Allen + Roth A102002101 User manual

ITEM # 0887556/38115285
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
SM20445
ATTACH YOUR RECEIPT HERE
SUN SHELTER
MODEL # A102002101
Français p. 30
1
ALLEN + ROTH and logo design are
trademarks or registered trademarks of LF,
LLC. All rights reserved.
ALLEN + ROTH et le logo sont des marques de
commerce ou des marques de commerce
déposées de LF, LLC. Tous droits réservés.

2
PACKAGE CONTENTS

PART DESCRIPTION QTY# PART DESCRIPTION QTY#
3
P ACKAGE CONTENTS
B5 Front Netting Pipe 2
D6 Side Netting Pipe 4
F7 Support Beam Connector 1 4
F8 Support Beam Connector 2 2
R1 PC Panel 1 4
R2 PC Panel 2 4
R3 PC Panel 3 4
R4 PC Panel 4 1
R5 PC Panel 5 1
R6 PC Panel 6 1
R7 PC Panel 7 1
I1 Decorative Railing 1 1
I2 Decorative Railing 2 1
I3 Decorative Railing 3 1
I4 Decorative Railing 4 1
Q1 L-Shaped Bracket 2
J Cover 2
K Support Bar 2
L Wall Mount Sheet 4
M1 Base 1 2
M2 Base 2 2
N1 Base Cover 1 2
N2 Base Cover 2 2
O Mosquito Netting 1
P Curtain 1
A1 Post 1 1
A2 Post 2 1
A3 Post 3 1
A4 Post 4 1
A5 Post 5 1
A6 Post 6 1
B3 Front Beam 1 1
B4 Front Beam 2 1
C1 Rear Beam 1 1
C2 Rear Beam 2 1
D1 Side Beam 1 1
D2 Side Beam 2 1
D3 Side Beam 3 1
D4 Side Beam 4 1
D5 Beam Connector 4
E1 Top Beam 1 3
E2 Top Beam 2 3
E3 Top Beam 3 1
E4 Top Beam 4 1
E5 Top Beam 5 1
E6 Top Beam 6 1
E7 Top Beam Connector 1 2
E8 Top Beam Connector 2 3
F1 Support Beam 1 1
F2 Support Beam 2 1
F3 Support Beam 3 2

4
HARDWARE CONTENTS
M6 x 15 mm Bolt
Qty. 22 + 2 spare
M6
Wrench
Qty. 2
M6 Flat Washer
Qty. 178 + 9 spare
M6 x 45 mm Bolt
Qty. 16 + 1 spare
AA CC DD
BB
EE GG
Z2
FF
M6 Spring Washer
Qty. 68 + 4 spare
M6 x 20 mm Bolt
Qty. 24 + 2 spare
HH
II JJ KK
Z1
M6 x 15 mm
Sockets Bolt
Qty. 16 + 1 spare
M6 x 55 mm Bolt
Qty. 3 + 1 spare
M6 Nut
Qty. 12 + 1 spare
Φ8*180 mm Stake
Qty. 8
M6 Socket Head
Allen Key
Qty. 1
M6 x 20 mm Bolt
Qty.82 + 5 spare
LL
Hook
Qty. 76 + 4 spare
MM
Plastics Stopper
Qty. 6 + 1 spare
M6 x 80 mm Expansion
Qty. 4
NN
M6 x 15 mm Bolt
Qty. 26 + 2 spare
OO
M6 Plastics Cap
Qty. 12 + 1 spare
PP
M6 x 50 mm Bolt
Qty. 1 + 1 spare

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or
install the product.
• Keep all children and pets away from assembly area. Children and pets should
be supervised while gazebo is being assembled.
• The assembled gazebo should be located at least 6 feet from any obstruction
such as fence, garage, house, overhanging branches, laundry lines or electrical
wires.
•Some parts may contain sharp edges. Wear protective gloves if necessary,
during assembly.
•This unit is heavy. For safety, do not assemble this item alone. Six to eight
people are recommended for safe assembly.
•Keep all flame and heat sources away from the tent fabric. This tent is made
with fabric that meets CPAI-84 specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may render the
flame-resistant properties ineffective.
•Check all nuts and bolts periodically for tightness and, when required, tighten
them again.
•While this gazebo is manufactured to withstand winds through only the supplied
ground stakes, in areas subject to frequent severe weather, securing the
gazebo to a deck, concrete patio or footings should be considered.
•Do not use ladder leaning against the gazebo or climbing onto the roof.
•Do not use or enter the gazebo if there exists any of the following or of similar
conditions:
1. Visible movement of support members, roofing panels or sagging roofline.
2. Creaks or audible noise from the gazebo.
3. Cracks, fractures or malformation of support members or roof panels.
4. Damaged or missing fasteners.
WARNING
5

•Install the gazebo on level ground. Stakes are provided to secure the gazebo to
the ground. Do not assemble the gazebo on sandy, muddy or loose soil, as
stakes do not have enough anchorage in these types of soil. If you wish to secure
the gazebo to a wood deck or concrete surface, use anchors suited to these
surfaces. Snow must be cleared off regularly during snowy days. Remove all
excess snow from the roof. In order to avoid damage, use a plastic snow rake to
remove excessive snow and ice buildup from roof and keep away from falling
debris. Any assembly or maintenance of the product must be carried out by adults
only. Please check your state and local regulations prior to purchasing. Some
jurisdictions may require permits for installation and use. Some special
procedures may be valid in your area.
•For outdoor use only.
•If any scratch paint, please touch up to prevent rusting.
PREPARATION
6
CAUTION
Before beginning assembly of product, make sure all parts are present. Compare
parts with package contents list and hardware contents list. If any part is missing or
damaged, do not attempt to assemble the product.
Estimated Assembly Time: 60-90 minutes.
Tools Required for Assembly (included): Wrench.
Required for Assembly (not included): Phillips screwdriver, hammer, and 2 ladders
(no less than 8.2-feet tall) .

7
ASSEMBLY INSTRUCTIONS
1. Insert the posts (A1/A2) into the base
cover (N2), and then install the base
(M2) to the bottoms of posts (A1/A2)
using bolts (AA) and washers (BB).
Hardware Used
x 4
x 4
AA M6 x 15 Bolt
BB M6 Flat Washer

8
ASSEMBLY INSTRUCTIONS
2. Insert the posts (A3/A4) into the base
cover (N1), and then install the base
(M1) to the bottoms of posts (A3/A4)
using bolts (AA) and washers (BB).
Hardware Used
x 4
x 4
AA M6 x 15 Bolt
BB
BB M6 Flat Washer
4.Insert the posts (A5/A6) into posts (A1/
A2), using bolts (NN), washers (BB).
Tighten with wrench (Z2).
3.Connect the side beams (D1/D2/
D3/D4) with beam connector (D5) using
bolts (DD/FF), washers (BB) and spring
washers (EE). Tighten with wrench (Z2).
Hardware Used
DD x 16
x 8
BB x 16
x 16
EE
FF
Z2
M6 x 20 Bolt
M6 x 20 Bolt
M6 Flat Washer
M6 Spring Washer
M6 Wrench x 1
Hardware Used
x 2
NN
BB x 2
Z2x 1
M6 x 15 Bolt
M6 Flat Washer
M6 Wrench

9
ASSEMBLY INSTRUCTIONS
5. Attach the other end of side beams (D1/
D2) to posts (A1/A2) using bolts (HH).
Tighten with allen key (Z1).
Hardware Used
x 8
x 1
Allen Key
HH M6 x 15 Sockets bolt
Z1
M6 Socket Head
7. Attach the other end of side beams
(D3/D4) to posts (A3/A4) using bolts
(HH). Tighten with allen key (Z1).
Hardware Used
x 4
x 1
Allen Key
HH M6 x 15 Sockets bolt
Z1
Attach side beams (D3/D4) to posts (A3/
A4) using bolts (DD), flat washers (BB)
and spring washers (EE). Tighten with
wrench (Z2).
6.
Hardware Used
x 4
DD
BB x 4
Z2x 1
x 4
EE
M6 x 20 Bolt
M6 Flat Washer
Spring Washer
M6 Wrench

10
ASSEMBLY INSTRUCTIONS
8.Connect the front beam (B3) to front beam (B4)
with beam connector (D5) using bolts (DD/FF),
washers (BB) and spring washers (EE).
Tighten with wrench (Z2).
Hardware Used
DD x 6
x 4
BB x 10
x 10
EE
FF
Z2
M6 x 20 Bolt
M6 x 20 Bolt
M6 Flat Washer
M6 Spring Washer
M6 Wrench x 1
9.Connect the beams (C1/C2) with beam
connector (D5) using bolts (DD/FF), washers
(BB) and spring washers (EE). Tighten with
wrench (Z2).
Hardware Used
DD x 6
x 4
BB x 10
x 10
FF
EE
Z2
M6 x 20 Bolt
M6 x 20 Bolt
M6 Flat Washer
M6 Spring Washer
M6 Wrench x 1

11
ASSEMBLY INSTRUCTIONS
Attach beams (B3/B4) to posts (A3/A4)
using bolts (DD), flat washers (BB) and
spring washers (EE). Tighten with
wrench (Z2).
11-1.
Hardware Used
x 4
DD
BB x 4
Z2x 1
x 4
EE
M6 x 20 Bolt
M6 Flat Washer
Spring Washer
M6 Wrench
Attach rear beams (C1/C2) to posts
(A5/A6) using bolts (CC), flat washers
(BB) and spring washers (EE).
Tighten with wrench (Z2).
10.
Hardware Used
x 8
CC
BB x 8
Z2x 1
x 8
EE
M6 x 45 Bolt
M6 Flat Washer
Spring Washer
M6 Wrench
11-2. Attach beams (B3/B4) to posts
(A3/A4) using bolts (HH). Tighten
with allen key (Z1).
Hardware Used
x 4
x 1
Allen Key
HH M6 x 15 Sockets bolt
Z1
M6 Socket Head

12
ASSEMBLY INSTRUCTIONS
Attach support bar (K) to side beam 1/3
(D3/D4) and front beam 1/2 (B3/B4) using
bolts (DD), flat washers (BB) and spring
washers (EE). Tighten with wrench (Z2).
13.
Hardware Used
x 4
DD
BB x 4
Z2 x 1
M6 x 20 Bolt
M6 Flat Washer
W6 Wrench
x 4
EE Spring Washer
12-1.Insert hooks (LL) into the beams (B5/D6)
as shown, then attach plastic caps (MM)
to one end of each side beams (B5/D6).
Hardware Used
x 6
Hook
LL
MM Plastics Stopper
x 76
7x
6x
Attach beams (B5/D6) to beams (D1/
D2/D3/D4/B3/B4) using bolts (DD), flat
washers (BB) . Tighten with wrench
(Z2).
12-2.
Hardware Used
x 12
DD
BB x 12
Z2x 1
M6 x 20 Bolt
M6 Wrench
M6 Flat Washer

13
ASSEMBLY INSTRUCTIONS
14.Attach cover (J) using bolts (DD), flat
washers (BB). Tighten with wrench (Z2).
x 4
DD
BB x 4
Z2x 1
M6 x 20 Bolt
M6 Flat Washer
M6 Wrench
15-1. Connect support beams (F1/F2/
F3) with beam connector (F8) using
bolts (NN), flat washers (BB) .Tighten
with wrench (Z2).
Hardware Used
x 4
NN
BB x 4
Z2x 1
M6 x 15 Bolt
M6 Flat Washer
M6 Wrench
Hardware Used

ASSEMBLY INSTRUCTIONS
14
Connect top beams (E1) to top beams
(E2) with beam connector (E8), using
bolts (NN) and flat washers (BB). Tighten
with wrench (Z2).
Hardware Used
x 12
NN
BB x 12
Z2 x 1
M6 x 15 Bolt
M6 Flat Washer
M6 Wrench
16.Attach support beams (F1/F2/F3) to
side beam (D1/D2/D3/D4) using bolts
(DD) and flat washers (BB). Tighten
with wrench (Z2).
Hardware Used
x 8
DD
BB x 8
Z2x 1
M6 x 20 Bolt
M6 Flat Washer
M6 Wrench
17.
15-2. Connect support beams (F1/F2/
F3) with beam connector (F7) using
bolts (CC), flat washers (BB) , spring
washers (EE) ,nuts (JJ)and cap
(OO).Tighten with wrench (Z2).
Hardware Used
x 8
x 8
x 16
x 8
x 2
Z2 M6 Wrench
x 8
CC M6 x45 Bolt
BB M6 Flat Washer
EE Spring Washer
JJ M6 Nut
OO M6 Plastics Cap

15
ASSEMBLY INSTRUCTIONS
18. Attach top beam (E2) to rear beams
(C1/C2) using bolts (DD) and flat
washers (BB). Tighten with wrench (Z2).
Hardware Used
x 6
DD
BB x 6
Z2x 1
M6 x 20 Bolt
M6 Flat Washer
M6 Wrench
19-1. Attach top beam (E1/E2) to support
beams (F3) using bolts (II), flat
washers (BB), spring washers
(EE), nuts (JJ) and cap (OO).
Tighten with wrench (Z2).
Hardware Used
x 3
x 3
x 6
x 3
BB M6 Flat Washer
EE Spring Washer
JJ M6 Nut
M6 x55 Bolt
x 2
Z2 M6 Wrench
x 3
OO M6 Plastics Cap
I I
19-2. Attach top beam (E1) to support
beams 1/2 (F1/F2) using bolts (PP),
flat washers (BB), spring washers
(EE), nuts (JJ) and cap (OO).Tighten
with wrench (Z2).
Hardware Used
x 1
x 1
x 2
x 1
x 2
x 1
PP M6 x50 Bolt
BB M6 Flat Washer
EE Spring Washer
JJ M6 Nut
OO M6 Plastics Cap
Z2 M6 Wrench

16
ASSEMBLY INSTRUCTIONS
Connect top side beams (E4/E6) to rear
beam top side beams (E3/E5) with beam
connector (E7), using bolts (NN) and flat
washers (BB). Tighten with wrench (Z2).
21.
Hardware Used
x 8
NN
BB x 8
Z2 x 1
M6 x 15 Bolt
M6 Flat Washer
M6 Wrench
20. Attach top beam (E1) to front beam
(B3/B4) using bolts (DD) and flat
washers (BB). Tighten with wrench
(Z2).
Hardware Used
x 6
DD
BB x 6
Z2 x 1
M6 x 20 Bolt
M6 Flat Washer
M6 Wrench
19-3.Attach top beam (E1) to support
beams (F1/F2) using bolts (DD)
and flat washers (BB). Tighten with
wrench (Z2).
Hardware Used
x 2
DD
BB x2
Z2 x 1
M6 x 20 Bolt
M6 Flat Washer
M6 Wrench

17
ASSEMBLY INSTRUCTIONS
23. Attach top side beams (E3/E5) to
posts (A3/A4) using bolts (FF) and flat
washers (BB).
Hardware Used
BB M6 Flat Washer x 4
x 4
FF M6 x 20 Bolt
22. Attach top side beams (E4/E6) to
posts (A5/A6) using bolts (FF) and flat
washers (BB).
Hardware Used
BB M6 Flat Washer x 4
x 4
FF M6 x 20 Bolt

18
ASSEMBLY INSTRUCTIONS
25.Insert PC panel (R3) to the lower slot
of the top beam (E2), do not fully insert.
26-2.Insert PC panel (R2) to the middle
slot of the top beam (E2), do not fully
insert.
24.Insert PC panels (R4/R6) and PC
panels (R5/R7) to side beams (D1/
D2/D3/D4) and top side beams (E3/
E4/E5/E6).
26-1.Lock PC panel (R2) to PC panel
(R3) and then fully insert the
PC panel (R3) to the lower slot
of top beam (E2).
Remove the film
Remove the film
Remove the film Remove the film

19
ASSEMBLY INSTRUCTIONS
28. Insert PC panel (R1) to the upper slot
of the top beam (E2).
27. Lock PC panel (R1) to PC panel
(R2) and then fully insert the PC
panel (R2) to the middle slot of
top beam (E2).
Remove the film

20
ASSEMBLY INSTRUCTIONS
31. Attach L-shaped brackets (Q1) to top
side beams 1/2 (E6/E4) and side
beams 1/2 (D1/D2) using bolts (AA)
and washers (BB).
Hardware Used
AA M6 x15 Bolt BB
BB Flat Washer
x 4
x 4
30. Attach decorative railings (I3/I4) to
top beam (E2) using bolts (AA) and
washers (BB).
Hardware Used
AA M6 x15 Bolt
BB M6 Flat Washer
x 3
x 3
29. Attach decorative railings (I3/I4) to
top side beam (E4/E6) using bolts
(AA) and washers (BB).
Hardware Used
AA M6 x15 Bolt
BB M6 Flat Washer
x 2
x 2
