select heating or cooling
operation.
39 Run Indicator
Indicates the outdoor unit is in operation, flashes when on delay.
40 Set Back Indicator
Indicates that the system is operating to achieve Set back temperature.
41 Timer Indicator
Indicates timer is in operation.
42 Lock Symbol
Shows during backlight adjustments and when Turning the button
backlight. In addition, when the following is enabled: Mode Lock, Fan
Speed Lock, Set Point Lock and Keypad Lock.
43 Set Indicator
Illuminates during time and time clock setting adjustments.
44 Continuous Indicator
Illuminates when fan is set to continuous mode of operation.
45 High Fan Speed Indicator
Illuminates when the fan is set to high speed operation.
46 Medium Fan Speed Indicator
Illuminates when the fan is set to medium speed operation.
47 Low Fan Speed Indicator
Illuminates when the fan is set to low speed operation.
48 Outside Indicator
Illuminates when the outside temperature is being displayed.
49 Inside Indicator
Illuminates when the inside temperature is being displayed.
26
48

Operation Manual LC7-2 Wall Control
Page 10
Return to Home Page
08. Turning Air Conditioner On/Off
NOTE
The air conditioning system will re-start on your last settings and operating
mode e.g. 22oC set temperature, AUTO mode, HIGH fan speed.
The display will show the Set Temperature, Fan Speed, Fan Mode and Mode of
Operation.
08.01. Turn On and Off the Air Conditioner
1. Press the button once to turn On and Press the
button once again to turn Off.
NOTE
The button back light will illuminate when unit is turned on.
The button back light will not be illuminated when unit is turned off.
09.Adjusting Set Temperature
Press either the or button to either increase
or decrease the temperature correspondingly.
NOTE
•For a WARMER room temperature, press the button.
•For a COOLER room temperature, press the button.
•The Set Temp is adjustable between 16°C and 30°C in 0.5°C increments.
•The Set Temp is adjustable in control even when the system is OFF.
•No Set Temp displayed during Fan-Only Mode.
10. Changing Operating Mode
NOTES
For all modes of operation, LOW, MED, HIGH, LOW CONT, MED CONT
and HIGH CONT Fan Speeds can only be selected if the 3-Speed Fan setting
option is selected. Otherwise MED and MED CONT are available for 1-Speed
Fan.
NOTES
When in Fan-Only Mode LOW CONT, MED CONT and HIGH CONT will not
be available
NOTES
When the system is On, the Indoor Fan can run continuously and is indicated
by the CONT indicator on the LCD. This is generally preferred during the
Cooling Mode to ensure maximum air circulation. When set to LOW, MED or
HIGH the fan will cycle with the compressor operation according to set point
and room temperatures.
10.01. Fan-Only Operation
1. Press the MODE button until FAN appears on the
display.

Operation Manual LC7-2 Wall Control
Page 11
Return to Home Page
2. Adjust the Indoor Fan speed (LOW, MED and
HIGH) by pressing the FAN button successively
until you reach the desired speed.
NOTE
Additionally, whilst the system is Off, pressing the FAN button will allow
Fan Only operation.
10.02. Cooling Operation
1. Press the MODE button until COOL appears on the
display.
2. Set the desired temperature by pressing either the
or buttons.
3. Adjust the desired Indoor Fan speed by pressing
the FAN button. Available settings are: LOW,
MED, HIGH, CONT LOW, CONT MED and CONT
HIGH.
10.03. Heating Operation
1. Press the MODE button until HEAT appears on the
display.
2. Set the desired temperature by pressing either the
or buttons.
3. Adjust the desired Indoor Fan speed by pressing
the FAN button. Available settings are: LOW, MED,
HIGH, CONT LOW, CONT MED and CONT HIGH.
NOTE
Setting the indoor fan speed to continuous mode can cause cool drafts when
operating the system on heating mode during compressor off cycles.
10.04. Auto Operation
1. Press the MODE button until AUTO appears on
the display.
2. Set the desired temperature by pressing either the
or button.
Adjust the desired Indoor Fan speed by pressing
the FAN button. Available settings are: LOW,
MED , HIGH, CONT LOW, CONT MED and CONT
HIGH.
■

Operation Manual LC7-2 Wall Control
Page 12
Return to Home Page
11. Timer Operation
NOTE
Setting up the timer operation can only be made via Wall Control 1 (C-1).
When you press TIMER button on Wall Control 2 or 3, it will show C-2 or
C-3 on the display. This is to indicate that the wall control is not the C-1 wall
control, and setting up the timer is not possible.
11.01. OFF Timer
1. Press the TIMER button to enter the timer menu.
NOTE
The system’s status must be in the On position to set an OFF timer.
2. Press the or buttons to select the desired
time for the system to remain operating before
turning Off. The maximum adjustable timer
hours are 24 with 0.5 hour (30 minute) adjustable
increments.
3. 3 seconds after the last press of the or
buttons or simply press TIMER, the display will
go back to the main screen and the OFF Timer
countdown will start. The unit will turn Off after
the timer has expired.
4. If a timer is active, TIMER indicator will be
displayed. To cancel the OFF Timer, press the
button and the TIMER indicator will disappear.

Operation Manual LC7-2 Wall Control
Page 13
Return to Home Page
11.02. ON Timer
1. Press the TIMER button to enter timer menu.
NOTE
The system’s status must be in the Off position to set an ON timer.
2. Press the or buttons to select the desired
time for the system to turn On.
The maximum adjustable timer hours are 24 with
0.5 hour (30 minute) adjustable increments.
3. 3 seconds after the last press of the or
buttons or simply press TIMER, the display will
go back to the main screen and the ON Timer
countdown will start. The unit will turn On after
the timer has expired.
4. To cancel the ON Timer, press the button.
12. Backlight Function
12.01. LCD Backlight Level Adjustment
1. Press and continue to hold the REPEAT button.
2. Press the or buttons to adjust the
backlight level as follows:
• To brighten the backlight, press the button.
• To dim the backlight, press the button.
3. Release the Buttons at the desired level of LCD
brightness. The symbol will appear for 3
seconds showing that the backlight level is set.

Operation Manual LC7-2 Wall Control
Page 14
Return to Home Page
12.02. Permanently Turn On LCD Backlight
NOTE
By default, the LCD backlight is programmed to turn off 15 seconds after
a button has been last pressed.
1. Press and hold the REPEAT button for 4 seconds.
2. When the symbol appears, release the REPEAT
button and the backlight will remain Illuminated.
3. To return to default settings, repeat steps 1 and 2.
12.03. ON/OFF Button Backlight
NOTE
The Wall Control must be turned On before operating this procedure.
By default, the button backlight is On.
12.03.01. Turn On the ON/OFF Button Backlight
1. Press and hold the REPEAT button.
2. Press and release the button, along with the
REPEAT button.
3. The symbol will appear for 3 seconds showing
that the button backlight is set. backlight
will remain lit.
12.03.02. Turn Off the ON/OFF Backlight
1. Press and hold the REPEAT button.
2. Press and release the button, along with the
REPEAT button.
3. The symbol will appear for 3 seconds showing
that the backlight is set. The backlight will
turn Off.
13. Program Menu
NOTE
• The Program Menu has a 60 second inactive time out, once expired,
display will return to the home screen.
• Program Menu 01 (7-Day Programmable Function), 02 (Clock) and 03
(Temperature Set back) can only be set via Wall Control 1 (C-1). Wall
Control 2 and 2 (C2 and C3) will skip these Menu and directly proceed
to Menu 04.
13.01. 7-Day Programmable Function
13.01.01. Time clock Operation
NOTE
• The 7-Day Time clock feature of the LC7-2 control allows you to set the air
conditioning system to Turn-On and Turn-Off at different times for each
day of the week.
• Each day can have 2-Programmed Events.
• Each event has an On and Off time.
• Ensure that the current day and time are set correctly before proceeding
with programming.
• To reset any scheduled time clock events, press and hold the PROG and
DISP buttons for 3 seconds.

Operation Manual LC7-2 Wall Control
Page 15
Return to Home Page
13.01.02. Example of Time Clock Operation
13.01.03. Activating the 7-Day Time Clock
1. Press the PROG button to enter program Menu.
TIME CLOCK and PROG indicators will be
illuminated in the screen.
2. Press the PROG button to enter the time clock
menu. By default, Time clock program is Off.
TIME CLOCK and PROG indicators are still
illuminated. OFF indicator will be flashing in the
screen.
3. Press the button to scroll from OFF to ON.
4. Press the PROG button to accept the selection and
re-activate the time clock.
5. Press the EXIT button twice to go back to main
display screen. TIME CLOCK indicator will
re-appear in the screen, indicating that the Time
clock has been reactivated.
MON TUE WED THU FRI SAT SUN
EVENT 1
ON
TIME 6:00am 6:00am 6:00am 6:00am 6:00am 7:00am 8:00am
OFF
TIME 10:00am 10:00am 10:00am 10:00am 10:00am 9:00am 11:00am
EVENT 2
ON
TIME 4:00pm 4:00pm 4:00pm 4:00pm 1:00pm -:-- -:--
OFF
TIME 10:00pm 10:00pm 10:00pm 10:00pm 11:00pm -:-- -:--

Operation Manual LC7-2 Wall Control
Page 16
Return to Home Page
13.01.04. Setting the Programmable Time Clock
1. Press the PROG button to enter program Menu.
TIME CLOCK and PROG indicators will be
illuminated in the screen.
2. Press the PROG button to enter the time clock
menu. Time clock program is currently On.
TIME CLOCK and PROG indicators are still
illuminated. ON indicator will be flashing in the
screen.
3. Press the PROG button (ON is selected) to
program time clock. TIME CLOCK, PROG, ON,
EVENT 1, MON and SET indicators and Time Fields
will be shown in the screen. You can now set the
Event 1 On time for Monday.
NOTE
Pressing the button will enable or disable the Time Clock
program.
Example:
Press the button to adjust the time in 15
minutes increments. AM and PM will toggle after
the 12th Hour.

Operation Manual LC7-2 Wall Control
Page 17
Return to Home Page
4. Press the PROG button to move to Event 1 Off
time. Press the or button to adjust the
time in 15 minutes increments.
5. Press the PROG button to move to Event 2 On
time. Repeat Step 4 to program Event 2 On and
Off time.
NOTE
Press the EXIT button at any time if no further changes to later
Days/Events are required.
6. Press the PROG button to move onto Event 1 On
Time of following day, TUE.
7. Repeat the above steps until you have
programmed all the events you require.
Otherwise, press the EXIT button twice to exit
Program Menu. TIME CLOCK display will show on
the screen to indicate that it is active.
NOTE
If a button has not been pressed after 60 seconds the controller
will exit the Time Clock program menu and return to the home
screen. During a power failure, the controller will retain the time
and time clock settings.

Operation Manual LC7-2 Wall Control
Page 18
Return to Home Page
13.01.05. Repeating a Day’s Events and Time
This feature allows you to automatically repeat the
previous days, events, and time, into the succeeding
days.
1. Proceed to the day you wish to copy the
programmed events and time. See Programming
the Events from previous page. SET, EVENT 1,
TIME CLOCK and ON will be illuminated in the
screen.
NOTE
For this example, events from Monday will be repeated on Tuesday.
Repeat function can only be applied to the succeeding day with
programmed events.
2. Press the PROG button until you reach the
succeeding day, TUE, to paste the copied
programmed events and time.
3. Press the REPEAT button.
4. You have now copied the previous day’s events
into the current day displayed. Repeat steps 2 and
3 above for the remaining days where you wish to
repeat the programmed events and time.
13.01.06. Programming Past Midnight
NOTE
•Event On times can be set up to 11:45 PM of the current day.
•Event Off times can be set to the following day up to 23 hours and 45
minutes after the On time.
•If you program Event 1 past midnight, Event 2 will be automatically
canceled.

Operation Manual LC7-2 Wall Control
Page 19
Return to Home Page
13.01.07. Canceling an Individual Event
In the following example, Event 1 of Tuesday will be
canceled.
1. Press the PROG button to enter program Menu.
TIME CLOCK and PROG indicators will be
illuminated in the screen.
2. Press the PROG button to enter the time clock
menu. TIME CLOCK and PROG indicators are still
illuminated. ON indicator will be flashing in the
screen.
3. Press the PROG button (ON is selected) to
program time clock. TIME CLOCK, PROG, ON,
EVENT 1, MON and SET indicators and time fields
will be shown in the screen. You can now set the
Event 1 ON time for Monday.
4. Continue pressing the PROG button to get to the
desired event to cancel.
5. Press the button to delete Tuesday’s event.
-:-- will be displayed indicating the event is
canceled.

Operation Manual LC7-2 Wall Control
Page 20
Return to Home Page
6. Repeat above process to repeat other days event
otherwise, press the EXIT button twice to exit
Program Menu.
NOTE
Canceling Event 1 will cancel both Event 1 and Event 2.
Canceling Event 2 will only cancel Event 2.
13.01.08. Re-activating an Individual Event
In the following example, Event 1 of TUE will be
re-activated.
1. Press the PROG button to enter program Menu.
TIME CLOCK and PROG indicators will be
illuminated in the screen.
2. Press the PROG button to enter the time clock
menu. Time clock program is currently ON.
TIME CLOCK and PROG indicators will still be
illuminated, with the ON indicator flashing.
3. Press the PROG button (ON is selected) to
program time clock. TIME CLOCK, PROG, ON,
EVENT 1, MON and SET indicators and time fields
will be shown in the screen. You can now set the
Event 1 On time for Monday.
4. Continue pressing the PROG button to get to
desired event to re-activate.
