ADF Web HD67615-A1 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 1 of 29
For other Gateways / Bridges:
Serial / Modbu TCP - converter
See also the following links:
www.adfweb.com?product=HD67521 (Modbus TC Slave)
CAN bu to Modbu
See also the following links:
www.adfweb.com?product=HD67011 (Modbus RTU Master)
www.adfweb.com?product=HD67012 (Modbus RTU Slave)
www.adfweb.com?product=HD67514 (Modbus TC Master)
www.adfweb.com?product=HD67515 (Modbus TC Server)
Do you have an your customer protocol?
See the following links:
www.adfweb.com? roduct=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual
Revision 1.001
English
PROFINET / NMEA 0183 - Converter
(Order Code: HD67615-A1, HD67615-422-A1)
for Website information:
www.adfweb.com? roduct=HD67615
for rice information:
www.adfweb.com? rice=HD67615-A1
www.adfweb.com? rice=HD67615-422-A1
Benefit and Main Feature :
Very easy to configure
32mm Rail DIN mount
Wide supply input range
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 2 of 29
INDEX:
age
INDEX 2
U DATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAM LE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
OWER SU LY 8
FUNCTION MODES 9
LEDS 10
RS485 11
RS422 12
RS232 13
ETHERNET 14
USE OF COM OSITOR SW67615 15
NEW ROJECT / O EN ROJECT 16
SOFTWARE O TIONS 17
SET COMMUNICATION 19
RECEIVE FRAMES 22
ROFINET XML 23
OBJECTS MA 23
U DATE DEVICE 24
MECHANICAL DIMENSIONS 26
ORDER CODES 27
ACCESSORIES 27
DISCLAIMER 28
OTHER REGULATIONS AND STANDARDS 28
WARRANTIES AND TECHNICAL SU ORT 29
RETURN OLICY 29
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that you
need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code” that
appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/ and
search for the corresponding code on the page. Click on the proper “Document
Code” and download the updates.
REVISION LIST:
Revi ion Date Author Chapter De cription
1.000 15/06/2017 Ff All First release version
1.001 29/04/2020 Ff All Added RS422 version
WARNING:
ADFweb.com reserves the right to change information in this manual about our
product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 3 of 29
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each
individual application, legal and safety regulation. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e. independent limit
switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and who have
appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state of the art and is safe. The instrument can represent a potential hazard if they are inappropriately installed and operated by
personnel untrained. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is danger for people to serious injury or death and / or the possibility
of damage.
CE CONFORMITY
The declaration is made by us. You can send an email to [e-mail] or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 4 of 29
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 5 of 29
CONNECTION SCHEME:
Figure 1a: Connection scheme for HD67615-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 6 of 29
Figure
1
b
: Connection scheme for HD67615
-
422
-
A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 7 of 29
CHARACTERISTICS:
The “ ROFINET / NMEA 0183 – Converter” allows the following characteristics:
electrical isolation between NMEA 0183 – ROFINET, ower Supply – ROFINET, ower Supply – NMEA 0183;
Multiple independent NMEA 0183 lines;
Mountable on Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67615 software on your C in order to perform the following:
Define the parameter of NMEA 0183;
Define the parameter of ROFINET;
Define the list of NMEA 0183 sentences in reception;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 8 of 29
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two
tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Con umption [W/VA]
HD67615-xxx-A1 3.5
Caution: Not rever e the
polarity power
HD67615-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 9 of 29
FUNCTION MODES:
The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for uploading the roject and/or Firmware.
For the operations to follow for the updating, see ‘U DATE DEVICE’ section.
According to the functioning mode, the LEDs will have specific functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 10 of 29
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blink quickly: Boot state
Blink very lowly (~0.5Hz): update in progress
2: Ethernet Link (green) ON: Ethernet cable connected
OFF: Ethernet cable disconnected
ON: Ethernet cable connected
OFF: Ethernet cable disconnected
3: NMEA 0183
communication (green) Blinks when NMEA 0183 frames are received Blink quickly: Boot state
Blink very lowly (~0.5Hz): update in progress
4: ROFINET communication
(green)
Blinks when ROFINET communication is
running
Blink quickly: Boot state
Blink very lowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 11 of 29
RS485:
For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 1200m (4000 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 12 of 29
RS422:
For terminating the RS422 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure.
The maximum length of the cable should be 1200m (4000 feet).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 13 of 29
RS232:
The connection from RS232 socket to a serial port must be made with a Null Modem cable (a
serial cable where the pins 2 and 3 are crossed).
It is recommended that the RS232 cable not exceed 15 meters.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 14 of 29
ETHERNET:
The Ethernet connection must be made using Connector5 of HD67615 with at least a Category 5E cable. The maximum length of the cable
should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to
a Hub/Switch the use of a straight cable is recommended. To connect the device to a C/ LC/other the use of a cross cable is recommended.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 15 of 29
Figure 2: Main window for SW67615
USE OF COMPOSITOR SW67615:
To configure the Converter, use the available software that runs with Windows called SW67615. It is downloadable on the site www.adfweb.com
and its operation is described in this document. (This manual is referenced to the last version of the software present on our web site). The
software works with MSWindows (X , Vista, Seven, 8, 10; 32/64bit).
When launching the SW67615, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 16 of 29
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “ ROFINET / NMEA 0183 - Converter” in
order to configure another device in the same manner, it is necessary to maintain the
folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the button
“Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 17 of 29
SOFTWARE OPTIONS:
By pressing the “Setting ” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67615 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 18 of 29
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in the
different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 19 of 29
SET COMMUNICATION:
By ressing the “Set Communication” button from the main window for SW67615
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The window is divided in different sections in order to define the different parameters
of the converter:
ROFINET
RS232
RS485 / RS422
RS485 2
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET / NMEA 0183
-
Converter
Document code: MN67615_ENG Revision 1.001 age 20 of 29
Figure 3b: “Set Communication  ROFINET” window
Figure 3c: “Set Communication

RS232” window
Figure 3d: “Set Communication  RS485 / RS422”
window
PROFINET:
This section is used to define the parameters of ROFINET side of the converter. It is
possible to define:
In the field “IP Addre ” the I address of the converter is defined;
In the field “SubNet Ma k” the SubNet Mask of the converter is defined;
In the field “Gateway” the default gateway of the net is defined. This feature
can be enabled or disabled pressing the Check Box field. This feature is used for
going out of the net;
In the field “PROFINET Name of Station” the name for ROFINET side of the
converter is defined.
In the field “Num Byte ” the number output bytes of the converter is defined.
RS232:
This section is used to define the main parameters of RS232 line. The means of the
fields are:
If the field “Enable RS232” is checked, the serial port is enabled;
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bit ” the number of stop bits of the serial line is defined.
RS485 / RS422:
This section is used to define the main parameters of RS485 / RS422 line. The
means of the fields are:
If the field “Enable RS485 / RS422” is checked, the serial port is enabled;
In the field “Baudrate” the baudrate for the serial line is defined;
In the field “Parity” the parity of the serial line is defined;
In the field “Stop Bit ” the number of stop bits of the serial line is defined.
