AEG A18HPI User manual

A18HPI
Original instructions

2
2
Important!
It is essential that you read the instructions in this manual before
assembling, operating and maintaining the product.
Subject to technical modifications.

33
8
9
5
6
7
11
10
3
4
2
1
BAR
1. Nozzle holder
2. High pressure hose
3. Hose holder
4. Battery port
5. Tapered raft nozzle
6. Presta valve adapter
7. Sports ball needle
8. Digital display
9. Control dial
10. Trigger
11. Handle

4
4
5
14
6
10
8

55
1. 2.

6
6
1. 2.
1. 2.

77
78-100 %
33-54 %
55-77 %
10-32 %
<10 %

8
8
BAR
PSI
A
1.
2.
3. 4. 4.
A B
1 sec
3 sec
BAR
18.8
M A N U A L S E TA UT O
B A R P S I

99
B
3.
2.
4. 4.
A B
BAR
1.
2 sec
AUTO
BAR
PSI
1.
2.
3 sec
BA R

10
10
1
3
2
4
Manual
BAR
Start
BA R
BA R
Risk of Bursting.

11 11
Auto
1 2
5 6Stop
BA R B AR
BA R
Risk of Bursting.

12
12
3
65
4
Auto Stop
Start
BA R
BAR
BAR
Risk of Bursting.

13 13
BAR
KPA
PSI
60 sec AUTO-OFF
BAR
BAR BAR
Risk of Bursting.

14
14
Remove the battery pack before starting any work on the product.

15 15
BATTERY AND CHARGER
Compatible battery pack
(not included)
Compatible charger
(not included)
L1820R
L1820S
L1825R
L1830R-X5
L1840R
L1850R
L1860R-X5
L1890R
AL18G
BL1218
BLK1218
BL18DPS
BL18S
Use AEG 18V battery and charger only
WARNING!
Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow
all instructions listed below may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for future reference.
INFLATOR SAFETY WARNINGS
Risk of bursting. Do not preset the product resulting in its output
pressure to be greater than the marked maximum pressure of the
item to be inflated. Do not use at pressure greater than 150 PSI (10.3
bars).
Make sure the hose is free of obstructions or snags. Entangled
or snarled hoses can cause loss of balance or footing and may be
damaged.
Never leave the product unattended with the hose still connected and
operating.
Never leave the product unattended with the nozzle attached to the
item being inflated.
To reduce the risk of electrical shock, do not put the product in water
or other liquid. Do not place or store an appliance where it can fall or
be pulled into a tub or sink.
Do not continue to use the product or nozzle which leaks air or does
not function properly.
Do not attempt to pull or carry the product by the hose.
Store indoors.
Always disconnect the air and power supply before making
adjustments and servicing, or when not in use.
Inspect yearly for cracks, pin holes or other imperfections which could
cause the product to become unsafe. Never cut or drill holes in the
product.
Know your inflator. Read operator’s manual carefully. Learn its
applications and limitations, as well as the specific potential hazards
related to this tool. Following this rule will reduce the risk of electric
shock, fire, or serious injury.
To reduce the risk of electric shock, do not expose the product to
rain. Store indoors.
Never cut or drill holes in the product.
Use the product only for its intended use. Do not alter or modify the
TECHNICAL DATA HIGH PRESSURE INFLATOR A18HPI
Rated voltage 18 V
High pressure flow rate
@ 90psi 14 L/min
@ 35psi 23 L/min
Maximum pressure 150 PSI, 10.3 BAR
Pressure hose length 51 cm
Weight - not including battery pack 1.05 kg
Measured values determined according to EN 62841.
A-weighted sound pressure level L
pA
= 89.0 dB(A)
Uncertainty K 3 dB(A)
A-weighted sound power level LWA = 100.0 dB(A)
Uncertainty K 3 dB(A)
Wear ear protectors.
The vibration total values (triaxial vector sum) determined according to EN 62841:
Vibration emission value Ah= 4.0 m/s2
Uncertainty K 1.5 m/s2
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 62841 and
may be used to compare one tool with another. It may be used for a preliminary assessment of exposure. The declared vibration emission level
represents the main applications of the tool. However if the tool is used for dierent applications, with dierent accessories or poorly maintained,
the vibration emission may dier. This may significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running but
not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep the
hands warm, organisation of work patterns.

16
16
product from the original design or function.
Do not attempt to modify this product or create accessories or
attachments not recommended for use with the product. Any such
alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
Always be aware that misuse and improper handling of the product
can cause injury to yourself and others.
Household use only.
Do not use the product as a breathing device.
Never direct a jet of compressed air toward people or animals. Take
care not to blow dust and dirt towards yourself or others. Following
this rule will reduce the risk of serious injury.
Protect your lungs. Wear a face or dust mask if the operation is dusty.
Following this rule will reduce the risk of serious personal injury.
Do not use the product to spray chemicals. Your lungs can be
damaged by inhaling toxic fumes.
Risk of bursting. Carefully monitor objects during inflation to reduce
the risk of over inflation. Use a reliable pressure gauge periodically
during inflation.
To reduce the risk of over inflation, use a reliable pressure gauge
periodically during inflation. The pressure gauge on the inflator is for
reference only and is therefore not binding for exact values.
Allow the product to cool for ten (10) minutes after every ten (10)
minutes of continuous use. Never block the inflating or deflating
outlets while operating.
Remove the battery pack before starting any work on the product.
Do not dispose of used battery packs in the household refuse or
by burning them. AEG Distributors oer to retrieve old batteries to
protect our environment.
Do not store the battery pack together with metal objects (short
circuit risk).
Use only System AEG chargers for charging System AEG battery
packs. Do not use battery packs from other systems.
Battery acid may leak from damaged batteries under extreme
load or extreme temperatures. In case of contact with battery
acid wash it o immediately with soap and water. In case of eye
contact rinse thoroughly for at least 10 minutes and immediately seek
medical attention.
Ambient temperature range for tool during operation is between 0°C
and 40°C.
Ambient temperature range for tool storage is between 0°C and 40°C.
The recommended ambient temperature range for the charging
system during charging is between 10°C and 38°C.
SPECIFIED CONDITIONS OF USE
The inflator may be used for the following applications.
■Inflating high pressure items like motorbike/car/bicycle tyres and
sport equipment.
■Inflating low pressure items like air mattresses, pool inflatables
and rafts.
Do not use the product for any other purpose.
BATTERIES
Battery packs which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance of
the battery pack. Avoid extended exposure to heat or sunshine (risk
of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged,
after used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery pack storage longer than 30 days:
• Store the battery pack where the temperature is below 27°C and
away from moisture.
• Store the battery packs in a 30% - 50% charged condition.
• Every six months of storage, charge the pack as normal.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING! To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them. Corrosive or
conductive fluids, such as seawater, certain industrial chemicals, and
bleach or bleach containing products, etc., can cause a short circuit.
Ambient temperature range for battery during use is between 0°C
and 40°C.
Ambient temperature range for battery storage is between 0°C and
27°C.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
■The user can transport the batteries by road without further
requirements.
■Commercial transport of lithium-ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
■Ensure that battery contact terminals are protected and insulated
to prevent short circuit.
■Ensure that battery pack is secured against movement within
packaging.
■Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
BATTERY PACK PROTECTION
The battery pack has overload protection that protects it from being
overloaded and helps to ensure long life. Under extreme stress the
battery electronics switch o the product automatically. To restart,
switch the product o and then on again. If the product does not start
up again, the battery pack may have discharged completely. In this
case it must be recharged in the battery charger.
THERMAL OVERLOAD PROTECTION
Overheated cells will reduce performance, run time and life.
Overheating can occur from battery packs being exposed to very hot
environments or from the tool they are powering being over-worked.

17 17
The control electronics will automatically shut down the battery pack
to protect the cells which in turn protects the electronics and motor
within the tool. The battery pack will automatically shut itself down
again should the temperature condition remain high when the trigger
is pulled again. The system will continue to shut the battery pack
down until the temperature is returned to a safe operating level.
CURRENT OVERLOAD PROTECTION
The control electronics will instantly shut down the battery back when
excessive current draw is detected - protecting both the battery cells
and the motor of the tool. Releasing the trigger will reset the battery
pack each time.
INDIVIDUAL CELL MONITORING
The control electronics constantly check each individual cell
and automatically adjust its charge and discharge requirements
accordingly.
This system maximises individual cell life whilst ensuring that the
battery pack is delivering peak performance to the tool at all times.
MAINTENANCE
The ventilation slots of the product must be kept clear at all times.
Use only AEG accessories and AEG spare parts. Should components
need to be replaced which have not been described, please contact
one of our AEG service agents (see our list of guarantee/service
addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the product type printed on the label and
order the drawing at your local service agents or directly at:
Techtronic Industries Australia Pty Ltd
PO Box 1065
Mount Waverley VIC 3149
Tel. no. 1300 234 797
Australia
Techtronic Industries N.Z. Limited
PO Box 12-806
Penrose AUCKLAND 1642
Tel. no. 0800 234 797(0800 AEGPWR)
New Zealand
SYMBOLS
Safety alert
VVolts
Direct current
Indoor use only
Regulatory Compliance Mark (RCM). Product meets
applicable regulatory requirements.
Please read the instructions carefully before starting
the product.
Wear ear protectors.
Always wear goggles when using the machine.
Risk of injury. Explosive material.
For indoor use only
Do not dispose of electric tools together with
household waste material. Electric tools and
electronic equipment that have reached the end of
their life must be collected separately and returned
to an environmentally compatible recycling facility.

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
www.aegpowertools.com.au
www.aegpowertools.co.nz
AEG is a registered trade mark used under
license from AB Electrolux (publ).
© 2021 Techtronic Cordless GP.
