MIC-75G20-10A2 Startup Manual 1
Before you begin installing your i-Module, please make sure
that the following items have been shipped:
1. MIC-75G20 i-Module x 1 P/N: MIC-75G20-
10A2
2. 4-Pin phoenix connector x 2 P/N: 1652003234
3. SATA cable (30 cm) x 1 P/N: 1700017838
4. SATA cable (40 cm) x 1 P/N: 1700020978-01
5. HDD BP power cable x 1 P/N: 1700024985-01
6. GPU power cable P/N: 1700023022-01
(6- to 6/8-pin) x 2
7. Mounting bracket (L) P/N: 1960005359T00A
8. Mounting bracket (R) P/N: 1960094392N013
9. Screw for mounting bracket x 6 P/N: 1930007259-01
10. MIC-75G20 Startup Manual x 1 P/N: 20415G2010
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
le. Acrobat Reader can be downloaded at: get.
adobe.com/reader (Acrobat is a trademark of
Adobe)
PCIe Slots
• One PCIe x16 socket
• One PCIe x4 socket
MIC-75G20-10A2
GPU Card Expansion i-Module for MIC-7 Series
Embedded System
Startup Manual
Environment
• Operating Temperature: -10 ~ 60 °C (35W CPU w/ indus-
trial wide-temp. RAM/SSD)
• Storage Temperature: -40 ~ 85 °C (-40 ~ 185 °F)
• Relative Humidity: 95% @ 40 °C (non-condensing)
Mechanical
• i-Module Dimensions: i-Module Dimension (W x H x D):
130 x 192 x 385 mm
• With MIC-7 series: With MIC-7 series (W x H x D): 207 x
192 x 385 mm
Note: Width will be increased by 4 mm with MIC-77xx.
Connectors
No. Item Function
1 DCIN1 24VDC in
2 PPCIE1 PCIe x16 slot
3 PPCIE2 PCIe x4 slot
4 SATAPWR1 4-pin SATA power connector (5V)
5SATA1 SATA signal connector
6 GPUPWR1 6-pin power connector for GPU card
(12V, 17A)
7 GPUPWR2 6-pin power connector for GPU card
(12V, 17A)
8 DC12VOOUT1 4-pin power connector (12V, 5A)
9 SYSFAN1 4-pin fan connector
10 SYSFAN2 4-pin fan connector (reserved)
11 LED GPU card power status
Specications(Cont.)Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
This manual is for the MIC-75G20-10 Rev. A1.
Part No. 20415G2010
Printed in China
1st Edition
November 2022
I/O Connectors
Specications

2 MIC-75G20-10A2 Startup Manual
System Installation
MIC-75G20 can be assembled with all MIC-7 series IPC
systems.
1. Undo MIC-7 series system screws and remove the
bottom cover.
2. Remove the 2 dust covers (IMPORTANT!).
3. Undo the 4 screws on MIC-75G20.
Simple Maintenance Process
Front View
4. Align MIC-75G20 and MIC-7 and secure 4 screws.
5. Assemble the MIC-75G20 cover and secure with 6
screws.
6. Reassemble the cover and secure with the screws.
SimpleMaintenanceProcess(Cont.)

MIC-75G20-10A2 Startup Manual 3
1. Undo the 5 screws on top of the GPU card bracket
module.
2. Remove the adapter bracket to make space for the
GPU card.
3. Release screw groups 1, 2, 3, and 4 for further GPU
card installation.
Memo: If the GPU card has two screw holes on the rear
side, please follow the assembly instruction. If not, please
skip steps 4 and 5.
4. Undo the screws in group 5 to remove the GPU rear
bracket.
5. Assemble the GPU rear bracket to the GPU with 2
screws and reassemble it to the chassis with the group
5 screws.
Memo: The GPU rear bracket can be adjusted to t di󰀨erent
heights of the GPU card by undoing the group 5 screws.
6. After the GPU card has been installed, secure 2 screws
to the bracket of the GPU.
7. Secure the GPU to the adjustable GPU card bracket
module with 5 screws.
8. Secure the GPU card by adjusting the GPU card
bracket module.
GPUCardBracketAssembly GPUCardBracketAssembly(Cont.)

4 MIC-75G20-10A2 Startup Manual
9. Release the group 1 screws to adjust bracket A to the
optimal position to attach the GPU card.
10. Release the group 2 screws to adjust bracket A to the
optimal height to secure the GPU Card.
11. Release group 3 screws to adjust bracket B to the
optimal position to clamp the GPU card.
12. Release group 4 screws to adjust the width of bracket B
to secure the front and back side of the GPU Card.
PowerSupplyCablingGuide
GPUCardBracketAssembly(Cont.)
It is recommended that you replace the fan lter regularly to
ensure the stability of system cooling.
1. Undo the system cover and remove the old fan lter.
2. Replace with the new fan lter and reassemble the system
cover with screws.
FanlterReplacement

MIC-75G20-10A2 Startup Manual 5
1. Type 1: Secure 1 mounting bracket (L)
(1960005359T00A) and 1 mounting bracket (R)
(1960094392N013) with 6 screws (1930007259-01)
2. Type 2: Secure 1 mounting bracket (L)
(1960005359T00A) and 1 mounting bracket (R)
(1960094392N013) with 6 screws (1930007259-01)
MountingBracketAssembly PowerSupplyCablingGuide(Cont.)
* Width is 207 mm with MIC-77xx installed.
System Dimensions
