ADF Web HD67661-A1 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 1 of 26
User Manual
Revision 1.001
En lish
PROFINET / EtherNet/IP Master -
Converter
(Order Code: HD67661-A1)
for Website information:
http://www.adfweb.com/?Product=HD67661
for Price information:
http://www.adfweb.com/?Price=HD67661-A1
Benefits and Main Features:
Triple electrical isolation
Two Ethernet ports
Temperature ran e: -40°C/+85°C (-40°F/+185°F)
For others EtherNet/IP Master devices, see also the followin links:
EtherNet/IP Master from/to …
www.adfweb.com?Product=HD67158 (SNMP gent)
www.adfweb.com?Product=HD67643 (PROFIBUS Slave)
www.adfweb.com?Product=HD67645 (C N)
www.adfweb.com?Product=HD67646 (C Nopen)
www.adfweb.com?Product=HD67647 (DeviceNet Slave)
www.adfweb.com?Product=HD67661 (PROFINET)
www.adfweb.com?Product=HD67665 (Modbus TCP Slave)
www.adfweb.com?Product=HD67667 (Serial)
www.adfweb.com?Product=HD67669 (Modbus Slave)
www.adfweb.com?Product=HD67689 (B Cnet Slave)
www.adfweb.com?Product=HD67806 (KNX)
www.adfweb.com?Product=HD67955 (MQTT)
Do you have an your customer protocol?
See the followin links:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the followin link:
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 2 of 26
INDEX:
Pa e
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67661 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
ETHERNET/IP ACCESS 16
PROFINET XML 17
UPDATE DEVICE 18
MECHANICAL DIMENSIONS 20
ORDERING INFORMATIONS 21
ACCESSORIES 21
PLC CONFIGURATION (for PROFINET) 22
DISCLAIMER 25
OTHER REGULATIONS AND STANDARDS 25
WARRANTIES AND TECHNICAL SUPPORT 26
RETURN POLICY 26
Pagina 2 di 26
UPD TED DOCUMENT TION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the followin document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top ri ht-hand corner of each pa e of this document.
With this “Document Code” o to web pa e www.adfweb.com/download/
and search for the correspondin code on the pa e. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
Revision Date uthor Chapter Description
1.000 13/03/2018 Ff All First release version
1.001 10/12/2018 Ff All Revision
W RNING:
ADFweb.com reserves the ri ht to chan e information in this manual about
our product without warnin .
ADFweb.com is not responsible for any error this manual may contain.
TR DEM RKS:
All trademarks mentioned in this document belon to their respective
owners.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 3 of 26
SECURITY LERT:
G ENER L I NFORM TION
To ensure safe operation, the device must be operated accordin to the instructions in the manual. When usin the device, le al and
safety re ulation are required for each individual application. The same applies also when usin accessories.
I NTENDED U SE
Machines and systems must be desi ned so the faulty conditions do not lead to a dan erous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q U LIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissionin and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDU L R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the followin symbol:
This symbol indicates that non-observance of the safety instructions is a dan er for people that could lead to serious injury or
death and / or the possibility of dama e.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or ive us a call if you need it.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 4 of 26
EX MPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 5 of 26
CONNECTION SCHEME:
Figure
1
: Connection scheme for HD67
661
-
A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 6 of 26
CH R CTERISTICS:
The HD67661-A1 is a PROFINET / EtherNet/IP Master Converter.
It allows the followin characteristics:
Up to 1440 bytes in readin and 1440 bytes in writin ;
Two-directional information between EtherNet/IP and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input ran e: 8…24V AC or 12…35V DC;
Wide temperature ran e: -40°C / 85°C [-40°F / +185°F].
CONFIGUR TION:
You need Compositor SW67661 software on your PC in order to perform the followin :
Define the parameter of the PROFINET;
Define the parameter of the EtherNet/IP;
Define the list of EtherNet/IP slaves connected to the converter;
Update the device.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 7 of 26
POWER SUPPLY:
The devices can be powered between a wide ran e of tensions. For more details see the two tables below.
V C
VDC
Vmin Vmax Vmin Vmax
HD67661- 1 8V 24V 12V 35V
Consumption at 24V DC:
Device W/V
HD67661-A1 4
Caution: Not reverse the polarity power
HD67661-A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 8 of 26
FUNCTION MODES:
The device has ot two functions mode dependin of the position of the Dip2 of ‘Dip-Switch B’:
The first, with Dip2 in Off position (factory settin ), is used for the normal workin of the device.
The second, with Dip2 in On position, is used for upload the Project/Firmware.
For the operations to follow for the updatin (see ‘UPDATE DEVICE’ section).
Accordin to the functionin mode, the LEDs will have specifics functions (see ‘LEDS’ section).
Warnin :
Dip1 of ‘Dip-Switch A’ must be at ON position to work even if the Ethernet cable is not inserted.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 9 of 26
LEDS:
The device has ot six LEDs that are used to ive information of the functionin status.
The various meanin s of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: ON [supply volta e ]
( reen)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: MT [maintenance display]
(yellow)
ON: Device not able to communicate with at least one
EtherNet/IP slave
OFF: No maintenance are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
3: BF [bus fault] (red)
ON: The Ethernet connection is defective; the IP
address exists several times in the network; the own
NameOfStation exists several times in the network; no
IP address has been set
Flashing: At least one confi ured AR is no lon er in
the data exchan e
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
4: SF [ roup error] (red) ON: At least one AR is not in the data exchan e
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
5: Ethernet1 Tx ( reen) Blinks when is transmittin Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress
6: Ethernet2 Tx ( reen) Blinks when is transmittin Ethernet frames Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in pro ress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 10 of 26
ETHERNET:
The Ethernet connection must be made usin Connector3 or Connector4 of HD67661-A1 with at least a Cate ory 5E cable. The maximum
len th of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To
connect the device to an Hub/Switch is recommended the use of a strai ht cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 11 of 26
USE OF COMPOSITOR SW67661:
To confi ure the Converter, use the available software that runs with Windows called SW67661. It is downloadable on the site
www.adfweb.com and its operation is described in this document. (This manual is referenced to the last version of the software present on
our web site). The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit).
When launchin the SW67661, the window below appears (Fi . 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure 2: Main window for SW67661

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 12 of 26
NEW CONFIGUR TION / OPEN CONFIGUR TION:
The “New Configuration” button creates the folder which contains the entire device’s confi uration.
A device’s confi uration can also be imported or exported:
To clone the confi urations of a pro rammable “PROFINET / EtherNet/IP Master -
Converter” in order to confi ure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 13 of 26
SOFTW RE OPTIONS:
By pressin the “Settings” ( ) button there is the possibility to chan e the lan ua e of the software and check the updatin s for the
compositor.
In the section “Lan ua e” it is possible to chan e the lan ua e of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatin s of the software compositor in ADFweb.com website.
Checkin the option “Check Software Update at Start of Program”, the
SW67661 check automatically if there are updatin s when it is launched.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 14 of 26
In the section “Software Settin s”, it is possible to enable/disable some
keyboard’s commands for an easier navi ation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 15 of 26
SET COMMUNIC TION:
This section define the fundamental communication parameters of two buses,
PROFINET and EtherNet/IP.
By Pressin the “Set Communication” button from the main window for SW67661
(Fi . 2) the window “Set Communication” appears (Fi . 3).
The means of the fields for “PROFINET” are:
In the fields “IP DDRESS” the IP address for PROFINET side of the converter
is defined;
In the fields “SUBNET Mask” the SubNet Mask for PROFINET side of the
converter is defined;
In the fields “G TEW Y” the default ateway of the net is defined. This
feature can be enabled or disabled pressin the Check Box field. This feature is
used for oin out of the net;
In the field “Port” the port used for PROFINET communication is defined. The
port has a fixed value of 34964.
In the field "Name of Station" the name of the PROFINET node is defined.
The means of the fields for “EtherNet/IP Master” are:
In the fields “IP DDRESS” the IP address for EtherNet/IP side of the
converter is defined;
In the fields “SUBNET Mask” the SubNet Mask for EtherNet/IP side of the
converter is defined;
In the fields “G TEW Y” the default ateway of the net is defined. This
feature can be enabled or disabled pressin the Check Box field. This feature is
used for oin out of the net;
In the field “Port” the port used for EtherNet/IP communication is defined. The
port has a fixed value of 44818.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 16 of 26
Figure 4: “Set EtherNet/I Slaves Access” window
ETHERNET/IP CCESS:
By Pressin the “EtherNet/IP ccess” button from the main window for SW67661 (Fi . 2) the window “Set EtherNet/IP Slaves Access”
appears (Fi . 4).
This section is used to define the list of the EtherNet/IP slaves to read/write with the PROFINET Master.
The means of the fields are:
If the field “Enable” is checked, the pollin to the EtherNet/IP slave is enabled;
In the field “IP ddress” the IP Address of the EtherNet/IP slave is defined;
In the field “Start Input” the startin Input byte of the EtherNet/IP slave to map on PROFINET side is defined;
In the field “Num Input” the number of consecutive Input byte to map on PROFINET side is defined;
In the field “Start Output” the startin Output byte of the EtherNet/IP slave to write from PROFINET side is defined;
In the field “Num Output” the number of consecutive Output byte to write from PROFINET side is defined;
In the field “Time Poll” the pollin time in ms is defined;
In the field “Instance T > O” the instance of the assembly for the Tar et to Ori inator data direction is defined;
In the field “Conn. Point T > O” the connection point of the assembly for the Tar et to Ori inator data direction is defined;
In the field “Instance O > T” the instance of the assembly for the Ori inator to Tar et data direction is defined;
In the field “Conn. Point O > T” the connection point of the assembly for the Ori inator to Tar et data direction is defined;
In the field “Mnemonic” a brief description is defined.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 17 of 26
Figure 5: “ ROFINET XML” window
PROFINET XML:
By pressin the “PROFINET XML” button it is possible to save the GSDML
file for the PROFINET side.

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 18 of 26
UPD TE DEVICE:
By pressin the “Update Device” button, it is possible to load the created
Confi uration into the device; and also the Firmware, if necessary. This by usin the
Ethernet port.
If you don’t know the actual IP address of the device you have to use this procedure:
Turn OFF the Device;
Put Dip2 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip2 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual IP address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically oes at Normal Mode.
At this point the confi uration/firmware on the device is correctly updated.
Figure 6: “Update device” windows

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 19 of 26
Note:
When you receive the device, for the first time, you also have to update the Firmware in the HD67661 device.
Warnin :
If Fi . 7 appears when you try to do the Update try these points before seekin
assistance:
Check if the serial COM port selected is the correct one;
Check if the serial cable is connected between the PC and the device;
Try to repeat the operations for the updatin ;
Try with another PC;
Try to restart the PC;
Check the LAN settin s;
If you are usin the pro ram inside a Virtual Machine, try to use in the main
Operatin System;
If you are usin Windows Seven, Vista, 8 or 10 make sure that you have the
administrator privile es;
In case you have to pro ram more than one device, usin the "UDP Update", you
have to cancel the ARP table every time you connect a new device on Ethernet. For
do this you have to launch the "Command Prompt" and write the command "arp -
d". Pay attention that with Windows Vista, Seven, 8, 10 you have to launch the
"Command Prompt" with Administrator Ri hts;
Pay attention at Firewall lock.
Warnin :
In the case of HD67661 you have to use the software “SW67661”: www.adfweb.com\download\filefold\SW67661.zip.
Figure 7: “Error” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
PROFINET /
EtherNet/IP
Master
Document code: MN67661_ENG Revision 1.001 Pa e 20 of 26
MECH NIC L DIMENSIONS:
Figure
8
: Mechanical dimensions scheme
for H
D6766
1
-
A1
