ADF Web HD674-A002 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 1 of 28
User Manual
evision 1.000
English
Modbus TCP Slave / Modbus Master –
Converter
(Order Code: HD674-A002)
For Website information:
www.adfweb.com?Product=HD674-A002
For Price information:
www.adfweb.com?Price=HD674-A002
Benefits and Main Features:
Very easy to configure
Wide supply input range
Electrical isolation
Industrial temperature range:
-40°C / 105°C (-40°F / 221°F)
For others Gateways / Bridges:
J1939 to Modbus
See also the following links:
www.adfweb.com?Product=HD67212 (Modbus TU)
CA open to Modbus
See also the following links:
www.adfweb.com?Product=HD67001 (Modbus TU Master)
www.adfweb.com?Product=HD67002 (Modbus TU Slave)
www.adfweb.com?Product=HD67004 (Modbus TCP Master)
www.adfweb.com?Product=HD67005 (Modbus TCP Slave)
For others Gateways / Bridges:
For CA bus 2.0A and/or CA bus 2.0B to Modbus
See also the following links:
www.adfweb.com?Product=HD67011 (Modbus TU Slave)
www.adfweb.com?Product=HD67012 (Modbus TU Master)
www.adfweb.com?Product=HD67014 (Modbus TCP Slave)
www.adfweb.com?Product=HD67015 (Modbus TCP Master)
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 2 of 28
I DEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
EVISION LIST 2
WA NING 2
T ADEMA KS 2
SECU ITY ALE T 3
EXAMPLES OF CONNECTION 4
CONNECTION SCHEME 5
CHA ACTE ISTICS 7
CONFIGU ATION 7
POWE SUPPLY 8
LEDS 9
S485 10
ETHE NET 11
USB 11
USE OF COMPOSITO SW674-A002 12
NEW P OJECT / OPEN P OJECT 13
SOFTWA E OPTIONS 14
SET COMMUNICATION 15
OPE ATION MODE 17
T ANSLATE TABLE 18
ENABLED FUNCTIONS 19
UPDATE VIA UDP 20
MECHANICAL DIMENSIONS 22
O DE CODE 26
ACCESSO IES 26
DISCLAIME 27
OTHE EGULATIONS AND STANDA DS 27
WA ANTIES AND TECHNICAL SUPPO T 28
ETU N POLICY 28
Pagina 2 di 28
UPDATED DOCUME TATIO :
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
elated to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISIO LIST:
Revision Date Author Chapter Description
1.000 11/01/2017 Ff All First released version
WAR I G:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 3 of 28
SECURITY ALERT:
G E ERAL I FORMATIO
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I TE DED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSO EL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CO FORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 4 of 28
EXAMPLE OF CO ECTIO :

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 5 of 28
Figure
1a
: Connection scheme
for HD674
-
A0
02
-
E4x
-
xx
CO ECTIO SCHEME:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 6 of 28
Figure
1b
: Connection scheme
for HD674
-
A0
02
-
E7x
-
xx

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 7 of 28
CHARACTERISTICS:
The “HD674-A002” series are rugged devices used to interface Modbus TU Slave devices with Modbus TCP Master network.
With its particular enclosure, equipped with four fixing lugs, makes available the mounting of the device in any plane surface (horizontal,
vertical, oblique).
It is possible to have the device varnished or totally resined and also in both cases with “Mini-Fit®” connectors or “AMP SuperSeal 1.5”
connectors. If is resined, the enclosure, like the “AMP SuperSeal 1.5" connectors, is waterproof.
All the four series have these characteristics:
Triple 4kV isolation between Power Supply / Modbus / Modbus TCP;
Varnished / esined (optionally);
Wide power supply input range: 8…26V AC | 10…40V DC;
Mini-Fit® / AMP SuperSeal 1.5 connectors;
Metal enclosure with fixing lugs;
Possibility to use Metal hose clamps for fixing it without using lugs;
Microprocessor for data control;
Wide temperature range: -40°C / 105°C (-40°F / 221°F).
CO FIGURATIO :
You need Compositor SW674-A002 software on your PC in order to perform the following:
Define the parameter of Modbus line;
Define the parameter of Modbus TCP line;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 8 of 28
POWER SUPPLY:
The devices can be powered between a wide range of tensions. For more details see the two
tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD674-A002-Exx-xx 8V 26V 10V 40V
Consumption at 24V DC:
Device W/VA
HD674-A002-Exx-xx 4
Note: It is possible to use also negative tensions. In this case the polarity must be
inverted.
Caution: ot reverse the polarity power
HD674-A002-E4x-xx HD674-A002-E7x-xx

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 9 of 28
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED ormal Mode Boot Mode
1: Device state (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: Serial Communication
(green) Blinks when Modbus messages are received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: USB Link (yellow) O : USB cable inserted
OFF: USB cable not inserted
O : USB cable inserted
OFF: USB cable not inserted
4: Ethernet communication
(green)
Blinks when Modbus TCP communication is
working
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 10 of 28
RS485:
The connection of the S485 in the HD674-A002-E4x-xx device must be made with a 3way
MiniFit Female connector. The pinout of Male MiniFit connector of the board is at right side of
the page.
The connection of the S485 in the HD67-A002-E7x-xx device must be made with a AMP
SuperSeal 1.5 Male connector. The pinout of Female connector of the board is at right side of
the page.
The termination of S485 line, with a 120Ω resistor, in the HD674-A002-Exx-xx is made
internally of the device; when the order is performed. If the device have the S485 terminated
the code is the follow: HD674-A002-Exx-Yx; otherwise is this other: HD674-A002-Exx-Nx.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid
shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid
shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.
Link for Mini-Fit® connectors: http://www.molex.com/molex/products/group?key=minifit_products&channel=products
Link for SuperSeal 1.5 connectors: http://www.te.com/catalog/cinf/en/c/10876/956

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 11 of 28
ETHER ET:
The connection of Ethernet in the HD674-A002 device must be made with at least a Category 5E cable. The maximum length of the cable
should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device
to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross
cable.
The connection of Ethernet in the HD674-A002-E4x-xx device must be made with J45
connector.
The connection of the Ethernet in the HD674-A002-E7x-xx device must be made with a AMP
SuperSeal 1.5 Male connector. The pinout of Female connector of the board is at right side of
the page.
USB:
The USB port is used to start the converter in Boot Mode. It is necessary to use a Micro USB type B cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 12 of 28
USE OF COMPOSITOR SW674-A002:
To configure the Converter, use the available software that runs with Windows called SW674-A002. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit).
When launching the SW674-A002, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for
SW674
-
A0
02

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 13 of 28
EW CO FIGURATIO / OPE CO FIGURATIO :
The “ ew Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “ Modbus TCP Slave / Modbus Master -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 14 of 28
SOFTWARE OPTIO S:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW674-A002 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 15 of 28
SET COMMU ICATIO :
This section define the fundamental communication parameters of two buses,
Modbus TCP Slave and Modbus Master.
By Pressing the “Set Communication” button from the main window of SW674-
A002 (Fig. 2) the window “Set Communication” appears (Fig. 3).
The section “Operation Mode” defines the operation of the Converter in “Routing
Mode” or “ AT Mode” (see the description at page 17).
The means of the fields for the “Modbus TCP Slave” section are:
In the fields “IP ADDRESS” the IP address of Modbus TCP side of the
converter is defined;
In the fields “SUB ET Mask” the SubNet Mask of Modbus TCP side of the
converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “Port” the port used for Modbus TCP communication is defined;
Checking “Enable UDP Port” field it is possible to do a Broadcast request.
This request must be made at Port 64223 ($FADF) with these six byte of
data: $53, $45, $41, $52, $43, $48. Each device in response sends a total of
10 Bytes. These bytes are four for the IP and the other for the MAC address
(Example of response: 0xC0, 0xA8, 0x01, 0x2A, 0x11, 0x22, 0x33, 0x44,
0x55, 0x58. So the IP is: 192.168.1.42; and the MAC Address: 11-22-33-44-
55-58 );
If the field “Enable Special Command” is checked, it is possible to send a
no-Modbus request through the Converter. i.e. a TCP frame with the first two
characters 0x55 and 0xAA is sent in the Modbus TU line as is. If you don’t
want to send the first two bytes (0x55, 0xAA) in the TU line it is possible to
check the field “Cancel the first two bytes”;
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 16 of 28
If the field “ o TCP frame on RTU Timeout” is checked, the Converter don’t sends back the reply on TCP (error response) if the
Slave TU interrogated has not replied.
If the field “Fast StartUp (only 100Mb/s)” is checked, the Converter take less time to go online. This command can use only if the
Converter is used in a 100Mb/s network;
The means of the fields for the “Modbus Master” section are:
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bits” the number of Stop Bits of the serial line is defined;
In the field “Data Bits” the number of Data Bits of the serial line is defined;
In the field “TimeOut (ms)” the maximum time that the converter attends for the answer from the Slave interrogated is defined;
In the field “Communication Idle Time (ms)” the delay (idle time) between two Modbus requests is defined.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 17 of 28
OPERATIO MODE:
R OUTI G :
A few characteristics of the Modbus TU package have been modified in the standard of the Modbus TCP protocol. Two bytes of the final C C
were eliminated (no longer necessary for the information to reach its already corrected destination). The first byte of the slave identification
was changed, leaving the one that is called PDU. A frame denominated as MBAP header with dimensions of 7 bytes was added to the head of
the PDU.
It is composed by the following:
Word transaction identifier (recopied from the slave in the response phase);
Word protocol identifier (0=Modbus protocol);
Word length (number of successive bytes);
Byte unit identifier (used for the routing operation).
By using the last byte of the MBAP header, it is possible to carry out the routing from a requested Modbus TCP toward a serial line using the
address from the slave which is specified by the byte unit identifier.
Example:
A requested Modbus TCP made in the device as the address 192.168.0.200 for the holding register address $2000, which is MBAP unit
identifier has the value of 2. It will be followed by the request on the serial for the device with the address 2 at the word $2000.
After the request is made, the TU will respond. The master TCP will be given the same response which will be reconstructed according to
the specifications of the Modbus TCP.
If the TU slave responds with an exception, that exception code will be transmitted again to the TCP master. If the TU slave does not
respond in the estimated time defined by the Timeout parameter, an exception response will be given: error code $0B.
ATTI G :
When NAT operation mode is used, the requested data will be processed through a table of translations of the Modbus network addresses.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 18 of 28
TRA SLATE TABLE
Within the section “Translate Table” it is
possible to define the variables that can be
read or written by the TCP bus on the TU bus
when the device is in NAT mode.
By pressing the “Translate Table” button
from the main window for SW674-A002 (Fig.
2), the window “Set Translate Table” appears
(Fig. 4).
The data of the columns have the following
meanings:
In the field “Data Type” the type of
data for the Modbus translation is
defined;
In the field “Slave ID TCP” the address of the virtual Modbus TCP node is defined;
In the field “Address TCP” the Modbus Address of the virtual TCP node is defined;
In the field “Slave ID” the ID of the Modbus slave to poll is defined;
In the field “Address” the Modbus address of the data on the TU device is defined;
In the field “ Point” the number of consecutive registers to read/write is defined;
In the field “Mnemonic” a brief description is defined.
Figure 4: “Set Translate Table” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 19 of 28
E ABLED FU CTIO S
By pressing the “Enabled Functions” button from the main window for SW674-A002 (Fig. 2), the window “Enabled Functions” appears (Fig.
5). This section is used to filter some specific Modbus requests in relation to the function code used.
Figure
5
:
“Enabled Functions” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
Modbus TCP Slave
/
Modbus Master
-
Converter
Document code: MN674-A002_ENG evision 1.000 Page 20 of 28
Figure
6
: “
Update Device
” window
s
UPDATE VIA UDP:
By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if
necessary.
If you don’t know the actual IP address of the device you have to use this procedure:
Connect the USB cable;
Connect the Ethernet cable;
Turn ON the converter;
Insert the IP “192.168.2.205”;
Press the “Ping” button, “Device Found! must appear”;
Press the “ ext” button;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK”, the updating is done;
emove the USB cable.
At this point the configuration/firmware on the device is correctly updated.
If you know the actual IP address of the device, you have to use this procedure:
Turn on the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Press the “Ping” button, must appear “Device Found!”;
Press the “ ext” button;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode
