ADF Web EnOcean User manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 1 of 25
User Manual
Revision 1.
English
EnOcean / PROFIBUS Slave - Converter
(Order Code: HD67C75-B2)
For Website information:
www.adfweb.com?Product=HD67C75-B2
For Price information:
www.adfweb.com?Price=HD67C75-B2
Benefits and Main Features:
Very easy to configure
Power Supply 18…35V DC and 8…24 V AC
Temperature range: -4 °C/+85°C (-4 °F/+185°F)
For others EnOcean products, see also the following links:
Converter EnOcean to
www.adfweb.com?Product=HD67C5 (Serial)
www.adfweb.com?Product=HD67C52 (Mod us Slave)
www.adfweb.com?Product=HD67C54 (Mod us TCP Slave)
www.adfweb.com?Product=HD67C56 (BACnet Slave)
www.adfweb.com?Product=HD67C57 (CAN)
www.adfweb.com?Product=HD67C58 (CANopen)
www.adfweb.com?Product=HD67C61 (DeviceNet Slave)
www.adfweb.com?Product=HD67C63 (EtherNet/IP Slave)
www.adfweb.com?Product=HD67C65 (IEC61850 Server)
www.adfweb.com?Product=HD67C66 (J1939)
www.adfweb.com?Product=HD67C67 (KNX)
www.adfweb.com?Product=HD67C7 (MQTT)
www.adfweb.com?Product=HD67C72 (NMEA 0183)
www.adfweb.com?Product=HD67C73 (NMEA 2000)
www.adfweb.com?Product=HD67C77 (PROFINET Slave)
www.adfweb.com?Product=HD67C79 (SNMP Agent)
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
User Manual

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 2 of 25
INDEX:
Page
INDEX 2
UPDATED DOCUMENTATION 2
REVISION LIST 2
WARNING 2
TRADEMARKS 2
SECURITY ALERT 3
EXAMPLE OF CONNECTION 4
CONNECTION SCHEME 5
CHARACTERISTICS 6
CONFIGURATION 6
POWER SUPPLY 7
FUNCTION MODES 8
LEDS 9
ETHERNET 1
ENOCEAN 11
PROFIBUS 11
USE OF COMPOSITOR SW67C75 12
NEW CONFIGURATION / OPEN CONFIGURATION 13
SOFTWARE OPTIONS 14
SET COMMUNICATION 16
ENOCEAN ACCESS 17
FILE GSD 19
UPDATE DEVICE 2
MECHANICAL DIMENSIONS 22
ORDERING INFORMATIONS 23
ACCESSORIES 23
DISCLAIMER 24
OTHER REGULATIONS AND STANDARDS 24
WARRANTIES AND TECHNICAL SUPPORT 25
RETURN POLICY 25
UPDATED DOCUMENTATION:
Dear customer, we thank you for your attention and we remind you that
you need to check that the following document is:
Updated
Related to the product you own
To obtain the most recently updated document, note the “document code”
that appears at the top right-hand corner of each page of this document.
With this “Document Code” go to web page www.adfweb.com/download/
and search for the corresponding code on the page. Click on the proper
“Document Code” and download the updates.
REVISION LIST:
WARNING:
ADFweb.com reserves the right to change information in this manual about
our product without warning.
ADFweb.com is not responsible for any error this manual may contain.
TRADEMARKS:
All trademarks mentioned in this document belong to their respective
owners.
Revision Date Author Chapter Description
1. 5/12/2 19 Ff All First release version

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 3 of 25
SECURITY ALERT:
G ENERAL I NFORMATION
To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and
safety regulation are required for each individual application. The same applies also when using accessories.
I NTENDED U SE
Machines and systems must be designed so the faulty conditions do not lead to a dangerous situation for the operator (i.e.
independent limit switches, mechanical interlocks, etc.).
Q UALIFIED P ERSONNEL
The device can be used only by qualified personnel, strictly in accordance with the specifications.
Qualified personnel are persons who are familiar with the installation, assembly, commissioning and operation of this equipment and
who have appropriate qualifications for their job.
R ESIDUAL R ISKS
The device is state-of-the-art and is safe. The instruments can represent a potential hazard if they are inappropriately installed and
operated by untrained personnel. These instructions refer to residual risks with the following symbol:
This symbol indicates that non-observance of the safety instructions is a danger for people that could lead to serious injury or
death and / or the possibility of damage.
CE CONFORMITY
The declaration is made by our company. You can send an email to [email protected]om or give us a call if you need it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 4 of 25
EXAMPLE OF CONNECTION:

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 5 of 25
CONNECTION SCHEME:
Figure 1: Connection scheme for HD67C75-B

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 6 of 25
CHARACTERISTICS:
The HD67C75-B2 is a EnOcean / PROFIBUS Slave Converter.
It allows the following characteristics:
Electrical isolation between Ethernet and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12…35V DC and 8…24V AC;
Wide temperature range: -4 °C / 85°C [-4 °F / +185°F].
CONFIGURATION:
You need Compositor SW67C75 software on your PC in order to perform the following:
Define the parameter of PROFIBUS line;
Define the parameter of EnOcean line;
Generate the GSD file for PROFIBUS Master configuration;
Update the device.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 7 of 25
POWER SUPPLY:
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below.
VAC
VDC
Vmin Vmax Vmin Vmax
8V 24V 12V 35V
Consumption at 24V DC:
Device Consumption [W/VA]
HD67C75-B2 3.5
HD67C75-B2
Caution: Not reverse the polarity power

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 8 of 25
FUNCTION MODES:
The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’:
The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device.
The second, with ‘Dip1 of Dip-Switch A’ at “ON” position, is used for upload the Project and/or Firmware.
For the operations to follow for the updating, see ‘UPDATE DEVICE’ section.
According to the functioning mode, the LEDs will have specifics functions, see ‘LEDS’ section.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 9 of 25
LEDS:
The device has got four LEDs that are used to give information of the functioning status.
The various meanings of the LEDs are described in the table below.
LED Normal Mode Boot Mode
1: Device State (green) Blinks slowly (~1Hz) Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
2: PROFIBUS communication
(yellow) Blinks when PROFIBUS communication is running Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
3: EnOcean communication
(yellow) Blinks when EnOcean data is received Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
4: Error state (yellow) ON: An error in the communication busses occurs
OFF: No errors are present
Blinks quickly: Boot state
Blinks very slowly (~0.5Hz): update in progress
5: Link Ethernet (green) ON: Ethernet cable inserted
OFF: Ethernet cable not inserted
ON: Ethernet cable inserted
OFF: Ethernet cable not inserted

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 1 of 25
ETHERNET:
The Ethernet port is used for programming the device.
The Ethernet connection must be made using Connector2 of HD67C75-B2 with at least a Category 5E cable. The maximum length of the
cable should not exceed 1 m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 1 Mbps. To connect the
device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC is recommended the use of a cross cable.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 11 of 25
ENOCEAN:
EnOcean is a protocol designed for energy harvesting devices communication. The main
fields of application are building automation and domotics, but it can also be potentially
used in the industrial field.
EnOcean products include solutions for environment monitoring, smart metering and
lighting. Each device uses a unique ID for identification and one of the standardized profiles
(EEPs) for data transmission. Communication process may be secure or unsecure and may
be unidirectional or bidirectional (for devices that support Smart Acknowledge operating
mode).
EnOcean is based on wireless communication on 868.3 MHz ASK.
It is possible to connect up to 1 EnOcean devices to a single converter, where up to 32
can be in Secure Mode and up to 19 with Smart Acknowledge.
The Antenna connector is a SMA Female (‘Female Outer Shell’ and ‘Female Receptacle’) so
the Antenna must have a SMA Male connector.
PROFIBUS:
The PROFIBUS uses a 9-pin D-SUB connector. The pin assignment is defined like in
the right figure.
Here some codes of cables:
Belden: p/n 183 79A - Continuous Armor DataBus® ISA/SP-5 PROFIBUS
Cable;

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 12 of 25
USE OF COMPOSITOR SW67C75:
To configure the Converter, use the available software that runs with Windows called SW67C75. It is downloadable on the site
www.adfweb.com and its operation is described in this document. The software works with MS Windows (XP, Vista, Seven, 8, 1 ; 32/64bit).
When launching the SW67C75, the window below appears (Fig. 2).
Note:
It is necessary to have installed .Net Framework 4.
Figure : Main window for SW67C7
5

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 13 of 25
NEW CONFIGURATION / OPEN CONFIGURATION:
The “New Configuration” button creates the folder which contains the entire device’s configuration.
A device’s configuration can also be imported or exported:
To clone the configurations of a Programmable “EnOcean / PROFIBUS Slave -
Converter” in order to configure another device in the same manner, it is necessary to
maintain the folder and all its contents;
To clone a project in order to obtain a different version of the project, it is sufficient to
duplicate the project folder with another name and open the new folder with the
button “Open Configuration”.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 14 of 25
SOFTWARE OPTIONS:
By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the
compositor.
In the section “Language” it is possible to change the language of the
software.
In the section “Connection Options”, it is possible to check if there are some
updatings of the software compositor in ADFweb.com website.
Checking the option “Check Software Update at Start of Program”, the
SW67C75 check automatically if there are updatings when it is launched.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 15 of 25
In the section “Software Settings”, it is possible to enable/disable some
keyboard’s commands for an easier navigation inside the tables contained in
the different sections of the software.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 16 of 25
SET COMMUNICATION:
By Pressing the “Set Communication” button from the main window for SW67C75 (Fig. 2)
the window “Set Communication” appears (Fig. 3).
The means of the fields for “PROFIBUS” are:
In the field “ID Device” the ID for the PROFIBUS side is defined;
In the field “Buadrate” the data rate of PROFIBUS is defined (fixed to “Auto
Baudrate”);
In the field “Num er Byte In” the number of input byte of PROFIBUS is defined;
In the field “Num er Byte Out” the number of output byte of PROFIBUS is defined.
The means of the fields for “Ethernet” are:
In the field “IP Address” the IP address of the converter is defined;
In the field “Su Net Mask” the SubNet Mask of the converter is defined;
In the field “Gateway” the default gateway of the net is defined. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out
of the net;
In the field “DNS” the IP Address of the DNS server is defined.
Figure 3: “Set Communication” window

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 17 of 25
Figure 4: “
EnOcean Access
” window
ENOCEAN ACCESS:
By Pressing the “EnOcean Set Access” button from the main window for SW67C75 (Fig. 2) the window “EnOcean Set Access” appears (Fig.
4). This section is used to define the list of the EnOcean devices to read/write.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 18 of 25
Figure 5: “Add/Modify EnOcean device”
window
By clicking on “+” or “Modify” under “ID Devices List”, it is possible to add/modify a new EnOcean device inserting its characteristics. The
window “Add/Modify EnOcean device” appears (Fig. 5).
The means of the fields are:
In the field “Device ID” the ID of the EnOcean device is defined;
In the field “Secure Type ” the type of EnOcean communication is defined;
In the field “Key” the key used for encryption of frames in Secure Mode is defined;
In the field “Rolling Code” the Rolling Code for the EnOcean communication is
defined;
In the field “Rolling Code Algorithm” the type of Rolling Code is defined;
In the field “Rolling Code Tx” the transmission of the Rolling Code is
enabled/disabled;
In the field “CMAC Algorithm” the MAC field at the end of the EnOcean frame is
defined;
In the field “Data Encrypted” the encryption of the data is enabled/disabled;
In the field “PTM” the type of EnOcean device is defined.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 19 of 25
Figure 6: “Add/Modify EnOcean variable”
window
By clicking on “+” or “Modify”, it is possible to add/modify a new variable for the selected ID. The window “Add/Modify EnOcean variable”
appears (Fig. 6).
The means of the EEP fields are:
In the field “Rorg” the type of EnOcean telegram is defined;
In the field “Func” the type of EnOcean instance is defined;
In the field “Type” the type of event is defined.
The means of the Variable fields are:
In the field “Case” the format of the EnOcean telegram is defined;
In the field “Varia le” the variable to read/write is defined;
In the field “Position” the starting byte of the internal array where
mapping/taking the variable is defined;
In the field “Bit Start” the starting bit of the defined Position where
mapping/taking the variable is defined.
GSD FILE:
By pressing the “GSD File” button it is possible to save the GSD file for the PROFIBUS side.
With this feature you can save the configuration of the gateway of the PROFIBUS side.
Note:
When you import the .gsd file on your Master PROFIBUS you have to add all the modules that are present inside it.

Industrial Electronic Devices
ADFweb.com S.r.l.
User Manual
EnOcean / PRO
FIBUS Slave
Document code: MN67C75_ENG Revision 1. Page 2 of 25
UPDATE DEVICE:
By pressing the “Update Device” button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary. This by using the
Ethernet port.
If you don’t know the actual IP address of the device you have to use this procedure:
Turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in ON position;
Turn ON the device
Connect the Ethernet cable;
Insert the IP “192.168.2.205”;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” turn OFF the Device;
Put Dip1 of ‘Dip-Switch A’ in OFF position;
Turn ON the device.
If you know the actual IP address of the device, you have to use this procedure:
Turn ON the Device with the Ethernet cable inserted;
Insert the actual IP of the Converter;
Select which operations you want to do;
Press the “Execute update firmware” button to start the upload;
When all the operations are “OK” the device automatically goes at Normal Mode.
At this point the configuration/firmware on the device is correctly updated.
Figure 7: “Update device” windows
