Allen-Bradley ControlNet 1747-SCNR User manual

Publication 1747-5.36 - May 2000
Installation Instructions
SLC ControlNet Scanner Module
Catalog Number 1747-SCNR
Use this document to help you install the ControlNet™ 1747-SCNR
Scanner module.
For information about See page
preventing electrostatic discharge 2
compliance to European Union Directives 2
related publications 3
module features 4
preparing the module for installation 5
selecting the ControlNet node address 6
inserting the 1747-SCNR scanner into the chassis 6
connecting to a ControlNet network 8
cables 10
applying chassis power 11
status indicators 15
specifications 17
Allen-Bradley Replacements

2SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Prevent Electrostatic Discharge
The scanner module is sensitive to electrostatic discharge.
Compliance to European Union Directives
If this product has the CE mark, it is approved for installation within
the European and EEA regions. It has been designed and tested to
meet the following directives.
EMC Directive
This product is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards, in
whole or in part, documented in a technical construction file:
•EN 50081-2 EMC — Generic Emission Standard, Part 2 —
Industrial Environment
•EN 50082-2 EMC — Generic Immunity Standard, Part 2 —
Industrial Environment
This product is intended for use in an industrial environment.
ATTENTION
!
Electrostatic discharge can damage integrated circuits or
semiconductors if you touch backplane connector pins. Follow
these guidelines when you handle the module:
•touch a grounded object to discharge static potential
•wear an approved wrist-strap grounding device
•do not touch the backplane connector or connector pins
•do not touch circuit components inside the module
•if available, use a static-safe work station
•when not in use, keep the module in its static-shield bag

SLC ControlNet Scanner Module 3
Publication 1747-5.36 - May 2000
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC Low
Voltage by applying the safety requirements of EN 61131-2
Equipment Requirements and Tests.
For specific information required by EN 61131-2, see the appropriate
sections in this publication as well as the following Allen-Bradley
publications:
•Industrial Automation Wiring and Grounding Guidelines For
Noise Immunity, publication 1770-4.1
•Guidelines For Handling Lithium Batteries, publication AG-5.4
•Automation Systems Catalog, publication B113
This equipment is classified as open equipment and must be
installed (mounted) in an enclosure as a means of providing safety
protection.
Related Publications
For software configuration information, refer to the ControlNet
1747-SCNR Reference Manual, publication 1747-6.23.
For planning and installation information, refer to the ControlNet
Cable System Planning and Installation Manual, publication
1786-6.2.1. If you need a copy of this manual, access the
Automation Bookstore website at
http://www.theautomationbookstore.com or the Manuals On line
website at http://www.ab.com/manuals.
For information on terminating ControlNet coaxial cables, refer to
Terminating Your ControlNet Coaxial Cables, CD number
CNET-DM001A-EN-C.
Allen-Bradley Replacements

4SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Identify Scanner Module Features
Use this illustration to identify the features of the 1747-SCNR
Scanner module.
Node Address and Status Display
Displays scanner node address and status
Module Status Indicator
Indicates whether the device is powered and is
functioning properly
ControlNet Redundant Media Ports
BNC connectors (Channels A and B)
Channel B
Status Indicator
Channel A
Status Indicator
ControlNet Network
Access Port
(NAP)-RJ45 connector
30751-M

SLC ControlNet Scanner Module 5
Publication 1747-5.36 - May 2000
Prepare for Module Installation
Before you install your module, you need the following items:
Before you install the module, you must know how to:
•program and operate an Allen-Bradley SLC 500 programmable
controller
•install and configure the devices on your ControlNet network
Make Sure That Your Processor and Scanner Are Compatible
The 1747-SCNR Scanner module fits in any slot of the chassis except
for the left-most slot of the first chassis, which is reserved for either
the SLC 500 processor or the SLC ControlNet adapter.
Reference
Manual
ControlNet
1747-SCNR
(Cat. No. 1747-SCNR)
Personal Computer with
MicrosoftWindows
RSNetWorx for
ControlNet,
catalog number
9357-CNETL3 1747-SCNR Scanner Module
Reference Manual,
publication 1747-6.23
SLC1746 chassis with SLC
5/02, 5/03, 5/04, or 5/05 processor and
the appropriate configuration software
(RSLogix 500)
ControlNet 1784-PCC (shown), or
1784-KTCX15, or 1770-KFC15
41523
Allen-Bradley Replacements

6SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Select the ControlNet Node Address
Select the ControlNet node address of the 1747-SCNR by setting the
two 10-digit rotary switches on the top of the scanner. Valid switch
settings range from 01 through 99. Zero (00) is not a valid node
address.
Important: Since 00 is the default value from manufacturing, you
must change the default value when using the
scanner for the first time.
Insert the 1747-SCNR Scanner Into the Chassis
To insert the 1747-SCNR Scanner the SLC chassis:
1. Turn off the SLC chassis power supply.
Important: If you disconnect the ac power, you lose the chassis
ground. Electrostatic damage (ESD) protection is lost.
ATTENTION
!
Do not install the 1747-SCNR Scanner module with the
chassis power supply on. Installing the module with the
chassis power supply on may damage the module.
Top View of Module
10-digit rotary switches: ones digit
10-digit rotary switches: tens digit
30752

SLC ControlNet Scanner Module 7
Publication 1747-5.36 - May 2000
2. Select a slot for the module in the chassis. Choose any slot
except the left-most slot of the first chassis, which is reserved
for either the SLC 500 processor.
3. Insert the module into the slot you have selected. We
recommend that you insert the 1747-SCNR Scanner as close to
the chassis power supply as possible.
4. Apply firm, even pressure to seat the module in the I/O
chassis backplane connectors.
5. Restore power to the SLC chassis.
30801-M
Allen-Bradley Replacements

8SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Connect to a ControlNet Network
Connect the 1747-SCNR Scanner module to a ControlNet network
via a tap with a 1 m (39.4 in.) drop cable.
Four Allen-Bradley ControlNet taps are available from Rockwell
Automation as shown below.
We recommend that you use a tap with a straight connector—
1786-TPS or 1786-TPYS—when you attach a ControlNet 1747-SCNR
Scanner to a ControlNet network.
Important: Allen-Bradley ControlNet taps contain passive
electronics and must be purchased from Rockwell
Automation for the network to function properly.
After terminating your network segments, connect your node to the
network.
Straight T-tap Straight Y-tap Right-angle T-tap Right-angle Y-tap
1786-TPS 1786-TPYS 1786-TPR 1786-TPYR 20094-M
AA
B
Redundant media
Nonredundant media
30802-M

SLC ControlNet Scanner Module 9
Publication 1747-5.36 - May 2000
Remove the tap’s dust cap—located on the straight or right-angle
connector—and set it aside.
For detailed information about planning and installing your
ControlNet system, see the following information sources.
If your network supports Connect the tap’s straight or right-angle connector
nonredundant media to the channel A connector on the scanner—channel B is
not used.1
redundant media from trunk-cable A to channel A on the scanner and
from trunk-cable B to channel B on the scanner.
1. Rockwell Automation recommends using channel A for nonredundant media.
Source Source Number
ControlNet Coax Cable System Planning and Installation Manual 1786-6.2.1
ControlNet Media System Component List AG-2.2
ControlNet Coax Tap Installation Instructions 1786-5.7
ControlNet Network Access Cable Installation Instructions 1786-2.6
ControlNet Repeater Installation Instructions 1786-2.7
Industrial Automation Wiring and Grounding Guidelines 1770-4.1
Terminating Your ControlNet Coaxial Cables CNET-DM001A-EN-C
Allen-Bradley Replacements

10 SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Cables
Several types of RG-6 quad-shield cables may be appropriate for
your ControlNet installation—depending on the environment factors
associated with your application and installation site.
The following Allen-Bradley ControlNet cable system components
are available from Rockwell Automation:
Important: Install all wiring for your ControlNet system in
accordance with the regulations contained in the
National Electronic Code (or applicable country
codes), state codes, and applicable municipal codes.
For detailed information about ControlNet cabling, see the
ControlNet System Overview, publication 1786-2.9 and the
publications listed in the table on the previous page.
Item1Cat. No.
ControlNet Coax Tool Kit - ControlNet Coax Tool (enables you to make
successful coaxial cables)
1786-CTK
Coax Tap Kit Right-angle T-tap
Straight T-tap
Right-angle Y-tap
Straight Y-tap
1786-TPR
1786-TPS
1786-TPYR
1786-TPYS
Repeaters Dual channel coaxial repeater 1786-RPCD
Fiber Optic Repeaters
Low-voltage dc coax adapter 1786-RPA
Short-range fiber module 1786-RPFS
Medium-range fiber module 1786-RPFM
RG-6 Quad Shield Cable Standard-PVC CM-CL2 1786-RG6
ControlNet Network Access Cable–3.05 m (10 ft) 1786-CP
BNC Connectors Barrel (plug to plug) 1786-BNCP
BNC/RG-6 plug 1786-BNC
Bullet (jack to jack) 1786-BNCJ
Isolated-bulkhead (jack to jack) 1786-BNCJI
Terminators (BNC-75Ω) 1786-XT
1. For a complete list of Allen-Bradley ControlNet cable system components that are available from
Rockwell Automation and cable system components available from other suppliers, see the ControlNet
Cable System Component List, publication AG-2.2.

SLC ControlNet Scanner Module 11
Publication 1747-5.36 - May 2000
Apply Chassis Power
When you apply chassis power, the module address and status
display cycles through the following displays:
1. POST - The 1747-SCNR runs Power On Self Test.
2. 1111, 2222, etc. - The 1747-SCNR is executing its startup
sequence.
3. REV#, S/R, QXXX - The 1747-SCNR firmware version
temporarily displays after startup: S=series, R=revision, and
XXX=build number.
4. A#nn (where nn = ControlNet node address) then I/O or
I/OX (based on the number of connections configured and
established) then IDLE or RUN (based on the scanner mode).
Alphanumeric Display
The four character alphanumeric display provides you with
additional visual information about the current operational status of
the module.
The following tables describes problems that may occur while using
your 1747-SCNR, the probable causes, and the recommended action.
Node Address and
Status Display
30750-M
Allen-Bradley Replacements

12 SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
OK Indicator and Display Mnemonics
The OK indicator is handled consistently with the ControlNet
specifications for the Identity object.
Sequence OK
Indicator
Alpanumeric
Display
Module Status
Word (M1 file)
Description Probable
Cause
Recommended
Action
Startup Alternately
red/ green
POST N/A The
1747-SCNR
module is
running Power
On Self Test.
Power was
applied to the
module.
No action
required.
REV#
S/R
QXXX
N/A 1747-SCNR
Firmware
revision:
S=series
R=Revision
XXX=build
number. This is
a temporary
display after
startup.
Power was
applied to the
module.
No action
required.
Run time Green A#XX N/A ControlNet
node address.
None. No action
required.
I/O 0x26 All configured
connections
are
established.
None. No action
required.
IDLE N/A The scanner is
in idle mode.
The SLC
processor or
adapter in
slot 0 is in
program
mode or the
Scanner
Mode
Command bit
of the Module
Command
word is clear
(O:x.0/10
where x is the
scanner slot
number).
If you want to
put the scanner
into run mode,
put the SLC
processor or
adapter in slot
0 into run mode
and set the
Scanner Mode
Command bit of
the Module
Command word
(O:x.0/10).

SLC ControlNet Scanner Module 13
Publication 1747-5.36 - May 2000
Sequence OK
Indicator
Alpanumeric
Display
Module Status
Word (M1 file)
Description Probable
Cause
Recommended
Action
Run time Green RUN N/A The scanner is
in run mode.
The SLC
processor or
adapter in
slot 0 is in run
mode and the
Scanner
mode
Command bit
of the Module
Command
word is set
(O:x.0/10).
If you want to
put the scanner
into program
mode, either
put the SLC
processor or
adapter in slot
0 into program
mode or clear
the Scanner
Mode
Command bit of
the Module
Command word
(O:x.0/10).
Flashing
Green
I/OX 0x20 The module is
not configured.
Module not
configured.
Use the SLC
500 SCT 500 to
download a
new
configuration.
0x21 The current
configuration is
not valid.
The module is
not able to
start any
scheduled
communication
to the remote
device. Only
unscheduled
communication
is possible.
Module not
configured.
Use the SLC
500 SCT to
download a
new
configuration.
I/O 0x22 Connections
configured but
no connection
established.
Connections
are disabled.
Check to see if
the 1747-SCNR
and the target
devices are
correctly
connected to
the ControlNet
network.
Allen-Bradley Replacements

14 SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Sequence OK
Indicator
Alpanumeric
Display
Module Status
Word (M1 file)
Description Probable
Cause
Recommended
Action
Run time Flashing
Green
I/O
I/O
I/O
0x23
0x24
0x25
Connections
Configured but
only
25% are
successfully
established.
50%
75%
Remote
devices are
not on line.
Check to see if
the remote
devices are
correctly
connected to
the ControlNet
network.
Errors Off None N/A Module not
communicating
.
Power supply
fault.
Check power
supply, cable
connectors, and
seat module
firmly in
chassis.
Flashing
Green
N/A 0x43 Network error. Cable error or
no other
nodes on the
network.
Verify network
cabling.
Red None N/A Module Auto
reset.
Module
power supply
problem.
Move module in
a slot close to
the power
supply.
ERR0 N/A Module faulted. Pre-boot
code failed
during
power-up.
Contact
Rockwell
Automation
representative
or distributor.
ERR1 through
ERR9
N/A Power On Self
Test failure.
RAM or Flash
test failed.
Processor
fault or
watchdog
timeout.
Reset the
module. If fault
persists,
contact
Rockwell
Automation
representative
or distributor.
FALT
NNNN
0x40 Module faulted. Internal error
detected.
Contact
Rockwell
Automation
representative
or distributor.
Flashing
Red
A#00
FLSH
CFG
ERAS
0x42 Module erased
network and
connection
configuration
stored in flash.
Network node
address set
to 00.
Power down
the module and
change the
address
switches.

SLC ControlNet Scanner Module 15
Publication 1747-5.36 - May 2000
Status Indicators
The ControlNet status indicators inform you of the operational state
of the ControlNet network.
Sequence OK
Indicator
Alpanumeric
Display
Module Status
Word (M1 file)
Description Probable
Cause
Recommended
Action
Errors Flashing
Red
DUPL
A#XX
0x44 Duplicate
node.
Another
device with
the same
ControlNet
address is on
the link.
Power down
the 1747-SCNR
module and
change the
network
address
switches to a
correct node.
BOOT 0x45 Running boot
code.
The
1747-SCNR
firmware is
corrupted.
Reset the
module. If fault
persists,
contact
Rockwell
Automation
representative
or distributor.
Indicator Color1Probable Cause Recommended Action
A and B
Off No power No action required or apply power.
Steady Red Faulty unit Cycle power or reset unit. If fault
persists, contact your Rockwell
Automation representative or
distributor.
Alternating
Red/Green
Self-test No action required.
Alternating
Red/Off
Incorrect node
configuration or
duplicate
ControlNet node
address
Check network address and other
ControlNet configuration parameters.
1. Definition of terms:
steady - indicator is on continuously in the defined state.
alternating - the two indicators alternate between the two defined states at the same time (applies to
both indicators
viewed together ); the two indicators are always in opposite states, out of phase.
flashing - the indicator alternates between the two defined states (applies to each indicator
viewed
independent
of the other); if both indicators are flashing, they flash together, in phase.
Allen-Bradley Replacements

16 SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
Indicator Color1Probable Cause Recommended Action
A or B
Off Channel disabled Program network for
redundant media, if required.
Steady
Green
Normal operation No action required.
Flashing
Green/Off
Temporary network
errors •Check media for broken cables, loose connectors, missing
terminators, etc.
•If condition persists, refer to
ContolNet Cable Planning and
Installation Manual, publication
1786-6.2.1.
Flashing
Red/Off
Media fault •Check media for broken cables,
loose connectors, missing
terminators, etc.
•If condition persists, refer to
ContolNet Cable Planning and
Installation Manual, publication
1786-6.2.1.
No other nodes
present on network
Add other nodes to the network.
Flashing
Red/Green
Incorrect node
address
Change 1747-SCNR node address so that
it is less than or equal to SMAX2.
Incorrect network
configuration
Reconfigure ControlNet network so that
SMAX2 is greater than or equal to
1747-SCNR node address.
1. Definition of terms:
steady - indicator is on continuously in the defined state.
alternating - the two indicators alternate between the two defined states at the same time (applies to
both indicators
viewed together ); the two indicators are always in opposite states, out of phase.
flashing - the indicator alternates between the two defined states (applies to each indicator
viewed
independent
of the other); if both indicators are flashing, they flash together, in phase.
2. SMAX is the highest node address on a ControlNet network that can transmit scheduled data.

SLC ControlNet Scanner Module 17
Publication 1747-5.36 - May 2000
Specifications
Module Location Slot 1 or above
Module Defaults Node Address -00
Maximum Backplane Current 900 mA @ 5V dc
Isolated Voltage Optical Isolation between backplane and ControlNet
channel 1 Megohm resistor from ControlNet channel to
chassis
Environmental Conditions:
Operational Temperature
Storage Temperature
Relative Humidity
0-60°C (32-140°F)
-40 to 85°C (-40 to 185°F)
5-95% without condensation
Shock unpackaged 30g operational
50g non-operational
Vibration Unpackaged 5g from 10-150Hz
Immunity Radiated Fields 10 V/m
27 mHz-1000 mHz
Agency Certification
(when product or packaging is
marked)
Reference Manual 1747-6.23
marked for all applicable directives
Class 1 Division 2, groups A, B, C, D2
Allen-Bradley Replacements

18 SLC ControlNet Scanner Module
Publication 1747-5.36 - May 2000
CSA logo is a registered trademark of the Canadian Standards Association.
CSA Hazardous Location Approval
CSA certifies products for general use as well as for use in hazardous locations. Actual CSA
certification is indicated by the product label as shown below, and not by statements in
any user documentation.
Example of the CSA certification product label:
To comply with CSA certification for use in hazardous locations, the following information
becomes a part of the product literature for this CSA-certified industrial control product.
•This equipment is suitable for use in Class I, Division 2, Groups A, B, C, D, or non-hazardous
locations only.
•The products having the appropriate CSA markings (that is, Class I, Division 2, Groups A, B, C, D)
are certified for use in other equipment where the suitability of combination (that is, application or
use) is determined by the CSA or the local inspection office having jurisdiction.
Important: Due to the modular nature of a programmable control system, the product with the
highest temperature rating determines the overall temperature code rating of a programmable
control system in a Class I, Division 2, location. The temperature code rating is marked on the
product label as shown.
Temperature code rating:
The following warnings apply to products having CSA certification for use in hazardous
locations.
ATTENTION: Explosion hazard -
•Substitution of components may impair suitability for Class I, Division 2.
•Do not replace components unless power has been switched off or the area is known
to be non-hazardous.
•Do not disconnect equipment unless power has been switched off or the area is
known to be non-hazardous.
•Do not disconnect connectors unless power has been switched off or the area is
known to be non-hazardous. Secure any user-supplied connectors that mate to
external circuits on this equipment by using screws, sliding latches, threaded
connectors, or other means such that any connection can withstand a 15 Newton (3.4
lb.) separating force applied for a minimum of one minute.
Approbation d’utilisation dans des emplacements dangereux par la CSA
CL I, DIV 2
GP A,B,C,D
TEMP
CL I, DIV 2
GP A,B,C,D
TEMP
/RRNIRUWHPSHUDWXUH
FRGHUDWLQJKHUH
!

SLC ControlNet Scanner Module 19
Publication 1747-5.36 - May 2000
Le sigle CSA est la marque déposée de l'Association des Standards pour le Canada.
La CSA certifie les produits d'utilisation générale aussi bien que ceux qui s'utilisent dans des
emplacements dangereux. La certification CSA en vigueur est indiquée par l'étiquette du
produit et non par des affirmations dans la documentation à l'usage des utilisateurs.
Exemple d'étiquette de certification d'un produit par la CSA:
Pour satisfaire à la certification de la CSA dans des endroits dangereux, les informations
suivantes font partie intégrante de la documentation ce produit industriel de contrôle certifiés
par la CSA.
•Cet équipement convient à l'utilisation dans des emplacements de Classe 1, Division 2, Groupes A,
B, C, D, ou ne convient qu'à l'utilisation dans des endroits non dangereux.
•Les produits portant le marquage approprié de la CSA (c'est à dire, Classe 1, Division 2, Groupes A,
B, C, D) sont certifiés à l'utilisation pour d'autres équipements où la convenance de combinaison
(application ou utilisation) est déterminée par la CSA ou le bureau local d'inspection qualifié.
Important: Par suite de la nature modulaire du système de contrôle programmable, le produit
ayant le taux le plus élevé de température détermine le taux d'ensemble du code de
température du système de contrôle d'un programmable dans un emplacement de Classe 1,
Division 2. Le taux du code de température est indiqué sur l'étiquette du produit.
Taux du code de température:
Les avertissements suivants s'appliquent aux produits ayant la certification CSA pour leur
utilisation dans des emplacements dangereux.
AVERTISSEMENT: Risque d’explosion -
•La substitution de composants peut rendre ce matériel inacceptable pour
lesemplacements de Classe I, Division 2.
•Couper le courant ou s’assurer quel’emplacement est désigné non dangereux avant de
remplacer lescomposants.
•Avant de débrancher l’équipement, couper le courant ou s’assurer que l’emplacement
est désigné non dangereux.
•Avant de débrancher les connecteurs, couper le courant ou s’assurer que
l’emplacement est reconnu non dangereux. Attacher tous connecteurs fournis par
l’utilisateur et reliés aux circuits externes d’un appareil Allen-Bradley à l ‘aide de vis,
loquets coulissants, connecteurs filetés ou autres moyens permettant aux connexions
de résister à une force de séparation de 15 newtons (3,4 lb. - 1,5 kg) appliquée
pendant au moins une minute.
CL I, DIV 2
GP A,B,C,D
TEMP
CL I, DIV 2
GP A,B,C,D
TEMP
Le taux du code de
température est indiqué ici
!
Allen-Bradley Replacements

Publication 1747-5.36 - May 2000 PN 955133-33
© 2000 Rockwell International Corporation. Printed in the U.S.A.
Allen-Bradley is a registered trademark of Rockwell Automation.
SLC is a trademark of Rockwell Automation.
ControlNet is a trademark of ControlNet International.
Microsoft Windows is a registered trademark of Microsoft Corporation.
RSNetWorx for ControlNet and RSLogix 500 are trademarks of Rockwell Software, Inc.
