AGPtek A209(s) User manual

A20(s) Music Player

CONTENTS
01/04
05/08
09/12
13/16
17/20
21/24
English
Deutsch
Italiano
Español
Francais
日本語

Before use
Thank you for purchasing AGPtek MP3 Player. Please
read the manual carefully before using the product.
Specifications are subject to change without prior
notice.
Buttons and Controls
Charge the Player
1. Charge by computer USB port
2. By the USB cable with charger(Not included)
The USB cable can both be used for data transfer and
1. Back button
2. Scroll up/Volume +
3. Previous/Fast
backward button
4. Play/Pause/Enter
5. USB port
6. Strap hole
7. Earphone jack
8. Menu button/Screen
Lock
9. Power button/Screen
on/off
10. Card slot
11. Next/Fast forward
12. Scroll down/
Volume -
1

charging the player.
Please note: The specifications of the charger must meet
the following requirements or any accident or failure
happened will be regarded as man-made damage.
Input: AC110-240V 50/60Hz Max:1000mA
Output: DC5.0-5.5V 500mA-800mA
Power On/Off
Hold button to switch on/off the device. Click to turn
off the screen. Click again to wake up the player and
display the clock, then click any button to go back to the
interface.
Please note: When the player is on the music playing
interface, if you hold button to turn off it, next time
you switch on the player, it will start from the last position
it left off.
Date Transfer
Connect to the computer by the attached USB cable.
Copy the musics and other related files you need to
transfer in the computer, and then paste in the player.
Screen Lock
Hold button to lock screen, then all the buttons are
useless except the screen lock button. Click button to
wake up screen and display the clock, press any button to
go back to interface, then hold button again to
unlock screen, then you can use other buttons.
Setting
Find "Set" on main menu, click button to access to its
function. The related list will show as below:
Play mode: Choose to play music from/repeat/shuffle
the songs in "Music".
2

Sound settings: Set the equalizer;
Power off: Shut off automatically when reaches the set
time;
Sleep timer: Choose off to turn off this function. Select
on and set the time between 1-99(minutes), when it
reaches the sleep time you set, the player will power
off automatically;
Display settings: Set the Brightness, Backlight timer and
Screensaver of your player;
Backlight timer: set the time at
10(seconds)/20(seconds)/ 30 (seconds)/Always on. The
default time is 30 seconds.
Date and time: Set the Date and time according to
your need; Click button / to select
year/month/day/ hour/minute. Click ▲/▼to adjust the
value of year/month/day/hour/minute. Click button
to save your settings.
Language: Choose your language;
Record
Select "Record" on main interface, click button to
access to its function. Select "Start Voice Recording" and
click to start your recording. Click and then click
to save your recording;
Stopwatch
Select "Tools" on main interface, click button to access
to its function. Find Stopwatch and click button to
enter, click again to start the timer, then click again to
stop/resume. Press to start a new one. Click to go
3
