ADF Web HD67B82-A1 User manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 1 of 26
User Manual
Revision 1 000
English
IEC 61850 Server / PROFINET Master -
Converter
(Order Code: HD67B82-A1)
for Website information:
www adfweb com/?Product=HD67B82
for Price information:
www adfweb com/?Price=HD67B82-A1
Benefits and Main Feat res:
Triple electrical isolation
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -40°C/+85°C (-40°F/+185°F)
For others PROFINET Master devices, see also the following links:
PROFINET Master from/to …
www adfweb com?Product=HD67B45 (OPC UA Server)
www adfweb com?Product=HD67B70 (Serial)
www adfweb com?Product=HD67B71 (Modb s Slave)
www adfweb com?Product=HD67B72 (PROFIBUS Slave)
www adfweb com?Product=HD67B73 (CAN)
www adfweb com?Product=HD67B74 (CANopen)
www adfweb com?Product=HD67B75 (DeviceNet Slave)
www adfweb com?Product=HD67B76 (Modb s TCP Slave)
www adfweb com?Product=HD67B77 (SNMP Agent)
www adfweb com?Product=HD67B78 (EtherNet/IP Slave)
www adfweb com?Product=HD67B79 (KNX)
www adfweb com?Product=HD67B80 (MQTT)
www adfweb com?Product=HD67B81 (BACnet Slave)
www adfweb com?Product=HD67B84 (Ethernet)
Do you have an your customer protocol?
See the following links:
www adfweb com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www adfweb com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 2 of 26
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 10
USE OF COMPOSITOR SW67B82 11
NEW PROJECT / OPEN PROJECT 12
SOFTWARE OPTIONS 13
SET COMMUNICATION 15
PROFINET ACCESS 16
IEC61850 ACCESS 19
TLS KNOWN CERTIFICATE 20
UPDATE DEVICE 21
MECHANICAL DIMENSIONS 23
ORDERING INFORMATIONS 24
ACCESSORIES 24
DISCLAIMER 25
OTHER REGULATIONS AND STANDARDS 25
WARRANTIES AND TECHNICAL SUPPORT 26
RETURN POLICY 26
Pagina 2 di 26
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document
With this “Document Code” go to web page www adfweb com/download/
and search for the corresponding code on the page Click on the proper
“Document Code” and download the updates
REVISION LIST:
Revision Date A thor Chapter Description
1 000 13/03/2019 Ff All First release version
WARNING:
ADFweb com reserves the right to change information in this manual about
our product without warning
ADFweb com is not responsible for any error this manual may contain
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 3 of 26
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual When using the device, legal and
safety regulation are required for each individual application The same applies also when using accessories
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i e
independent limit switches, mechanical interlocks, etc )
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job
R ESIDUAL R ISKS
The device is state-of-the-art and is safe The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage
CE CONFORMITY
The declaration is made by our company You can send an email to support@adfweb com or give us a call if you need it

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 4 of 26
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 5 of 26
Figure
1
: Connection scheme for HD67
B
82
-
A1
CONNECTION SCHEME:

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 6 of 26
CHARACTERISTICS:
The HD67B82-A1 is a IEC 61850 Server / PROFINET Master converter
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between PROFINET and IEC 61850;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F]
CONFIGURATION:
You need Compositor SW67B82 software on your PC in order to perform the following:
Define the parameter of the IEC 61850;
Define the parameter of the PROFINET;
Define the list of PROFINET slaves connected to the converter;
Define the list of IEC 61850 variables available for reading and writing;
Update the device

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 7 of 26
POWER SUPPLY:
The devices can be powered between a wide range of tensions For more details see the two tables below
VAC
VDC
Vmin Vmax Vmin Vmax
HD67B82-A1 8V 24V 12V 35V
Consumption at 24V DC:
Device W/VA
HD67B82-A1 4
Ca tion: Not reverse the polarity power
HD67
B8
2
-
A1

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 8 of 26
FUNCTION MODES:
The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’:
The first, with Dip1 in Off position (factory setting), is used for the normal working of the device
The second, with Dip1 in On position, is used for upload the Project/Firmware
For the operations to follow for the updating (see ‘UPDATE DEVICE’ section)
According to the functioning mode, the LEDs will have specifics functions (see ‘LEDS’ section)

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 9 of 26
LEDS:
The device has got six LEDs that are used to give information of the functioning status
The various meanings of the LEDs are described in the table below
LED Normal Mode Boot Mode
1: ON [supply voltage ]
(green)
ON: Device powered
OFF: Device not powered
ON: Device powered
OFF: Device not powered
2: MT [maintenance display]
(yellow)
ON: Maintenance are present
OFF: No maintenance are present
Blinks q ickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: BF [bus fault] (red)
ON: The Ethernet connection is defective; the IP
address exists several times in the network; the own
NameOfStation exists several times in the network; no
IP address has been set
Flashing: At least one configured AR is no longer in
the data exchange
OFF: No errors are present
Blinks q ickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: SF [group error] (red) ON: At least one AR is not in the data exchange
OFF: No errors are present
Blinks q ickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Ethernet1 Tx (green) Blinks when is transmitting Ethernet frames Blinks q ickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
6: Ethernet2 Tx (green) Blinks when is transmitting Ethernet frames Blinks q ickly: Boot state
Blinks very slowly (~0.5Hz): update in progress

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 10 of 26
ETHERNET:
The Ethernet connection must be made using Connector3 and Connector4 of HD67B82-A1 with at least a Category 5E cable The maximum
length of the cable should not exceed 100m The cable has to conform to the T568 norms relative to connections in cat 5 up to 100 Mbps To
connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended
the use of a cross cable

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 11 of 26
USE OF COMPOSITOR SW67B82:
To configure the Converter, use the available software that runs with Windows called SW67B82 It is downloadable on the site
www adfweb com and its operation is described in this document (This manual is referenced to the last version of the software present on
our web site) The software works with MSWindows (XP, Vista, Seven, 8, 10; 32/64bit)
When launching the SW67B82, the window below appears (Fig 2)
Note:
It is necessary to have installed Net Framework 4
Figure 2: Main window for SW67B
8
2

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 12 of 26
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Config ration” button creates the folder which contains the entire device’s configuration
A device’s configuration can also be imported or exported:
To clone the configurations of a programmable “IEC 61850 Server / PROFINET Master
- Converter” in order to configure another device in the same manner, it is necessary
to maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Config ration”

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 13 of 26
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the
language of the software and check the updatings for the compositor
In the section “Language” it is possible to change the language of the
software
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb com website
Checking the option “Check Software Update at Start of Program”, the
SW67B82 check automatically if there are updatings when it is launched

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 14 of 26
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 15 of 26
SET COMMUNICATION:
This section define the fundamental communication parameters of two buses, IEC 61850 and
PROFINET
By Pressing the “Set Comm nication” button from the main window for SW67B82 (Fig 2)
the window “Set Communication” appears (Fig 3)
The means of the fields for “PROFINET Master” are:
In the fields “IP Address” the IP address for PROFINET side of the converter is
defined;
In the fields “S bNet Mask” the SubNet Mask for PROFINET side of the converter is
defined;
In the fields “Gateway” the default gateway of the net is defined This feature can be
enabled or disabled pressing the Check Box field This feature is used for going out of
the net;
In the field "Name of Station" the name of the PROFINET node is defined
The means of the fields for “IEC61850 Server” are:
In the field “Port” the port number used for IEC 61850 communication is defined;
If the field “Password” the password used for accessing to IEC 61850 variables is
defined
The means of the fields for “TLS (Transport Layer Security) Server” are:
If the field “Enable TLS” is checked, the TLS protocol for secure connection is
enabled;
In the field “Key” the key for the authentication is defined;
In the field “Key Password” the password for decrypting the key is defined;
In the field “Server Certificate” the certificate for the server is defined;
In the field “Root Certificate” the root of the server is defined;
If the field “Enable Only Known Certificates” is checked, the converter will accept
just connection from known Clients (defined in the section “TLS Known Certificate”)
Figure
3
:
“Set Communication” window

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 16 of 26
Figure 4: “
Definition of ROFINET Devices resent in Network
” window
PROFINET ACCESS:
By Pressing the “PROFINET Access” button from the main window for SW67B82 (Fig 2) the window “Definition of PROFINET Devices
Present in Network” appears (Fig 4)
This section is used to define the list of the PROFINET slaves to read/write with the PROFINET Master It is possible to add the PROFINET
slaves from the hardware catalog If a new device will be connected, it is possible to instal the GSDML file

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 17 of 26
The means of the fields below are:
In the field “Name of Station” is checked, the name of the PROFINET slave is defined;
In the field “IP Address” the IP Address of the PROFINET slave is defined;
If the field “A tomatic new session when StationProblemIndicator is Active” is checked, the converter opens a new
communication session when an error is present in the slave station;
In the field “Update Time [ms]” the delay used for IO communication is defined;
In the field “Answer TimeO t” the allowed number of cycles without response from the slave is defined
Warning:
The data from/to the slaves are mapped consecutively into the IN/OUT PROFINET arrays, following the order with which they are
defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 18 of 26
Figure 5: “Definition Module and/or Submodules of ROFINET Device” window
By clicking on “Mod les” button, it is possible to import the modules for the selected PROFINET slave device The window “Definition Module
and/or Submodules of PROFINET Device” appears (Fig 5) In the main table it is possible to import the Modules of the PROFINET device in
use In the properties below, it is possible to set the parameters of the slave These options depends on the slave in use, refer to the manual
of the PROFINET device
The means of the checkboxes inside the table are:
If the field “Map Only Data” is checked, only the data of the modules are mapped into the IEC 61850 map Otherwise, for each
module there will be the status of IN and OUT areas too (1 byte);
If the field “Different Word” is checked, the data of the different modules are mapped in different and consecutive words

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 19 of 26
Figure
6
: “
IEC 61850 Access
” window
IEC 61850 ACCESS:
By Pressing the “IEC 61850 Access” button from the main window for SW67B82 (Fig 2) the window “Set Variables Access for IEC 61850”
appears (Fig 6)
This section is used to define the IEC 61850 variables accessible from serial side
The means of the fields are:
If the field “Enable” is checked, the IEC 61850 variable is enabled;
In the field “Name” the name of the IEC 61850 variable is defined;
In the field “Type” the data format of the IEC 61850 variable is defined;
If the field “Read Only” is checked, the IEC 61850 variable is just in reading Otherwise, it is writeable too;
In the field “Position” the starting byte of the PROFINET arrays from/to which taking/mapping the data is defined;
In the field “Start Bit” the starting bit of the byte of the field “Position” is defined;
In the field “Conversion” the conversion of the data is defined This option is used to convert the data format between PROFINET
and IEC 61850;
In the field “Molt. Factor” a multiplicative factor of the value is defined;
If the field “Swap” is checked, the bytes’ order is swapped;
If the field “Swap Word” is checked, the words’ order is swapped;
In the field “Mnemonic” a description of the variable is defined

Industrial Electronic Devices
ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com hone +39.0438.30.91.31
User Manual
IEC
61850
S
erver
/ P
ROFINET
Master
Document code: MN67B82_ENG Revision 1 000 Page 20 of 26
TLS KNOWN CERTIFICATE:
By pressing the “TLS Known Certificate” button from the Main Window of SW67B82 (Fig 2) the “Definition the list of Known Certificates”
window appears (Fig 7)
The data of the columns have the following meanings:
If the field “Enable” is checked, the TLS certificate is allowed;
In the field “Certificate” the certificate of the Client is defined;
In the field “Mnemonic” a description is defined
Figure 7: “TLS Known Certificate” window
