AGPtek G6 User manual

E
CONTENT
English
Deutsch
Français
Italiano
Español
日本語
01/07
08/16
17/24
25/32
33/40
41/47

1
Quick Guide
Unit Overview
1. Charge the Player
Use 5V/500mA Charger
Plug one end of the micro USB cable into the USB port of a charger, the other end into
the port on your device.
Charge by Computer
Connect the device to a running computer via included USB cable.
Note: The charging time should not exceed 3 hours. It is recommended to turn off the
device before charging.
1.Menu
2.Back
3.Scroll up/Volume +
4.Scroll down/Volume -
5.Previous/Fast backward
6.Next/ Fast Forward
7.Enter/Play/Pause
8.Power on/off;
Screen on/off
9.Earphone jack
10. Screen lock/unlock
11.TF card slot
12.Micro-USB port
13.Mic hole
14.Clip

2
2. Basic Operation
Power on/off. Long press the power button for 3 seconds to turn on/off the player.
Screen on/off. Short press the power button to turn on/off the screen display.
Screen lock/unlock. Slide the button on the right side up to lock the screen and all
the buttons will be unavailable; slide it down to unlock and enable the buttons.
Browse item. Press button / or +/-to browse and choose items
Enter/Confirm. Press button to enter item or confirm your option.
Submenu. Press button Mto access to the relative submenu
Back. Press button to go back.
3. Play the music
Next/Previous track. When is on music playing interface or the screen display is off,
press button to switch to next music file; press button to skip to the
previous music file
Fast forward/backward. When is on music playing interface or the screen display is
off, hold down the button to fast forward; hold down the button to fast
backward.
Play/Pause. When is on music playing interface or the screen display is off, press
button to play/pause.
Adjust volume. Long press the button +/-to adjust volume. Note: Volume
adjustment is not available when on menu list interface
4. Import and Transfer Music
Connect the computer via the USB cable. Copy the music and other files you need to
transfer in the computer, and then paste in the player, or just drag and drop the music
files or folders directly when connected to computer.
Note: Do not disconnect your player during the transferring process. If you do, the file
being transferred will be damaged.
5. Insert/Remove Micro SD Card
Insert the Micro SD card into its slot and push inward, the deck will automatically lock
the Micro SD card. When remove the Micro SD card, push inward and then let go, the

3
Music
card will automatically pop up.
Note: Please insert the memory card while the player is off, or it may not able to read
the data.
Find “Music”on Home menu and press the button to access to its function. The
related list will show, including: All Songs, Now playing, Artists, Albums, Genres,
Playlists, Update playlists. While it’s on music playing interface, press button Mto
access to the submenu. The related list will show:
Home. Go back to Home menu directly.
Play mode. Choose play mode: Shuffle, Repeat playlist, Repeat one, Play by playlist,
View playing. If you select option “View playing”, the player will only play the first 10
seconds of a track and then skip.
Equalizer. Choose from the 7 sound effects, or choose "off" to turn off equalizer.
Variable speed playback. Adjust playback speed from -8(Slowest) to +8(Fastest).
Bookmarks. Choose to add bookmark for the song/audiobook that is playing now,
or go to /delete the bookmark you added.
Repeat settings. A-B repeat mode.
-Replay Mode. Set A-B repeat period. Press button to confirm the starting time
A when A is flashing. Then press the button to set the ending time B when B is
flashing. The passage from time A to B will be repeated automatically. The icon for
A-B indication will appear on the screen. Press button again to back to normal
playback.
-Replay times. Set the replay times from 1 to 10.
-Replay intervals. Set the replay interval from 1 to 10 (seconds)
Delete. Choose to delete the song that is playing now.
Add to playlist/ Remove from playlist. Choose to add to or remove from the 3
existing playlist.

4
FM Radio
Bluetooth
Find “Bluetooth”on Home menu and press button to access to its function.
Bluetooth On/Off
Choose to enable or disable Bluetooth.
Search for device
When the Bluetooth is enabled, choose “Search for device”to search the nearby
devices, then all of the devices which has opened its Bluetooth will be listed.
Device List
Choose from the available devices and select to connect/disconnect. Select the device
you want to connect, and then press button to connect. After successfully connected,
this player is ready to play music or FM radio by Bluetooth earphones, Bluetooth speaker,
etc.
Note: Please turn on the Bluetooth of the device you want to connect to at first.
Find “FM radio”on Home menu with the button to enter to its function.
While it’s on radio playing interface, press the button Mto access to its submenu
which includes: Turner Region, Auto tune, Presets, Save to preset, Clear preset, Start
FM radio recording, and FM Recording.
Tuner region
The player is defaulted to common band, if you are in Japan, you need to change to
Japan Band. If you are in Europe, you need to change to European band.
Auto tune/Save to/Clear preset
-Auto tune. Search stations automatically. You can see the searched stations in
“Presets”. While is on radio playing interface, press to switch among the saved
stations.
-Save. Save the station you are listening to “Presets”.

5
Recordings
-Clear preset. Choose “Clear preset”to enter the station list, then press button
and choose “yes”to clear the station you are listening.
Note: If you use auto tune, all the station you saved in “Presets”manually will be
deleted.
Start FM radio recording
Choose "Start FM radio recording", press button to pause/continue, press button
and select “Yes”to save the recording file.
FM recording
View the radio recording files. The radio recordings will also be saved in “Recordings”>
“Recordings library”
Note: You can choose to turn on/off the radio background in “Settings”>“Background
radio”. If you turn it off, the radio will stop when you exit from the radio interface.
Find “Recordings”on the Home menu, press button to access to its function. The
related list will show, including: Start voice recording, Recordings library, Set rec birate,
Track AVR mode.
Start voice recording. Choose “Start Voice Recording”and press button to start
voice recording, press again to pause. Press the button and choose “Yes”to
save the recording file.
Recordings library. Find the saved recordings in Recordings >Recordings library.
Press button to play the recording file. When it’s on recording file playing
interface, press button Mand choose “Delete”to delete the file you are playing.
Set rec bitrate. Choose from 32 kbps/64 kbps/128 kbps/192 kbps for MP3 format;
Choose from 512 kbps/768 kbps/1024 kbps/1536 kbps for WAV format.
Track AVR mode. If you start recording under AVR mode, the recorder will start
recording automatically when sound is detected and stop recording when no sound
detected.

6
Folder view & Tools
Settings
Note: Recording function is not available while using Bluetooth function.
Folder view. Find “Folder view”on Home menu with the button to enter to its
function. Here you can check files you have saved in the device including music,
recordings and pictures.
Tools. Find “Tools”on Home menu with the button to enter to its function.
-Clock. Check the time and date.
-Stopwatch. Press button to start the timer, then press button again to pause
or press button Mto resume. Press button -to start a new one. The maximum
Stopwatch list is 5.
Find “Settings”on Home menu with the button to enter to its function. A related list
will show, including: Language, Date and time, Screensaver, Display settings,
Background radio, Power off, Information, Format device, Factory settings. Always tap
button to confirm when you’ve done the settings.
Date and time. Choose “Date settings”to set date format and date. To set date,
press button Mto switch among day|month|year, press button +/-to adjust the
value of day|month|year. Set time under “Time setting”and adjust the time in the
same way.
Screensaver. Choose to set screensaver as digital clock or turn off screensaver
display.
Display settings
-Brightness. Set the screen brightness
-Backlight timer. The screen backlight will be off automatically when reaches the set
time.
Background radio. Choose to turn on / off the radio background,

7
Technical Specification
Power off
-Power off. When there is no operation on the device, the device will shut down
automatically when reaches the set time.
-Sleep timer. The device will shut down automatically when reaches the set time.
Information. check player information and disk space about your player.
Format device / Factory settings. Format the device or restore to factory settings.
Note: Before formatting the device, please backup the file so as not to lose any files.
If you have any questions about this player, please feel free to contact
[email protected].
Screen
1.5 inch 240*240 TFT display
Flash memory
8GB
Bluetooth Version
4.0
Audio format
MP3/WMA/OGG/APE/FLAC/WAV/AAC-LC/ACELP
Recording format
FM/MIC record and WAV
Battery
Li-polymer rechargeable 300mAh
FM frequency
87.0-108MHZ
Micro-SD card
Support up to 128GB
Photo format
JPG,BMP and GIF
Charging time
3 hours

8
Kurzanleitung
Geräteübersicht
1. Laden Sie den Player auf
Verwenden Sie 5V / 500mA Ladegerät
Stecken Sie ein Ende des Micro-USB-Kabels in den USB-Anschluss eines Ladegeräts, das
andere Ende in den Anschluss Ihres Geräts.
Laden durch Computer
Schließen Sie das Gerätüber das mitgelieferte USB-Kabel an einen laufenden
Computer an.
Hinweis: Die Ladezeit sollte 3 Stunden nicht überschreiten. Es wird empfohlen, das
Gerät vor dem Laden auszuschalten.
2. Grundbetrieb
1. Menü
2. Zurück
3. Scroll auf / Lautstärke +
4. Scroll runter /Lautstärke -
5. Vorheriger /schneller zurück
6. Nächste / Schneller Vorlauf
7. Eingabe/ Wiedergabe/ Pause
8. Power ein / aus;
Bildschirm ein / aus
9. Kopfhörerbuchse
10. Bildschirm sperren /
entsperren
11. TF-Karte Slot
12. Micro-USB-Anschluss
13. Mic Loch
14.Clip
