aldes ADVANCED CE Series User manual

ADVANCED SERIES
HEAT & ENERGY
RECOVERY VENTILATORS
CE and CH MODELS
IOM
READ AND SAVE THESE INSTRUCTIONS
Always turn o electrical power and verify that
the unit is electrically safe before performing any
maintenance on the unit. This unit contains
high-voltage electrical components.
CAUTION
Aldes products are guaranteed to be defect-free for a
period of (2) years from the date of purchase.
• Labor not included.
WARRANTY
This unit has moving parts. All repairs and
maintenance should be performed by a qualied
technician to avoid serious injuries.
CAUTION
• Always turn o electrical power and verify that
the unit is electrically safe before performing
any maintenance on the unit.
• No modications shall be made to the unit
under any circumstances. Warranty will be
immediately voided.
• Do not use this device to exhaust steam,
inammable or explosive gases.
• Electrical connections shall be made by a
qualied electrician.
• Airows shall be as per the approved submittal
in order for the ventilation system to function
properly and the warranty be honorred.
• Installation shall be completed in conformance
with local construction and safety codes.
• All drawings, photos and diagrams contained
in this document are for reference purposes
only. Units may dier.
• Carnes reserves the right to modify unit and its
components without prior warning.
IMPORTANT
WARRANTY
2 YEARS
• Modications were made by or for the client.
• Product was poorly installed.
• Maintenance, cleaning and lubrication were not
executed in accordance with recommendations made
by Aldes.
WARRANTY DOES NOT APPLY IF:
• All installation fees and labor relating to product
repairs.
• All fees related to a loss of operations, merchandise,
inventory or equipment due to a defective Aldes
product.
WARRANTY EXCLUSIONS
Unpacking Your Unit
Remove the protective wrapping from the unit including the
foam protection at each corners. Extra care should taken to not
scratch the painted surfaces. Appropriately dispose of materials
accordingly to local and/or project specic requirement.
Inspecting Your Unit
Visually inspect the unit to ensure that no sheet metal has been
dented or scratched. Verify that the air intake and exaust hoods
have not been damaged in transport.
Warning: Do not remove the shipping attachments until the
unit has been moved to its nal location.

Page 2 | ADVANCED SERIES CE and CH MODELS
Transport Method
Your unit is equipped with anchors for handling purposes only. Strictly follow all directions before handling your unit. Always use all six
(6) anchors points simultaneously as shown in the diagram.
Using a Forklift to Move the Unit
Before using a forklift to move your unit, you must follow several safety rules.
• Weigh the unit and compare to the forklift capacity. The capacity of the forklift must exceed the weight of the device.
• Raise the device as shown in the diagram below. This is the only method authorized by Carnes to move the unit using a forklift.
• Transportation of the unit must be executed by a qualied forklift operator.
• Ensure that the forklift skids are a minimum of 6 inches longer than the width of the unit.

Page 3 | ADVANCED SERIES CE and CH MODELS
Roof curb Installation (optional) Electrical Components
• Open the exterior panel using the handles (Photo 1).
• Turn the handles downwards and counterclockwise as
indicated in the photo.
• Be aware that you must unlock the handles with the
appropriate key in order to open the panel.
Roof
Covering
Ventilation Unit
Waterproof Seal
(not included)
Galvanized Steel
Flashing
Rigid Insulation
(optional)
Building Structure
Transport Attachments
Once the unit has been placed in its nal location, remove all
transport attachments.
Remove the screws
located at each of
the four corners.
This device contains high-voltage electrical components.
All maintenance must be done by a qualied technician
to prevent serious injury and possible death. Installation
should be completed in conformance with local building
standards and safety codes.
DANGER
5/16”
Photo 1
Connect the unit to the power grid using the disconnect switch.
Such connection shall be made by a certified electrician in
accordance with the applicable electrical code.
* Unit’s specic control panel may dier. For reference only.

Page 4 | ADVANCED SERIES CE and CH MODELS
Device Start-Up
Verify that the motors and blowers are rotating in the proper
direction.
Set-Up Sequence
Make sure the Ground Wire is securely fasten to the appropriate
socket. Such connection shall be made by a certied electrician
in accordance with the applicable electrical code.
This device contains high-voltage electrical components. All maintenance must
be done by a qualied technician to prevent serious injury and possible death.
Installation should be completed in conformance with local building standards and
safety codes.
DANGER
1- Measure the voltage of the main circuit breaker and note
the values (1 to 3 steps). Such Measurement shall be made by a
certied electrician in accordance with the applicable electrical
code.
* Unit’s specic control panel may dier. For reference only.







2- With the unit’s Electrical Wiring Diagram (supplied separatly),
close the Start/stop and Occupancy
control Dry contact.
3- Close the main disconect switch,
the unit should start
WARNING, from this point on, the unit
is no longer Electrically safe.
This device has moving parts. All repairs
should be made by a qualied technician
in order to avoid serious injury.
DANGER
Before turning on your new device,
inspect the condition of the ventilation
ducts. Clean the ducts before turning
on your device. If building construction
has not yet been completed, we
recommend that you wait until work
has been nished before starting up
your device. An abnormal volume of
dust in the air could clog the device
lters and cause damage to the motors.
Ensure that all diusers are opened to their maximum
capacity before turning on your device. It is common to
notice a faint smell of burning upon the rst start-up.
RECOMMENDATION

Page 5 | ADVANCED SERIES CE and CH MODELS
Options Glossary Continued
Defrost Modes
• Built-in self controlled electric preheating coil
(SSR-controlled).
• The unit preheat the outside air at a given set point at
which no frost will occur.The electric coil is Self controlled
and powered by the unit (single point power connection).
• Built-in liquid preheating coil.
• The unit preheat the outside air at a given set point
at which no frost will occur. A 0 to 10VDC control signal
is available to control external hydronic valves (supplied
by others).
• Fan exhaust defrost cycles.
• The unit monitors the outdoor air and when it reaches
below a specic temperature, the unit cycles the supply
air blower on and o for a specic duration to remove
any built frost inside the xed plate recovery core.
• Recirculation defrost cycles.
• The unit monitors the outdoor air and when it reaches
below a specific temperature, the unit cycles the
exhaust air blower and the recirculation damper on and
o for a specic duration to remove any built frost inside
the xed plate recovery core. During such cycles, the
unit will recirculate the air drawn from the building
directly back into the building.
Options Glossary
Control Options
Dirty lters contact: A dry contact, available at the unit’s terminal
board, closes when the pressure drop accros a specic lter banks
reaches its nal pressure drop.
Blowers rotation detection: Unit stops if rotation if the pressure
increase in the supply air blower is null.
Free-Cooling Management: The unit measures and monitors
outdoor air temperature and when within a specic range, the
unit goes into free-cooling.
End switch on Dampers: Unit start-up conditionnaly to the
dampers openings.
BACnet compatible Controler: Unit is controlled using a BACnet
compatible controller. The controller can communicate with
either a:
• MS/TP connection or
• IP connection
Remote Displays:
Offered with command buttons or with touch screen (Only
available with the BACnet controller).
This device should be installed and
balanced by a specialized contractor in
ventilation services.
CAUTION WARNING
Electrical currents remain at the capacitors
for 5 minutes after circuits disconnect have
been opened. The following electrical
components may not be electrically safe
immediately:
• Variable Frequency Drive for the
enthalpyl wheel motor;
• Variable Frequency Drive for the blowers motors.
The following options may not be included with
your device. Consult the specications form provided
with your device for more information.
All of the defrost modes listed below may not be
included with your device. Consult the specications
form provided with your device for more information.
FIXED PLATE EXCHANGER
°C °F  
°C  N/A 
   
   
T0 = -5 C for Aluminum and Polypropylene cores (HRV).
T0 = -10 C for Enthalpy cores (ERV).

Page 6 | ADVANCED SERIES CE and CH MODELS
Options Glossary Continued
Blowers Motor Options
Construction: TEFC
Two speeds application: A single speed motor is controlled with
a preprogrammed VFD for a two speed application.The unit goes
into high speed unis a dry contact.
Variable speeds: A single speed motor is controlled with a VFD.
The unit speed is controlled using a 0-10 VDC signal provided
by others.
Maintenance
Every 3 months
• Check the condition of the lters and make replacements
if necessary.
• Check the condition and tension of belts. Adjust or replace
if necessary.
• Check the condition of ventilators and clean if needed.
Every 12 months
• Clean the cores with water and mild soap.
• Clean the inside of the unit using a vacuum cleaner or soapy
water.
Options Glossary
Components Options
MERV13 Filters: Addittion of a second MERV13 lters bank on
the fresh air circuit only.
Extruded Aluminum Insulated dampers: Activated by a
servomotor upon admission of fresh or exauhst air.
Non-Insulated Backdraft Gravity dampers (for evacuation
purposes only).
Backward Inclined blowers (BI).
Post-Heating Coil: Electric or liquid (0-10 VDC signal or 0-10
VDC signal provided by other components to maintain air input
temperature).
Liquid Cooling Coil: Cold water cooling coil installed inside the
unit (0 to 10 VDC signal by others). Supplied with a drain pan.
DX Cooling Coil: Direct expansion cooling coil installed inside the
unit. Condensation unit provided by other components. Supplied
with a drain pan.
Unit Features
Intake and Exhaust Hoods: Hoods on the intake opening and
the exhaust opening to protect from rain and snow. Comes with
3/8 bird screen mesh.
Roof curb: 14 inches in height, insulated or non-insulated, in
18-calibre galvanized steel.
Piping connection (for hydronic coils and drain pan): Can be
located either at the front of the unit (same side as the doors) or
at the back of the unit (opposite side of the doors).
Always consult a professional plumber to connect the drain
pans. Typical installation uses a properly sized P-Trap. (For
outdoor installation, the P-trap can be removed to avoid frozen
condensation).
The following options may not be included with
your device. Consult the specications form provided
with your device for more information.
Always turn o electrical power before
performing device maintenance.
Device contains high-voltage electrical
components.
CAUTION

Page 7 | ADVANCED SERIES CE and CH MODELS
©2021 American ALDES Ventilation Corporation and ©2021 ALDES Canada. Advanced Series_ CE and CH_IOM_1021. Aldes reserves the right to modify its products at any time to introduce new technologies.
For more information, contact your Aldes sales advisor, visit aldes-na.com, call 1.800.255.7749, or find us on
Before making a service request, please have the following information ready concerning your
device:
• Device series number
• Model number
• Project number
This information is necessary in order to address your problem as quickly as possible. The information
is available on the specication card located on your device (see photo below).
IMPORTANT – Please read the following before placing a service call
Model Number
Project Number
Serial Number
