Advantech PCIE-1730H Installation and operation manual

PCIE-1730H Startup Manual 1
Before installation, please make sure that you have re-
ceived the following:
• PCIE-1730H card
• Driver CD
• Quick Start User Manual
If anything is missing or damaged, contact your distributor
or sales representative immediately.
For more detailed information on this product, please refer to
the PCIE-1730H User Manual on the CD-ROM (PDF format)
FCC Class A
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in ac-
cordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this
equipment in a residential area is likely to cause interfer-
ence in which case the user is required to correct interfer-
ence at his own expense.
CE
This product has passed the CE test for environmental
specifications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact
your local supplier for ordering information.
PCIE-1730H 32-ch Isolated Digital I/O with
Digital Filter PCI Express Card
Startup Manual
The Advantech PCIE-1730H is a 32-channel, isolated digi-
tal input/output card for the PCI Express bus. The isolated
digital input/output channels feature high isolation protec-
tion which can save your system investment. In addition,
this card also offers 32-channel 5V/TTL compatible digital
input/output channels. The PCI Express interface makes
this card workable with latest computing platform.
Isolated Digital Input
• Input Channels: 16
• Input Voltage:
- Logic 0: 3 V max. (0 VDC min.)
- Logic 1: 10 V min. (30 VDC max.)
• Input Current:
- 12 VDC @ 3.18 mA
- 24 VDC @ 6.71 mA
• Interrupt Capable Channel: 16
• Digital Filter Channel: 16
• Isolation Protection: 2,500 VDC
• Overvoltage Protection: 70 VDC
• ESD Protection: 2,000 VDC
• Opto-Isolator Response: 50 μs
Isolated Digital Output
• Output Channels: 16
• Output Type: Sink (NPN)
• Isolation Protection: 2,500 VDC
• Output Voltage: 5 ~ 40 VDC
• Sink Current: 500 mA/channel (max.)
• Opto-isolator Response: 50 μs
Non-isolated Digital Input/Output
• Input Channels: 16 (support digital filter and interrupt
function)
• Input Voltage:
- Logic 0: 0.8 V max.
- Logic 1: 2 V min.
• Output Channels: 16
• Output Voltage:
- Logic 0: 0.5 V max. @ 24 mA (sink)
- Logic 1: 2.4 V min. @ -15 mA (source)
• Digital Filter for DI/ IDI:
Digital Filter Time[sec.] = 2n / (8 x 106) n: = setting
data(0 - 20)
OverviewPacking List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/products/ProView/
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCIE-1730H.
Part No. 2001173000
Print in China
1st Edition
April 2017
User Manual
Declaration of Conformity
Specications

2 PCIE-1730H Startup Manual
Specications (Cont.)
Setting
Data
(n)
Digital
Filter
Time
Setting
Data
(n)
Digital
Filter
Time
Setting
Data
(n)
Digital
Filter
Time
0 (00h)
The lter
function
is not
used.
7 (07h) 16
μsec 14 (0Eh) 2.048 msec
1 (01h) 0.25
μsec 8 (08h) 32 μsec 15 (0Fh) 4.096 msec
2 (02h) 0.5
μsec 9 (09h) 64 μsec 16 (10h) 8.192 msec
3 (03h) 1
μsec 10 (0Ah) 128 μsec 17 (11h) 16.384 msec
4 (04h) 2
μsec 11 (0Bh) 256 μsec 18 (12h) 32.768 msec
5 (05h) 4
μsec 12 (0Ch) 512 μsec 19 (13h) 65.536 msec
6 (06h) 8
μsec 13 (0Dh) 1.024 msec 20 (14h) 131.072 msec
General
• Bus Type: PCI Express V1.0
• I/O Connector Type” 37-pin D-Sub female
• Dimensions: 175 mm x 100 mm (6.9” x 3.9”)
• Power Consumption:
+3.3 V @ 280 mA, +12 V @ 330 mA (typical)
+3.3 V @ 420 mA, +12 V @ 400 mA (max)
• Operation Temperature: 0 ~ 60°C (32 ~ 140°F)
• Storage Temperature: -25 ~ 85°C (-4 ~ 185°F)
• Relative Humidity: 5 ~ 95% (non-condensing)
• Certification: CE certified
1. Turn off your computer and unplug the power cord and
cables. TURN OFF your computer before installing or
removing any components on the computer.
2. Remove the cover of your computer.
3. Remove the slot cover on the back panel of your
computer.
4. Touch the metal part on the surface of your computer
to neutralize the static electricity that might be on your
body.
5. Insert the PCIE-1730H card into a PCI Express slot.
Hold the card only by its edges and carefully align it
with the slot. Insert the card firmly into place. Use of
excessive force must be avoided; otherwise, the card
might be damaged.
6. Fasten the bracket of the PCI Express card on the back
panel rail of the computer with screws.
7. Connect appropriate accessories (37-pin cable, wiring
terminals, etc. if necessary) to the PCI Express card.
8. Replace the cover of your computer chassis. Re-
connect the cables you removed in step 2.
9. Plug in the power cord and turn on the computer.
Jumper JP2
Connection Function Description
JP2
(1, 2 short)
Output channels will keep last status after
system resets
JP2
(2,3 short)
Output channels will set their values to
Low after system resets (Default)
Hardware Installation
Pin Assignments
Switch and Jumper Settings

PCIE-1730H Startup Manual 3
Note: On: 1, Off: 0; Default setting: All Off
TL-level Digital Input/Output
The PCIE-1730H has 16 TTL-level digital inputs and 16
TTL-level digital outputs. The following figure shows con-
nections to exchange digital signals with other TTL devices:
If you want to receive an OPEN/SHORT signal from a switch
or relay, add a pull-up resistor to ensure that the input is
held at a high level when the contacts are open.
See the figure below:
Board ID Settings
Isolated Digital Input
Each of the 16 isolated digital input channels accepts
voltages from 10V to 30 V. Every eight input channels share
one external common. (Channels 0 ~ 7 use ECOM0. Chan-
nels 8 ~ 15 use ECOM1.) The following figure shows how
to connect an external input source to the card’s isolated
inputs.
Isolated Digital Output
If the external voltage source (5~40 V) is connected to
each isolated output channel (IDO) and its isolated digital
output turns on (500 mA max./ch), the card’s current
will sink from the external voltage source. CN5 provides
two EGND pins for IDO connection. The following figure
shows how to connect an external output load to the card’s
isolated outputs.
Connections
Connections (Cont.)
