AEG BHO18B User manual

BHO18B
Original instructions

2
2
Important!
It is essential that you read the instructions in this manual before assembling, operating and
maintaining the product.
Subject to technical modifications.

33
1. Handle, insulated gripping surface
2. Lock-off button
3. Trigger
4. Dust port
5. Depth adjustment knob
6. Depth scale
7. Hex key
8. Aux fence knob
9. Side fence
10. Battery port
11. Dust flow direction knob
12. V-shape notch
13. Blade
14. Kickstand
