AGPtek G05S User manual

Unit overview
G05S USER MANUAL
1.Previous song/Fast backward/ Return
2.Return / Scroll down
3.Submenu button / Lock /Unlock / Scroll up
4.Play / Pause / Enter / Power On-off
5.Next song/Fast forward
6.Micro-USB port
7.MIC hole
8.Power on-off
9.Earphone jack
10. Micro SD card slot
11.Vol+/Vol-
12.Clip
13.1.5”TFT screen

Technical Specification
Basic Operation
Power On/Off
Push on-off button to the “on”side or long press button
for about 3 seconds to turn it on.
Push on-off button to the “off”side or long press button
for about 3 seconds to turn it off.
Scroll Up/Down
Click button / to scroll up/down one by one. Hold to
scroll up/down quickly.
Return
At any interface, long press to enter Main menu.(not
available for Bluetooth function)
At main menu, press back to the interface you just
use(music or FM).
Screen
1.5 inch 128*128 TFT display
Flash memory
8GB
Audio format
MP3/WMA/OGG/APE/FLAC/WAV/A
AC-LC/ACELP
Recording format
FM/MIC record and WAV
Battery
Li-polymer rechargeable 300mAh
FM frequency
87.0-108MHZ
Micro-SD card
Extend to 64GB
Photo format
JPG,BMP and GIF
Charging time
3 hours

MUSIC
Lock the Screen
Long press to lock the screen. Repeat to unlock. When
the screen is locked, all of the buttons on the key pad are
not available.
Note: You can not lock the screen under music/submenu
list interface.
Battery Charging
When there is a battery indicator on the screen, you must
charge the device.
The device has two charge options:
a)You can charge the device via the USB connector.
b)You can also charge the device via a 5V 500mA USB wall
adapter(not included)
Note:The charging time should not exceed 4 hours. It is
recommended to turn off the device before charging.
Press buttons definition
Action
Basic operation
Short press
Press time is less than 1-2 seconds
Long press
Press time is more than 1-2 seconds
Hold
Keep pressing one button
Note:Without special instruction, all pressing mean short
pressing in this user manual.
Play your music
On music menu, press to enter music function, and by
pressing / to view sub-menu from up to down: “All
songs”,“Now playing”,“Resume”,“Artists”,“Albums”,
“Genres”,“Playlists”and “Create playlists”. Press to
confirm your option and start to play your music.
Please note: The submenu for music is different under

Bluetooth mode and normal mode.
Repeat
Here appears 4 options, Repeat 1, and Repeat All, Repeat
off, View Playing.
Shuffle
Choose On or Off mode as you want.
Equalizer
Here are 7 equalizers for your option, Off, Rock, Funk, Hip
Hop, Jazz, Classical, Techno.
Variable Speed Playback
Adjust the play speed from (the slowest)-8 to +8(the
fastest).
Repeat settings(only available when the music is playing)
Repeat mode(A-B):choose the option Replay mode, click
to confirm the starting time A (A is flashing).
Then click the button to set the ending time B(B is
flashing). Click the button again to confirm. The icon for
A-B indication will appear on playing screen. And the audio
from time A to B will be repeated automatically.
Replay times: Set the replay times from 1 to 10.
Replay intervals: Set the replay interval for 1 to 10
(seconds).
Bookmarks
It is marked by the stopping time as “hh:mm:ss”. So you can
set the stopping time before you add it for continues
playing next time conveniently.
You can add up to 10 bookmarks for each of the song. If
there are more than 10 bookmarks, the old one bookmark
will be replaced by the new.
You can find the bookmarks you saved with the option “Go
to bookmark”under submenu “Bookmarks”, and you can
delete them with the option “Delete bookmark”.

SET
Note: Only when the song is playing, you can find all of the
bookmarks you added for this song with the option “Go to
bookmark”. That is to say, if you want to find the
bookmark of one song, you must play the song at first and
then find the option “Go to bookmark”. All of the
bookmarks for this song will be listed under the option “Go
to bookmark”.
Add to playlist
There are 3 options prepared for you, including “Playlist on
the go [1]”,“Playlist on the go [2]”and “Playlist on the go
[3]”, you can add the song which is playing to any one of
these three as you like.
Remove from playlist
You can remove the song which is playing to any one of
these three Playlist as you like.
Delete
It will show”...(song name)”delete? Press to choose yes
to delete this song.
To create playlists by yourself
There is a free program called Media Go. It's the easiest
program to use for transferring playlists to the AGPTek. Just
create your playlists in Media Go and then right-click its
name and select 'Add playlist to X :( Which is your MP3
player's disk) '. (You can download it at
http://mediago.sony.com/chs/download).
On setting menu and press to access the following
settings: “Language”,“Date and time”,“Screensave mode”,

RECORD
“play mode”,“sound settings”,“Brightness”,”Backlight
timer”,“Sleep timer”,”Power off”,“Format device”,
“Factory settings”,“Information”.
Press to default your setting.
Sleep timer: When it reaches the sleep time you set, the
player will power off automatically;
Power off : When it reaches the power-off time you set, the
player will shut off automatically when the
MP3 is not playing and you have no action on it.
Select Off to make it always on;
Backlight timer: Set the backlight time of your player;
Screensave mode: Choose “Screen off”to turn off the
screensave mode, or choose the clock style to
select from the 4 clock styles. You can press
and to select it;
Language : Choose the language according to your need;
Information : See information about your player.
On record menu and press to enter voice recording. The
following lists will show: Start Voice Recording, Recordings
library, Recording Format and Record Settings. Press /
to select from these lists.
•Quick Record: scroll to “Start Voice Recording”, press
to start your recording, click button to resume or stop
recording, and press and choose YES to save the
recording.
•In recording library view recording files(such as
REC001.WAV, you can play it as music) and delete all files.

FM RADIO
On radio menu press to enter below radio playing
interface.
You can press / to search programs manually.
At radio playing interface, press and will show a related
lists including “Bluetooth link”,“Presets”,“Save to preset ”,
“Clear preset”,“Auto tune”,“Start FM recording”and “Tuner
Region”.
Listen to the Radio by Bluetooth
Find Bluetooth link, and click button to access to its
submenu:
Bluetooth Status: choose to turn on/off the Bluetooth, turn
on Bluetooth before searching the Bluetooth around.
Bluetooth Search: all of the Bluetooth searched will be
listed, choose the device and click the button to
connect/disconnect.
Bluetooth Device: all of the Bluetooth connected before will
be listed.
Presets
You can see both preset station and auto tune station. Press
, you can see clear preset and clear all presets.
Clear preset: Press to enter the station list and
press / to select the station, and then press to
ensure. It will show etc: “Clear preset01?”press to
confirm Yes or No.
Clear all presets: Press It will show “Clear all
presets”. Press to confirm Yes or No.
Tip: if you use auto tune, all the station you had saved will
be deleted.
Save to preset
The frequency points of radio station are displayed with 30

FOLDER
BLUETOOTH
frequency points reserved at most.
Clear preset
Press to clear preset stations.
Auto tune
Press to enter Auto tune mode, it will show “Do you
want to auto-tune ”, press to confirm Yes or No. If
choose Yes, it will be searching automatically and
automatically save searched station in “ Station list”.
FM recording
Press to start recording, and press , it will show“Save
recording?”press to confirm Yes or No. If choose Yes, it
will saved recording content in the formats of
FMREC001.WAV…
You will find saved FM recording in Record folder under
FOLDER menu.
Tuner region
The player is defaulted to command band, if you are in
Japan, you need to change to Japan Band. If you are in
Europe, you need to set to European band.
On folder view menu press to enter folder menu. Here
you can check files you have stored on the device
including music, recording and pictures.
When you play music under “Folder”, it will shuffle songs
by folder if you turn shuffle on.
Open the Bluetooth of the device you want to connect with
the player. Then click to search the nearby devices, then

all of the devices which has opened its Bluetooth will be
listed. Select the device you want to connect, then click
to connect. After successfully connected, this player is
ready to play music by Bluetooth earphones, Bluetooth
speaker etc. Press button to enter its submenu:
Bluetooth Search, choose to restart searching;
Bluetooth Device, choose from the available devices and
select to connect/disconnect;
Music list, choose to list all of the musics;
Music, choose to go to the music playing interface.
Note:
1.when playing music or FM radio by Bluetooth, it is not
allowed to go back to the main interface unless
disconnected with Bluetooth;
2. When the player is powered off by holding the middle
button, it will connect to last device it connected by
Bluetooth automatically once powered on next time;
3. If the player is connecting to external device by Bluetooth
with card inserted, there will be options popped out for
choosing internal memory or memory card.
If you have any questions about this player, please feel free
to contact [email protected]om.
