Allen + Roth L-GZ815PCO-F User manual

allen + roth® is a registered trademark
of LF, LLC. All Rights Reserved.
WOVEN GAZEBO
ITEM #0740241
MODEL #
L-GZ815PCO-F
Serial Number Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Friday.
EB 16127
ATTACH YOUR RECEIPT HERE
Español p.13
allenandroth.com
1

allenandroth.com
PART
A
B
C
D
E
F
4
2
4
4
4
4
4
Post
Long Crossbeam
Short Crossbeam
Ferrule
Long netting pipe
Short netting pipe
Sloped beam
Sloped beam down pipe
DESCRIPTION QUANTITY
G
G1
2
2Long middle beam
H
H1 Long middle beam down pipe 2
PART
J
K
L
M
N
O1
1
1
1
1
1
1
1
1
Big top connector
Small top sloped beam
Hook
Small top connector
Finial
Small canopy
Big canopy
Curtain
Mosquito netting
DESCRIPTION QUANTITY
O2
P
Q
4
2
Short middle beam
I
I1 Short middle beam down pipe 2
2
PACKAGE CONTENTS

WARNING
liable for any loss of the product or other items due to the failure to take down the item during any
inclement weather.
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
are
lightning.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 45 minutes
No Additional Tool Required for Assembly except A Ladder (no less than 8.2-feet tall) (Not included).
Qty. 104 Qty. 12 Qty. 48
Ring Stake Short Bolt
AA CC
Long Bolt
Qty. 4
DDBB
allenandroth.com
3
HARDWARE CONTENTS

allenandroth.com
4
ASSEMBLY INSTRUCTIONS
1. Unfold long crossbeams (B) and short
crossbeams (C).
1
BC( )
B
D
D
DC
C
D
B
E
E
E
E
FF
F
F
A
AA
A
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
2. Secure the middle of each long
crossbeam (B) and short crossbeam (C)
with long bolt (DD).
x 4
Long Bolt
Hardware Used
DD
2
DD
( )
BC

3. Insert the unfolded long crossbeams (B)
and short crossbeams (C) into posts (A),
securing with short bolts (CC).
x 24
Short Bolt
Hardware Used
CC
3
CC
BC
A
CC
CC CC
4. Attach long netting pipes (E) to long
crossbeams (B) and short netting pipes (F)
to short crossbeams (C), securing with
short bolts (CC).
x 16
Short Bolt
Hardware Used
CC
4
FE
CC B
CC CC
5. Attach ferrules (D) to the middle of long
crossbeams (B) and short crossbeams (C),
securing with short bolts (CC).
x 8
Short Bolt
Hardware Used
CC
G
5
BC
D
CC
CC
allenandroth.com
5
ASSEMBLY INSTRUCTIONS

allenandroth.com
6
ASSEMBLY INSTRUCTIONS
6. Insert sloped beams (G) into the sloped
beam down pipes (G1).
D
6
G
G1
Fig.11
Fig.11
Fig.11
Fig.13
Fig.10
Fig.14
Fig.15
Fig.7
Fig.12
Fig.6
Fig.9
Fig.8
A
A
O2
G
G
G
H
G1
H1
G1
G1
I1
I
O1 N
CB
K
J
M
L

allenandroth.com
7
ASSEMBLY INSTRUCTIONS
7. Insert sloped beams (G) into every other
prong on the big top connector (J).
8. Insert sloped beam down pipes (G1) into
posts (A). 8
G1
A
7
G
J
9. Insert long middle beams (H) and short
middle beams (I) into the long middle
beam down pipes (H1) and short middle
beam down pipes (I1), respectively.
9
I1
I
H1
H

allenandroth.com
8
ASSEMBLY INSTRUCTIONS
•
12. Insert small top sloped beams (K) into
small top connector (M). 12
M
KK
K
11. Attach long middle beam down pipes
(H1) to short crossbeams (C) and short
middle beam down pipes (I1) to long
crossbeams (B). Then, place large
canopy (O2) over the assembly, but do
not secure yet.
11
B
C
I1
H1
10. Insert long middle beams (H) and short
middle beams (I) into big top connector
(J). Then attach hook (L) to the bottom
of big top connector (J).
J
L
I
H
10
H
I

allenandroth.com
15. Align the corners and stretch small
canopy (O1) onto small top sloped
beams (K) to secure.
P
12-1
O1
K
15
9
ASSEMBLY INSTRUCTIONS
13. Insert small top sloped beams (K) into
sloped beams (G).
13
K
G
14. Attach small canopy (O1) to the top,
but do not secure it yet. Attach finial (N)
to top of small top connector (M).
1414
N
M
O1
N

allenandroth.com
10
ASSEMBLY INSTRUCTIONS
A
Q
P
O2
Fig.17
Fig.18
Fig.16
17. Hang mosquito netting (Q) and
curtain (P) onto long netting pipes (E)
and short netting pipes (F) using the
rings (AA).
NOTE: The mosquito netting (Q) installs
around the inside poles (A). Be mindful
of the dimensions of the item to ensure
you install the mosquito netting (Q) and
curtain (P) correctly.
x 104
Ring
Hardware Used
AA
17
AA
P
Q
EF
16. Spread large canopy (O2) along the
sloped beam down pipes (G1), long
middle beam down pipe (H1) and
short middle beam down pipe (I1),
aligning the corners and stretching
it to fit. Secure using the hook and
loop fasteners preassembled to large
canopy (O2).
O2
G1
11
O2
I1 H1
（ ）
16

allenandroth.com
ASSEMBLY INSTRUCTIONS
11
withstand inclement weather, including high winds, rain, and snow. In order to avoid damage in such
instances, remove any accumulated water and the roof immediately. Disassemble the item in the
reverse order of the assembly steps.
The steel components of this item
wind and inclement weather, and therefore can be damaged and/or cause damage.
is scratched. This is a natural process. To minimize this condition, it is recommended that care
be taken when assembling and handling the product, in order to prevent the paint from being
scratched.
environment.
ONE-YEAR LIMITED WARRANTY
workmanship of your item provided the item is maintained with care and used only for personal,
residential purposes.
The manufacturer warranty for this item, is to be free of defects in material and workmanship for a
period of one year. If any defect is found, please call our customer service department at
1-866-439-9800 for help. The manufacturer will not cover transportation or delivery costs or
compensate the individual or any outside party for assembling or disassembling the product.
This warranty gives you certain rights, and you may have other rights that vary from state to state.
CARE AND MAINTENANCE
18. Secure the gazebo to lawn with the
stakes (BB).
x 12
Stake
Hardware Used
BB
18
A
BB BB

12
A
B
C
D
E
F
G
H
I
I1
For replacement parts, call our customer service department at 1-866-439-9800,
8 a.m. - 8 p.m., EST, Monday - Friday.
Printed in China
allen + roth® is a registered trademark
of LF, LLC. All Rights Reserved.
PART
J
K
L
M
N
O1
Big Top Connector
Small Top Sloped Beam
Hook
Small Top Connector
Finial
Small Canopy
Big Canopy
Curtain
Mosquito Netting
DESCRIPTION PART #
O2
P
Q
Ring
Stake
Short Bolt
Long Bolt
AA
BB
CC
DD
#0740241-J
#0740241-L
#0740241-M
#0740241-N
#0740241-O1
#0740241-O2
#0740241-P
#0740241-Q
#0740241-AA
#0740241-BB
#0740241-CC
#0740241-DD
#0740241-K
PART
#0740241-A
#0740241-C
#0740241-D
#0740241-E
#0740241-F
#0740241-G
#0740241-G1
Post
Long Crossbeam
Short Crossbeam
Ferrule
Long Netting Pipe
Short Netting Pipe
Sloped Beam
Sloped Beam Down Pipe
DESCRIPTION PART #
G1
#0740241-B
#0740241-HLong Middle Beam
H1 Long Middle Beam Down Pipe #0740241-H1
#0740241-I
Short Middle Beam
Short Middle Beam Down Pipe #0740241-I1
allenandroth.com
B
A
C
D
E
F
G
G1
H
K
O1
I1
M
P
J
N
Q
L
O2
H1
I
AA CC DDBB
REPLACEMENT PARTS LIST

GAZEBO TEJIDO
ARTÍCULO #0740241
MODELO #
L-GZ815PCO-F
allenandroth.com
13
Número de serie Fecha de compra
¿Preguntas, problemas, piezas faltantes?
Departamento de Servicio al Cliente al 1-866-439-9800, de lunes a viernes de 8 a.m. a 8 p.m.,
hora estándar del Este.
Antes de volver a la tienda, llame a nuestro
ADJUNTE SU RECIBO AQUÍ
allen + roth® es una marca registrada de LF, LLC.
Todos los derechos reservados.

allenandroth.com
PIEZA
A
B
C
D
E
F
4
2
4
4
4
4
4
DESCRIPCIÓN CANTIDAD
G
G1
2
2
H
H1 2
PIEZA
J
K
L
M
N
O1
1
1
1
1
1
1
1
1
Conector superior grande
Viga inclinada superior pequeña
Gancho
Conector superior pequeño
Remate
Toldo pequeño
Toldo grande
Cortina
Mosquitero
O2
P
Q
4
2
I
I1
Poste
Viga transversal larga
Viga transversal corta
Casquillo
Tubo para mosquitero largo
Tubo para mosquitero corto
Viga inclinada
Tubo de viga inclinada hacia abajo
Viga central larga
Tubo de viga central larga hacia abajo
Viga central corta
Tubo de viga central corta hacia abajo 2
DESCRIPCIÓN CANTIDAD
14
CONTENIDO DEL PAQUETE

Cant. 104 Cant. 12 Cant. 48
Anillo Estaca Perno corto
AA CC
Perno largo
Cant. 4
DDBB
allenandroth.com
15
ADITAMENTOS
ADVERTENCIA
de cualquier sustancia extraña a la tela de la tienda de campaña puede hacer que sus propiedades
ninguna pérdida del producto u otros artículos por no desensamblar al artículo cuando el clima sea
inclemente.
INFORMACIÓN DE SEGURIDAD
los niños.
hacerlo antes de usarlo para evitar que el artículo colapse o se dañe, lo que también podría resultar
en lesiones.
PREPARACIÓN
Tiempo estimado de ensamblaje:45 minutos
No hay ninguna herramienta adicional necesaria para el montaje, excepto Una Escalera (no menos de 8.2
pies) (no ésta Incluida).

allenandroth.com
16
INSTRUCCIONES DE ENSAMBLAJE
1. Despliegue las vigas transversales largas
(B) y las vigas transversales cortas (C).
1
BC( )
B
D
D
DC
C
D
B
E
E
E
E
FF
F
F
A
AA
A
Fig.1
Fig.2
Fig.3
Fig.4
Fig.5
2. Asegure el centro de cada viga transversal
larga (B) y cada viga transversal corta (C)
con un perno largo (DD).
x 4
Perno largo
Aditamentos Utilizados
DD
2
DD
( )
BC

3. Inserte las vigas transversales largas (B)
y las vigas transversales cortas (C)
desplegadas en los postes (A),
asegurándolas con los pernos cortos (CC).
x 24
Perno corto
Aditamentos Utilizados
CC
3
CC
BC
A
CC
CC CC
4. Fije los tubos para mosquitero largos (E)
a las vigas transversales largas (B) y los
tubos para mosquitero cortos (F) a las
vigas transversales cortas (C),
asegurándolas con los pernos cortos (CC).
x 16
Perno corto
Aditamentos Utilizados
CC
4
FE
CC B
CC CC
5. Fije los casquillos (D) en el centro de las
vigas transversales largas (B) y las vigas
transversales cortas (C), asegurándolos
con pernos cortos (CC).
x 8
Perno corto
Aditamentos Utilizados
CC
G
5
BC
D
CC CC
allenandroth.com
17
INSTRUCCIONES DE ENSAMBLAJE

allenandroth.com
18
INSTRUCCIONES DE ENSAMBLAJE
6. Inserte las vigas inclinadas (G) en los
tubos de viga inclinada hacia abajo (G1).
D
6
G
G1
Fig.11
Fig.11
Fig.11
Fig.13
Fig.10
Fig.14
Fig.15
Fig.7
Fig.12
Fig.6
Fig.9
Fig.8
A
A
O2
G
G
G
H
G1
H1
G1
G1
I1
I
O1 N
CB
K
J
M
L

allenandroth.com
19
INSTRUCCIONES DE ENSAMBLAJE
7. Inserte las vigas inclinadas (G) en cada clavija
del conector superior grande (J).
8. Inserte los tubos de viga inclinada hacia
abajo (G1) en los postes (A). 8
G1
A
7
G
J
9. Inserte las vigas centrales largas (H) y
las vigas centrales cortas (I) en los tubos
de viga central larga hacia abajo (H1) y
los tubos de viga central corta hacia abajo
(I1), respectivamente.
9
I1
I
H1
H

allenandroth.com
20
INSTRUCCIONES DE ENSAMBLAJE
•
12. Inserte las vigas inclinadas superiores
pequeñas (K) en el conector superior
pequeño (M).
12
M
KK
K
11. Fije los tubos de viga central larga hacia
abajo (H1) a las vigas transversales
cortas (C) y los tubos de viga central
corta hacia abajo (I1) a las vigas
transversales largas (B). Luego,
coloque el toldo grande (O2) sobre el
ensamble, pero no lo asegure aún.
11
B
C
I1
H1
10. Inserte las vigas centrales largas (H) y
las vigas centrales cortas (I) en el
conector superior grande (J). Luego,
fije el gancho (L) a la parte inferior del
conector superior grande (J).
J
L
I
H
10
H
I
