AKG DMC 700 User manual

Table of contents:
Last modification :
Page 5, pos.7 and 8. visa versa
Page 8, new number for MiniXLR socket added
V2 added
Page 11, screw quantity corrected
Page 13, added CU700
Page 4, corrected wiring
front panel number removed
D7 version added
Page 11, pos 21 new number
Page 6, add dismantle DHT700
The complete DSM 700 family
3
Die komplette DMS 700 Familie
DHT 700 Digital handheld transmitter
4
DHT 700 Digitaler Handsender
DPT 700 Digital bodypack transmitter
7
DPT 700 Digitaler Taschensender
DSR 700 Digital stationary receiver
9
DSR 700 Digital Empfänger
CU 700 Charging unit
13
CU 700 Ladegerät

Frequency range, Mhz,
Band 1
548,100 –697,900 / 50mW
Band 2
710,100 –861,900 / 50mW
863,100 –864,900 / 10mW
DPT 700
Digital bodypack
transmitter
CU 700
Charging unit
DSR 700
Digital stationary
receiver
DHT 700
Digital handheld
transmitter
Mains cable:
EU 0110E03160
US 0110E03170
DSR 700 Antenna:
Band 1 (long) 9999N07440
Band 2 (short) 9999N07450
Front mount cable 0110E01890
Manual:
User manual V1 9100U12810
User manual V2 9100U13560
For information about PSU4000, HUB4000Q,
PS4000 and antenna system SRA2B/W,
RA4000B/W, AB4000 and ASU4000 please refer
to the WMS4000/4500 Service information.

DHT 700 D5 3157Z00…
DHT 700 C5 3157Z00…
DHT 700 D7 3157Z00…
Sleeve 5 to be glued on end cap 9
after it is completely screwed onto
part 4 (thread part).
Use UHU PLUS ENDFEST 300.
Cut out of end cap 6 has to be align
with charging contacts!
Wiring / Verkabelung
1
3
14
2
17
16
15
33
27
6
12
7
9
5
8
10
20
24
19
13
11
25,26
21
23
22
29
28
31
30
4
33
32
32
34
19
35
37
Apply Loctite 415 to secure
transducer capsule.
D5
D7
C5
non corrosive silicon glue
inphase
(red)
inphase
(red)
36
36
C5
D5/D7
blue
black
red
screen
red

DHT 700 Parts list / Stückliste
Description
Pos.
Part number
Bestellnummer
Quantity
Stück
Bezeichnung
C5
D5
D7
Wire-mesh cap
1
3157M12010
1
-
-
Gitterkappe
Wire-mesh cap
1
3157M12020
-
1
-
Gitterkappe
Wire-mesh cap
1
3157M12030
-
-
1
Gitterkappe
Foam insert
2
3138Z25020
1
-
-
Innenwindschutz
Foam insert
2
3138Z25010
-
1
1
Innenwindschutz
Electret capsule C5
3
3157M15010
1
-
-
Elektretkapsel C5
Dynamik capsule D5
3
2610Z00050
-
1
-
Dynamische Kapsel D5
Dynamik capsule D7
3
2610Z00070
-
-
1
Dynamische Kapsel D7
Housing with thread
4
3157M14010
1
1
1
Gehäuse mit Gewindeteil
Battery sleeve
5
3157Z19020
1
1
1
Batteriehülse
End cap
6
3157Z20010
1
1
1
Kappe
Housing shell, lower
7
3157Z11010
1
1
1
Untere Gehäuseschale
Housing shell, upper
8
3157Z10010
1
1
1
Obere Gehäuseschale
Contact cover
9
3157Z42010
1
1
1
Kontaktabdeckung
Half ring, upper
10
3157Z21010
1
1
1
Halbring, oben
Half ring, lower
11
3157Z31010
1
1
1
Halbring, unten
Battery clamp
12
3157M10010
1
1
1
Batterieklammer
Friction
13
3157Z40010
1
1
1
Reibung
Display cover
14
3157M13010
1
1
1
Display Abdeckung
Mute button
15
3157Z14010
1
1
1
Mute Knopf
Foam
16
3157Z37010
1
1
1
Schaumstoffstück
Foam
17
3157Z38010
1
1
1
Schaumstoffstück
Display holder
19
3157Z15010
1
1
1
Displayhalter
Foam
20
3157Z28010
2
2
2
Schaumstoffstück
LCD display
21
0050E00070
1
1
1
LCD Display
On/Off button
22
3157Z16010
1
1
1
ON/Off Knopf
IR window
23
3157Z17010
1
1
1
IR Fenster
Foam
24
3157Z27010
1
1
1
Schaumstoffstück
Main board Band 1
25
3157M01010
1
1
1
Hauptprint Band1
Main board Band 2
26
3157M01020
1
1
1
Hauptprint Band 2
Antenna board Band 1
27
3157M02010
1
1
1
Antennenprint Band 1
Antenna board Band 2
27
3157M02020
1
1
1
Antennenprint Band 2
Clamp cushion
28
3157Z48010
1
1
1
Auflage
Contact support
29
3157Z47010
4
4
4
Kontaktfederung
Battery contact
30
3157Z22010
2
2
2
Batteriekontakt
Battery contact
31
3157Z23010
2
2
2
Batteriekontakt
Screw EJOT PT KB18x6
32
0099N18050
2
2
2
Schraube PT KB18x6
Screw EJOT PT KB22x8
33
0099N22140
3
3
3
Schraube PT KB22x8
Screw EJOT PT KB22x8
34
0099N22040
2
2
2
Schraube PT KB22x8
Screw EJOT PT KB25x10
35
0099N25050
1
1
1
Schraube PT KB25x10
Cable for D5 capsule
36
2548K00010
-
1
1
Kabel für D5 Kapsel
Device sticker DHT 700 D5
37
4808S10…
-
1
-
Geräteaufkleber DHT 700 D5
Device sticker DHT 700 C5
37
4809S10…
1
-
-
Geräteaufkleber DHT 700 C5
Device sticker DHT 700 D7
37
4813S10…
-
-
1
Geräteaufkleber DHT 700 D7
Standadapter SA63
-
6000H63050
1
1
1
Stativklammer
Windscreen
-
2630Z01040
1
1
1
Windschutz
Colorbandset
-
2630Z00210
1
1
1
Farbbandset
Adapter PB1000
-
2334Z05010
1
-
-
Vorsatz PB1000
-
Important!
For ordering the DHT700 main transmitter board we need the following information:
1. Board number: 3157M0101 for Band1 or 3157M0102 for Band2
2. Preset programming for Band2: standard, IL, IT, BY……etc. (please see table on next page)
3. What microphone head is used: D5, D7 or C5.

To dismantle the DHT700 proceed as follows:
1. Remove Battery sleeve
2. Remove housing screws
3. Remove display cover and mute button
4. Remove housing
5. Open
Frequency band and power / Frequenzband und Leistung
Preset--
Main board
BD1
50mW
BD1 U
50mW
BD2
10/50mW
BD2 RO
30mW
B2 NZ
10/50mW
BD2 AU
50mW
BD2 JP
10mW
BD2 TH
50mW
BD2 HK
10/20mW
BD2 KR
10mW
BD2 BY
50mW
BD2 IT
10/50mW
BD2 IL
10mW
3157M01010
x
x
-
-
-
-
-
-
-
-
-
-
-
3157M01020
-
x
x
x
x
x
x
x
x
x
x
x
Device sticker
D5-4808S10…
C5-4809S10…
D7-4813S10…
010
130
020
030
040
050
060
070
080
090
100
110
120

DPT 700 D5 3156Z00…
DPT 700V2 D5 3156Z02…
All charging contact solder joints:
1. pre-solder related pads on pcb
2. assemble pcb and frame assy.
3. melt solder by heating up charging contacts with
soldering tip (apply some pressure)
All cables from pcb carrier assy. To be soldered directly on
charging contacts like shown in this view
Wiring / Verkabelung
1
2
3
4
5
6
77
9
11
10
8
14
12
13
15
14
17
141416
18
19,20

DPT 700 Parts list / Stückliste
Description
Pos.
Part number
Bestellnummer
Quantity
Stück
Bezeichnung
V1
V2
Housing compl.*, upper
1
3156M11010
1
1
Gehäuseoberteil kompl.
Housing, bottom
2
3156Z11010
1
1
Gehäuseunterteil
Battery cover assy.
3
3156M14010
1
1
Batteriedeckel
Frame assy.
4
3156M12010
1
-
Rahmen kompl.
Frame assy.
4
3156M12020
-
1
Rahmen kompl.
LCD display
5
0050E00070
1
1
LCD Display
Display holder
6
3156Z17010
1
1
Displayhalter
Foam
7
3157Z28010
2
1
Schaumstoffstück
Antenna assy. Band 1
8
3156M10020
1
1
Antenne kompl. Band 1
Antenna assy. Band 2
8
3156M10010
1
1
Antenne kompl. Band 2
Foam
9
2932Z34010
1
1
Schaumstoffstück
On/Off button
10
3156Z18010
1
1
On/Off Knopf
Mute button
11
3156Z19010
1
1
Mute Knopf
Cover
12
3156Z20010
1
1
Abdeckung
Mainboard Band 1
13
3156M01010
1
1
Hauptprint Band 1
Mainboard Band 2
13
3156M01020
1
1
Hauptprint Band 2
Bolt, DIN7 2h8 x 20mm
14
0007D20050
2
2
Stift, DIN7 2h8 x 20mm
Belt clip
15
3156Z25010
1
1
Gürtelklammer
Screw, M2.5x10
16
7045D25030
3
3
Schraube, M2.5x10
Device sticker
17
4807S00…
1
-
Geräteaufkleber
Device sticker
17
4807S12…
-
1
Geräteaufkleber
Foam
18
2932Z21010
2
2
Schaumstoffstück
Mini-XLR socket with wires
19
3156M15010
1
1
Mini-XLR Buchse
Nut for Mini-XLR socket
20
2781Z20020
1
1
Mutter für Mini-XLR Buchse
* Housing compl. upper includes display window and Mini-XLR socket.
Important!
For ordering the DPT700 main transmitter board we need the following information:
Board number: 3156M0101 for Band1 or 3156M0102 for Band2, V1 or V2.
Preset programming for Band1: BD1 or BD1U (please see below table)
Preset programming for Band2: IL, IT, BY……etc.(please see below table)
Mainboard (13) will always delivered together with frame assy. (4)
Frequency band and power / Frequenzband und Leistung
Preset--
Main board
BD1
50mW
BD1 U
50mW
BD2
10/50mW
BD2 RO
30mW
B2 NZ
10/50mW
BD2 AU
50mW
BD2 JP
10mW
BD2 TH
50mW
BD2 HK
10/20mW
BD2 KR
10mW
BD2 BY
50mW
BD2 IT
10/50mW
BD2 IL
10mW
3156M01010
x
x
-
-
-
-
-
-
-
-
-
-
3156M01020
-
x
x
x
x
x
x
x
x
x
x
x
Device sticker
V1 4807S00…
V2 4807S12…
010
130
020
030
040
050
060
070
080
090
100
110
120

DSR 700 3155Z00…
1
2
3
4
5
8
10
9
7
20,21
2
13
15,16
17
12
11
22
3
4
24
13
39
23
40
6

Frontpanel
21
22
3
23
38
25
24
28
29
31
26
27
30
32
33
35
36
37
36
34
42
41
43
