ADF Web HD67B31 Series User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 1 of 3
User Manual
Revision 1.
English
OPC UA Server / BACnet Master -
Converter
(Order Code: HD67B31-B2)
for Website information:
http://www.adfweb.com/?Product=HD67B31
for Price information:
http://www.adfweb.com/?Price=HD67B31-B2
Benefits and Main Features:
Triple electrical isolation
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For others OPC UA Server devices, see also the following links:
OPC UA Server from/to …
www.adfweb.com?Product=HD67B26 (Serial)
www.adfweb.com?Product=HD67B27 (Modbus Master)
www.adfweb.com?Product=HD67B28 (Modbus Slave)
www.adfweb.com?Product=HD67B29 (Modbus TCP Master)
www.adfweb.com?Product=HD67B3 (Modbus TCP Slave)
www.adfweb.com?Product=HD67B32 (Bacnet Slave)
www.adfweb.com?Product=HD67B33 (CA )
www.adfweb.com?Product=HD67B34 (CA open)
www.adfweb.com?Product=HD67B35 (Device et Master)
www.adfweb.com?Product=HD67B36 (Device et Slave)
www.adfweb.com?Product=HD67B37 (DMX)
www.adfweb.com?Product=HD67B38 (Ether et/IP Master)
www.adfweb.com?Product=HD67B39 (Ether et/IP Slave)
www.adfweb.com?Product=HD67B4 (J1939)
www.adfweb.com?Product=HD67B41 (K X)
www.adfweb.com?Product=HD67B42 (MQTT)
www.adfweb.com?Product=HD67B43 ( MEA0183)
www.adfweb.com?Product=HD67B44 ( MEA2000)
www.adfweb.com?Product=HD67B45 (PROFI ET Master)
www.adfweb.com?Product=HD67B46 (PROFI ET Slave)
www.adfweb.com?Product=HD67B47 (S MP Manager)
www.adfweb.com?Product=HD67B48 (S MP Agent)
Do you have an your customer protocol?
See the following links:
www.adfweb.com?Product=HD67 3
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 2 of 3
I DEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 7
CONFIGURATION 7
POWER SUPPLY 8
FUNCTION MODES 9
LEDS 1
RS485 (FOR BACNET MS/TP) 11
ETHERNET 12
USE OF COMPOSITOR SW67B31 13
NEW PROJECT / OPEN PROJECT 14
SOFTWARE OPTIONS 15
SET COMMUNICATION 17
OPC UA ACCESS 2
SET BACNET ACCESS 21
UPDATE DEVICE 25
MECHANICAL DIMENSIONS 27
ORDERING INFORMATIONS 28
ACCESSORIES 28
DISCLAIMER 29
OTHER REGULATIONS AND STANDARDS 29
WARRANTIES AND TECHNICAL SUPPORT 3
RETURN POLICY 3
Pagina 2 di 30
UPDATED DOCUME TATIO :
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISIO LIST:
Revision Date Author Chapter Description
1. 13/ 3/2 19 Tf All First release version
WAR I G:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 3 of 3
SECURITY ALERT:
G E ERAL I FORMATIO
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I TE DED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSO EL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CO FORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 4 of 3
EXAMPLE OF CO ECTIO :

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 5 of 3
CO ECTIO SCHEME:
Figure
1
a
: Connection
scheme
for HD67
B
3
1
-
I
-
B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 6 of 3
Figure
1
b
: Connection
scheme
for HD67
B
3
1
-
MST
-
B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 7 of 3
CHARACTERISTICS:
The HD67B31-B2 is a OPC UA Server / BACnet Master converter.
It allows the following characteristics:
Up to 15 bytes in reading and 15 bytes in writing;
Two-directional information between BACnet and OPC UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CO FIGURATIO :
You need Compositor SW67B31 software on your PC in order to perform the following:
Define the parameter of OPC UA;
Define the parameter of BACnet line;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 8 of 3
POWER SUPPLY:
The devices can be powered between a wide range of tensions. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B31-B2 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67B31-B2 4
Caution: ot reverse the polarity power
HD67B31-xxx-B2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 9 of 3
FU CTIO MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device.
The second, with Dip1 in On position, is used for upload the Project/Firmware.
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section).
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section).

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 1 of 3
LEDS:
The device has got five LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED ormal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: BACnet comm. (yellow) Flashing: BACnet response
OFF: No BACnet response
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: OPC UA comm. (yellow) Flashing: OPC UA request
OFF: No OPC UA request
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: OPC UA error (yellow) O : An error has occurred
OFF: The device is correctly running
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) O : Ethernet cable connected
OFF: Ethernet cable disconnected
O : Ethernet cable connected
OFF: Ethernet cable disconnected

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 11 of 3
RS485 (for BACnet MS/TP):
For terminating the RS485 line with a 12 Ω resistor it is necessary to put ON dip 1, like in figure.
The maximum length of the cable should be 12 m (4 feet).
Here some codes of cables:
Belden: p/n 8132 - 2x 28AWG stranded twisted pairs conductor + foil shield + braid shield;
Belden p/n 82842 - 2x 24AWG stranded twisted pairs conductor + foil shield + braid shield;
Tasker: p/n C521 - 1x 24AWG twisted pair conductor + foil shield + braid shield;
Tasker: p/n C522 - 2x 24AWG twisted pairs conductor + foil shield + braid shield.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 12 of 3
ETHER ET:
The Ethernet connection must be made using Connector3 of HD67B31-xxx-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a
cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 13 of 3
USE OF COMPOSITOR SW67B31:
To configure the Converter, use the available software that runs with Windows called SW67B31. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67B31, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67B
3
1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 14 of 3
EW CO FIGURATIO / OPE CO FIGURATIO :
The “ ew Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “OPC UA Server / BACnet Master -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 15 of 3
SOFTWARE OPTIO S:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67B31 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 16 of 3
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 17 of 3
SET COMMU ICATIO :
This section define the fundamental communication parameters of two buses, OPC UA
Server and BACnet Master.
By Pressing the “Set Communication” button from the main window for SW67B31
(Fig. 2) the window “Set Communication” appears (Fig. 3a).
The window is divided in three sections in order to define the different parameters of
the converter:
OPC UA Server
BACnet Master
NTP (Network Time Protocol)
Figure 3a: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 18 of 3
Figure 3c: “Set Communication  BACnet Master”
window
OPC UA S ERVER :
The means of the fields for “OPC UA Server” are:
In the field “IP Address” the IP address for OPC UA side of the converter is
defined;
In the field “Sub et Mask” the SubNet Mask for OPC UA side of the
converter is defined;
In the field “Gateway” the default gateway of the net is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “D S” the IP Address of the DNS server is defined. This feature
can be enabled or disabled pressing the Check Box field;
In the field “Port” the port of OPC UA Server is defined.
BAC ET M ASTER ( FOR BAC ET /IP):
This section is used to define the main parameters of BACnet/IP line. The means of
the fields are:
the fields “IP ADDRESS” the IP address of BACnet/IP side of the converter is
defined;
In the fields “SUB ET Mask” the SubNet Mask of BACnet/IP side of the
converter is defined;
In the fields “GATEWAY” the default gateway of the network is defined. This
feature can be enabled or disabled pressing the Check Box field. This feature
is used for going out of the net;
In the field “Port” the port used for BACnet communication is defined. The
default port used for BACnet communication is 478 8, but is possible to
insert any value;
In the field "BACnet Device ame" the name of BACnet/IP side of the
converter is defined;
In the field “Device Identifier” the ID of BACnet/IP side of the converter is
defined;
In the field “TimeOut Polling (ms)” the timeout for the BACnet requests is defined.
Figure 3b: “Set Communication  O C UA Server”
window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 19 of 3
Figure 3d: “Set Communication  BACnet Master”
window
Figure 3e: “Set Communication  NT (Network
Time rotocol” window
BAC ET M ASTER ( FOR BAC ET MS/TP):
This section is used to define the main parameters of BACnet MS/TP line. The means
of the fields are:
In the field “Baudrate” the data rate of the BACnet line is defined;
In the field “Parity” the parity of the line is defined;
In the field “BACnet Device ame” the name to give to the BACnet node is
defined;
In the field “MAC Address” the MAC of BACnet node (from to 254) is
defined;
The field “Max Master” specifies the highest allowable address for master
nodes. The value shall be less than or equal to 127;
The field “Max Info Frames” specifies the maximum number of information
frames the node may send before it must pass the token;
In the field “Device Instance” the of the BACnet MS/TP side of the converter
is defined.
TP ( ETWORK T IME P ROTOCOL )
This section is used to define the parameters of NTP protocol. The means of the
fields are:
In the field “Server URL” the URL or the IP Address of the NTP Server is
defined;
In the field “Poll Time (seconds)” the polling time for the time
synchronization is defined.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
OPC UA
Server
/
BACnet
Master
Document code: MN67B31_ENG Revision 1. Page 2 of 3
Figure 4: “O C UA Server Access” window
OPC UA ACCESS:
By Pressing the “OPC UA Access” button from the main window for SW67B31 (Fig. 2) the window “OPC UA Server Access” appears (Fig. 4).
This section is used to define the list of OPC UA variables to read/write.
The means of the checkboxes inside the table are:
In the field “Type” the data format of the OPC UA variable is defined;
In the field “Position” the starting byte of the internal memory arrays where getting the value is defined;
In the field “Length” the byte length of the OPC UA variable is defined;
In the field “ ame” the name of the OPC UA variable is defined;
In the field “R/W” the access type of the OPC UA variable is defined;
In the field “Mnemonic” a description of the OPC UA variable is defined.
