Advantech PCA-6119P7 Installation and operation manual

PCA-6119P7 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
1. PCA-6119P7 startup manual 2002611903
2. Screw M4*6L (15 pcs) 1939000410
3. 2-year quality warranty card 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
Standard Functions
• PICMG 1.0 slots: PCA-6119P7 supports PICMG 1.0 CPU
boards
• ISA slots: Ten ISA slots
• 32-bit PCI: Seven 32 bit/33 MHz PCI slots
• PICMG/PCIslot: One PICMG/PCI slot
Mechanical and Environment
• Dimension: 417.02 mm x 269.99 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,
• Power requirements: Refer to the CPU board, add-on
card, and peripherals
• Operating temperature: 0 ~ 60° C
• Weight: 0.964 kg
PCA-6119P7 Backplane: 19-slot BP for 20-slot Chassis, 10 ISA, 7
PCI, 2 PICMG
Startup Manual
The board has a number of jumpers that allow you to con-
figure your system to suit your application.
The table below lists the function of each of the jumpers and
connectors.
Jumpers and Connectors
Connectors
Label Function
PICMG1, PICMG2 PICMG1.0 CPU board slot
ISA3~ISA12 16-bit ISA bus connector
ISA1, ISA2 PICMG connector (ISA slot in
PICMG1, PICMG2)
PPCI1~PPCI3 32 bit / 33MHz PCI slot
SPCI4~SPCI7 32 bit / 33MHz PCI slot
AT 1 AT power connector
AT 2 5V power connector (6 Pin)
AT 3 3.3V power connector (6 Pin)
ATX2 5V power connector (6 Pin)
ATX3 3.3V power connector (6 Pin)
BIG1 Big 4-pin power connector
CN1 PS-On, to CPU card for ATX
power signal
CN2 Alarm board power connector
CN3 +5V and +12V fan connector
KB1 Keyboard-in connector
KB2 Keyboard-out connector
KB3 Keyboard-out connector
Jumpers
Label Function
CN1 ATX/AT Mode Selection
No jumper needed AT Mode
Connect 3-pin ATX
connector cable ATX Mode
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCA-6119P7 Series.
Part No. 2002611903
Printed in China
4th Edition
May 2014
Jumpers and Connectors

2 PCA-6119P7 Startup Manual
Jumpers and Connectors
AT1
Pin Name
1 N/C
2 5V
3 12V
4 -12V
5 GND
6 GND
7 GND
8 GND
9 -5V
10 5V
11 5V
12 5V
AT2
Pin Name
1 5V
2 5V
3 5V
4 GND
5 GND
6 GND
AT3
Pin Name
1 3.3V
2 3.3V
3 3.3V
4 GND
5 GND
6 GND
ATX2
Pin Name
1 5V
2 5V
3 5V
4 GND
5 GND
6 GND
ATX3
Pin Name
1 3.3V
2 3.3V
3 3.3V
4 GND
5 GND
6 GND
BIG1
Pin Name
1 12V
2 GND
3 GND
4 5V
CN1
Pin Name
1 PSON
2 GND
3 5VSB
CN2
Pin Name
1 5VSB
2 GND
3 GND
4 -5V
5 5VSB
6 3.3V
7 -12V
8 12V
CN3
Pin Name
1 12V
2 GND
3 5V

PCA-6119P7 Startup Manual 3
KB1 ~ KB3
Pin Name
1 KBCLK
2 KBDAT
3 MSDAT
4 KB_GND
5 KB_VCC
6 MSCLK
Jumpers and Connectors
PCI
Slot IDSEL
PCI Interrupt Pin Route
INTA INTB INTC INDTD
PPCI1 P_AD31 INTB INTC INTD INTA
PPCI2 P_AD30 INTC INTD INTA INTB
PPCI3 P_AD29 INTD INTA INTB INTC
SPCI4 S_AD20 INTA INTB INTC INTD
SPCI5 S_AD21 INTB INTC INTD INTA
SPCI6 S_AD22 INTC INTD INTA INTB
SPCI7 S_AD23 INTD INTA INTB INTC
Board Diagram
PCI Routing Tables
When PCI card and ISA card are inserted in PPCI1 and ISA1, those cards may conict with each other.

4 PCA-6119P7 Startup Manual
Locating Connectors & Jumpers
SPCI7SPCI5
SPCI6SPCI4
PPCI3
PPCI2
PPCI1
ISA1
ISA2
ISA3
ISA4
ISA5
ISA6
ISA7
ISA8
ISA9
ISA10
ISA11
ISA12
KB1KB3
CN2
BIG1
ATX3AT3
CN1
ATX1
AT2
ATX2 CN3
KB2

PCA-6119P7 Startup Manual 5
Board Dimensions
