AEMC OX 5022B User manual

WITH AEMC
®
INSTRUMENTS
PORTABLE OSCILLOSCOPES
ENGLISH
Handscope Harmonic Analyzer
Oscilloscope
Model OX 5022B
Quick Start Guide

Copyright©Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments. All rights reserved.
No part of this documentation may be reproduced in any form or by any means (including electronic
storage and retrieval or translation into any other language) without prior agreement and written consent
from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive • Dover, NH 03820 USA
Tel: [phone] or [phone] • Fax: [phone]
This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise.
Chauvin Arnoux®, Inc. has made every reasonable e󰀨ort to ensure that this documentation is accurate;
but does not warrant the accuracy or completeness of the text, graphics, or other information contained
in this documentation. Chauvin Arnoux®, Inc. shall not be liable for any damages, special, indirect,
incidental, or inconsequential; including (but not limited to) physical, emotional or monetary damages
due to lost revenues or lost prots that may result from the use of this documentation, whether or not the
user of the documentation has been advised of the possibility of such damages.

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
certies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met the instrument’s published
specications.
An NIST traceable certicate may be requested
at the time of purchase, or obtained by returning
the instrument to our repair and calibration
facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair and
calibration section at www.aemc.com/calibration.
Serial #:
Catalog #: 2150.20
Model #: OX 5022B
Please ll in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.aemc.com

PRODUCT PACKAGING (2150.20)
Handscope Oscilloscope
Model OX 5022B
Cat. #2150.20
(1) USB Cable + Driver
Cat. #2135.41
(1) Probe 10:1 600 V
BNC-M
Cat. #5000.50
(1) US Wall Plug,
Adapter 5 V
Cat. #2153.78
(1) USB Drive
SX-METRO Software
&
OX 5022B / OX 5042B
User Manual
(2) Adapter Banana-F
BNC-M
Cat. #2118.46
(2) Sets of two color-coded leads
and clips (5 ft)
(Note: Color of replacement leads
are solid red & solid black)
Metrix Carrying
Pouch
(2) Red Test Probe
Cat. #5000.98
(2) Black Test Probe
Cat. #5000.97
OX 5022B / OX 5042B
Cable - Replacement USB
Charging Cable
Cat . #5100.17
Also Included:
(1) Test Report
(1) European 220 V Wall Plug
(1) Battery Information Sheet
(6) 1.2 V NiMH rechargeable batteries 2700 mA·h

Handscope Harmonic Analyzer Oscilloscope Model OX 5022B 5
Thank you for purchasing an AEMC®Instruments Portable Oscilloscope
Model OX 5022B.
For the best results from your instrument and for your safety, you must
read the enclosed operating instructions carefully and comply with the
precautions for use. Only qualied and trained operators should use this
product.
Symbols and Denitions
Signies that the instrument is protected by double or reinforced insulation
CAUTION - Risk of Danger! Indicates a WARNING. Whenever this symbol
is present, the operator must refer to the user manual before operation
Indicates a risk of electric shock. The voltage at the parts marked with this
symbol may be dangerous
Indicates important information to acknowledge
This product complies with the Low Voltage & Electromagnetic Compatibility
European directives (73/23/CEE & 89/336/CEE)
Ground/Earth
The product has been declared recyclable
The UKCA marking certies that the product is compliant with the
requirements that apply in the United Kingdom, specically regarding
Low-Voltage Safety, Electromagnetic Compatibility, and the Restriction of
Hazardous Substances
In the European Union, this product is subject to a separate collection
system for recycling electrical and electronic components in accordance with
directive WEEE 2002/96/EC
Denition of Measurement Categories (CAT)
CAT IV: Corresponds to measurements performed at the primary electrical
supply (< 1000 V).
Example: primary overcurrent protection devices, ripple control units,
and meters.
CAT III: Corresponds to measurements performed in the building installation
at the distribution level.
Example: hardwired equipment in xed installation and circuit
breakers.
CAT II: Corresponds to measurements performed on circuits directly
connected to the electrical distribution system.
Example: measurements on household appliances and portable tools.

6 Handscope Harmonic Analyzer Oscilloscope Model OX 5022B
Precautions For Use
The operator and/or the responsible authority must carefully read and
completely understand the precautions before use. If you use this instrument
in an unspecied manner, the protection it ensures can be compromised, thus
putting you in danger.
■This instrument is designed for use:
indoors
in a level 2 pollution environment
at an altitude below 2000 m
at a temperature between 0 °C and 40 °C
with a relative humidity of less than 80 % up to 35 °C
■The safety of all systems, including the instrument, is the responsibility of the
operator.
■It can be used for measurements on 600 V CAT III circuits, relative to the
ground/earth.
■Before each use, check the condition of the insulation on the cables, boxes,
sensors and accessories. Any element on which the insulation is damaged
(even partially) must be taken out of service for repair or disposal.
■Respect the environmental and storage conditions.
■The external power supply must be connected to the instrument and to the
network (98 to 264) VAC.
■The power supply to the instrument is tted with an automatically resettable
electrical protection after disappearance of the fault.
■As a safety measure, only use factory supplied parts and accessories.
■It is advised to use individual safety protection whenever the environmental
situation in which the instrument is used requires protection.
■When handling the sensors or test probes, do not place your ngers beyond
the physical guard.
■If the battery housing cover is absent, damaged or incorrectly positioned, the
instrument must not be used other than to adjust the sensors.

Handscope Harmonic Analyzer Oscilloscope Model OX 5022B 7
Power Supply
The oscilloscope is supplied with one external power supply and set of
(6) 1.2 V NiMH rechargeable batteries 2700 mA·h.
When the supplied wall plug is connected from the instrument to an external
power source, battery power is not needed. The batteries are only used when
there is no external power supply available.
Before the rst use, start by fully charging the battery.
NOTE: The batteries automatically begin charging when the
Oscilloscope is powered o󰀨, but connected to an external power supply.
When the batteries are charging, the Battery Charge LED on the front panel will
turn on steady.
The LED will blink in the following situations:
pre-charge of very low batteries
temperature is too low or too high
batteries are damaged
When the charge is complete, the LED will turn o󰀨.
If the batteries need to be replaced, they must be replaced with NiMH
rechargeable batteries. Battery charge life is guaranteed for same-capacity
batteries (in mA·h) as those shipped with the oscilloscope.
To remove the battery cover, use a coin to turn the slot on the back of the unit
counter-clockwise.
Description
The Handscope Oscilloscope Model OX 5022B combines three instruments into
one:
20 MHz oscilloscope
Independent 8000 ct multimeter with power measurements
Built-in harmonic analyzer out to the 31st harmonic (fundamental between
20 Hz and 450 Hz)
The instrument operates at a constant acquisition depth of 2500 points.
An LCD TFT screen is used to view the applied signals along with all the setting
parameters.
The main command functions are accessible using the buttons on the front
panel.
A graphic interface is used to:
adjust the parameters related to the selected button
navigate using a horizontal main menu showing the current settings and
vertical sub-menus

8 Handscope Harmonic Analyzer Oscilloscope Model OX 5022B
Channel Isolation
The two oscilloscope input channels are isolated from each other and from
the ground/earth and the main power supply block. This isolation is provided
by double or reinforced insulation, in compliance with the safety standards
IEC 61010-1 and IEC 61010-2-030.
This makes it possible to make measurements on installations or systems
connected to the electricity supply network for voltages of up to 600 V in
CAT III. The common mode authorized between the two channels is
600 V in CAT III. Thus the operator, the test systems and the environment
are completely protected at all times.
Any voltage (even dangerous) on one channel will not be present on the other
channel. The low points of the inputs are completely insulated, so there is
no possibility of the low points looping (which can be dangerous and highly
destructive).
NOTE: The use of accessories with a voltage and/or category lower
than 600 V CAT III reduces the operating range to the lower voltages
and/or categories.
The oscilloscope is rated 600 V CAT III; at least 600 V CAT III
accessories must be used.
Measurement Terminals
Input
Channel A
External
power
supply
Input
Channel B

Handscope Harmonic Analyzer Oscilloscope Model OX 5022B 9
Control Features
Item Button Description
1
OPERATING MODE BUTTONS
Press these buttons to select the desired operating mode:
■Oscilloscope
■Multimeter
■Harmonic analyzer
2
NAVIGATION BUTTONS
Use these navigation buttons to the menus and dialog boxes:
VERTICAL
■Vertical movement and automatic selection in the secondary
menus
■Adjustment of values in the main menus
■Vertical movement in a dialog box
HORIZONTAL
■Horizontal movement through the main menus
■Adjustment of values in the secondary menus
■Horizontal movement in a dialog box
ENTER
■Opens a dialog box from a main menu or a secondary menu
■Validation of the items in a dialog box
1
2
3
4
5
6
7
8
9
10

10 Handscope Harmonic Analyzer Oscilloscope Model OX 5022B
Item Button Description
3
CHANNEL A, B
■A single press selects channel A (or B) and shows the
corresponding menu
■Pressing twice deselects the channel
MATH/MEMORY BUTTONS
■A single press selects channel M (Math) and shows the
corresponding menu
■Pressing twice deselects the channel
NOTE: For the M (memory) channel, pressing twice invalidates
the channel. Pressing once again selects the Math channel, the
memory is lost and must be reloaded.
4
ON/OFF BUTTON
■The instrument is turned ON by a short press on this button. It is
turned OFF by a long press (a message about the shutdown will
appear and a beep will sound).
5
FUNCTION BUTTONS
Auto Set: Performs an automatic adjustment on channels A and B.
The success of each vertical autoset conditions the
activation of the channel.
Run Hold: Starts or stops an acquisition.
6CHARGE STATUS
■Battery Charge LED
7OPTICAL COMMUNICATOR
■Provides the communication between the oscilloscope and a PC
8
TIME BASE BUTTONS
■Increases the time base for acquisition up to 200 s
■Decreases the time base for acquisition down to 25 ns
9
SENSITIVITY BUTTONS
■Decreases the vertical sensitivity of the last selected channel
down to 5 mV
■Increases the vertical sensitivity of the last selected channel up to 200 V
NOTE: For the M channel, the “sensitivity” buttons vary the
amplitude factor but only if a math channel is validated.
10
MENU BUTTONS
■Displays the main Trigger menu
■Displays the main Tools menu
■Displays the main Acquisition menu
■Displays the main Memory menu
■Displays the main Measurement/Cursor menu
■Displays the Help window
