Advantech EPC-R3430 User manual

User Manual
EPC-R3430
NXP ARM® Cortex®-A9 i.MX6
Dual 1GHz Fanless Box

EPC-R3430 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2020
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgements
ARM is a trademark of ARM Corporation
ROCKCHIP is a trademark of ROCKCHIP Corporation
All other product names or trademarks are properties of their respective owners
Product Warranty (2 years)
Advantech warrants to you, the original purchaser, that each of its products will be
free from defects in materials and workmanship for two years from the date of pur-
chase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation. Advantech assumes no
liability under the terms of this warranty as a consequence of such events.
Because of Advantech’s high quality-control standards and rigorous testing, most of
our customers never need to use our repair service. If an Advantech product is defec-
tive, it will be repaired or replaced at no charge during the warranty period. For out-
of-warranty repairs, you will be billed according to the cost of replacement materials,
service time and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Advantech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date
is not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.
Part No. 2006R34300 Edition 1
Printed in Taiwan January 2020

iii EPC-R3430 User Manual
Declaration of Conformity
FCC Class B
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful inter-
ference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be determined by turning the equip-
ment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Ordering Information
Packing List
Before installation, please ensure the following items have been shipped.
1 x EPC-R3430 BOX PC
2 x Wall Mount
1 x China RoHS
Part No. Description
EPC-R3430ID-PLA100 NXP i.MX6 Dual computer box with RS-485
EPC-R3430ID-PLA120 NXP i.MX6 Dual computer box with 2nd LAN
EPC-R3430ID-PLA140 NXP i.MX6 Dual computer box with CAN bus

EPC-R3430 User Manual iv
Optional Accessories
Part No. Description
96PSA-A36W12R1 ADP A/D 100-240V 36W 12V C6 DC PLUG 90°
1700001524 Power Cord 3P UL 10A 125 V 180 cm
170203180A Power Code 3P UK 2.5A/3A 250V 1.83cm
170203183C Power Code 3P Europe 183cm
1700019146 Power Cord CCC 3P 10A 250V 183cm
SQF-MSDM1-8G-21C SQF MICRO SD C10 MLC 8G (-25 ~ 85 °C)
EWM-W162M201E 802.11 ac/a/b/g/n Wi-Fi and BT4.2 M.2 card
1750007965-01 Wi-Fi cable, SMA (M) to MHF4, 50 cm
1750000318 2DBI 2.4 GHz SMA CONN
EWM-C106FT02E HSPA/WCDMA/GPRS Cellular module
1750006264 Antenna SMA(F)/MHF 15cm
SMALFN8-3150A-00X00R for a cellular module
Antenna L 10.9cm 50Ohm AN8921F-5701SM for 3G

v EPC-R3430 User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged
Liquid has penetrated into the equipment
The equipment has been exposed to moisture
The equipment does not work well, or you cannot get it to work according to
the user's manual
The equipment has been dropped and damaged
The equipment has obvious signs of breakage
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Safety Precaution – Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.

EPC-R3430 User Manual vi

vii EPC-R3430 User Manual
Contents
Chapter 1 General Introduction ...........................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications ............................................................................................ 2
1.2.1 Functional Specifications .............................................................. 2
1.2.2 Mechanical Specifications............................................................. 3
1.2.3 Electrical Specifications ................................................................ 3
1.3 Environmental Specifications .................................................................... 3
Chapter 2 H/W Installation....................................5
2.1 Introduction ............................................................................................... 6
2.2 EPC-R3430 IO Overview .......................................................................... 6
2.3 Connectors................................................................................................ 6
2.3.1 COM RS-232/422/485 .................................................................. 6
2.3.2 USB............................................................................................... 7
2.3.3 DC-IN ............................................................................................ 7
2.3.4 LAN ............................................................................................... 8
2.3.5 HDMI............................................................................................. 8
2.3.6 Micro SD and Nano SIM slot......................................................... 9
2.3.7 Antenna......................................................................................... 9
2.4 Quick Start of EPC-R3430 ...................................................................... 10
2.4.1 Debug Port Connection............................................................... 10
2.4.2 Debug Port Settings.................................................................... 10
Chapter 3 Software Functionality ......................11
3.1 Test Tools ............................................................................................... 12
3.1.1 USB Test..................................................................................... 12
3.1.2 LAN ............................................................................................. 12
3.1.3 3G Test (Telit HE910D) .............................................................. 12
3.1.4 M.2 module test (EWM-W162M201E) - WIFI / BT Function WIFI
.................................................................................................... 12
3.1.5 LVDS Test................................................................................... 13
3.1.6 Audio Test................................................................................... 13
3.1.7 RTC :........................................................................................... 13
3.1.8 RS-232/ RS-422/ RS-485 Port Test (For RSB-3430 COM port). 13
3.1.9 RS-485 Port Test (For UIO-4030 COM port) .............................. 14
3.1.10 GPIO Port define......................................................................... 15
3.1.11 RS-232 Port Test (For UIO-4032 COM port) .............................. 15
3.1.12 RS-232 Port Test (For UIO-4034 COM port) .............................. 15
3.1.13 CAN Bus Port Test (For UIO-4034 CAN port) ............................ 15
3.1.14 Watch Dog Test .......................................................................... 15
3.2 System Recovery .................................................................................... 16
Chapter 4 Advantech Services ..........................17
4.1 Contact Information................................................................................. 18
4.2 Global Service Policy .............................................................................. 18
4.2.1 Warranty Policy........................................................................... 18
4.2.2 Repair Process ........................................................................... 19

EPC-R3430 User Manual viii

Chapter 1
1General Introduction
This chapter gives background
information on the EPC-R3430
Sections include:
 Introduction
 Specifications

EPC-R3430 User Manual 2
1.1 Introduction
EPC-R3430 is an ARM-based Box Computer powered by Rockchip ARM Cortex-A17
RK3288 quad core high performance processor, which supports 4K display and
4Kx2K multi-format video decoding via HDMI. It features M.2, Mini-PCIe and SIM
card slots for WIFI, BT and 4G connectivity. EPC-R3430 also offers rich interfaces
such as 6 USB2.0, 6 UART, 1 GbE and 8 GPIO. It is an ideal solution for kiosk, vend-
ing machine and digital signage applications.
1.2 Specifications
1.2.1 Functional Specifications
Processor:
–ARM Cortex™-A9 high performance processor, Dual core 1 GHz
–Supports 2 IPU, OpenGL ES 2.0 for 3D BitBLT for 2D and OpenVG™ 1.1
–Video decoder: MPEG-4 ASP, H.264 HP, H.263, MPEG-2 MP, MJPEG BP
–Video encoder: MPEG-4 SP, H.264 BP, H.263, MJPEG BP
System Memory Support:
–DDR3 1066 MHz
–Capacity: on board DDR3 1 GB
Gigabit Ethernet:
–Chipset: NXP i.MX6 integrated RGMII
–1 x 10/100/1000 Mbps
Peripheral Interface:
–1 x HDMI, 1920 x 1080
–2 x USB Type A
–1 x Micro SD slot
–1 x 4-wire RS-232/485, 4 x 4-wire RS-232/422/485
–1 x mini PCIe Slot
–1 x M.2 Slot
–1 x Nano SIM Slot
–8 x GPIO, 1 x RS-485, 1 x RS-232
–1 x GbE, 2 x USB, 2 RS-232
OS Support: EPC-R3430 supports Android and Linux

3 EPC-R3430 User Manual
Chapter 1 General Introduction
1.2.2 Mechanical Specifications
Dimension: 174 x 108 x 25 mm
Reference Weight: 1.3kg (including whole package)
1.2.3 Electrical Specifications
Power supply type: DC-in 12V
RTC Battery:
–Typical voltage: 3V
–Normal discharge capacity: 210 mAh
1.3 Environmental Specifications
Operating Temperature: -20~60°C (-4~140°F)
Operating Humidity: 0% ~ 90% relative humidity, non-condensing
Storage Temperature: -40~85°C (-40~185°F)
Storage Humidity: 60°C @ 95% RH Non-condensing

EPC-R3430 User Manual 4

Chapter 2
2H/W Installation
This chapter gives mechanical
and connector information on the
EPC-R3430.
Sections include:
Jumper Information
Connector Information
Mechanical Drawing
Quick Start Guide

EPC-R3430 User Manual 6
2.1 Introduction
The following sections show the external connectors and pin assignments for appli-
cations.
2.2 EPC-R3430 IO Overview
2.3 Connectors
2.3.1 COM RS-232/422/485
EPC-R3430 supports 1 x RS-232/RS-422/RS-485. Pins are defined below:
COM Pin Define
Pin Description
1 N/C RS-422 TX- RS-485-
2 COM 2_RXD RS-422 TX+ RS-485+
3 COM2_TXD RS-422 RX+
4 N/C RS-422 RX-
5GND
6NC
7COM2_RTS
8COM2_CTS
9NC

7 EPC-R3430 User Manual
Chapter 2 H/W Installation
2.3.2 USB
EPC-R3430 supports 2 x USB2.0 type A connectors
USB 1/2
2.3.3 DC-IN
EPC-R3430 supports 12V DC in by DC-Jack
Pin Description
1 USB1 PWR
2 USB1 D-
3 USB1 D+
4 USB1 GND
5 USB2 PWR
6 USB2 D-
7 USB2 D+
8 USB2 GND

EPC-R3430 User Manual 8
2.3.4 LAN
2.3.5 HDMI
Pin Description
R1 100nF Capacitor to GND
R2 MDI0+
R3 MDI0-
R4 MDI1+
R5 MDI1-
R6 MDI2+
R7 MDI2-
R8 MDI3+
R9 MDI3-
R10 GND
L1 LAN1_100_LINK#
L2 LAN1_1000_LINK#
L3 Pull up to +3.3V
L4 LAN1_ACT
Pin Description Pin Description
1 HDMI _D2+ 11 GND
2 GND 12 HDMI _CLK-
3 HDMI _D2- 13 HDMI_CEC
4 HDMI_ D1+ 14 NC
5 GND 15 HDMI _CTRL_CLK
6 HDMI _D1- 16 HDMI _CTRL_DAT
7 HDMI _D0+ 17 GND
8GND 18+5V
9 HDMI _D0- 19 HDMI _HPD
10 HDMI_CLK+

9 EPC-R3430 User Manual
Chapter 2 H/W Installation
2.3.6 Micro SD and Nano SIM slot
2.3.7 Antenna
Here are a total of five reserved openings for antenna to support WiFi/3G/4G/GPS
modules.

EPC-R3430 User Manual 10
2.4 Quick Start of EPC-R3430
2.4.1 Debug Port Connection
1. Connect debug cable to EPC-R3430 debug port.
2. Connect the other side of debug cable to USB-to-RS232 cable then connect to
your PC.
2.4.2 Debug Port Settings
EPC-R3430 can communicate with a host server by using serial cables. Common
serial communication programs such as HyperTerminal, Tera Term or Putty can be
used in this case. The example below describes the serial terminal setup using
HyperTerminal on a Windows host:
1. Connect EPC-R3430 with your PC by using a serial cable
2. Open HyperTerminal on your Windows PC and select the settings as shown
below
3. After the boot loader is programmed on Micro SD card, insert power adapter
connector to DC jack on EPC-R3430 to power up the board. The boot loader
prompt is displayed on the terminal screen.
HyperTerminal Settings for Terminal Setup

Chapter 3
3Software Functionality
This chapter details the software
programs on the EPC-R3430 plat-
form.

EPC-R3430 User Manual 12
3.1 Test Tools
All test tools must be verified on the RSB-3430. Please prepare the required test fix-
tures before verifying each specified I/O. If you have any problems with testing,
please contact your Advantech contact window for help.
3.1.1 USB Test
Insert a USB disk
usb 1-1.2: new high-speed USB device number 4 using ci_hdrc
usb-storage 1-1.2:1.0: USB Mass Storage device detected
scsi2 : usb-storage 1-1.2:1.0
scsi 2:0:0:0: Direct-Access Generic- SD/MMC 1.00 PQ: 0 ANSI: 0 CCS
sd 2:0:0:0: [sda] 3862528 512-byte logical blocks: (1.97 GB/1.84 GiB)
sd 2:0:0:0: [sda] Write Protect is off
sd 2:0:0:0: [sda] No Caching mode page found
sd 2:0:0:0: [sda] Assuming drive cache: write through
sd 2:0:0:0: [sda] No Caching mode page found
sd 2:0:0:0: [sda] Assuming drive cache: write through
sda: sda1
sd 2:0:0:0: [sda] No Caching mode page found
sd 2:0:0:0: [sda] Assuming drive cache: write through
sd 2:0:0:0: [sda] Attached SCSI removable disk
3.1.2 LAN
*Use Different Domain
LAN - Front IO -eth0
ifconfig eth0 8.8.8.8
LAN - Rear IO -eth1
ifconfig eth1 8.8.8.8
3.1.3 3G Test (Telit HE910D)
pppd connect 'chat -v -s -t 10 "" "AT" "" "ATDT*99#" "CONNECT" ""' user username
password password /dev/ttyACM3 460800 nodetach crtscts debug usepeerdns
defaultroute &
3.1.4 M.2 module test (EWM-W162M201E) - WIFI / BT Function WIFI
$ ifconfig mlan0 up
$ wpa_passphrase ${SSID} ${WPA_KEY} > /tmp/wpa.conf
$ wpa_supplicant -BDwext -imlan0 -c/tmp/wpa.conf
$ udhcpc -b -i mlan0
