ADF Web HD67B75-A1 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 1 di 26
User Manual
Revision 1.
English
PROFINET Master / DeviceNet Slave –
Converter
(Order Code: HD67B75-A1)
for Website information:
www.adfweb.com?Product=HD67B75
for Price information:
www.adfweb.com?Price=HD67B75-A1
Benefits and Main Features:
Very easy to configure
Wide supply input range
Electrical isolation
Industrial temperature range:
For others PROFINET products see also the following link:
Converter PROFINET to
www.adfweb.com?Product=HD67 78 M-Bus)
www.adfweb.com?Product=HD67 9 M-Bus Wireless)
www.adfweb.com?Product=HD67178 SNMP Manager)
www.adfweb.com?Product=HD676 NMEA2000)
www.adfweb.com?Product=HD676 1 RS232/RS485)
www.adfweb.com?Product=HD676 2 Modbus Master)
www.adfweb.com?Product=HD676 3 Modbus Slave)
www.adfweb.com?Product=HD676 4 PROFIBUS Master)
www.adfweb.com?Product=HD676 5 PROFIBUS Slave)
www.adfweb.com?Product=HD676 6 CAN)
www.adfweb.com?Product=HD676 7 CANopen)
www.adfweb.com?Product=HD676 8 DeviceNet Master)
www.adfweb.com?Product=HD676 9 DeviceNet Slave)
www.adfweb.com?Product=HD6761 J1939)
www.adfweb.com?Product=HD67611 Modbus TCP Master)
www.adfweb.com?Product=HD67612 Modbus TCP Slave)
www.adfweb.com?Product=HD67613 SNMP Agent)
www.adfweb.com?Product=HD67614 DMX)
www.adfweb.com?Product=HD67615 NMEA 0183)
www.adfweb.com?Product=HD6766 EtherNet/IP Slave)
www.adfweb.com?Product=HD67679 BACnet Slave)
www.adfweb.com?Product=HD67719 BACnet Master)
www.adfweb.com?Product=HD67818 KNX)
www.adfweb.com?Product=HD67848 DALI)
www.adfweb.com?Product=HD67952 MQTT)
Do you have an your customer protocol?
www.adfweb.com?Product=HD67 3
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 2 di 26
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
PROFINET 1
CAN 11
USE OF COMPOSITOR SW67B75 12
NEW PROJECT / OPEN PROJECT 13
SOFTWARE OPTIONS 14
SET COMMUNICATION 15
PROFINET ACCESS 17
UPDATE DEVICE 21
MECHANICAL DIMENSIONS 23
ORDERING INFORMATIONS 24
ACCESSORIES 24
DISCLAIMER 25
OTHER REGULATIONS AND STANDARDS 25
WARRANTIES AND TECHNICAL SUPPORT 26
RETURN POLICY 26
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
To obtain the updated documentation for the product that you own, note
the “Document Code” (Abbreviated written "Doc. Code" on the label on the
product) and download the updated from our web site
www.adfweb.com/download/
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1. 3/ 9/2 2 Dp All First Release

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 3 di 26
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for
each individual application, legal and safety regulation. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e. independent limit
switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and who
have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state of the art and is safe. The instrument can represent a potential hazard if they are inappropriately installed and operated
by personnel untrained. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is danger for people to serious injury or death and / or the
possibility of damage.
CE CONFORMITY
The declaration is made by us. You can send an email to [e-mail] or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 4 di 26
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 5 di 26
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67B75-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 6 di 26
CHARACTERISTICS:
The HD67B75-A1 is a PROFINET / DeviceNet Converter.
It has the following characteristics:
Triple isolation between CAN - Power Supply, CAN - Ethernet, Power Supply - Ethernet.
Two-directional information between DeviceNet bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67B75 software on your PC in order to perform the following:
Define the parameter of PROFINET line;
Define the parameter of DeviceNet line;
Define the list of PROFINET slave devices to read and write;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 7 di 26
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67B75-A1 3.5
HD67B75-A1
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 8 di 26
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip2 of Dip-Switch A’:
The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip2 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.
Warning:
Dip1 of ‘Dip-Switch A’ must be at ON position for working even if the Ethernet cable isn’t inserted.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 9 di 26
LEDS:
The device has got six LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: MT [maintenance display]
(yellow)
ON: Maintenance Problem is present
OFF: No maintenance are present
Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
3: BF [bus fault] (red)
ON: The Ethernet connection is defective; the IP
address exists several times in the network; the own
NameOfStation exists several times in the network; no
IP address has been set
Flashing: At least one configured AR is no longer in
the data exchange
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
4: SF [group error] (red) ON: At least one AR is not in the data exchange
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks quickly: Boot state
Blinks very slowly ~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 1 di 26
PROFINET:
The PROFINET connection must be made using Connector3 and/or Connector4 of HD67B75-A1 with at least a Category 5E cable. The
maximum length of the cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to
1 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is
recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 11 di 26
CAN:
For terminate the CANopen line with a 12 Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position.
Cable characteristics:
DC parameter: Impedance 7 Ohm/m
AC parameters: Impedance 12 Ohm/m
Delay 5 ns/m
Length Baud Rate [bps] Length MAX [m]
1 K 5
2 K 25
5 K 1
1 K 65
125 K 5
25 K 25
5 K 1
8 K 5
1 K 25

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 12 di 26
USE OF COMPOSITOR SW67B75:
To configure the Converter, use the available software that runs with Windows called SW67B75. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67B75, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67
B75

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 13 di 26
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “PROFINET Master / DeviceNet Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 14 di 26
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67B75 checks automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 15 di 26
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 16 di 26
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses,
PROFINET and DeviceNet.
By Pressing the “Set Communication” button from the main window of SW67B75
(Fig. 2) the window “Set Communication” appears (Fig. 3).
The means of the fields for “PROFINET Master” are:
In the fields “IP Address” the IP address for PROFINET side of the converter
is defined;
In the fields “SubNet Mask” the SubNet Mask for PROFINET side of the
converter is defined;
In the fields “Gateway” the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field "Name of Station" the name of PROFINET side of the converter
is defined.
The means of the fields for the “DeviceNet Slave” section are:
In the field “ID Device” the address for the DeviceNet Slave is defined;
In the field “Baudrate” the velocity of the DeviceNet Master bus is defined:
In the field “Number Byte IN” the number input bytes of DeviceNet Slave is
defined (max 455 bytes);
In the field “Number Byte OUT” the number output bytes of DeviceNet
Slave is defined (max 455 bytes).
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 17 di 26
Figure 4: “Definition of ROFINET Devices resent in Network” window
PROFINET ACCESS:
By Pressing the “PROFINET Access” button from the main window for SW67B75 (Fig. 2) the window “Definition of PROFINET Devices
Present in Network” appears (Fig. 4).
This section is used to define the list of the PROFINET slaves to read/write with the PROFINET Master. It is possible to add the PROFINET
slaves from the hardware catalog. If a new device will be connected, it is possible to instal the GSDML file.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 18 di 26
The means of the fields below are:
If the field “Name of Station” is checked, the name of the PROFINET slave is defined;
In the field “IP Address” the IP Address of the PROFINET slave is defined;
If the field “Automatic new session when StationProblemIndicator is active” is checked, the converter will restart the
PROFINET communication when the error indicator in the slave is present;
In the field “Update Time [ms]” the delay used for IO communication is defined;
In the field “Answer TimeOut” the allowed number of cycles without response from the slave is defined.
Warning:
The data from/to the slaves are mapped consecutively into the IN/OUT PROFINET arrays, following the order with which they are
defined.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 19 di 26
Figure 5: “Definition Module and/or Submodules of ROFINET Device” window
By clicking on “Modules” button, it is possible to import the modules for the selected PROFINET slave device. The window “Definition Module
and/or Submodules of PROFINET Device” appears (Fig. 5). In the main table it is possible to import the Modules of the PROFINET device in
use. In the properties below, it is possible to set the parameters of the slave. These options depends on the slave in use, refer to the manual
of the PROFINET device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET
Master
/
DeviceNet Slave
Document code: MN67B75_ENG Revision 1. Pagina 2 di 26
The means of the checkboxes inside the table are:
If the field “Map Only Data” is checked, only the data of the modules are mapped into the DeviceNet arrays. Otherwise, for each
module there will be the status of IN and OUT areas too (1 byte);
If the field “Different Word” is checked, the data of the different modules are mapped in different and consecutive words without
splitting them.
