Advantech ITA-2211 Installation and operation manual

ITA-2211 Startup Manual 1
Before installing the board, please ensure that the following
items have been shipped:
1. 1 x ITA-2211 IPC
2. 1 x ITA-2211 Accessory Box
3. 1 x ITA-2211 Warranty Card
If any of the above items are missing or damaged, please
contact your distributor or sales representative immediately.
Note: Adobe Acrobat Reader is required to view PDF
files. Adobe Acrobat Reader can be downloaded at www.
adobe.com/Prodindex/acrobat/readstep2.html (Acrobat is a
trademark of Adobe).
ITA-2211 Intel® Atom™ E3845 Fanless 2U Rackmount
System with 3 ITAM Slots
Startup Manual
Standard Function
• Chip & Chipset: Intel Atom™ E3845 processor
• BIOS: AMI SPI 64 Mb
• Memory: Onboard DDR3 1600 up to 4GB
• Display:
Intel Gen 7, Frequency 543 MHz,
Share system memory up to 256 MB SDRAM
• Dual display mode:
Resolution of single display up to 2048 x 1536,
1 x VGA, 1 x DVI-I
• Storage:
- 1 x 3.5”HDD or 2 x 2.5”HDD
- 1 x Full Size mSATA
• Expansion slot:
- 3 x ITAM slot
- 1 x PC104+
- 1 x Mini PCIe slot
SystemSpecications
• Ethernet: 2 x 10/100/1000M Ethernet
• USB: 1 USB 3.0, 6 USB 2.0
• DVI: 1 x VGA, 1 x DVI-I
• Serial port: 2 DB9 ports, support RS-232/422/485
• Digital I/O: 1 x 8-ch TTL GPIO
• Audio: 1 Speaker Out (support 2x4W Amp),1 Mic-in
• ITAM module (optional): ITAM modules can be optional
inserted into three ITAM slots to make LAN or COM ports
up to 24 additional ports for expansion needs.
Mechanical and Environment
• Dimensions (W x H x D): 427 x 88 x 325 mm
• Voltage input: AC 100-240 or DC 110V
• Working temperature:
- 0 -40° C (32 ~ 104° F , with HDD)
- 25 - 60° C (-13 ~ 140° F, with SSD)
• Weight:
- Single Power: 7.7 kg
- Dual Power: 8 kg
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the ITA-2211 Series.
Part No. 2001221110
Printed in China
1st Edition
August 2015

2 ITA-2211 Startup Manual
Jumper/Connector Setting
The board has a number of jumpers and connectors that
allow you to configure your system to suit your application.
The table below lists the function of each of the jumpers
and connectors.
Name / Function
JCMOS1 Clear CMOS setting
PSON1 Power on mode setting
VCCGPIO1 GPIO voltage setting
VIO1 PC/104-Plus Connector VI/O
Voltage setting
COM 1~2 Serial ports
DVI-D DVI-Digital connector
VGA 1 VGA connector
USB 1 USB3.0 connector
USB 2~7 USB2.0 connector
DIO Digital I/O
Audio Audio in
JCMOS1: Clear CMOS Setting
Pins Setting
1-2 Default*
2-3 Clear CMOS setting
*Default setting
Default Clear CMOS
PSON1: Power On Mode Setting
Pins Setting
1-2 AT mode
2-3 ATX mode*
*Default setting
AT Mode ATX Mode
VCCGPIO1: GPIO Voltage Setting
Pins Setting
1-3 Normal(+V5_SB)*
2-4 +V3.3_SB
3-5 +V5
4-6 +V3.3
*Default setting
VIO1: PCI VIO Voltage Setting
Pins Setting
1-6 +3.3V
4-9 Normal(+5V)*
*Default setting
COM 1~2: Serial Ports
RS232 RS422 RS485
Pins Signal Name Signal Name Signal Name
1 DCD Tx- DATA-
2 RxD Tx+ DATA+
3 TxD Rx+ NC
4 DTR Rx- NC
5 GND GND GND
6 DSR NC NC
7 RTS NC NC
8 CTS NC NC
9 RI NC NC
Jumpers and Connectors

ITA-2211 Startup Manual 3
DVI-D
Pins Signal Name Pins Signal Name
1 T.M.D.S. Data2- 13 T.M.D.S. Data3+
2 T.M.D.S. Data2+ 14 +5V Power
3T.M.D.S. Data2/4
Shield 15 Ground (for +5V)
4 T.M.D.S. Data4- 16 Hot Plug Detect
5 T.M.D.S. Data4+ 17 T.M.D.S. Data0-
6 DDC Clock 18 T.M.D.S. Data0+
7 DDC Data 19 T.M.D.S. Data0/5
Shield
8 No Connect 20 T.M.D.S. Data5-
9 T.M.D.S. Data1- 21 T.M.D.S. Data5+
10 T.M.D.S. Data1+ 22 T.M.D.S. Clock
Shield
11 T.M.D.S. Data1/3
Shield 23 T.M.D.S. Clock+
12 T.M.D.S. Data3- 24 T.M.D.S. Clock-
VGA 1: VGA
Pins Signal Name Pins Signal Name
1 Red(Red) 9 +5V
2 Green(Green) 10 GND
3 Blue(Blue) 11 NC
4 NC 12 DDC-DATA
5 GND 13 H-SYNC
6 GND 14 V-SYNC
7 GND 15 DDC-CLK
8 GND
Jumpers and Connectors (Cont.)
USB 1: USB3.0 A Type
Pins Signal Name Pins Signal Name
1 VBUS 6 StdA_SSRX+
2 D- 7 GND_DRAIN
3 D+ 8 StdA_SSTX-
4 GND 9 StdA_SSTX+
5 StdA_SSRX-
USB 2~7: USB2.0
Pins Setting
1 +V5(VCC)
2 USB DATA-
3 USB DATA+
4 GND
DIO: Digit Connector
Pins Signal Name Pins Signal Name
1 GPIO0 6 GPIO4
2 GPIO1 7 GPIO5
3 GPIO2 8 GPIO6
4 GPIO3 9 GPIO7
5 GND
Audio: Audio In
Pins Signal Name Pins Signal Name
1 AUD_GND 6 LOUT_L
2 MIC1_L 7 LOUT_JD
3 MIC_JD 8 AUD_GND
4 AUD_GND 9 LOUT_R
5 MIC_R

4 ITA-2211 Startup Manual
PowerConnectorDenition
The IPC has a 3-channel Terminal Block power input con-
nector which provides AC 100~240V or 110V DC voltage to
the board. The definition is as below:
Phoenix Connector DC-in:
Pin Definition:
Pin1 GND
Pin2 N
Pin3 L
AC/DC Power Input Connector
EthernetLEDDenition
The system has 2 RJ45 connectors with LEDs showing
network status.
LAN1~LAN2:
LED Status:
1000M Green (top left LED)
100M Orange (top left LED)
10M No lights
Connection Green flickering (top right LED)
RJ45 Connector
IndicatorLEDColorDenition
The system has 3 indicator LEDs at bottom left，with LEDs
showing network status.
LED Color Status
Storage device LED Orange
Power LED Green
Warning LED Red
The system has 3 indicator LEDs at right ahead，with LEDs
showing network status.
LED Color Status
Storage device LED Orange
Power LED Green
Warning LED Red
COMLEDDenition
The system has 2 COM connectors with LEDs showing
network status.
COM1~2:
LED Status:
TX Active Green
TX No Data No light
RX Active Orange
RX No Data No light
1. Open ITA-2211 system chassis cover.
2. Following Pic shown below to insert ITAM Module.
a. Then fix the module front part into c hassis front panel.
b. Check whether the interface of ITAM Module is paral-
lel with ITAM slot on the backplane.
c. Check whether the rivet of the module is fully inserted
in.
3. Fix ITAM Module upon ITA-2211 system with screws in
front and rear both side.
Jumpers and Connectors (Cont.) Safety Precaution - Static Electricity
ITAM Installation Instructions

ITA-2211 Startup Manual 5
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from
harm and the products from damage.
1. To avoid electrical shock, always disconnect the power
from the PC chassis before working on the device.
2. Disconnect the power before adjusting the configu-
ration. A sudden rush of power when connecting a
jumper or installing a card can damage sensitive
electronic components.
3. Always disconnect the power cord from the chassis
when making adjustments. Do not connect when the
power is on. A sudden rush of power can damage
sensitive electronic components. Only experienced
electronics personnel should open the chassis. Always
ground yourself to remove any static electric charge
before touching the motherboard, backplane, or add-
on cards. Modern electronic devices are very sensitive
to static electric charges. Use a grounding wrist strap
at all times. Place all electronic components on a
static-dissipative surface or in a static shielded bag.
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this startup manual for future reference.
3. Disconnect the equipment from all AC outlets before
cleaning. Do not use liquid or spray detergents for
cleaning.
4. For pluggable equipment, the power outlet must be
located near the equipment and easily accessible.
5. Protect the equipment from humidity.
6. Position the equipment on a reliable surface during
installation. Dropping or letting the equipment fall can
cause damage.
7. Ensure the power supply voltage is correct before con-
necting the equipment to a power outlet.
8. Position the power cord away from high-traffic areas.
Do not place anything over the power cord.
9. All cautions and warnings on the equipment should
be noted.
10. If unused for a long time, disconnect the equipment
from the power source to avoid damage from transient
overvoltages.
11. Never pour liquid into the equiptment openings. This
can cause fire or electrical shock.
12. Never open the equipment. For safety reasons, the
equipment should only be opened by qualified service
personnel.
13. If any of the following occurrs, have the equipment
checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated into the equipment.
• The equipment has been exposed to moisture.
• The equipment is malfunctioning, or does not oper-
ate according to the user manual.
• The equipment has been dropped or damaged.
• The equipment shows obvious signs of breakage.
14. Do not leave this equipment in an environment with a
storage temperature of below -25 °C (-13 °F) or above
60 °C (140 °F). This may damage the equipment. The
equipment should be kept in a controlled environment.
15. There is a danger of explosion if the battery is incor-
rectly replaced. Replace only with the same or equiva-
lent type recommended by the manufacturer, and
discard used batteries according to the manufacturer’s
instrcuctions.
16. This equipment has been tested and found to comply
with the requirements for a Class A digital device. Op-
eration of this equipment in a residential area is likely
to cause harmful interference to radio communica-
tions; in such events, users are required to correct this
interference.
17. This equipment is sold without a power cord. Users are
advised to purchase a CCC-certified power cord.
The sound pressure level at the operator’s position does
not exceed 70 dB (A) as per the IEC 704-1:1982 specifica-
tions.
DISCLAIMER: These instructions are provided according to
the IEC 704-1 standard. Advantech assumes no responsi-
bility for the accuracy of this manual.

6 ITA-2211 Startup Manual
Board Jumper Setting Drawing
Mainboard Jumpers and Connectors Location
Backplane Jumpers and Connectors Location
SATA2 SATA1
SATA_PWR1 SATA_PWR2
LPT1
MSATA1
SODIMM1
VCCGPIO1
PSON1
JCMOS1
MINIPCIE1
VIO1
PC104_ISA
PC104_PCI
ITAM Slot1
ITAM Slot2
ITAM Slot3

ITA-2211 Startup Manual 7
Rear I/O View
PS2 DVI D
Serial Port x 2 VGA
USB2.0 x 4
USB3.0 x 1
RJ45 x 2 Power Module
Front I/O View
USBReset Button
Power Button
HDD LED
Alert LED
LAN LED
COM LED
System Diagram
IT AM
DVI D SL OT 2SL OT 3 SL OT 1
