AFRISO ACU 2030 User manual

Issue 6: 20/11/2018
1 of 8
If In Doubt ASK !
[phone]
[email protected]
ACU 2030
Alarm Control
Unit
About this User Guide
This guide is part of the device installation.
Read this guide before using the device.
Keep this guide during the entire service life of the device and
always have it readily available for reference.
Always hand this guide over to future owners or users of the
device.
Contents
2 Warning terms
General installation and wiring requirements
General troubleshooting
3 General safety
General handling and storage
4 Staff qualification
Modification
Warranty
Spare parts
Recycling
Limit of liability
Copyright
Customer satisfaction
Contact Afriso Eurogauge
5 Application
Mechanical installation
Electrical installation
6 Electrical wiring diagram
Commissioning
7 Specification
8 Declaration of conformity
Declaration of origin
+Read guide before use!
+Observe all safety information!
+Keep guide for future use!
User Guide
ACU 2030

Issue 6: 20/11/2018
2 of 8
WARNING TERMS
The type and source of danger associated with this device is shown here.
Precautions to take in order to avoid the danger are shown here.
There are three different levels of warning:
DANGER Imminent danger!
Failure to observe the information will result in death or serious injuries.
WARNING Possible imminent danger!
Failure to observe the information may result in death or serious injuries.
CAUTION Dangerous situation!
Failure to observe the information may result in minor or serious injuries and
damage to property or device not working as expected.
General Installation and Wiring requirements
The device must be installed in accordance with the details given later in this guide.
All wiring must be in suitable cable for the application conditions and must comply with the relevant
regulations of the electrical supply authority concerned, together with any other statutory requirements
which may affect the complete installation.
It is recommended that cable with polyethylene or PVC insulation with a conductor size of at least
1.0mm2 is used.
CAUTION ATEX installations may only be carried out by qualified and trained personnel in accordance
with ATEX specific requirements.
MICC cable (Pyro) must never be used under any circumstances
Signal cables should be run separately from any cables carrying mains voltages.
If signal cables are to be run through areas of high electrical interference it is recommended that
screened cable is used with the screens being terminated only to the device earth terminal or as
specified.
Specific terminal connection information may be found on identification label(s) on the device unless
otherwise advised..
Refer to separately supplied installation guides for information regarding external components of the
system such as level sensors, sounders and beacons etc.
CAUTION Electrical systems may be impacted and the device switching contact (if fitted) may be destroyed by
voltage peaks when inductive loads are switched off.
Use commercially available standard RC combinations such as 0.1µF/100� for inductive load switching.
Troubleshooting
Repairs and fault finding may only be performed by Afriso Eurogauge personnel or qualified personnel
under Afriso Eurogauge instruction.
Refer to separately supplied installation guides for information regarding fault finding and repairs on
external components.
User Guide
ACU 2030

Issue 6: 20/11/2018
3 of 8
Safety
Intended use
The alarm switch device may only be used for continuous alarm monitoring in containers, silos and
tanks etc. for the storage of the following media, provided such media can be detected with suitable
alarm sensors and switches.
Liquids
Granulated materials
Powdered materials
Any use other than the application explicitly permitted in this guide or authorised by Afriso Eurogauge
is not permitted.
Predictable incorrect application
The device must never be used in the following cases:
Hazardous area (ATEX)
If the device is operated in hazardous areas, sparks may cause deflagrations, fires or
explosions.
Safe handling
This product represents state-of-the-art technology and is made according to the pertinent safety
regulations. Each device is subjected to a function and safety test prior to shipping.
Operate the device only when it is in perfect condition. Always observe the operating
instructions, all pertinent local and national directives and guidelines as well as the
applicable safety regulations and directives concerning the prevention of accidents.
WARNING Severe burns or death caused by mains voltage (110/230 VAC, 50/60Hz) in the device
Do not expose the control unit to water.
Interrupt the mains voltage supply before opening the device or before performing maintenance
and cleaning work and make sure it cannot be switched on by accident.
Do not tamper with or modify the device in any way whatsoever.
Transport and storage
CAUTION Damage to the device due to improper transport.
Do not throw or drop the device.
Protect from wetness, humidity, dirt and dust.
CAUTION Damage to the device due to improper storage.
Protect from wetness, humidity, dirt and dust.
Store the device in a clean and dry environment.
Only store the device within the permissible temperature range.
User Guide
ACU 2030

Issue 6: 20/11/2018
4 of 8
Staff Qualification
The device may only be mounted, commissioned, operated, maintained, shut down and disposed of by trained staff.
Electrical work may only be performed by trained electricians and in compliance with all applicable local and national
directives.
Modifications to the device
Changes or modifications made to the device by unauthorised persons may lead to malfunctions and are prohibited for
safety reasons unless specifically instructed by the manufacturer.
Use of spare parts and accessories
Use of unsuitable spare parts and accessories may cause damage to the device. Use only genuine manufacturer spare
parts and accessories.
Liability information
The manufacturer shall not be liable in any form whatsoever for direct or consequential damage resulting from failure to
observe the technical instructions, guidelines and recommendations given in this guide or ancillary documents.
The manufacturer or sales agent shall not be liable for costs or damages incurred by the user or by third parties in the
usage or application of this panel, in particular in case of improper use of the device, misuse or malfunction of the
connection, malfunction of the device or of connected devices.
The manufacturer or sales agent shall not be liable for damage whatsoever resulting from any use other than the use
explicitly permitted in this guide or ancillary documents.
The manufacturer shall not be liable for misprints.
Disposal and Recycling
Switch off the supply voltage and disconnect from device.
Disconnect all other terminals and remove wiring from device.
Dismount the device.
To protect the environment, this device must not be disposed together with normal household waste
Dispose of the device according to according to local directives and guidelines.
This device consists of materials that can be recycled.
Electronic inserts can be easily separated and the device consists of recyclable materials.
Where it is not possible to dispose of the device locally in accordance with environmental regulations please contact us
for return or disposal instructions.
Warranty
The manufacturer's warranty for this device is 24 months after the date of purchase.
This warranty shall be good in all countries this device is sold by the manufacturer or its authorised dealers or agents.
Refer to separately supplied installation guides for information regarding warranty on external components.
Copyright
The manufacturer retains the copyright to this device. This guide or any separately supplied installation guide may not
be reprinted, translated, copied in part or in whole without prior written consent.
We reserve the right to make technical modifications with reference to the specifications in this guide without notice.
Customer Satisfaction
Customer satisfaction is our prime objective.
Please get in touch with us if you have any questions, suggestions or problems concerning the device or external
components.
Contact
Afriso Eurogauge Ltd
Unit 4, Satellite Business Village
Fleming Way, Crawley
West Sussex. RH10 9NE
Tel: [phone] Fax: [phone]
email: [email protected]
Web: www.eurogauge.co.uk
User Guide
ACU 2030

Issue 6: 20/11/2018
5 of 8
User Guide
ACU 2030
1. Application
The ACU2030 heavy duty level alarm system is designed to operate in conjunction with any level
switch possessing a voltage-free relay output contact.
The unit provides audible and visual alarms of level alarm conditions in tanks, sumps or bund
enclosures. The unit is specifically designed for outdoor mounting and is protected to IP65.
2. Operation
The system consists of the ACU 2030 alarm control unit and any of the Afriso Eurogauge range of
level switches possessing voltage free relay output contacts. The ACU 2030 incorporates both
visual and audible alarms, a set of voltage-free output relay contacts, as well as an alarm Test switch
and an audible alarm Mute switch. When the relay contacts on the level switch change state, due
to the presence of an alarm condition, a DC circuit is completed and the alarm circuit in the
ACU2030 is activated. When an alarm condition is present the red alarm LED will come on, the
sounder will operate and the output relay will energise. Operating the Mute switch will silence the
sounder. Operating the test switch will simulate an alarm condition causing the red alarm LED to
come on, the sounder to operate and the output relay to energise.
3. Installation
3.1 General
The ACU 2030 unit is designed for outdoor mounting on any suitable flat vertical surface. Unscrew
the four captive screws in the lid of the unit and carefully remove the lid. The base of the unit is then
fixed to the mounting surface by means of four screws through the fixing holes in the base of the
unit. Fixing hole spacing centres are 160 x 110 mm and take M4 screws.
3.2 Wiring
Wiring to the ACU2030 alarm control unit must be in suitable cable for the application conditions,
and the installation must comply with all statutory requirements that may affect the complete
installation. The unit must be supplied via an unswitched fuse unit to prevent unauthorised isolation
of the system. Standard electrical installation cable, suitable for the intended supply voltage must
be used and consideration must also be given to any special environmental conditions.
The instrument must be wired in accordance with the wiring diagram.
4. Testing of System Function
Once the unit has been wired up the system function should be tested by operating the test switch.
This will cause the red alarm LED to come on, the sounder to operate and the output relay to energise.
The sounder can be muted by operating the mute switch.

Issue 6: 20/11/2018
6 of 8
User Guide
ACU 2030
5. Electrical Connection Diagram
NC C NO
Voltage free output contacts
shown in alarm condition.
Live Earth
Neutral
24Vdc
+ve 0v
24/48Vac
~ ~ Input from external level or
float switch (voltage free)
Note: Supply
Voltage depends
on unit ordered

Issue 6: 20/11/2018
7 of 8
User Guide
ACU 2030
6. Specification
Part Numbers 2030 02 000-1 230Vac
2030 02 000-2 110Vac
2030 02 000-3 24 Vac
2030 02 000-4 24 Vdc
2030 02 000-5 48 Vac
Supply 110/230 Vac : 50 Hz : 3VA. Input voltage factory set.
24/48 Vac : 50 Hz : 3VA. Input voltage factory set.
24 Vdc : 2 Watts.
Indicator Red LED cluster lamp
Sounder 90 dB at 0.6 metre.
Controls Test switch: Mute Sounder switch.
Input Voltage-free relay contact from external level switch (not included).
Relay Output SPCO - Voltage Free.
3 Amps at 250 Vac : 750 VA.
1 A at 12 Vdc non-inductive load.
Housing IP65 Polycarbonate ABS for vertical wall mounting.
Dimensions (mm) 175 x 125 x 75 (Enclosure)
Cable Entry 5 x M16 cable glands fitted at base of unit.
Weight 0.63 kg.
Protection IP65.
Note We reserve the right to alter the design or specification of this product

Issue 6: 20/11/2018
Afriso Eurogauge Ltd, Unit 4, Satellite Business Village Fleming Way, Crawley, West Sussex. RH10 9NE Tel: [phone] Fax: [phone] email: [e-mail] Web: www.eurogauge.co.uk
8 of 8
User Guide
ACU 2030
ACU 2030 Alarm Control Unit
Signed: D C Ward Position: Technical Manager Date: 21/02/2007
Declaration of Product Origin
We confirm that the following product designs originate and have been wholly manufactured within the
United Kingdom of Great Britain and Northern Ireland by:
Afriso Eurogauge Ltd.
Unit 4, Satellite Business Village,
Fleming Way, Crawley,
West Sussex.
RH10 9NE. United Kingdom.
Tel: [phone]
Fax:[phone]
[email protected]
www.eurogauge.co.uk
This is to certify that the above named product fully complies with the
Electromagnetic Compatability Directive 89/336/EEC and the Low Voltage
Directive 73/23/EEC of the European Union and with the requirements of
the normative sections of the following harmonised European Standards.
EN61000-3: Electromagnetic Compatibility - Generic Emission Standard.
Residential, Commercial and Light Industry.
EN61000-2: Electromagnetic Compatibility - Generic Immunity Standard.
Heavy Industry.
EN61010-1: Safety requirements for electrical equipment for measurement,
control and laboratory use.
Signed:
Declaration of Conformity
ACU 2030 Alarm Control Unit
D C Ward
Position: Technical Services Manager,
Date: 16/09/09
This declaration applies to the following part number(s):
2030 02 000-1 230Vac Unit 2030 02 000-2 110Vac Unit
2030 02 000-3 24Vac Unit 2030 02 000-4 24Vdc Unit
2030 02 000-5 48Vac Unit
