Agilent Technologies Medalist i1000 User manual

Agilent Technologies
Medalist i1000 In-circuit
Test System
Installation Guide

Notices
© Agilent Technologies, Inc. 2007
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or
translation into a foreign language) without
prior agreement and written consent from
Agilent Technologies, Inc. as governed by
United States and international copyright
laws.
Manual Part Number
U9401-96000
Edition
First edition, September 2007
Printed in Taiwan
Agilent Technologies, Inc.
1601 California Street
Palo Alto, CA 94304 USA
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
WARNING
A WARNING notice with this sym-
bol indicates a risk of electric
shock. The operator must follow
the instructions carefully to avoid
electric shock.
WARNING
A WARNING notice calls attention
to a procedure, practice, or condi-
tion which could possibly cause
bodily injury or death.
CAUTION
A CAUTION notice calls attention
to a procedure, practice, or condi-
tion which could possibly cause
damage to the equipment of per-
manent loss of data.

1
Medalist i1000 In-circuit Test System
Installation Guide
Medalist i1000 Installation Guide
Safety Precautions 2
Front Panel Access 3
Installation Overview 6
Preparing the Power Cord 8
Hardware Installation 11
Software Installation 18
Control Buttons 19
Installing the Fixture on the Press Down Model (U9401A) 20
Installing the Fixture on the Vacuum Model (U9402A) 24
System Check 31
Adjusting Fixture Press Travel on the Press Down Model (U9401A) 32
This guide describes how to install the Medalist i1000 In- circuit Test
Systems. Procedures are provided for both the press down model (U9401A)
and the vacuum model (U9402A).

2Medalist i1000 Installation Guide
Safety Precautions
WARNING Installation
Before you turn on the power, verify that the ac mains supply voltage matches
the voltage marked on the system specifications plate on the back of the
equipment.
This equipment must be connected to a properly installed earth ground. Do not
operate the equipment until it has been properly earthed by a qualified
electrician.
Overcurrent protection must be provided for this equipment. Do not operate
the equipment until proper overcurrent protection has been installed by a
qualified electrician.
This equipment is not intended for use near explosive or corrosive hazards.
CAUTION Servicing
All fuses must be replaced only with fuses of the specified type. Do not modify
the equipment or use unapproved replacement parts.

Medalist i1000 Installation Guide 3
Front Panel Access
The front panel of the Medalist i1000 provides access to the power
switches and cards in the testhead. The front panel can also be removed
when servicing is required.
•Opening the Front Panel
•Removing the Front Panel
•Replacing the Front Panel
Opening the Front Panel
1The front panel has two recessed handles, one on each side of the
panel. Push the bottom of the handle on the front panel as shown in
Figure 1 and rotate the handle out from its recessed position. Do the
same on the other side of the front panel.
2Latches on the inside of the front panel secures the panel in place. You
have to open the side panel to reach and unfasten the latch (Figure 2).
Do the same on the other side of the test station.
Figure 1 Handle on front panel
Figure 2 Unlock front panel
Location of latch

4Medalist i1000 Installation Guide
3Hold the handles of the front panel and pull towards you. The front
panel opens from the top and is supported by two cables when fully
open (Figure 3).
With the door in this position, you will be able to access the power
switches and replace any cards.
Removing the Front Panel
If the front panel needs to be removed, continue with the following steps.
1Support the front panel while you loosen the screws that secure the
supporting cables to the test station (Figure 4). Then unhook the cables
from the screws.
2Once the supporting cables are released, use the handles to lift the
front panel upwards and away from the test station.
Figure 3 Front panel open
supporting
cable
Figure 4 Unfasten supporting cables

Medalist i1000 Installation Guide 5
Replacing the Front Panel
Follow these steps to replace the front panel:
1There are two pins at the bottom of the front panel. Fit the pins into
the corresponding holes at the bottom front edge of the test station
(Figure 5).
2Support the front panel while you loop the supporting cables over the
screws (Figure 3). Tighten the screws to secure the cables.
3Close the front panel.
4Open the side panels and secure the latches on the inside of the front
panel.
Figure 5 Replace front panel
Figure 6 Secure supporting cables
fit pin into this hole

6Medalist i1000 Installation Guide
Installation Overview
Figure 7 shows where the hardware components are installed on the
U9401A (press down model). On the U9402A (vacuum model), the
controller is installed in the same location.
Figure 7 U9401A (press down model)
1Press Down Unit
2Sensors
3Fixture
4Debug probe/ESD ground connector
5CPU
6Monitor, keyboard, and mouse
1
2
3
4
5
6
2

Medalist i1000 Installation Guide 7
Before you begin installation, prepare the power cable for the system.
Refer to the instructions in “Preparing the Power Cord” on page 8. Then
continue with the installation procedure for your system:
•Installation Procedure for Press Down Model (U9401A)
•Installation procedure for Vacuum Model (U9402A)
Installation Procedure for Press Down Model (U9401A)
1Install the Press Down Unit (U9401A)
2Install the Controller
3Connect the Debug Probe
4Connect Power and Compressed Air Supply
5Power Up the System
6Install Medalist i1000 Software
7Install the Fixture
8Align the Safety Sensors
9Perform a System Check
Installation procedure for Vacuum Model (U9402A)
1Install the Controller
2Connect the Debug Probe
3Connect Power and Compressed Air Supply
4Power Up the System
5Install Medalist i1000 Software
6Install the Fixture
7Perform a System Check

8Medalist i1000 Installation Guide
Preparing the Power Cord
To assemble the power cord, follow these steps:
1Locate the power connector provided (Figure 8).
2Loosen the two screws holding the cable retainer at the back of the
power connector. Then unscrew the black connector insert to separate
it from the metal casing (Figure 9).
WARNING The Medalist i1000 is shipped without a power cord. This allows local support
engineers to purchase a power cord that is suitable for use in the facility
where the system is installed and meets the regulatory requirements of the
country.
Be sure to purchase a power cord rated to operate at 200~240 VAC and
10 Amps, with a minimum length of 2.5 m.
Figure 8 Power connector
Figure 9 Remove black connector insert

Medalist i1000 Installation Guide 9
3Strip the insulation of the power cord to expose the wires. Insert the
power cord through the metal casing of the power connector
(Figure 10).
4Solder the wires to the correct terminals on the connector insert. The
terminals are numbered as shown in Figure 11.
Figure 10 Strip power cord and insert in connector
WARNING Ensure the wires are connected to the correct terminals as shown in
Figure 11. Otherwise the system could be damaged.
Figure 11 Solder wires to terminals
1
2
3
Earth
Neutral Live

10 Medalist i1000 Installation Guide
5Screw the connector insert back into the metal casing. Also replace and
fasten the cable retainer to hold the power cord in place (Figure 12).
CAUTION Ensure that the retainer holds the power cord securely to prevent any movement
that may break the solder connections of the wires to the terminals in the
connector.
Figure 12 Reassemble connector
cable retainer

Medalist i1000 Installation Guide 11
Hardware Installation
•Install the Press Down Unit (U9401A)
•Install the Controller
•Connect the Debug Probe
•Connect Power and Compressed Air Supply
•Power Up the System
Install the Press Down Unit (U9401A)
1Place the PVC pad on the left side of the test station and place the
Press Down Unit on the pad.
2Secure the four L- brackets that hold the Press Down Unit to the test
station.
3Locate the control cable connected to the system card (at the rear of
the test station). Connect the other end to the rear of the Press Down
Unit. See Figure 14 (a).
4Connect the compressed air hose to the connector at the rear of the
Press Down Unit (a) and the rear of the test station (b).
CAUTION The Press Down Unit weighs approximately 70 kg. Be very careful when lifting
the Press Down Unit onto the test station to avoid personal injury and any
damage to the system.
Figure 13 Secure L-brackets
L-bracket

12 Medalist i1000 Installation Guide
5Install the pair of safety sensors on the arms at either side of the Press
Down Unit.
Install the Controller
1Set up the monitor (Figure 16):
aAttach the collar to the back of the monitor with the four screws
provided.
bClamp the base to the right side or back of the test station.
cAssemble the support arm as shown. Tighten the screws with the
Allen key provided.
dSet the monitor on top of the arm.
Figure 14 Control cable and compressed air hose
Figure 15 Sensor
(a) (b)

Medalist i1000 Installation Guide 13
2Place the keyboard and mouse next to the monitor.
3Open the front panel (see “Front Panel Access” on page 3). Place the
CPU in the right compartment of the test station.
4Connect the keyboard, mouse, and monitor cables to the CPU.
5Connect the three flat cables from the CPU to the system card.
Figure 16 Monitor
(a) (b) (c) (d)
Figure 17 CPU

14 Medalist i1000 Installation Guide
6Plug the power cables of the CPU and monitor firmly into the sockets
labeled PC POWER OUTLET.
Figure 18 Flat cables
JPD1
JPD2
JPA1
WARNING Before connecting the power cables, check them for damage and ensure that
no internal wires are exposed.
Figure 19 Power cables

Medalist i1000 Installation Guide 15
Connect the Debug Probe
1Connect the debug probe to the connector on the front of the press
down model (a) or the control box (b) of the vacuum model.
Figure 20 Connector for debug probe
(a) (b)

16 Medalist i1000 Installation Guide
Connect Power and Compressed Air Supply
1Connect the power cable from the test station to a power outlet.
2Connect the compressed air supply to the inlet at the rear of the test
station.
3For the vacuum model, also connect the vacuum hose.
Figure 21 Main power cable
Figure 22 Compressed air supply

Medalist i1000 Installation Guide 17
Power Up the System
Turn on the power to the system in the following order:
1MAIN POWER
2PC POWER
3SYSTEM POWER
4CPU power
5Testhead power
Figure 23 Power up the system
1
54
32

18 Medalist i1000 Installation Guide
Software Installation
Before installing the Medalist i1000 software, set the screen resolution to
to 1024 x 768 pixels and color quality to 16-bit color (Start > Control Panel >
Display > Settings tab).
1Insert the Medalist i1000 Software disc in the controller’s drive.
2Follow the instructions to install the software and restart the system
when prompted.
3When installation is completed, select the option Yes, launch the program
file and click Finish.
This will start the installation of the KEY PRO driver.
4When installation is completed, launch the Medalist i1000 software by
clicking its icon on the desktop.
5At the prompt Use Demo Version? click No.
6Enter the license key and click OK.
If a new license key is needed, copy the serial number from the title
bar of the dialog box, and contact your Agilent representative to apply
for a license key.
7You have to log in to use the software. The default user name and
password are both i1000. The security level for this user name is
Administrator.
