ALIGATOR D920 User manual

D920 Dual SIM
Quick Guide

Contents
Important instructions........................................................3
Your mobile phone............................................................5
Insert battery, SIM and memory cards..............................6
Battery charging................................................................6
Switch On Off..................................................................6
Making calls.......................................................................7
Keypad lock.......................................................................7
Volume control..................................................................7
Position of Antennas..........................................................8
Text insert..........................................................................8
Telephone directory...........................................................9
Torchlight...........................................................................9
Shortcuts............................................................................9
Safety and ecology..........................................................10
Declaration of conformity No.30 01 2016........................10
Before you start
Thank you for buying of our ALIGATO
mobile phone.
Before you start please read carefully this
instruction manual.
2

Important instructions
Protect microphone holes, headphone and speaker
against dust and penetration of sharp objects
Do not use the mobile phone in the prohibited areas
Do not use the mobile phone while driving the car
Do not use mobile phone near the petrol stations
Always switch off the mobile phone near explosives
Use only the original batteries supplied by the producer.
Danger of damage of the mobile phone or explostion.
SAR – mobile phone meets all prescriptions for maximal
emision of electromagnetic radiation
Please keep the mobile phone 2.5 cm away from the
body while calling. You lower by that the quantity of
electromagnetic radiation absorbed by your body.
Handle the mobile phone and accessories with care,
protect it from falling on the ground, from mechanical
damage, impurity or high temperatures. Never pick it to
pieces !
Do not throw the battery in the fire nor expose it to the
temperatures over +60°C. Danger of explosion or fire !
Do not use the mobile phone near the medical
appliances without having the confirmation that the radio
waves do not influence its function.
Mobile phone can influence the function of the cardiac
pacemakers or other implanted appliances – please
consult your medical doctor
Use the phone on the opposite side than a pacemaker or
other device are implanted at your body
In cases of suspected violation immediately turn off the
phone. Consult your doctor.

3

Switch off the mobile phone in the aircraft
Always switch off the mobile phone near explosives.
Do not place the mobile phone or its holder in the area
above the airbag in the car
Keep it out of reach of children. It contains small parts
that could be swollowed or may hurt
Software and hardware of the mobile phone are
continuously innovated. The importer reserves the right
to alter the instruction manual or particular functions of
the mobile phone without a prior notice.
4

Your mobile phone
1. Earphone
2. Display
3. Left functional button
4. Button „Calling“
5. Charger connector
6. Numeric keypad
7. Navigational button
8. Right functional
button contacts
9. Torchlight
10. Button: Switch
On Off
11. Button: OK
5

Insert SIM, memory card and battery
1. Remove the battery cover on the back side of the
phone.Insert firstly one or two SIM cards at the prepared
slots under the battery space. Contacts must lead
towards down. Battery must be removed.
2. Insert the memory microSD card at the slot
3. Insert battery
4. Put the battery cover back
Battery charging
Battery indicator is placed at the top of the screen. If the
battery is discharged, proceed as follows:
1. Plug the charger into an electrical outlet.
2. Connect the charger to the phone
3. After recharging the battery, disconnect the charger from
the phone and then from the electrical outlet.
The phone can be charged in both On Off mode.
If the battery is completely flat, eg. after a long period of
disuse, it may take up to several tens of minutes before the
charging indicator appears and before you can turn on your
phone and start using it.
Switch On / Off
To Switch On Off press and hold the button (10)
Press short button (10) to finish the call or the application,
event.you return to the main screen.
6

In case the lock of the cell phone is activated please insert
the password. The default password is 1122.
It is necessary to set the actual time and date after the first
switch on.
Making calls
Enter the tel.number with the use of the keypad buttons and
press the button (4). In case 2 SIM cards are inserted you will
be asked to choose which one will be used for calling.
Keypad lock
To set up the automatic keypad lock choose in menu :
Settings > Telephone > Display > Keypad lock
You can lock the keypad by press of the left functional button
(3) followed by a press of the button *.
To unlock the keypad please press first the left button (3)
followed by (*)
Even the keypad is locked you can call the emergency
number 112.
Volume
Volume level of the headphone can be adjusted during the
call by pressing of the directional button to the left right (7).
When listening to audio then use the buttons * and #.
For handsfree activation – during the call please press the
right functional button (8).
7

Warning : Exposing to an excessive noise can damage your
hearing. Listen to the music with reasonable volume level and
do not hold the device close to the ear, especially when using
a loud-speaker !
Position of antennas
Internal antennas for transmission and reception are placed
at the upper and bottom back part. Do not cover the places
where the antennas are placed. While making a call please
keep the mobile phone at least 2-3 cm away from the body to
minimalise the quantity of the el.magnetic radiation absorbed
by your body. Covered antennas may influence the intensity
of transmission and also the battery life.
Insert of text
Keypad of the cell phone enables to enter not only the digits
but also the letters characters. In case of inserting of the
characters each button offers to write several letters. For
example the button „2“ can write the letters A, B and C. A gap
can be written with a button „0“. You can insert the letter by
repeated presses of a button, everal times in quick
succession till the correct letter on the screen displays.
For example : letter A is the first in line it means you press
only once the button 2. Letter C is the third in line it means
you press quickly the button 3 times.
With the button # you can switch (when you write text)
between the writing of small and capital letters and digit
mode
With the button * you can enter the special characters
8

Telephone directory
Numbers of your telephone contacts can be stored both at the
SIM card memory and at the memory of the cell phone.
Dialing numbers from contact list
The simplest way to display the list, press the right function
key "Names" (8). Now you can enter the name that you are
looking for. After that a list of matching contacts will jump
immediately.
Move the button up and down to select the contact you
want to call and press the call button (4).
When viewing the list, the icon appears by each contact
in case the contact is stored in the phone's memory.
When stored on the SIM card, the icon of a card
appears.
Torchlight
Turn On Off a Torchlight (9) positioned on the back of the
phone by pressing and holding of a button „0“. umístěnou
Shortcuts
Favourite functions can be assigned to one press of one of
the 4 directional sides of the navigation button (7). Such a
function will start after the press of one of the direction.
For example : camera will start to work after pressing of the
directional button „up“ (set up from the production).
To change the settings, go to the menu :
Settings >Telephone > Shortcuts
9

Safety and ecology
Used electric device
Mobile phone is an electronic appliance. It means
it must not be manipulated as a common
residential waste! Never throw the used electric
device away at the common municipal waste!!!
Hand over the used electric device to the respective
collection point which provides the ecological liquidation.
Please contact your dealer to get more information how to
deal with the used products.
Battery liquidation
Used/old batteries and accumulators do not belong
to the common residential waste !!!
They may contain the substances dangerous to the
environment.
Hand over the battery to the respective collection point which
provides the ecological liquidation. Please contact your
dealer to get more information how to deal with the used
products.
Handling with the used batteries in contradiction with given
instructions is illegal!
Declaration of conformity
No. 30/01/2016
Issued in accordance with the prescription EU R&TTE
Directive 1999 5 EC
10

Product: Mobile phone for GSM network
Model: ALIGATOR D920
Dovozce: ADART COMPUTERS s.r.o.,
Sokolovská 161, 180 00 Praha 8, CZ
Reg.No. 25074547
Evaluated product is a mobile phone intended for the mobile
net of GSM standard and is planned to be used and stored in
standard conditions. The importer declares, that the product
is for its use safe and during the production there are taken
control and other measurements securing the confirmity of
the product with the basic requirements and technical
documentation. Relevant harmonized norms have been
applied to evaluate the conformity.
The tests were carried out and the protocol made by
authorised person :
PHOENIX TESTLAB GmbH, Königswinkel 10, D-32825
Blomberg, Germany
The product bears the European conformity mark CE 0700
in accordance with prescriptions of the EU.
Issued in Prague, on 30.01.2016:
……………………………………….
ADART COMPUTERS s.r.o.
11
